TOYOTA TUNDRA 2001 Workshop Manual

'01 TUNDRA_U (L/O 0008)
442001 TUNDRA (OM 34416U)

Do not modify or remove any wir-
ing. Do not modify, remove, strike
or open any components such as
the steering wheel pad, steering
wheel, column cover, front passen-
ger airbag cover, front passenger
airbag or airbag sensor assembly.
Doing any of these may cause sud-
den SRS airbag inflation or disable
the system, which could result in
death or serious injury.
Failure to follow these instructions
can result in death or serious injury.NOTICE
Do not perform any of the following changes without consulting yourToyota dealer. Such changes caninterfere with proper operation of the
SRS airbag system in some cases.
Installation of electronic devicessuch as a mobile two±way radio,
cassette tape player or compactdisc player
Modification of the suspension sys-tem
Modification of the front end struc-
ture
Attachment of a grille guard (bullbar, kangaroo bar, etc.), snowplow,winches or any other equipment tothe front end
Repairs made on or near the frontfenders, front end structure, con-
sole, steering column, steeringwheel or dashboard near the frontpassenger airbag
This SRS airbag system has a service
reminder indicator to inform the driver of
operating problems. If either of the follow-
ing conditions occurs, this indicates a
malfunction of the airbags. Contact your
Toyota dealer as soon as possible to
service the vehicle.

The light does not come on when the
ignition key is turned to the ªACCº or
ªONº position, or the light remains on.

The light comes on or flashes while
driving.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
452001 TUNDRA (OM 34416U)
In the following cases, contact your Toyota
dealer as soon as possible:

The SRS airbags have been inflated.

The front part of the vehicle (shaded
in the illustration) was involved in an
accident that was not severe enough to
cause the SRS airbags to inflate.

The pad section of the steering wheel
or front passenger airbag cover
(shaded in the illustration) is scratched,
cracked, or otherwise damaged.
NOTICE
Do not disconnect the battery cables
before contacting your Toyota dealer.
Indicator light
This on±off switch is designed to dis-
able the passenger airbag in order to
allow usage, if necessary, of a member
of a passenger risk group identified in
TABLE 1 is occupying the right front
passenger seating position. (For details,
see ªSRS driver and front passenger
airbagsº in this section.)
Operate on±off switch as follows:
Insert key into the keyhole and turn it.
To turn passenger airbag on: Turn the key
clockwise to the ªONº position.
To turn passenger airbag off: Turn the key
counterclockwise to the ªOFFº position.
The indicator comes on when the passen-
ger airbag system is off.
CAUTION

Make sure that the indicator light is
off.

Do not turn off the passenger air-
bag manual on±off switch except
when a member of a passenger risk
group identified in TABLE 1 (page
38) is occupying the right front pas-
senger seating position.

When the passenger airbag manual
on±off switch is turned off, the pas-
senger airbag will not inflate in a
collision and turning off the pas-
senger airbag can reduce the occu-
pant protection which your vehicle
safety systems can provide to you
in certain accidents and increase
the likelihood of serious personal
injuries.
For details, see ªSRS driver and front
passenger airbagsº in this section.
Passenger airbag manual
on±off switch
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
462001 TUNDRA (OM 34416U)
Toyota strongly urges the use of child
restraint systems for children small
enough to use them.
The laws of all fifty states in the U.S.A.
and Canada now require the use of a
child restraint system.
Your vehicle conforms to SAEJ1819.
If a child is too large for a child restraint
system, the child s hould sit in the seat
and must be restrained using the vehicle's
seat belt. See ªSeat beltsº for details.
CAUTION

For effective protection in automo-
bile accidents and sudden stops,
child must be properly restrained
using a seat belt or child restraint
system depending on the age and
size of the child. Holding a child in
your arms is not a substitute for a
child restraint system. In an acci-
dent, the child can be crushed
against the windshield, or between
you and the vehicle's interior.

STANDARD CAB MODELSÐ
Toyota strongly urges use of a
proper child restraint system which
conforms to the size of the child.
ACCESS CAB MODELSÐ
Toyota strongly urges use of a
proper child restraint system which
conforms to the size of the child,
and is put on the rear seat. Accord-
ing to accident statistics, the child
is safer when properly restrained in
the rear seat than in the front seat.

Never put infant or child age 1 to
12 in a passenger risk group on the
right front seat with the passenger
airbag manual on±off switch in the
ªONº position. In the event of an
accident, the force of the rapid
inflation of the passenger airbag
can cause death or serious injury
to the child.
If you must put infant or child age
1 to 12 in a passenger risk group
on the right front seat, make sure
the passenger airbag manual on±off
switch is in the ªOFFº position and
that the indicator light is on. (For
details, see ªSRS driver and front
passenger airbagsº in this section.)

Make sure that you have complied
with all installation instructions pro-
vided by the child restraint
manufacturer and that the system is
properly secured.
Child restraintÐ
ÐChild restraint precautions
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
472001 TUNDRA (OM 34416U)
ÐChild restraint system
A child restraint system for a small
child or baby must itself be properly
restrained on the seat with either the
lap belt or the lap portion of the lap/
shoulder belt. You must carefully con-
sult the manufacturer 's instructions
which accompany the child restraint
system.
To provide proper restraint, use a child
restraint system following the manufactur-
er 's instructions about the appropriate age
and size of the child for the child restraint
system.
Install the child restraint system correctly
following the instructions provided by its
manufacturer. General directions are also
provided under the following illustrations.
The child restraint system should be
installed on the rear seat if your vehicle
is equipped with rear seats. According to
accident statistics, the child is safer when
properly restrained in the rear seat than
in the front seat.CAUTION

Never put infant or child age 1 to
12 in a passenger risk group on the
right front seat with the passenger
airbag manual on±off switch in the
ªONº position. In the event of an
accident, the force of the rapid
inflation of the passenger airbag
can cause death or serious injury
to the child.
If you must put infant or child age
1 to 12 in a passenger risk group
on the right front seat, make sure
the passenger airbag manual on±off
switch is in the ªOFFº position and
that the indicator light is on. (For
details, see ªSRS driver and front
passenger airbagsº in this section.)

After installing the child restraint
system, make sure it is secured in
place according to the manufactur-
er's instructions. If it is not re-
strained securely, it may cause
death or serious injury to the child
in the event of a sudden stop or
accident.
When not using the child restraint system,
keep it secured with the seat belt or place
it somewhere other than the passenger
compartment. This will prevent it from in-
juring passengers in the event of a sud-
den stop or accident.
Your vehicle has anchors for securing the
top strap of a child restraint system.
For instructions on how to use the anchor
bracket, see ªÐUsing a top strapº in this
section.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
482001 TUNDRA (OM 34416U)
Child restraint systems are classified into
the following 3 types depending on the
child's age and size.
(A) Infant seat
(B) Convertible seat
(C) Booster seat
Install the child restraint system following
the instructions provided by its manufac-
turer.
(A) Infant seat
(B) Convertible seat
(C) Booster seat
ÐTypes of child restraint
system
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
492001 TUNDRA (OM 34416U)
(A) INFANT SEAT INSTALLATION
An infant seat is used in rear±facing
position only. With the child restraint system installed,
check that your driving position is satis-
factory and that the child restraint system
does not interfere with your driving.
If your driving position is not satisfactory,
or the child restraint system interferes
with your driving, install it at another posi-
tion.
CAUTION
Ignoring the above instructions may
result in a serious injury in case of
an accident.
CAUTION
Never put a rear±facing child restraint
system on the front seat with the
passenger airbag manual on±off
switch in the ªONº position. In the
event of an accident, the force of the
rapid inflation of the front passenger
airbag can cause death or serious in-
jury to the child.
ÐInstallation with 2±point
type seat belt
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
502001 TUNDRA (OM 34416U)
When you put a rear±facing child re-
straint system on the front seat, turn
the passenger airbag manual on±off
switch counterclockwise to the ªOFFº
position. (For details, see ªSRS driver
and front passenger airbagsº in this
section.)
The indicator comes on when the system
is off.
CAUTION
If you must put a rear±facing child
restraint system on the front seat,
make sure the passenger airbag
manual on±off switch is in the ªOFFº
position and that the indicator light is
on.
CAUTION

Do not put a rear±facing child re-
straint system on the rear seat if
the child restraint system interferes
with the front seat lock mechanism
or with your proper driving posi-
tion. This can cause severe injury
to the child and front passenger in
case of sudden braking or a colli-
sion.

If your driving position is not satis-
factory, install the child restraint
system at another position.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
512001 TUNDRA (OM 34416U)
1. Run the center lap belt through or
around the infant seat following the
instructions provided by its manufactur-
er and insert the tab into the buckle
taking care not to twist the lap belt.
CAUTION

After inserting the tab, make sure
the tab and buckle are locked and
that the lap belt is not twisted.

Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and
buckle.

If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
2. While pressing the infant seat firmlyagainst the seat cushion and seatback,
tighten the lap belt by pulling its free
end to hold the infant seat securely.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
522001 TUNDRA (OM 34416U)
CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
3. To remove the infant seat, press the
buckle±release button.(B) CONVERTIBLE SEAT INSTALLATION
A convertible seat is used in forward±
facing or rear±facing position depend-
ing on the child's age and size. When
installing, follow the manufacturer's in-
struction about the applicable child's
age and size as well as directions for
installing the child restraint system.
With the child restraint system installed,
check that your driving position is satis-
factory and that the child restraint system
does not interfere with your driving.
If your driving position is not satisfactory,
or the child restraint system interferes
with your driving, install it at another posi-
tion.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
532001 TUNDRA (OM 34416U)
CAUTION
Ignoring the above instructions may
result in a serious injury in case of
an accident.
CAUTION
Rear±facing child restraint system:
Never put a rear±facing child restraint
system on the front seat with the
passenger airbag manual on±off
switch in the ªONº position. In the
event of an accident, the force of the
rapid inflation of the front passenger
airbag can cause death or serious in-
jury to the child.
When you put a rear±facing child re-
straint system on the front seat, turn
the passenger airbag manual on±off
switch counterclockwise to the ªOFFº
position. (For details, see ªSRS driver
and front passenger airbagsº in this
section.)
The indicator comes on when the system
is off.
ProCarManuals.com
