TOYOTA SEQUOIA 2001  Service Repair Manual SA23K±03
F06626
 Non±reusable part Bearing Spacer
N´m (kgf´cm, ft´lbf): Specified torque
Differential
 Oil Seal
Oil Slinger
Rear Bearing
74 (750, 54)
Companion Flange
74 (750, 54)
See page SA

Page 3042 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA23L±04
Z00638
SST
R13369
SST
R13370
SST
R13371
SST SA±38
± SUSPENSION AND AXLEFRONT DIFFERENTIAL REAR OIL SEAL
3034 Author: Date:
2005 SEQUOIA   (RM1146U)
REPLACEMENT
1. REMOVE ENGINE UNDER COV

Page 3043 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual R13368
SST
R13374
SST
4.5 ± 0.3 mm
(0.177 ± 0.012 in.)
FA1083
SST
FA1084
R13338
Less than
5 mm (0.20 in.)
± SUSPENSION AND AXLEFRONT DIFFERENTIAL REAR OIL SEAL
SA±39
3035 Author: Date:
2005 SE

Page 3044 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA23M±03
F06629
A.D.D. Actuator
Connector RH Drive Shaft
 Snap RingVacuum Hose
Front
Differential
Carrier
Rear
Mounting Cushion
LH Drive Shaft Front (LH)
Mounting Cushion Front (RH)
Mounting
Cushion

Page 3045 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual F06628
 Oil Seal
 Snap Ring
Bearing
Intermediate
Shaft No. 2
Differential
Tube
78 (800, 58)
78 (800, 58)

A.D.D. Actuator
21 (210, 15)
 Snap Ring
Intermediate
Shaft No. 1
Clutch Case
Sleeve
 Sna

Page 3046 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA24Q±02
F06630
SA±42
± SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
3038 Author: Date:
2005 SEQUOIA   (RM1146U)
REMOVAL
1. DRAIN DIFFERENTIAL OIL
2. REMOVE DRIVE SHAFTS (See page SA±31)
3. DIS

Page 3047 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual W00493
30 mm (1.18 in.)
SA23N±04
R12683
SST
FA1158
F06631
± SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
SA±43
3039 Author: Date:
2005 SEQUOIA   (RM1146U)
DISASSEMBLY
1. CHECK COMPANION FLANGE R

Page 3048 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual R13208
R13209
SST
R13197
SST
SA2349
SST
R11391
SST SA±44
± SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
3040 Author: Date:
2005 SEQUOIA   (RM1146U)
6. REMOVE DIFFERENTIAL TUBE
(a) Using a torx so

Page 3049 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual SA2348
SST
Z00641
SST
W04006
R02482
SST
R13226
± SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
SA±45
3041 Author: Date:
2005 SEQUOIA   (RM1146U)
11. REMOVE OIL SEAL AND OIL SLINGER
(a) Using SST,

Page 3050 of 4323

TOYOTA SEQUOIA 2001  Service Repair Manual R13210
SST
R13211F14774
SSTSST
R13213
SSTSST
FA1998
Matchmarks
R11392
SST
SST SA±46
± SUSPENSION AND AXLEFRONT DIFFERENTIAL CARRIER
3042 Author: Date:
2005 SEQUOIA   (RM1146U)
(b) Using SST, remov
