TOYOTA TUNDRA 2001 Manual PDF

'01 TUNDRA_U (L/O 0008)
642001 TUNDRA (OM 34416U)
4. To remove the convertible seat, press
the buckle±release button and allow the
belt to retract completely. The belt will
move freely again and be ready to
work for an adult or older child passen-
ger.(C) BOOSTER SEAT INSTALLATION
A booster seat is used in forward±fac-
ing position only.
CAUTION
A forward±facing child restraint sys-
tem which belongs to a passenger
risk group should never be put on
the right front seat with the passen-
ger airbag manual on±off switch in
the ªONº position, because the force
of the deploying airbag could cause
death or serious injury to the child in
forward seating position. (For details,
see ªSRS driver and front passenger
airbagsº in this section.)
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
652001 TUNDRA (OM 34416U)
1. Sit the child on a booster seat. Run
the lap and shoulder belt through or
around the booster seat and child fol-
lowing the instructions provided by its
manufacturer and insert the tab into
the buckle taking care not to twist the
belt.
Make sure the shoulder belt is correctly
across the child's shoulder and that the
lap belt is positioned as low as possible
on child's hips. See ªSeat beltsº for de-
tails.
CAUTION

Always make sure the shoulder belt
is positioned across the center of
child's shoulder. The belt should be
kept away from child's neck, but
not falling off child's s houlder. Fail-
ure to do so could reduce the
amount of protection in an accident
and cause serious injuries in a col-
lision.

Both high±positioned lap belts and
loose±fitting belts could cause seri-
ous injuries due to sliding under
the lap belt during a collision or
other unintended result. Keep the
lap belt positioned as low on a
child's hips as possible.

For child's safety, do not place the
shoulder belt under child's arm.

After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.

Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.

If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
662001 TUNDRA (OM 34416U)
2. To remove the child restraint system,
press the buckle±release button and al-
low the belt to retract.Follow the procedure below for a child
restraint system that requires the use
of a top strap.
Symbol
Anchor bracket
Separate seat
Symbol
Anchor brackets
Split and non±split bench seat
Ð U sin g a to p st rap
(standard cab models)
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
672001 TUNDRA (OM 34416U)
Use the anchor bracket on the back panel
to attach the top strap.
Anchor brackets are installed for (each)
passenger seat.
This symbol indicates the locations of
user ready anchor brackets.
TO USE THE ANCHOR BRACKET:
1. Remove the passenger head re- straint.2. Lightly push down on the top sur-face of the anchor bracket cover,
then pull it forward to remove.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
682001 TUNDRA (OM 34416U)
3. Fix the child restraint system with
the seat belt.
Latch the hook onto the anchor
bracket and tighten the top strap.
For instructions to install the child re-
straint system, see ªChild restraintº in this
section.
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
4. Replace the passenger head re- straint.
Store any removed covers in a safe place
such as the glove box.
Be sure to replace all covers when the
anchor bracket is not in use.Outside position
Center position
Ð U sin g a to p st rap
(access cab models)
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
692001 TUNDRA (OM 34416U)
Follow the procedure below for a child
restraint system that requires the use
of a top strap.Symbol Routing devices
Anchor brackets
Use the routing device on the rear of the
seat back and the anchor bracket on the
side floor to attach the top strap.
Anchor brackets are installed for each
rear seating position.
This symbol indicates the locations of
user ready anchor brackets.TO USE THE ANCHOR BRACKET:
Outside position 1. Remove the head restraint.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
702001 TUNDRA (OM 34416U)
Routing
device
2. Route the top strap through the
routing device as shown in the il-
lustration.
CAUTION
Make sure the top strap is not
twisted.
3. Fix the child restraint system withthe seat belt.
Latch the hook onto the anchor
bracket on the side floor and tighten
the top strap.
For instructions to install the child re-
straint system, see ªChild restraintº in this
section.
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
4. Replace the head restraint.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
712001 TUNDRA (OM 34416U)
Center position
1. Fold down the cup holder, unfasten the Velcro that attaches the anchor
bracket cover, and lift the cover.2. Route the top strap through the sloton top of the seat, pass the strap
through the seat, then latch the hook
onto the anchor bracket.
Close the cover and return the cup
holder to the original position.3. Move the child restraint system tothe correct position.
Then fix the child restraint system
with the seat belt and tighten the
top strap.
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
722001 TUNDRA (OM 34416U)
Tilt steering wheel
To change the steering wheel angle,
hold the steering wheel, pull the lock
release lever toward you, tilt the steer-
ing wheel to the desired angle and re-
lease the lever.
When the steering wheel is in a low posi-
tion, it will spring up as you release the
lock release lever.
CAUTION

Do not adjust the steering wheel
while the vehicle is moving. It may
cause the driver to mishandle the
vehicle and an accident may occur
resulting in death or serious inju-
ries.

After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Outside rear view mirrorsÐ
Adjust the mirror so that you can just
see the side of your vehicle in the mir-
ror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger 's side.
It is a convex mirror with a curved sur-
face. Any object seen in a convex mirror
will look smaller and farther away than
when seen in a flat mirror.
ProCarManuals.com

'01 TUNDRA_U (L/O 0008)
732001 TUNDRA (OM 34416U)
CAUTION
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting in
death or serious injuries.
To adjust a mirror, use the switches.
1. Master switchÐTo select the mirror to be adjusted
Push the switch at ªLº (left) or ªRº
(right).
2. Control switchÐTo move the mirror Push the switch in the desired direc-
tion.
Mirror can be adjusted when key is in the
ªACCº or ªONº position.
NOTICE
If ice should jam the mirror, do not operate the control or scrape the mir-ror face. Use a spray de±icer to freethe mirror.
ÐPower rear view mirror
control
ProCarManuals.com
