TOYOTA TUNDRA 2001 Manual Online

'01 TUNDRA_U (L/O 0008)
742001 TUNDRA (OM 34416U)
ÐFolding rear view mirrors
The rear view mirrors can be folded
backward for parking in restricted
areas.
To fold the rear view mirror, push back-
ward.
CAUTION
Do not drive with the mirrors folded
backward. Both the driver and pas-
senger side rear view mirrors must
be extended and properly adjusted
before driving.
Adjust the mirror so that you can just
see the rear of your vehicle in the mir-
ror.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror.
Daylight drivingÐLever at position 1
The reflection in the mirror has greater
clarity at this position.
Night drivingÐLever at position 2
Remember that by reducing glare you also
lose some rear view clarity.
CAUTION
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
personal injuries.
Anti±glare inside rear view
mirror
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
752001 TUNDRA (OM 34416U)
Sun visorsÐ
To block out glare, move the sun visor.
To block out glare from the frontÐSwing
down the sun visor (position 1).
To block out glare from the sideÐSwing
down the sun visor, remove it from the
hook and swing it to the lateral side (posi-
tion 2).
If glare comes from obliquely behind you,
extend the plate at the end of the visor
(to position 3).To block the glare from the front when the
main sun visor is swung to the lateral
side (position 2), swing down the sub vi-
sor.
CAUTION
Do not extend the plate at the end of
the sun visor when the visor is in the
position 1. It can cover the anti±glare
inside rear view mirror and obstruct
the rear view.
ÐVanity mirrors (with light)
To use the vanity mirrors, swing down
the sun visor and open the cover.
The vanity light comes on when you open
the cover.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
762001 TUNDRA (OM 34416U)
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
772001 TUNDRA (OM 34416U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights and Wipers
Headlights and turn signals 78
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Instrument panel light control 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Interior light 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Personal lights 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Ignition switch and step lights 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo lamp 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Windshield wipers and washer 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1± 4
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
782001 TUNDRA (OM 34416U)
Headlights and turn signals
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1ÐParking, tail, license plate and
instrument panel lights
Position 2ÐHeadlights and all of the
above
The lights automatically turn off when the
driver 's door is opened with the ignition
turned off. To turn them on again, turn the
key to the ªONº position or actuate the
headlight switch. If you are going to park
for over one week, make sure the head-
light switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights onfor a long period when the engine isnot running.
Daytime running light system (on some
models)
The headlights turn on at reduced intensi-
ty when the parking brake is released with
the engine started, even with the light
switch in the ªOFFº position. They will not
go off until the ignition switch is turned
off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Twist the knob to the position 2 to turn
the headlights to full intensity for driving
at night.
High±Low beamsÐ For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)ÐPull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to ªOFFº.

ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
792001 TUNDRA (OM 34416U)
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the ªONº position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.
Emergency flashers
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch onlonger than necessary when the en-gine is not running.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
802001 TUNDRA (OM 34416U)
Instrument panel light control
To adjust the brightness of the instru-
ment panel lights, turn the knob.
Front fog lights
To turn on the front fog lights, push
the switch. They will come on when the
headlights are on low beam.
Interior light
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
ªONºÐKeeps the light on all the time.
ªOFFºÐTurns the light off.
ªDOORºÐTurns the light on when any of
the doors are opened. The light goes off
when all of the doors are closed.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
812001 TUNDRA (OM 34416U)
Personal lights
The personal lights operate separately.
To turn on the light, push the lens on your
side. To turn the light off, push the lens
once again.
The personal light switch has the following
positions:
ªOFFºÐTurns the lights off.
ªDOORºÐTurns the lights on when any of
the doors are opened.
Ignition switch and step lights
For easy access to the ignition switch,
the ignition switch light comes on when
the driver's door is opened. The step
light also comes on when the driver's
door is opened.
The ignition switch light remains on for
some time after the driver's door is
closed.
Cargo lamp
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
822001 TUNDRA (OM 34416U)
The cargo lamp is designed to light up the bed of your vehicle. How to operate the cargo lamp is shown in the table below.
CARGO LAMP OPERATION
OPERATION AND FUNCTION
OFF"ONON "OFF
ªCARGO LAMPº switch*
1push oncepush once
Door lock or unlock with the power door
lock switch or key (with the power door
lock system)
*2
Unlock
(The lamp will automatically turn off after
20 seconds.)Lock
Door open or closeOpen any of the doors
Close all of the doors

The lamp will automatically turn off after
20 seconds when the ignition switch is
in the ªACCº or ªLOCKº position or the
key is removed.
*3

The lamp will turn off immediately when
the ignition switch is in the ªONº posi-
tion.
Off function with vehicle speedÐOver approximately 5 km/h (3 mph)
Off function with timerÐThe lamp remains on for 30 minutes.
*1: An indicator light will illuminate to indicate that the cargo lamp is on.
*2: When all of the doors are closed and the ignition switch is in the ªACCº or ªLOCKº position or the key is removed.
*3: When the ignition switch is turned to the ªONº position, the lamp will turn off immediately.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
832001 TUNDRA (OM 34416U)
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ªONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
The ªINT TIMEº band lets you adjust the
wiping time interval when the wiper lever
is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it. To squirt washer fluid, pull the lever
toward you and release it.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see ªAdding washer fluidº in Section 7±3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch theglass.
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ªONº position.
Lever position
Speed setting
Position 1Slow
Position 2Fast
For a single sweep of the windshield,
push the lever up and release it.
To squirt washer fluid, pull the lever
toward you and release it.
For instructions on adding washer fluid,
see ªAdding washer fluidº in Section 7±3.
Windshield wipers and washer
(intermittent type) Windshield wipers and washer
( mist typ e)
