2666-1. MOBILITY
Supra Owner's Manual
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
The tire characteristics and tire
inflation pressure influence the
following:
• The service life of the tires.
• Road safety.
• Driving comfort.
• Fuel consumption.The tire inflation pressure table,
refer to page 268, contains all
tire inflation pressure specifica-
tions for the specified tire sizes
at the ambient temperature. The
tire inflation pressure values
apply to tire sizes approved by
the manufacturer of the vehicle
for the vehicle type.
To identify the correct tire infla-
tion pressure, please note the
following:
If the tire's speed code cannot
be found, then the tire inflation
pressure for the corresponding
tire size applies.
• Tire sizes of your vehicle.
• Maximum permitted driving
speed.
Wheels and tires
Vehicle features and
options
Tire inflation pressure
General information
Safety information
WARNING
A tire with too little or no tire infla-
tion pressure may heat up signifi-
cantly and sustain damage. This
will have a negative impact on
aspects of handling, such as
steering and braking response.
There is a risk of an accident.
Regularly check the tire inflation
pressure, and correct it as
needed, for instance twice a
month and before a long trip.
Tire inflation pressure
specifications
In the tire inflation pressure
table

2756-1. MOBILITY
Supra Owner's Manual
6
MOBILITY
For each tire size, the manufac-
turer of the vehicle recommends
certain tire brands. The tire
brands can be identified by a
star on the tire sidewall.
Tire traction is not optimal due to
manufacturing circumstances
when tires are brand-new; they
achieve their full traction poten-
tial after a break-in time.
Drive conservatively for the first
200 miles/300 km.
The manufacturer of your vehi-
cle does not recommend the
use of retreaded tires.
Safety information
WARNING
Wheels and tires which are not
suitable for your
vehicle can dam-
age parts of the vehicle, for
instance due to contact with the
body due to tolerances despite
the same official size rating.
There is a risk of an accident. The
manufacturer of your vehicle
strongly suggests that you use
wheels and tires that have been
recommended by the vehicle
manufacturer for your vehicle
type.
WARNING
Mounted steel wheels can cause
technical problem s, for instance
independent loosening of the lug
bolts, damage to t he brake discs.
There is a risk of an accident. Do
not mount steel wheels.
WARNING
Incorrect wheel/tire combinations
will have a negative impact on the
vehicle's handling and on the
function of a variety of systems,
such as the Anti-lock Brake Sys-
tem or Vehicle S tability Control
System. There is a risk of an acci-
dent. To maintain good handling
and vehicle response, use only
tires with a single tread configura-
tion from a single manufacturer.
The manufacturer of the vehicle
recommends that you use wheels
and tires that have been recom-
mended by the vehicle manufac-
turer for your vehicle type.
Following tire damage, have the
original wheel/tire combination
remounted on the vehicle as soon
as possible.
Recommended tire brands
New tires
Retreaded tires
WARNING
Retreaded tires can have different
tire casing structures. With
advanced age the service life can
be limited. There is a risk of an
accident. The manufacturer of
your vehicle does not recommend
the use of retreaded tires.

2846-1. MOBILITY
Supra Owner's Manual
2Selecting tires:
• "Summer tires"
• "Winter tires/all-season tires"
3 "Current:"
4 Select the tire type that is
mounted on the rear axle:
• Tire size, e.g., 245/45 R18 96 Y.
• For tires with special approval: "Other tire"
5 Select the maximum road
speed that will be used with
the tires.
6 "Confirm settings"
The measurement of the current
tire inflation pressure is started.
The measurement progress is
displayed.
The system status can be dis-
played on the Control Display,
e.g., whether or not the system
is active.
Via Toyota Supra Command:
1 "My vehicle"
2 "Vehicle status"
3 "Tire Pressure Monitor"
The current status is displayed.
The current tire inflation pres- sure is displayed for each tire.
The current tire inflation pres-
sures may change during driv-
ing operation or depending on
the external temperature.
Depending on the model, the
current tire temperatures are
displayed.
The current tire temperatures
may change while driving or due
to the external temperature.
Tire and system status are indi-
cated by the color of the wheels
and a SMS text message on the
Control Display.
Any existing messages are not
deleted if the displayed target
pressure is not reached after the
tire inflation pressure is cor-
rected.
• The system is active and
bases warnings on the dis-
played target pressures.
• For tires with special approval: the system is active
and bases warnings on the
tire inflation pressures stored
during the last reset.
Status display
Current status
Current tire inflation pres-
sure
Current tire temperature
Tire conditions
General information
All wheels green

346Alphabetical Index
Supra Owner's Manual
Alphabetical Index
A
A/C button, see Air conditioning ............................................... 230
ABS, Antilock Brake System . 195
ACC, see Dynamic radar cruise control with fu ll-speed range
............................................... 204
Acceleration Assistant, see Launch Control..................... 130
Accessories and parts ............... 6
Activated charcoal filter ........ 233
Active Guard, see Toyota Supra Safety .................................... 172
Adaptive brake assist ............ 196
Adaptive variable suspension ............................................... 227
Additional coolant tank cooling, Capacity ................................ 333
Additives, engine oil types .... 299
Air circulation, see Recircu- lated-air mode....................... 231
Air conditioning ...................... 230
Air distribution, manual ......... 232
Air flow, automa tic air condition-
ing .......................................... 232
Air outlets, see Ventilation .... 233
Air pressure, tires .................. 266
Airbags .................................... 160
Airbags, indicator and warning light........................................ 162
Alarm system ............................ 92
Alarm, unintentional................. 94
All-season tires, see Winter tires ............................................... 276
Antilock Brake System, ABS . 195
Anti-slip control, see VSC ..... 196
Anti-theft protection, locking .. 80
Anti-theft protection, see Lug bolt lock ................................ 291
Apple CarPlay, connection to the vehicle ..................................... 72 Approved axle load ................333
Approved total weight ............333
Assistance when driving off, see
Hill-start assist control.........196
Assistance with breakdown ..316
AUTO program, automatic air conditioning ........ ..................231
Auto Start/Stop function ........ 116
Automatic air conditioning ....228
Automatic cruise control with Stop & Go ..............................204
Automatic Curb Monitor, exte- rior mirror ..............................106
Automatic deactivation, front-seat passenger airbags...............................................170
Automatic headlight control ..153
Automatic high-beam .............156
Automatic locking ....................91
Automatic transmission.........125
Automatic transmission, Fluid ...............................................333
Automatic transmission, see Automatic transm ission.......125
Automatic unlocking ................91
Automatic vehicle wash .........323
Autonomous Emergency Brak- ing ..........................................193
Axle loads, weights ................333
B
Backrest curvature, see Lumbar support ................ ..................100
Backrest tilt ...............................99
Backrest, seats .........................97
Backrest, width .......................100
Bar for tow-starting/towing....321
Battery, changing, remote con- trol of the vehicle ....................82
Battery, disposing of ..............309
Battery, vehicle .. .....................307

349Alphabetical Index
Supra Owner's Manual
Defrosting the windows ......... 232
Deleting personal data ............. 63
Departure time, parked-car venti- lation...................................... 235
Device list, displaying .............. 74
Devices, managing ................... 74
Diagnosis connectio n ............ 304
Differential oil ......................... 334
Dimensions ............................. 332
Dimmable exterior mirrors .... 106
Dimmable interior mirror ....... 107
Direct dial butto ns, see Program-
mable memory buttons.......... 54
Direction indicator, see Turn sig- nals ........................................ 121
Display in the windshield, see Head-up Display ................... 150
Display lighting , see Instrument
lighting .................................. 158
Displays .................................. 133
Displays and symbols ............... 4
Displays, screens ................... 329
Disposal, coolant ................... 301
Disposal, vehicle battery ....... 309
Distance control , see Parking
Sensors ................................. 214
Driver assistance, see Toyota Supra Safety ......................... 172
Driver attention control.......... 193
Driver Fatigue Detector.......... 193
Driver profiles ........................... 64
Drive-ready state, idle state, and standby state .......................... 42
Driving Assistant, see Toyota Supra Safety ......................... 172
Driving comfort ...................... 227
Driving instructions, break-in254
Driving mode, see Sport mode switch .................................... 131
Driving notes, general ........... 255
Driving on racetracks ............ 259 Driving stability
control systems
...............................................195
Driving tips ..............................255
Drying air, see Air conditioning ...............................................230
Dynamic radar cruise control with full-speed range............204
E
Electronic oil measurement...297
Emergency brake function when parking, Parking Sensors with
emergency braking function217
Emergency service, see Break- down assistance ...................317
Emergency unlocking, fuel filler flap .........................................265
Emergency unlocking, transmis- sion lock ................................129
Energy savings, see Gear shift indicator ................................142
Engine compartment ..............293
Engine compartment, working in ...............................................293
Engine coolant ........................300
Engine coolant, Capacity .......333
Engine oil ........................297, 333
Engine oil change ...................300
Engine oil filler neck...............298
Engine oil temperature...........140
Engine oil types to add ..........299
Engine oil, adding...................298
Engine start, jump-starting ....319
Engine temperature ................140
Engine, Auto Start/Stop function ............................................... 116
Entry comparison, navigation .44
Equipment, interior.................236
Error displays, see Vehicle mes- sages .....................................134
Exchanging wheels/tires........274
Exhaust gas system ...............255

353Alphabetical Index
Supra Owner's Manual
Manual operation, fuel filler flap ............................................... 265
Matte finish ............................. 326
Maximum cooling ................... 230
Maximum speed display, see Speed Limit Info ................... 143
Maximum speed of winter tires ............................................... 276
Measurement, uni ts of ............. 60
Memory function .................... 107
Menu, instrument cluster, see Selection lists ....................... 145
Menus, operating, see Toyota Supra Command .................... 43
Messages .................................. 61
Messages, see Vehicle mes- sages ..................................... 134
Microfilter ................................ 233
Minimum tread depth, tires ... 273
Mirror, see Memory function . 107
Mobile communication devices in the vehicle ........................ 256
Mobile devices, m anaging ....... 74
Mobility System ...................... 277
Modifications, t echnical, see For
Your Own Safety ....................... 5
Monitor, see Control Display ... 46
Mounting of child restraint sys- tems ....................................... 112
Multi-function hook ................ 250
Multifunction steering wheel, buttons .................................... 36
N
Neck restraints, front, see Head restraints ............................... 104
Net, cargo area ....................... 250
Neutral cleaner, see Light-alloy wheels ................................... 327
New wheels and tires ............. 274
NORMAL, see Sport mode switch ............................................... 131 Nylon rope for tow-starting/tow-
ing ..........................................321
O
OBD Onboard Diagnosis .......304
Obstacle marking, rearview cam-era ..........................................222
Octane rating, see Recom- mended fuel grade................296
Oil .............................................297
Oil change ...............................300
Oil change interval, see Service requirements .........................141
Oil filler neck ...........................298
Oil types to add, engine .........299
Oil, adding ...............................298
Onboard Diagnosis OBD .......304
Onboard literature, printed ......76
Onboard vehicle tool kit.........306
On-call service, see Breakdown assistance .............................317
Opening and closing ................78
Operating concept, Toyota Supra Command ................................43
Operating with the Controller ..49
Operation via touchscreen ......51
Overheating of engine, see Cool- ant temperature ....................140
Overwintering, see Long-term vehicle storage .....................329
Owner's Manual, printed ..........76
P
Paint, vehicle...... .....................325
Panic alarm, see Panic mode ..93
Panic mode ...............................93
Parked-car ventilation ............234
Parking aid, see Parking Sensors ...............................................214
Parking brake .......................... 119
Parking lights ..........................154
