Page 3031 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual R13280
SST
± SUSPENSION AND AXLEFRONT AXLE  HUB
SA±27
3023 Author: Date:
2005 SEQUOIA   (RM1146U)
8. 4WD:
INSTALL NEW OIL SEAL (INSIDE)
(a) Using SST and a plastic hammer, install a new oil seal (

Page 3032 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA23J±05
SA±28
± SUSPENSION AND AXLEFRONT AXLE  HUB
3024 Author: Date:
2005 SEQUOIA   (RM1146U)
INSTALLATION
1. INSTALL STEERING KNUCKLE
(a) 4WD:
Insert the drive shaft into the axle hub and temp

Page 3033 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA24P±03
F07264
R13372
SST
R13373WasherNut
± SUSPENSION AND AXLEFRONT WHEEL HUB BOLT
SA±29
3025 Author: Date:
2005 SEQUOIA   (RM1146U)
FRONT WHEEL HUB BOLT
REPLACEMENT
1. REMOVE FRONT WHEEL
2. RE

Page 3034 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA14E±08
F06645
 Snap Ring
Drive Shaft
 Dust Cover
Inboard Joint Shaft
 Inboard Joint Boot
 Outboard Joint Boot
 Boot Clamp
 Dust Seal Outboard Joint Shaft
 Cotter Pin Cotter Pin
Grease Cap L

Page 3035 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA24L±03
F06624
R12863
SST
R13233
± SUSPENSION AND AXLEFRONT DRIVE SHAFT
SA±31
3027 Author: Date:
2005 SEQUOIA   (RM1146U)
REMOVAL
1. REMOVE FRONT WHEEL
2. REMOVE ENGINE UNDER COVER
3. DRAIN DIFF

Page 3036 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual F07267
SSTLH: RH:
SST
SA±32
± SUSPENSION AND AXLEFRONT DRIVE SHAFT
3028 Author: Date:
2005 SEQUOIA   (RM1146U)
8. REMOVE DRIVE SHAFT
(a) RH drive shaft:
Using a brass bar and hammer, remove the RH

Page 3037 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA24M±03
F06646
F07259
W03190
Matchmarks
F06647
SST
F06648
SST
± SUSPENSION AND AXLEFRONT DRIVE SHAFT
SA±33
3029 Author: Date:
2005 SEQUOIA   (RM1146U)
DISASSEMBLY
1. CHECK DRIVE SHAFT
(a) Check

Page 3038 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA14H±06
F06649
W03195
Inboard Joint Boot Outboard Joint Boot
Vinyl Tape
W03218
Matchmarks
F06650
SA±34
± SUSPENSION AND AXLEFRONT DRIVE SHAFT
3030 Author: Date:
2005 SEQUOIA   (RM1146U)
REASSEMB

Page 3039 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual F07260
F07256
SST
F07257
SST
± SUSPENSION AND AXLEFRONT DRIVE SHAFT
SA±35
3031 Author: Date:
2005 SEQUOIA   (RM1146U)
(b) Using pliers, compress the clamp and attach the claws.
9. INSTALL OTHER BO

Page 3040 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA14I±10
SA±36
± SUSPENSION AND AXLEFRONT DRIVE SHAFT
3032 Author: Date:
2005 SEQUOIA   (RM1146U)
INSTALLATION
1. INSTALL DRIVE SHAFT TO DIFFERENTIAL
(a) Install a new snap ring to the inboard jo
