Page 609 of 3000
ES–3162GR-FE ENGINE CONTROL SYSTEM – SFI SYSTEM
ES
MONITOR DESCRIPTION
The battery supplies electricity to the ECM even when the ignition switch is off. This power allows the
ECM to store data such as DTC history, freeze frame data and fuel trim values. If the battery voltage falls
below a minimum level, these memories are cleared and the ECM determines that there is a malfunction
in the power supply circuit. When the engine is next started, the ECM illuminates the MIL and sets the
DTC.
HINT:
If DTC P0560 is set, the ECM does not store other DTCs.
MONITOR STRATEGY
TYPICAL ENABLING CONDITIONS
TYPICAL MALFUNCTION THRESHOLDS
WIRING DIAGRAM
DTC P0560 System Voltage
DTC No. DTC Detection Condition Trouble Area
P0560Open in ECM back up power source circuit (1 trip
detection logic)• Open in back up power source circuit
• EFI No. 1 fuse
•ECM
Related DTCs P0560: ECM system voltage
Required Sensors / Components (Main) ECM
Required Sensors / Components (Related) -
Frequency of Operation Continuous
Duration 3 seconds
MIL Operation Immediate (MIL illuminated after next engine start)
Sequence of Operation None
The monitor will run whenever these DTCs are not
presentNone
Stand-by RAM Initialized
ECM power source Less than 3.5 V
A118508E18
Page 2322 of 3000
TW–80TIRE AND WHEEL – TIRE PRESSURE WARNING SYSTEM
TW
DESCRIPTION
This is the power source for the tire pressure warning ECU.
WIRING DIAGRAM
INSPECTION PROCEDURE
NOTICE:
When replacing the tire pressure warning ECU, read the transmitter IDs stored in the old ECU
using the intelligent tester and write them down before removal.
It is necessary to register an ID code after replacing the tire pressure warning valve and
transmitter and/or the tire pressure warning ECU (See page TW-20).
(a) Remove the ECU-IG fuse from the instrument panel
junction block.
(b) Measure the resistance of the fuse.
Standard resistance:
Below 1
NG
ECU Power Source Circuit
1INSPECT FUSE (ECU-IG)
C162809E01
REPLACE FUSE
Page 2394 of 3000
BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEMBC–33
BC
DESCRIPTION
The ABS motor relay supplies power to the ABS pump motor. While the ABS is activated, the ECU turns
the motor relay on and operates the ABS pump motor.
If the voltage supplied to the motor relay (+BM) is below the DTCs detection threshold due to low voltage
from the battery/alternator, the DTCs may be stored.
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
After steps 1, 2 and 3 are completed, start the inspection from step 4 when using the intelligent tester, and
from step 5 when not using the intelligent tester.
(a) Remove the ABS 1 fuse from the FL block.
(b) Measure the resistance according to the value(s) in the
table below.
Standard resistance
DTC C0273/13 Open in ABS Motor Relay Circuit
DTC C0274/14 Short to B+ in ABS Motor Relay Circuit
DTC No. DTC Detection Condition Trouble Area
C0273/13With the IG1 terminal voltage 10 V or less during initial
check or ABS control, pump motor relay is turned ON
and relay contact is not ON for 0.2 seconds or more.• ABS 1 fuse
• ABS motor relay
• ABS motor relay circuit
• Brake actuator assembly
C0274/14The motor contact is ON for 3 seconds or more when
the motor relay is OFF.• ABS 1 fuse
• ABS motor relay
• ABS motor relay circuit
• Brake actuator assembly
1INSPECT FUSE (ABS 1 FUSE)
C119436E01
Tester Connection Specified Condition
ABS 1 (50 A) fuse Below 1
(Continuity)
Page 2397 of 3000
BC–36BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEM
BC
DESCRIPTION
This relay supplies power to each ABS solenoid.
Immediately after the ignition switch is turned to the ON position, the relay turns on if the solenoid is
determined to be normal as a result of self-diagnosis during initial check.
The relay turns off if an open/short is detected.
If the voltage supplied to the motor relay (+BS) is below the DTC detection threshold due to low voltage
from the battery/alternator, the DTCs may be stored.
WIRING DIAGRAM
Refer to DTCs C0226/21, C0236/22, C0246/23 and C0256/24 (See page BC-29).
INSPECTION PROCEDURE
(a) Remove the ABS 2 fuse from the FL block.
(b) Measure the resistance according to the value(s) in the
table below.
Standard resistance
NG
OK
DTC C0278/11 Open in ABS Solenoid Relay Circuit
DTC C0279/12 Short to B+ in ABS Solenoid Relay Circuit
DTC No. DTC Detection Condition Trouble Area
C0278/11The solenoid relay contact is OFF for 0.2 seconds or
more when the solenoid relay is turned ON.• ABS 2 fuse
• ABS solenoid relay
• ABS solenoid relay circuit
• Brake actuator assembly
C0279/12The solenoid relay contact is ON for 0.2 seconds or
more when the solenoid relay is OFF.• ABS 2 fuse
• ABS solenoid relay
• ABS solenoid relay circuit
• Brake actuator assembly
1INSPECT FUSE (ABS 2 FUSE)
Tester Connection Specified Condition
ABS 2 (30 A) fuse Below 1
(Continuity)
REPLACE FUSE (ABS 2 FUSE)
Page 2400 of 3000
BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEMBC–39
BC
DESCRIPTION
If there is a problem with the brake actuator assembly (skid control ECU) power supply circuit, the skid
control ECU outputs the DTC and prohibits the ABS operation with the fail safe function.
If the voltage supplied to the IG1 terminal is not within the DTC detection threshold due to malfunctions in
such as the battery and alternator circuit, this DTC is stored.
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
After steps 1 and 2 are completed, start the inspection from step 3 when using the intelligent tester, and
from step 4 when not using the intelligent tester.
DTC C1241/41 Low Battery Positive Voltage
DTC No. DTC Detection Condition Trouble Area
C1241/41When any of the following is detected:
• Vehicle speed is 3 km/h (1.8 mph) or
more and IG1 terminal voltage is 9.5 V or
less for at least 10 seconds.
• While the solenoid relay is ON, the IG1
terminal voltage is 10 V or less and the
relay contact is open solenoid fault
detecting conditions are established.
• Voltage of ECU terminal IG1 remains at
more than 17 V for 1 second or more..• Battery
•ECU-IG fuse
• Charging system
• Power source circuit
F045116E05
Page 2476 of 3000
BC–114BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEM
BC
DESCRIPTION
The ABS solenoid relay is built in the brake actuator assembly. This relay supplies power to each ABS
solenoid. If the initial check is OK, after the ignition switch is turned to the ON position, the relay goes on.
WIRING DIAGRAM
Refer to DTCs C0226/21, C0236/22, C0246/23 and C0256/24 (See page BC-105).
INSPECTION PROCEDURE
(a) Remove the ABS 2 fuse from the FL block.
(b) Measure the resistance according to the value(s) in the
table below.
Standard resistance
NG
OK
(a) Disconnect the skid control ECU connector.
(b) Turn the ignition switch to the ON position.
DTC C0278/11Open or Short Circuit in ABS Solenoid Relay
Circuit
DTC C0279/12 Short to B+ in ABS Solenoid Relay Circuit
DTC Code DTC Detection Condition Trouble Area
C0278/11When either of the following is detected:
1. Both of the following conditions continue for 0.2
sec. or more.
– The IG1 terminal voltage is between 9.5 and
18.5 V.
– The solenoid relay contact is open when the
relay is turned on.
2. Both of the following conditions continue for 0.2
sec. or more.
– IG1 terminal voltage becomes lower than 9.5 V
or less when the relay is turned on.
– The relay contact remains open.• ABS 2 fuse
• ABS SOL relay
• ABS SOL relay circuit
• Brake actuator assembly
C0279/12Immediately after IG1 is turned ON, when solenoid
relay is turned OFF, relay contact is "ON" for 0.2 sec. or
more.• ABS 2 fuse
• ABS SOL relay
• ABS SOL relay circuit
• Brake actuator assembly
1INSPECT ABS 2 FUSE
Tester Connection Specified condition
ABS 2 fuse Below 1
REPLACE ABS 2 FUSE
2INSPECT SKID CONTROL ECU
Page 2490 of 3000
BC–128BRAKE CONTROL – VEHICLE STABILITY CONTROL SYSTEM
BC
DESCRIPTION
WIRING DIAGRAM
INSPECTION PROCEDURE
(a) Remove the ECU-IG fuse from the driver side J/B.
DTC C1241/41 Low Battery Positive Voltage
DTC Code DTC Detection Condition Trouble Area
C1241/41When any of the following is detected:
1. At a vehicle speed of 3 km/h (2mph) or more, the
IG1 terminal voltage is 9.5 V or less for 10 sec. or
more.
2. When the solenoid relay remains ON and the IG1
terminal voltage is 9.5 V or less, the relay contact is
open for 0.2 sec. or more.
3. While the motor fail safe relay is ON after motor
relay ON, the IG1 terminal voltage is 9.5 V or less
and the actuator pump drive motor is OFF for 0.1
sec. or more.•Battery
• Charging system
• Power source circuit
1INSPECT ECU-IG FUSE
F045116E06
Page 2571 of 3000
BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEMBC–33
BC
DESCRIPTION
The ABS motor relay supplies power to the ABS pump motor. While the ABS is activated, the ECU turns
the motor relay on and operates the ABS pump motor.
If the voltage supplied to the motor relay (+BM) is below the DTCs detection threshold due to low voltage
from the battery/alternator, the DTCs may be stored.
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
After steps 1, 2 and 3 are completed, start the inspection from step 4 when using the intelligent tester, and
from step 5 when not using the intelligent tester.
(a) Remove the ABS 1 fuse from the FL block.
(b) Measure the resistance according to the value(s) in the
table below.
Standard resistance
DTC C0273/13 Open in ABS Motor Relay Circuit
DTC C0274/14 Short to B+ in ABS Motor Relay Circuit
DTC No. DTC Detection Condition Trouble Area
C0273/13With the IG1 terminal voltage 10 V or less during initial
check or ABS control, pump motor relay is turned ON
and relay contact is not ON for 0.2 seconds or more.• ABS 1 fuse
• ABS motor relay
• ABS motor relay circuit
• Brake actuator assembly
C0274/14The motor contact is ON for 3 seconds or more when
the motor relay is OFF.• ABS 1 fuse
• ABS motor relay
• ABS motor relay circuit
• Brake actuator assembly
1INSPECT FUSE (ABS 1 FUSE)
C119436E01
Tester Connection Specified Condition
ABS 1 (50 A) fuse Below 1
(Continuity)
Page 2576 of 3000
BC–36BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEM
BC
DESCRIPTION
This relay supplies power to each ABS solenoid.
Immediately after the ignition switch is turned to the ON position, the relay turns on if the solenoid is
determined to be normal as a result of self-diagnosis during initial check.
The relay turns off if an open/short is detected.
If the voltage supplied to the motor relay (+BS) is below the DTC detection threshold due to low voltage
from the battery/alternator, the DTCs may be stored.
WIRING DIAGRAM
Refer to DTCs C0226/21, C0236/22, C0246/23 and C0256/24 (See page BC-29).
INSPECTION PROCEDURE
(a) Remove the ABS 2 fuse from the FL block.
(b) Measure the resistance according to the value(s) in the
table below.
Standard resistance
NG
OK
DTC C0278/11 Open in ABS Solenoid Relay Circuit
DTC C0279/12 Short to B+ in ABS Solenoid Relay Circuit
DTC No. DTC Detection Condition Trouble Area
C0278/11The solenoid relay contact is OFF for 0.2 seconds or
more when the solenoid relay is turned ON.• ABS 2 fuse
• ABS solenoid relay
• ABS solenoid relay circuit
• Brake actuator assembly
C0279/12The solenoid relay contact is ON for 0.2 seconds or
more when the solenoid relay is OFF.• ABS 2 fuse
• ABS solenoid relay
• ABS solenoid relay circuit
• Brake actuator assembly
1INSPECT FUSE (ABS 2 FUSE)
Tester Connection Specified Condition
ABS 2 (30 A) fuse Below 1
(Continuity)
REPLACE FUSE (ABS 2 FUSE)
Page 2582 of 3000
BRAKE CONTROL – ANTI-LOCK BRAKE SYSTEMBC–39
BC
DESCRIPTION
If there is a problem with the brake actuator assembly (skid control ECU) power supply circuit, the skid
control ECU outputs the DTC and prohibits the ABS operation with the fail safe function.
If the voltage supplied to the IG1 terminal is not within the DTC detection threshold due to malfunctions in
such as the battery and alternator circuit, this DTC is stored.
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
After steps 1 and 2 are completed, start the inspection from step 3 when using the intelligent tester, and
from step 4 when not using the intelligent tester.
DTC C1241/41 Low Battery Positive Voltage
DTC No. DTC Detection Condition Trouble Area
C1241/41When any of the following is detected:
• Vehicle speed is 3 km/h (1.8 mph) or
more and IG1 terminal voltage is 9.5 V or
less for at least 10 seconds.
• While the solenoid relay is ON, the IG1
terminal voltage is 10 V or less and the
relay contact is open solenoid fault
detecting conditions are established.
• Voltage of ECU terminal IG1 remains at
more than 17 V for 1 second or more..• Battery
•ECU-IG fuse
• Charging system
• Power source circuit
F045116E05
