312-1. QUICK REFERENCE
Supra Owner's Manual
2
QUICK REFERENCE
Push the lever forward or pull it
backward.
• High beams on, arrow 1. The
high beams light up when the
low beams are switched on.
• High beams off/headlight flasher, arrow 2 .
• On: press the lever past the resistance point.
• Off: press the lever past the resistance point in the oppo-
site direction.
• Triple turn signal activation: lightly tap the lever up or down.
• Brief signaling: press the lever to the resistance point and
hold it there for as long as you
want the turn signal to flash.
High beams, headlight
flasher, turn signal
High beams, headlight
flasher
Turn signal
Lights and lighting
Light functions
SymbolFunction
Lights off.
Daytime running lights.
Parking lights.
Automatic headlight control.
Low beams.
Instrument lighting.
Right roadside parking light.
Left roadside parking light.

322-1. QUICK REFERENCE
Supra Owner's Manual
■Switching on
Press the lever up until the
desired position is reached.
• Resting position of the wipers: position 0.
• Rain sensor: position 1.
• Normal wiper speed: position 2.
• Fast wiper speed: position 3.
■Brief wipe and switching off
Press the lever down.
• Switching off: press the lever down until it reaches its stan-
dard position.
• Brief wipe: press the lever down from the standard posi-
tion.
■Activating/deactivating
To activate: press the lever up
once from its standard position,
arrow 1.
To deactivate: press the lever
back into the standard position.
■Adjusting the sensitivity
Turn the thumbwheel on the
wiper lever.
Washer/wiper system
Switching the wipers on/off
and brief wipe
Rain sensor
Cleaning the windshield

332-1. QUICK REFERENCE
Supra Owner's Manual
2
QUICK REFERENCE
Pull the wiper lever towards you. 1Press the rear edge of the
fuel filler flap to open it.
2 Turn the fuel cap counter-
clockwise.
3 Place the fuel cap in the
bracket attached to the fuel
filler flap.
For the best fuel efficiency, the
Climate control
ButtonFunction
Temperature.
Recirculated-air mode.
Maximum cooling.
AUTO program.
Air distribution, manual.
Switching off.
Defrost and defog the windshield.
Rear window defroster.
Seat heating.
Climate control opera- tion.
Air flow, manual.
Refueling
Refuelling
Fuel cap
Gasoline
ButtonFunction

342-1. QUICK REFERENCE
Supra Owner's Manual
gasoline should be sulfur-free or
very low in sulfur content.
Fuels that are marked on the
gas pump as containing metal
must not be used. P.287
The tire inflation pressure speci-
fications can be found in the tire
inflation pressure table in the
printed Owner's Manual.
With Tire Pressure Monitor
TPM:
With tires that cannot be found
in the tire pressure values on
the Control Display, reset the
Tire Pressure Monitor TPM.
Regularly check the tire inflation
pressure and correct it as
needed:
• At least twice a month.
• Before embarking on an extended trip.
The friction during hard braking
may produce brake dust and make the rims dirty. Brake dust
can be removed by cleaning the
rims. Toyota recommends using
vehicle care and cleaning prod-
ucts from Toyota.
A current measured value is
available after approx. 30 min-
utes of normal driving.
Via Toyota Supra Command:
1
"My Vehicle"
2 "Vehicle status"
3 "Engine oil level"
Different messages appear on
the Control Display depending
on the engine oil level. Pay
attention to these messages.
Safely park the vehicle and
switch off drive-ready state
before adding engine oil.
Wheels and tires
Tire inflation pressure speci-
fications
After correcting the tire infla-
tion pressure
Checking the tire inflation
pressure
Cleaning the wheels
Electronic oil measure-
ment
Functional requirements
Displaying the engine oil
level
Adding engine oil
General information

352-1. QUICK REFERENCE
Supra Owner's Manual
2
QUICK REFERENCEOnly add engine oil when the
message is displayed in the
instrument cluster.
Observe the quantity to be
added in the message.
Take care not to add too much
engine oil.
Observe recommended engine
oil types.
The button is located in the cen-
ter console.
Via Toyota Supra Command: 1
"Toyota Supra Connect"
2 "Toyota Supra Assistance"
3 "Roadside assistance"
A voice connection is established.
The Concierge offers informa-
tion on events, gas stations or
hotels, and provides phone
numbers and addresses. Many
hotels can be booked directly by
the Concierge.
Via Toyota Supra Command:
1"Toyota Supra Connect"
2 "Toyota Supra Assistance"
3 "Concierge"
A voice connection to the Con-
cierge is established.
Remote maintenance are ser-
vices that help to maintain vehi-
cle mobility.
Remote maintenance can com-
prise the following services:
• Roadside assistance.
• Battery guard.
When leaving the vehicle, turn
Adding
Providing assistance
Hazard warning flashers
Roadside assistance
Toyota Supra Connect
Concierge
Remote maintenance
After driving
When parking

362-1. QUICK REFERENCE
Supra Owner's Manual
the engine switch off, apply the
parking brake and lock the
doors.
When parking, stop the vehicle
in a safe and appropriate park-
ing area, operate the “P” (park-
ing) switch on the selector lever
and turn the engine switch off.
WA R N I N G
When taking a nap in the vehicle,
make sure to turn the engine
switch off.
When taking a nap in the vehicle
is unavoidable, park the vehicle in
a safe place, turn the engine
switch off, and if possible, sleep in
the passenger seat. If the engine
is left running, the accelerator
pedal may be depressed or selec-
tor lever may be operated unin-
tentionally, possib ly leading to an
accident. Also, if the engine is run
at a high speed for a long time,
the exhaust system and engine
may become extremely hot, pos-
sibly causing to a fire.
WA R N I N G
Be careful when parking, as to not
park the vehicle near flammable
materials.
Do not park the vehicle near flam-
mable materials, such as dry
grass, leaves, paper, oil, etc. If
these kinds of material touch a
part of the exhaust system, it may
cause a fire.

37
Supra Owner's Manual
3
3
CONTROLS
CONTROLS
.3-1. CONTROLSCockpit ........................... 38
Operating state of the vehi- cle................................. 42
Toyota Supra Command ..................................... 45
Voice activation system.. 57
General settings ............. 60
Opening and closing ...... 73
Seats, mirrors, and steering wheel ............................ 94
Transporting children safely .................................. 107
Driving ......................... 113
Displays ...................... 130
Lights .......................... 150
Safety .......................... 157
Driving stabilit y control sys-
tems .......................... 192
Driver assistance systems .................................. 197
Driving comfort ............ 224
Climate control ............ 225
Interior equipment ....... 233
Storage compartments .................................. 239
Cargo area .................. 241

383-1. CONTROLS
Supra Owner's Manual
3-1.CONTROLS
This chapter describes all standard, country-specific and optional
features offered with the series . It also describes features and func-
tions that are not necessarily available in your vehicle, e.g., due to
the selected options or country versions. This also applies to
safety-related functions and systems. When using these functions
and systems, the applicable laws and regulations must be observ ed.
1 Central locking system
Unlock P.81
Lock P.81
2 Power windows P.93
3 Exterior mirror operation
P.103
4 Lights Lights off P.150
Daytime running lights P.153
Parking lights P.152
Automatic headlight
control P.151
Automatic high-beam P.153
Cockpit
Vehicle features and options
In the vicinity of the steering wheel

393-1. CONTROLS
Supra Owner's Manual
3
CONTROLS
Low beams P.152
Instrument lighting
P.155
Right roadside parking
light P.152
Left roadside parking
light P.152
5 Steering column stalk, left
Turn signal P.118
High beams, headlight
flasher P.119
Automatic high-beam
P.153
Onboard Computer
P.130
6 Shift paddle P.126
7 Steering wheel buttons, left
Cruise control on/off
P.197
Adaptive Cruise Control
on/off P.201
Cruise control: store
speed P.197
Continuing cruise con-
trol/Pausing cruise contro
lP.197
Adaptive Cruise Con- trol: increase distance P.197
Adaptive Cruise Con-
trol: reduce distance P.197
Cruise control rocker switch
P. 1 9 7
8 Instrument cluster P.130
9 Steering wheel buttons, right
Selection lists P.142
Volume, see Owner's
Manual for Navigation, Enter-
tainment and Communication
Voice activation system
P. 5 7
Telephone, see
Owner's Manual for Naviga-
tion, Entertainment and Com-
munication
Thumbwheel for selection
lists P.142
10Shift paddle P.126
11Steering column stalk, right
Wiper P.119
Rain sensor P.120
Clean the windshield
P. 1 2 1
12Adjust the steering wheel P. 1 0 5
13 Horn, entire surface

403-1. CONTROLS
Supra Owner's Manual
14 Unlock hood P.286 15 Unlocking the trunk lid
P. 7 6
1 Control Display P.48
2 Hazard warning sys-
tem P.307
3 Ventilation P.230
4 Glove compartment P.240
5 Radio/multimedia, see
Owner's Manual for Naviga-
tion, Entertainment, and
Communication
6 Automatic climate control
P.225
7 Controller with buttons P.48
8 Sport mode button
P.128 SPORT driving mode
Toyota Supra Safety
P. 1 7 0
Auto Start/Stop func-
tion P.113
Parking Sensors P.211
Rearview camera P.217
Crossing traffic warning
P. 2 2 1
VSC Vehicle Stability
Control System P.193
9 Parking brake P.116
In the vicinity of the center console
1
4
23
5
6
7
89
10
11
