20. INSTALL DIFFERENTIAL CASE
21. INSTALL SIDE BEARING RETAINER
(a) Remove any old FIPG material and be careful not to drop
oil on the contact surfaces of the differential carrier and
side bearing retainer.
(b) Clean both installation surfaces with gasoline or alcohol.
(c) Apply FIPG to the side bearing retainer, as shown in the
illustration.
FIPG:
Part No. 08826±00090, THREE BOND 1281 or
equivalent
HINT:
Install the side bearing retainer within 10 minutes after applying
FIPG.
(d) Install the side bearing retainer with the 10 bolts.
Torque: 69 N´m (700 kgf´cm, 51 ft´lbf)
22. CHECK TOTAL PRELOAD (See step 12.)
23. RECHECK RING GEAR BACKLASH
(See page SA±43)
24. RECHECK TOOTH CONTACT BETWEEN RING GEAR
AND DRIVE PINION (See step 13.)
25. CHECK COMPANION FLANGE RUNOUT
(See step 1.)
26. STAKE DRIVE PINION NUT
27. INSTALL SIDE OIL SEAL
(a) Using SST and a plastic hammer, install a new oil seal un-
til its surface is flush with the differential carrier end.
SST 09608±32010
(b) Coat the oil seal lip with MP grease.
28. INSTALL INTERMEDIATE SHAFT NO. 1
(a) Install a new snap ring to the shaft.
(b) Using a plastic hammer, install the shaft to the differential
case.
(c) Check that the intermediate shaft will not come out by try-
ing to pull it out by hand.

SA0371
R13201
FIPG
F07258
Adhesive
F06634
FIPG
SA±58
± SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
3054 Author: Date:
2005 SEQUOIA (RM1146U)
29. INSTALL CLUTCH CASE TO DIFFERENTIAL TUBE
(a) Install a new O±ring to the tube.
(b) Coat the O±ring with MP grease.
(c) Install the clutch case to the tube.
(d) Using a torx® socket (E14), torque the 2 torx bolts.
Torque: 78 N´m (800 kgf´cm, 58 ft´lbf)
30. INSTALL CLUTCH SLEEVE
31. INSTALL DIFFERENTIAL TUBE TO DIFFERENTIAL
(a) Remove any old FIPG material and be careful not to drop
oil on the contact surfaces of the differential and clutch
case.
(b) Clean both installation surfaces with gasoline or alcohol.
(c) Apply FIPG to the differential, as shown in the illustration.
FIPG:
Part No. 08826±00090, THREE BOND 1281 or
equivalent
HINT:
Install the differential tube within 10 minutes after applying
FIPG.
(d) Install the differential tube to the differential.
(e) Clean the threads of the 2 long torx bolts and retainer bolt
holes with toluene or trichlorethylene.
(f) Apply adhesive to 2 or 3 threads of the long bolts end.
Adhesive:
Part No. 08833±00070, THREE BOND 1324 or equiva-
lent
(g) Using torx® socket (E14), torque the 4 torx bolts.
Torque: 78 N´m (800 kgf´cm, 58 ft´lbf)
32. INSTALL A.D.D. ACTUATOR
(a) Remove any old FIPG material and be careful not to drop
oil on the contact surfaces of the actuator and clutch case.
(b) Clean both installation surfaces with gasoline or alcohol.
(c) Apply FIPG to the clutch case, as shown in the illustration.
FIPG:
Part No. 08826±00090, THREE BOND 1281 or
equivalent
HINT:
Install the actuator within 10 minutes after applying FIPG.
(d) Install the A.D.D. actuator with the 4 bolts.
Torque: 21 N´m (210 kgf´cm, 15 ft´lbf)

SA14Q±06
± SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
SA±59
3055 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL DIFFERENTIAL MOUNTING CUSHIONS
(a) Install the 2 front mounting cushions with the 5 bolts.
Torque: 157 N´m (1,600 kgf´cm, 116 ft´lbf)
(b) Install the rear mounting cushion with the 2 bolts.
Torque: 108 N´m (1,100 kgf´cm, 80 ft´lbf)
2. INSTALL FRONT DIFFERENTIAL CARRIER
(a) Jack up the front differential.
(b) Install the 2 front mounting bolts.
Torque: 137 N´m (1,400 kgf´cm, 101 ft´lbf)
(c) Using a hexagon (12 mm) wrench, install the rear mounting nut.
Torque: 87 N´m (890 kgf´cm, 64 ft´lbf)
(d) Remove the jack.
3. INSTALL TUBE WITH WIRE HARNESS ASSEMBLY
(a) Install the tube with wire harness assembly with the bolt.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
(b) Connect the actuator connector, vacuum hose and breather hose.
4. CONNECT FRONT PROPELLER SHAFT (See page PR±9)
5. INSTALL DRIVE SHAFTS (See page SA±36)
6. FILL DIFFERENTIAL WITH HYPOID GEAR OIL (See page SA±38)

SA23P±03
F16856
4WD Control ECU
2WD/4HI and 4LO Switch
4WD and Center Diff. Lock
Indicator Light
(Combination Meter)
Transfer 4WD
Position Switch
Transfer L4 Position Switch
A.D.D. Actuator
Actuator Connector SA±60
± SUSPENSION AND AXLEA.D.D. CONTROL SYSTEM
3056 Author: Date:
2005 SEQUOIA (RM1146U)
A.D.D. CONTROL SYSTEM
LOCATION

SA23Q±03
F06635
Actuator side:
1423 56
F19317
2WD/4HI Switch
± SUSPENSION AND AXLEA.D.D. CONTROL SYSTEM
SA±61
3057 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. INSPECT A.D.D. ACTUATOR
(a) Disconnect the actuator connector.
(b) Measure the resistance between terminals 2 and 6.
Standard resistance: 0.3 ± 100 W
(c) Measure the resistance between terminal 2 or 6 and body
ground.
Standard resistance: More than 0.5 MW
If the resistance value is not as specified, replace the actuator
assembly.
2. INSPECT A.D.D. ACTUATOR OPERATION
Apply battery positive voltage between terminals 2 and 6, and
check the actuator operation by sound, A.D.D. status and conti-
nuity between terminals 3 and 4.
Battery voltage
applied terminal3 ± 4 terminals continuityA.D.D.
status
2 (+) ± 6 (±)ContinuityConnected
2 (±) ± 6 (+)No continuityDisconnected
If the operation is not as specified, replace the actuator assem-
bly.
3. INSPECT LIMIT SWITCH CONTINUITY
(a) Connect the actuator connector.
(b) Push the 2WD/4HI switch and check that the 4WD indica-
tor light comes on after it is blinking.
(c) Check the A.D.D. actuator operation by sound.
(d) Disconnect the actuator connector.
(e) Check the continuity between each terminal, as shown in
the chart.
Tester connected terminal numberSpecified condition
1 ± 3No continuity
1 ± 4No continuity
3 ± 5Continuity
4 ± 5No continuity
(f) Connect the actuator connector.

F16855
2WD/4HI Switch
SA0356
F06638
SA±62
± SUSPENSION AND AXLEA.D.D. CONTROL SYSTEM
3058 Author: Date:
2005 SEQUOIA (RM1146U)
(g) Push the 2WD/4HI switch and check that the 4WD indica-
tor light goes off after it is blinking.
(h) Check the A.D.D. actuator operation by sound.
(i) Disconnect the actuator connector.
(j) Check the continuity between each terminal, as shown in
the chart.
Tester connected terminal numberSpecified condition
1 ± 3Continuity
1 ± 4No continuity
3 ± 5No continuity
4 ± 5No continuity
(k) Connect the actuator connector.
4. INSPECT TRANSFER 4WD POSITION SWITCH
(See page TR±9)
5. REMOVE A.D.D. ACTUATOR (See page SA±43)
6. INSPECT CLUTCH HUB AND CLUTCH SLEEVE
(a) Check the clutch hub and clutch sleeve for wear and dam-
age.
If necessary, replace them.
(b) Check that clutch sleeve slides smoothly on the clutch
hub.
7. MEASURE SLEEVE FORK AND CLUTCH SLEEVE
CLEARANCE
Using a feeler gauge, measure the clearance between the
sleeve fork and clutch sleeve.
Maximum clearance: 0.35 mm (0.0138 in.)
If the clearance exceeds the maximum, replace the fork or
sleeve.

SA17Y±06
F14311
Shock Absorber
with Coil Spring
N´m (kgf´cm, ft´lbf)
: Specified torque
64 (650, 47)
Retainer
Cushion
Suspension
Support
Retainer
Coil Spring
Shock Absorber
25 (250, 18)
135 (1,400, 100)
Bushing

± SUSPENSION AND AXLEFRONT SHOCK ABSORBER
SA±63
3059 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT SHOCK ABSORBER
COMPONENTS

SA23R±03
F14315
R12773
SA±64
± SUSPENSION AND AXLEFRONT SHOCK ABSORBER
3060 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE FRONT WHEEL
2. DISCONNECT SHOCK ABSORBER FROM LOWER
SUSPENSION ARM
(a) Remove the shock absorber lower side set nut and wash-
er.
NOTICE:
Do not remove the bolt.
(b) Pry down the lower suspension arm to remove the bolt
and disconnect the shock absorber.
3. REMOVE SHOCK ABSORBER WITH COIL SPRING
Remove the 3 nuts and shock absorber with the coil spring.

SA23S±03
F14523
± SUSPENSION AND AXLEFRONT SHOCK ABSORBER
SA±65
3061 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
REMOVE SUSPENSION SUPPORT AND COIL SPRING
(a) Using a spring compressor, compress the coil spring.
NOTICE:

Use a spring compressor with which compressive
force of 12,740 N (1,300 kgf, 2,860 lbf) or more can be
applied.

Make sure that the suspension support is free from
the coil spring.

Do not compress the coil spring more than neces-
sary.

Do not place yourself over the top of the shock ab-
sorber.
(b) Remove the suspension support center nut.
(c) Remove the 2 retainers, cushion, suspension support
and coil spring.

SA180±04
SA0627
SA±66
± SUSPENSION AND AXLEFRONT SHOCK ABSORBER
3062 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
INSPECT SHOCK ABSORBER
Compress and extend the shock absorber rod and check that
there is no abnormal resistance or unusual operation sounds.
If there is any abnormality, replace the shock absorber with a
new one.
