ES–4882GR-FE ENGINE CONTROL SYSTEM – CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY
ES
12. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY (for Bank 2 Exhaust Side)
(a) Disconnect the camshaft timing oil control valve
assembly connector.
(b) Remove the bolt and camshaft timing oil control
valve assembly.
(c) Remove the O-ring from the camshaft timing oil
control valve.
13. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE
ASSEMBLY (for Bank 2 Intake Side)
(a) Disconnect the camshaft timing oil control valve
assembly connector.
(b) Remove the bolt and camshaft timing oil control
valve assembly.
(c) Remove the O-ring from the camshaft timing oil
control valve.
A135695
A135696

ED–232ENGINE HOOD / DOOR – BACK DOOR SUPPORT
ED
INSTALLATION
1. REMOVE BACK DOOR STAY SUB-ASSEMBLY LH
(a) Install the stay with the bolts to the door panel.
Torque: 19.5 N*m (200 kgf*cm, 14 ft.*lbf) for
door side
(b) Install the stay with the 2 bolts to the body panel.
Torque: 17.5 N*m (180 kgf*cm, 13 ft.*lbf) for
body side

ENGINE HOOD / DOOR – BACK DOOR SUPPORTED–233
ED
DISPOSAL
HINT:
On the RH side, use the same procedures as on the LH side.
1. DISPOSE OF BACK DOOR STAY SUB-ASSEMBLY LH
(a) Horizontally fix the stay in a vise with the piston-rod
pulled out.
(b) Wearing safety glasses, gradually cut a part
between A and B as shown in the illustration using a
metal saw to gradually release the gas.
Dimensions
NOTICE:
Although the gas inside the damper stay is
colorless, odorless and harmless, there is a
possibility that metal debris from cutting could
enter the assembly. Therefore, cover it with
cloth or something similar.
B065104E10
ab
80 mm (3.15 in.) 20 mm (0.80 in.)

2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–17
ES
REGISTRATION
NOTICE:
The Vehicle Identification Number (VIN) must be input
into the replacement ECM.
HINT:
The VIN is a 17-digit alphanumeric vehicle identification
number. The intelligent tester is required to register the VIN.
1. INPUT INSTRUCTIONS
(a) The general VIN input instructions using the
intelligent tester are shown below:
(b) The arrow buttons (UP, DOWN, RIGHT and LEFT)
and numerical buttons (0 to 9) are used to input the
VIN.
(c) Cursor Operation
To move the cursor around the tester screen, press
the RIGHT and LEFT buttons.
(d) Alphabetical Character Input
(1) Press the UP and DOWN buttons to select the
desired alphabetical character.
(e) Numerical Character Input
(1) Press the numerical button corresponding to
the number that you want to input.
HINT:
Numerical characters can be selected by using
the UP and DOWN buttons.
(f) Correction
(1) When correcting the input character(s), put the
cursor onto the character using the RIGHT and
LEFT buttons.
(2) Select or input the correct character using the
UP and DOWN buttons, or the numerical
buttons.
(g) Finishing Input Operation
(1) Make sure that the input VIN matches the
vehicle VIN after input.
(2) Press the ENTER button on the tester.
2. READ VIN (Vehicle Identification Number)
(a) The VIN reading process is shown in the flowchart
below. Reading the VIN stored in the ECM is
necessary when comparing it to the VIN provided
with the vehicle.
(b) Read the VIN using the intelligent tester.
(c) Check the vehicle's VIN.
(d) Connect the intelligent tester to the DLC3.
(e) Turn the ignition switch to the ON position.
(f) Turn the tester ON.

ES–182GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
(g) Enter the following menus: DIAGNOSIS /
ENHANCED OBD II / VIN.
3. WRITE VIN
(a) The VIN writing process is shown in the flowchart
below. This process allows the VIN to be input into
the ECM. If the ECM is changed, or the ECM VIN
and Vehicle VIN do not match, the VIN can be
registered, or overwritten in the ECM by following
this procedure.
(b) Write VIN using the intelligent tester.
(c) Connect the intelligent tester to the DLC3.
(d) Turn the ignition switch to the ON position.
(e) Turn the tester ON.
A103812E03

2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–19
ES
(f) Enter the following menus: DIAGNOSIS /
ENHANCED OBD II / VIN.
A103813E01

ES–202GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
A103814E03

2GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEMES–21
ES
A103815

2GR-FE ENGINE CONTROL SYSTEM – THROTTLE BODYES–493
ES
ON-VEHICLE INSPECTION
1. INSPECT THROTTLE BODY
(a) Listen to the throttle control motor operating sounds.
(1) Turn the ignition switch to the ON position.
(2) When pressing the accelerator pedal position
sensor lever, listen to the running motor. Make
sure that no friction noise comes from the
motor.
If friction noise exists, replace the throttle body.
(b) Inspect the throttle position sensor.
(1) Connect the intelligent tester to the DLC3.
(2) Turn the ignition switch to the ON position.
(3) Check that the MIL turns off.
(4) Under CURRENT DATA, the throttle valve
opening percentage (THROTTLE POS) should
be within the standard range below.
Standard throttle valve opening percentage:
60% or more
If the percentage is less than 60%, replace the
throttle body.
NOTICE:
When checking the throttle valve opening
percentage, the transmission should be in
neutral.
E144486E01

ES–4942GR-FE ENGINE CONTROL SYSTEM – THROTTLE BODY
ES
REMOVAL
1. REMOVE WINDSHIELD WIPER MOTOR ASSEMBLY
HINT:
(See page WW-4)
2. REMOVE FRONT OUTER COWL TOP PANEL SUB-
ASSEMBLY (See page EM-27)
3. DRAIN ENGINE COOLANT (See page CO-6)
4. REMOVE V-BANK COVER SUB-ASSEMBLY (See
page EM-28)
5. REMOVE NO. 2 AIR CLEANER INLET (See page EM-
28)
6. REMOVE NO. 1 AIR CLEANER INLET (See page EM-
28)
7. REMOVE AIR CLEANER CAP SUB-ASSEMBLY
(a) Disconnect the 3 vacuum hoses.
(b) Remove the No. 2 ventilation hose and air cleaner
hose band.
(c) Disconnect the vacuum hose (EVAP) from the air
cleaner hose.
(d) Disconnect the mass air flow meter connector.
(e) Remove the 2 bolts and air cleaner cap sub-
assembly.
8. REMOVE AIR CLEANER CASE SUB-ASSEMBLY (See
page EM-28)
A135112E01
A135113E01
A135114
