TOYOTA SUPRA 2020 Owners Manual (in English)

2414-1. CONTROLS
Supra Owner's Manual
4
CONTROLS
Pull off the cover. Open the cover.
Follow the information regarding
the connection of mobile
devices to the USB interface in
the section on USB connec-
tions, refer to page 71.
Safety information
WA R N I N G
Devices and cables in the unfold-
ing area of the airbags, such as
portable navigation devices, can
hinder the unfolding of the airbag
or be thrown around in the car's
interior during unfolding. There is
a risk of injury
. Make sure that
devices and cables are not in the
airbag's area of unfolding.
NOTICE
Battery chargers for the vehicle
battery can work with high volt-
ages and currents, which means
that the 12 volt on-board network
can be overloaded or damaged.
There is a risk of damage to prop-
erty. Only connect battery char-
gers for the vehi cle battery to the
starting aid terminals in the
engine compartment.
NOTICE
If metal objects fall into the
socket, they can cause a short cir-
cuit. There is a risk of damage to
property. Replace the socket
cover again after using the
socket.
Center console
Cargo area
Wireless charger
USB interface
General information

2424-1. CONTROLS
Supra Owner's Manual
The USB interface port is
located on the center console.
Properties:
USB port Type A.
 For charging external
devices.
 Charging current:
max. 1.5 A (vehicles without wire-
less charger)
max. 2.1 A (vehicles with wireless
charger)
For data transfer. This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
The following storage compart-
ments are available in the car's
interior:

Glove compartment, refer to
page 243.
 Compartments in the doors,
refer to page 243.
 Net in front passenger floor
area.
In the center console
Storage compart-
ments
Vehicle features and
options
Storage compartments
General information

2434-1. CONTROLS
Supra Owner's Manual
4
CONTROLS
Pull the handle.
The light in the glove compart-
ment switches on.
Fold cover closed.
The glove compartment can be
locked with an integrated key.
This prevents access to the
glove compartment.
After the glove compartment is
locked, the remote control can
be handed over without the inte-
grated key, for instance when
the vehicle is parked by valet
parking.
There are storage compart-
ments in the doors.
Safety information
WA R N I N G
Loose objects or devices with a
cable connection to the vehicle,
for instance mobile phones, can
be thrown into the car's interior
while driving, for
instance in the
event of an accident or during
braking and evasive maneuvers.
There is a risk of injury. Secure
loose objects or devices with a
cable connection to the vehicle in
the car's interior.
NOTICE
Anti-slip pads such as anti-slip
mats can damage the dashboard.
There is a risk of damage to prop-
erty. Do not use anti-slip pads.
Glove compartment
Safety information
WA R N I N G
Folded open, the glove compart-
ment protrudes in the car's inte-
rior. Objects in the glove
compartment can be thrown into
the car's interior while driving, for
instance in the event of an acci-
dent or during braking and eva-
sive maneuvers. There is a risk of
injury. Always close the glove
compartment immediately after
using it.
Opening
Closing
Locking
Compartments in the
doors
General information

2444-1. CONTROLS
Supra Owner's Manual
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
Safety information
WA R N I N G
Breakable objects, such as glass
bottles or glasses, can break in
the event of an accident or a brak-
ing or evasive maneuver. Broken
glass can be scattered in the car's
interior. There is a risk of injury or
risk of damage to property. Do not
use any breakable objects while
driving. Only stow breakable
objects in closed storage com-
partments.
Cup holders
Safety information
WA R N I N G
Unsuitable containers in the cup
holder may damage the cup hold-
ers or thrown into the car's inte-
rior, such as in the event of an
accident, braking or evasive
maneuver. Spilled liquids can dis-
tract from the traffic conditions
and lead to an accident. Hot
drinks can damage the cup holder
or lead to scalding. There is a risk
of injury or risk of damage to prop-
erty. Do not force objects into the
cup holder. Us
e lightweight,
unbreakable, and sealable con-
tainers. Do not transport hot bev-
erages.
Cargo area
Vehicle features and
options
Loading
Safety information
WA R N I N G
High gross weigh t can overheat
the tires, damage them internally
and cause a sudden drop in tire
inflation pressure. Driving charac-
teristics may be negatively
impacted, reducing lane stability,
lengthening the braking distances
and changing the steering
response. There is a risk of an
accident. Pay attention to the per-
mitted load capacity of the tires
and never exceed the permitted
gross weight.

2454-1. CONTROLS
Supra Owner's Manual
4
CONTROLS
1 Locate the statement “The
combined weight of occu-
pants and cargo should
never exceed XXX kg or XXX
lbs” on your vehicle’s plac-
ard.
2 Determine the combined
weight of the driver and pas-
sengers that will be riding in
your vehicle. 3
Subtract the combined
weight of the driver and pas-
sengers from XXX kg or XXX
lbs.
4 The resulting figure equals
the available amount of cargo
and luggage load capacity.
For example, if the “XXX”
amount equals 1,400 lbs and
there will be five 150 lbs pas-
sengers in your vehicle, the
amount of available cargo
and luggage load capacity is
650 lbs (1,400–750 (5 x 150)
= 650 lbs).
5 Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo
and luggage load capacity
calculated in Step 4.
6 If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your
vehicle. Consult this manual
to determine how this
reduces the available cargo
and luggage load capacity of
your vehicle.
WA R N I N G
Loose objects or devices with a
cable connection to the vehicle,
for instance mobile phones, can
be thrown into the car's interior
while driving, for instance in the
event of an accident or during
braking and evasive maneuvers.
There is a risk of injury. Secure
loose objects or devices with a
cable connection to the vehicle in
the car's interior.
WA R N I N G
Improperly stowed objects can
shift and be thrown into the car's
interior, for instance in the event
of an accident or during braking
and evasive maneuvers. Vehicle
occupants can be hit and injured.
There is a risk of injury. Stow and
secure objects a nd cargo prop-
erly.
NOTICE
Fluids in the cargo area can
cause damage. There is a risk of
damage to propert y. Make sure
that no fluids leak in the cargo
area.
Steps for Determining Cor-
rect Load Limit

2464-1. CONTROLS
Supra Owner's Manual
The maximum load is the sum of
the weight of the occupants and
the cargo.
The greater the weight of the
occupants, the less cargo that
can be transported.
Cover sharp edges and cor-
ners on the cargo.
 Heavy cargo: stow as far for-
ward and as low as possible,
ideally directly behind the
cargo partition.
 Smaller and lighter cargo:
secure with ratchet straps or
with a cargo net or draw
straps.
 Larger and heavy cargo:
secure with cargo straps. Attach load securing aids, such
as lashing straps, tensioning
straps, draw straps or cargo
nets, to the lashing eyes in the
cargo area.
There are four lashing eyes in
the cargo area for securing
cargo.
A multi-function hook is located
on the left and right side in the
cargo area.
Load
Stowing and securing
cargo
Lashing eyes in the cargo
area
General information
Lashing eyes
Multi-function hook
General information

2474-1. CONTROLS
Supra Owner's Manual
4
CONTROLS
A tensioning strap is available
on the right side trim for fasten-
ing small objects.
Small objects can be stowed in
the net on the left side. To trans-
port larger objects, slide the net
down. Grab the top of the net as
close as possible to the edge
next to the holder. At first, a
resistance must be overcome. A storage compartment is avail-
able on the right side of the
cargo area.
Unlock the cover of the right
side panel, arrow
1, and fold up,
arrow 2.
Safety information
WA R N I N G
Improper use of th
e multi-function
hooks can lead to a risk of objects
flying about during braking and
evasive maneuvers, for example.
There is a risk of injury and risk of
damage to property. Only hang
lightweight objects, such as shop-
ping bags, from the multi-function
hooks. Only transport heavy lug-
gage in the carg o area if it has
been appropriately secured.
Tensioning strap
Net
Storage compartment on
the right side
General information
Opening

2484-1. CONTROLS
Supra Owner's Manual

249
Supra Owner's Manual
5
5
DRIVING TIPS
DRIVING TIPS
.5-1. DRIVING TIPSThings to remember when driving........................ 250
Saving fuel .................. 255

2505-1. DRIVING TIPS
Supra Owner's Manual
5-1.DRIVING TIPS
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
Moving parts need to begin
working together smoothly.
The following instructions will
help you to achieve a long vehi-
cle life and good efficiency.
During break-in, do not use the
Launch Control, refer to page
130.Do not exceed the maximum
engine and road speed:

For gasoline engine 4,500
rpm and 100 mph/160 km/h.
Avoid full load or kickdown
under all circumstances.
The engine and vehicle speed
can gradually be increased.
Tire traction is not optimal due to
manufacturing circumstances
when tires are brand-new; they
achieve their full traction poten-
tial after a break-in time.
Drive conservatively for the first
200 miles/300 km.
Things to remember
when driving
Vehicle features and
options
Breaking-in period
General information
Safety information
WA R N I N G
Due to new parts and compo-
nents, safety and driver assis-
tance systems ca n react with a
delay. There is a risk of an acci-
dent. After installing new parts or
with a new vehicle, drive conser-
vatively and intervene early if nec-
essary. Observe the break-in
procedures of the respective parts
and components.
Engine, transmission, and
axle drive
Up to 1,200 miles/2,000 km
From 1,200 miles/2,000 km
Tires
