− DIAGNOSTICSENGINE (5VZ−FE)
DI−257
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
TOYOTA hand−held tester:
1 Connect TOYOTA hand−held tester and check operation of fuel pump.
PREPARATION:
(a) Connect the TOYOTA hand−held tester to the DLC3.
(b) Turn the ignition switch ON and push the TOYOTA hand−
held tester main switch ON.
(c) Use ”ACTIVE TEST” mode to operate the fuel pump.
CHECK:
Check for fuel pressure in the fuel inlet hose when it is pinched
off.
OK:
There is pressure in the fuel inlet hose.
HINT:
At this time, you will hear a fuel flowing noise.
OK Go to step 7.
NG
2 Check for ECM power source circuit (See page DI−244).
NG Repair or replace.
OK

Downloaded from www.Manualslib.com manuals search engine A00685
2 (+)
1 (+)
4 (−)
1 2
34
6
BE6653
P24225
P24335A00128
ON
For M/T
For A/TFC (+)
FC (+)
DI−258
− DIAGNOSTICSENGINE (5VZ−FE)
1996 TOYOTA T100 (RM449U)
3 Check circuit opening relay.
PREPARATION:
Remove the circuit opening relay (See page SF−46).
CHECK:
(a) Apply battery voltage between terminals 2 and 4.
(b) Measure voltage between terminals 1 and 4.
OK:
Voltage: Same as battery
NG Replace circuit opening relay.
OK
4 Check voltage between terminal FC of ECM connector and body ground.
PREPARATION:
(a) Remove the right cowl side trim (See page SF−61).
(b) Turn the ignition switch ON.
CHECK:
Measure voltage between terminal FC of ECM connector and
body ground.
OK:
Voltage: 9 − 14 V
NG Check for open in harness and connector be-
tween EFI main relay and circuit opening relay,
and ECM (See page IN−26).
OK

Downloaded from www.Manualslib.com manuals search engine A00686
1 2
34
6
3 (+)
6 (−)1
2
− DIAGNOSTICSENGINE (5VZ−FE)
DI−259
1996 TOYOTA T100 (RM449U)
5 Check fuel pump (See page SF−5).
NG Repair or replace fuel pump.
OK
6 Check for open in harness and connector between circuit opening relay and fuel
pump, fuel pump and body ground (See page IN−26).
NG Repair or replace harness or connector.
OK
Check and replace ECM (See page IN−26).
7 Check circuit opening relay.
PREPARATION:
Remove the circuit opening relay (See page SF−46).
CHECK:
(a) Apply battery voltage between terminals 3 and 6.
(b) Check continuity between terminal 1 and 2.
OK:
Continuity
NG Replace circuit opening relay.
OK

Downloaded from www.Manualslib.com manuals search engine A00687
START3
BE6653P24337P24336
A00773A00789
ON
For M/T
For A/TFC (+)
FC (+)
Fuel Inlet Hose
DI−260
− DIAGNOSTICSENGINE (5VZ−FE)
1996 TOYOTA T100 (RM449U)
8 Check voltage between terminal 3 of circuit opening relay connector and body
ground.
CHECK:
Measure voltage between terminal 3 of circuit opening relay
connector and body ground when engine is cranked.
OK:
Voltage: 9 − 14 V
NG Check for starter signal circuit (See page
DI−248).
OK
Check for open in harness and connector be-
tween terminal 6 of circuit opening relay con-
nector and body ground (See page IN−26).
OBD II scan tool (excluding TOYOTA hand−held tester):
1 Check operation of fuel pump.
PREPARATION:
(a) Remove the right cowl side trim (See page SF−61).
(b) Turn the ignition switch ON.
CHECK:
(a) Connect between terminal FC of ECM connector and
body ground.
(b) Check for fuel pressure in the inlet hose when it is pinched
off.
OK:
There is pressure in the fuel inlet hose.
HINT:
At this time, you will hear a fuel flowing noise.
OK Go to step 7.
NG

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSENGINE (5VZ−FE)
DI−261
1996 TOYOTA T100 (RM449U)
2 Check for ECM power source circuit (See page DI−251).
NG Repair or replace.
OK
3 Check circuit opening relay (See page DI−255, step 3).
NG Replace circuit opening relay.
OK
4 Check voltage between terminal FC of ECM connector and body ground (See
page DI−255, step 4).
NG Check for open in harness and connector be-
tween EFI main relay and circuit opening relay
and ECM (See page IN−26).
OK
5 Check fuel pump (See page SF−5).
NG Repair or replace fuel pump.
OK

Downloaded from www.Manualslib.com manuals search engine DI−262
− DIAGNOSTICSENGINE (5VZ−FE)
1996 TOYOTA T100 (RM449U)
6 Check for open in harness and connector between circuit opening relay and fuel
pump, fuel pump and body ground (See page IN−26).
NG Repair or replace harness or connector.
OK
Check and replace ECM (See page IN−26).
7 Check circuit opening relay (See page DI−255, step 7).
NG Replace circuit opening relay.
OK
8 Check voltage between terminal 3 of circuit opening relay connector and body
ground (See page DI−255, step 8).
NG Check for starter signal circuit (See page
DI−248).
OK
Check for open in harness and connector be-
tween terminal 6 of circuit opening relay con-
nector and body ground (See page IN−26).

Downloaded from www.Manualslib.com manuals search engine DI0VD−02
Vehicle Brought to Workshop
Customer Problem Analysis
Check DTC and Freezes Frame Data (Precheck)
Record or Print DTC and Freezed Frame Data P.
DI−265
Clear DTC and Freezed Frame Data P. DI−265
Visual Inspection
Setting the Check Mode Diagnosis P.
DI−265
1
Items insideare titles of pages in this manual, with the
page number indicated in the bottom portion. See the indicated
pages for detailed explanations.
P.
DI−264
Connect an OBD II scan tool or TOYOTA hand−held tester to DLC3
If the display shows ”UNABLE TO CONNECT TO VEHICLE” when you have connected the
scan tool/TOYOTA hand−held tester, inspect DLC3 P.
DI−265
2
3
4
5
6
symptom does not occur
Problem Symptom Confirmation8
7Symptom Simulation
P.
IN−16symptom occur
DTC Check
P. DI−265OK Code
11Preliminary Check
P.
DI−265
DTC Chart
P.
DI−276
Mechanical System Tests
P.
DI−265
Manual Shifting Test
P.
DI−265 OK
OK
Chapter 1
(Electronic)Chapter 2
(On−Vehicle)OKChapter 3
(Off−Vehicle)OK Problem Symptoms table
P. DI−282
Circuit
Inspection O/D Cancel Signal Check
 Stop Light Signal Check
NG
Parts Inspection
NG
NGNG
Identification of ProblemRepairConfirmation TestEnd
NG
NG
12
NG13
14
1516
17 9
10
P. DI−282
P. DI−286 to DI−316
18
P. DI−282P. DI−282
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−263
520 Author: Date:
1996 TOYOTA T100 (RM449U)
AUTOMATIC TRANSMISSION
HOW TO PROCEED WITH TROUBLESHOOTING
Troubleshoot in accordance with the procedure on the following page.

Downloaded from www.Manualslib.com manuals search engine DI0VE−01
Transmission Control
