TOYOTA SEQUOIA 2001 Service Repair Manual

H11174: 4 Clips
H11372
3 Clips
H11177
2 Clips
H16769
5 Clips
H24384
BO±90
± BODYINSTRUMENT PANEL
3643 Author: Date:
2005 SEQUOIA (RM1146U)
10. REMOVE LOWER FINISH PANEL
(a) Remove the 2 screws and hood lock release lever.
(b) Remove the 4 bolts and lower finish panel.
(c) Disconnect the connector.
11. REMOVE SWITCH BASE
(a) Using a screwdriver, lift up the switch base and remove it.
HINT:
Tape the screwdriver tip before use.
(b) Disconnect the connectors.
12. REMOVE NO. 2 HEATER TO REGISTER DUCT
13. REMOVE STEERING COLUMN (See page SR±14)
14. REMOVE CLUSTER FINISH PANEL
Remove the 2 screws and cluster finish panel.
15. REMOVE COMBINATION METER
(a) Remove the 4 screws.
(b) Remove the combination meter and disconnect the 4
connectors.
16. REMOVE INTEGRATION CONTROL PANEL
(a) Remove the 2 screws as shown in the illustration.
(b) Using a screwdriver, remove the integration panel, then
disconnect the connectors.
HINT:
Tape the screwdriver tip before use.
17. REMOVE RADIO TUNER ASSEMBLY
(a) Disconnect the connector.
(b) Remove the 4 bolts and radio tuner assembly.
18. REMOVE AIR CONDITIONER CONTROL ASSEMBLY
(See page AC±103)

H16202
H11371
H24860
4 Clips
H16748
6 Clips
± BODYINSTRUMENT PANEL
BO±91
3644 Author: Date:
2005 SEQUOIA (RM1146U)
19. DISCONNECT FRONT PASSENGER AIRBAG AS-
SEMBLY CONNECTOR
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(a) Using a clip remover, disengage the connector clamp.
(b) Disconnect the connector as shown in the illustration.
20. REMOVE GLOVE COMPARTMENT DOOR
Remove the 2 screws and glove compartment door.
21. REMOVE LOWER NO. 2 FINISH PANEL
Remove the 3 screws and lower No. 2 finish panel.
22. REMOVE SHIFTING HOLE COVER
Using a screwdriver, remove the shifting hole cover.
HINT:
Tape the screwdriver tip before use.
23. REMOVE UPPER CONSOLE PANEL
(a) w/ Seat heater:
Using a screwdriver, remove the seat heater switches,
then disconnect the connectors.
HINT:
Tape the screwdriver tip before use.
(b) Using a screwdriver, remove the power mirror control
switch, then disconnect the connector.
HINT:
Tape the screwdriver tip before use.
(c) Using a screwdriver, remove the upper console panel.
HINT:
Tape the screwdriver tip before use.

H16749
H18899
H243734 Claws
H16751
2 Clips
H21029
BO±92
± BODYINSTRUMENT PANEL
3645 Author: Date:
2005 SEQUOIA (RM1146U)
24. REMOVE REAR CONSOLE BOX
(a) w/ Rear heater A/C:
Using a screwdriver, remove the rear heater control pan-
el, then disconnect the connector.
HINT:
Tape the screwdriver tip before use.
(b) w/ Headphone terminal.
Using a screwdriver, remove the headphone terminal and
the connector.
(c) w/ Rear seat entertainment:
(1) Remove the disc bracket.
(2) Remove the 3 bolts and disc player.
(3) Disconnect the connector.
(d) Remove the 4 bolts and rear console box.
25. REMOVE CONSOLE BOX BEZEL
(a) Using a screwdriver, remove the console box bezel.
HINT:
Tape the screwdriver tip before use.
(b) Disconnect the connectors.
26. REMOVE FRONT CONSOLE BOX
Remove the 2 bolts, 2 clips and front console box.
27. REMOVE LOWER INSTRUMENT COVER
(a) Remove the 4 bolts and 3 screws.
(b) Using a screwdriver, remove the lower instrument cover.
HINT:
Tape the screwdriver tip before use.
28. REMOVE PASSENGER AIRBAG ASSEMBLY
(a) Remove the 2 bolts holding the front passenger airbag
assembly and instrument panel.
Torque: 5.0 N´m (51 kgf´cm, 44 in.´lbf)

H11181
± BODYINSTRUMENT PANEL
BO±93
3646 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Remove the bolt holding the front passenger airbag as-
sembly and instrument panel reinforcement.
Torque: 20 N´m (204 kgf´cm, 15 ft.´lbf)
CAUTION:

Do not store the front passenger airbag assembly
with the airbag deployment side facing down.

Never disassemble the front passenger airbag as-
sembly.
29. REMOVE NO. 4 HEATER TO REGISTER DUCT
30. REMOVE INSTRUMENT PANEL
(a) Remove the nut.
(b) Disconnect the connectors and remove the instrument
panel.

H11182
BO±94
± BODYINSTRUMENT PANEL
3647 Author: Date:
2005 SEQUOIA (RM1146U)
31. REMOVE CENTER HEATER TO REGISTER DUCT
32. REMOVE INSTRUMENT PANEL REINFORCEMENT
(a) Disconnect the connectors.
(b) Remove the bolt and door control receiver.
(c) Remove the 3 bolts, nut and No. 1 brace.
(d) Remove the bolt, nut and No. 2 brace.
(e) Remove the 3 bolts, 4 nuts and instrument panel rein-
forcement.
33. REMOVE CONSOLE COMPARTMENT BOX AS-
SEMBLY
34. REMOVE BOX PANEL SUB±ASSEMBLY
Remove the 3 bolts and box panel sub±assembly.
Torque: 40 N´m (408 kgf´cm, 30 ft´lbf)

H11183
BO439±03
H21030
H11185
H11186
H11187
± BODYINSTRUMENT PANEL
BO±95
3648 Author: Date:
2005 SEQUOIA (RM1146U)
DISASSEMBLY
1. REMOVE NO. 3 HEATER TO REGISTER DUCT
Remove the screw and No. 3 heater to register duct
2. REMOVE NO. 1 REGISTER
Remove the 2 screws and No. 1 register.
3. REMOVE CENTER STAY
Remove the 3 screws and center stay.
4. REMOVE CENTER BRACKET
Remove the 3 screws and center bracket.
5. REMOVE NO. 5 HEATER TO REGISTER DUCT
Remove the screw and No. 5 heater to register duct.
6. REMOVE SIDE DEFROSTER NOZZLE DUCT
Remove the screw and side defroster nozzle duct.
7. REMOVE NO. 2 REGISTER
Remove the 3 screws and No. 2 register.

BO1MO±03
BO±96
± BODYINSTRUMENT PANEL
3649 Author: Date:
2005 SEQUOIA (RM1146U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO±95).

BO43A±02
± BODYINSTRUMENT PANEL
BO±97
3650 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page BO±89).
1. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
2. PERFORM INITIALIZATION (See page IN±20)
Some systems need initialization when disconnecting the cable from the negative battery terminal.

BO4HM±01
H18897
Assist Gripw/ Rear A/C:
Rear No. 6 Air Duct
Roof Console BoxLens Map Lightw/ Rear No. 2 seat:
Assist Grip
Dome Light
LensRear Trim Roof Headlining
w/ Rear No. 2 seat:
Rear Trim Cover w/ Double Sun Visor:
Roof Headlining Roof Console Box
w/o Rear No. 2 seat:
Service Hole Cover
w/ Rear No. 2 seat:
Assist Grip
w/o Rear No. 2 seat:
Service Hole Cover
Sun VisorRoof Headlining
w/ Electro chrmic
inner rear view mirror:
Mirror Coverw/ Sliding roof:
Sun Visor
Sun Visor
Holder Holder
Assist Grip
Map Light
Lens
Sliding Roof Opening Trim
w/ Rear A/C:
Rear No.5 Air Duct
BO±98
± BODYROOF HEADLINING
3651 Author: Date:
2005 SEQUOIA (RM1146U)
ROOF HEADLINING
COMPONENTS

H18896
w/ Rear seat entertainment:
Sliding Roof Opening Trim
Roof Console BoxRoof Headlining
Multi Information Display
Display Panel
Lens
± BODYROOF HEADLINING
BO±99
3652 Author: Date:
2005 SEQUOIA (RM1146U)
