662What to do if... (Troubleshooting)
RAV4-HV_OM_OM42B81U_(U)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new mechanical keys can be made by
your Toyota dealer. ( →P. 109)
●If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. ( →P. 112)
●Is the electronic key battery weak or depleted? (→P. 522)
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( →P. 202)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. (→P. 138)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (→P. 1 1 6 )
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

663What to do if... (Troubleshooting)
RAV4-HV_OM_OM42B81U_(U)
●Did you press the power switch while firmly depressing the brake pedal?
(→P. 201)
●Is the shift lever in P? ( →P. 201)
●Is the electronic key anywhere detectable inside the vehicle? ( →P. 136)
●Is the steering wheel unlocked? (→P. 204)
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(→P. 596)
●Is the 12-volt battery discharged? ( →P. 597)
●Is the power switch in ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
power switch in ON mode: →P. 212
●It is locked automatically to prevent theft of the vehicle. ( →P. 204)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( →P. 162)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or ON mode (the hybrid system is not operating) for a period of
time. ( →P. 203)
If you think something is wrong
The hybrid system does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be tu rned after the hybrid system
is stopped
The windows do not open or close by operating the power
window switches
The power switch is turned off automatically

664What to do if... (Troubleshooting)
RAV4-HV_OM_OM42B81U_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (→P. 553)
●The brake system warning light is on
Is the parking brake released? (→P. 215)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 551, 560)
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( →P. 560)
●When a warning light turns on or a warning message is displayed, refer to
P. 551, 560.
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(→P. 581)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( →P. 607)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck
