TOYOTA TUNDRA 2008 2.G Owners Manual

191
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
Automatic door locking function
Screen text: DOOR AUTO LOCKING
“ABOVE 12MPH
(Metric: 20 km/h)”
∗“SHIFT OUTOF PA R K ”
“OFF”
Automatic door unlocking function
Screen text: DOOR AUTO UNLOCKING
“SHIFT TO PA R K ”
∗“DRIVER DOOROPEN”
“OFF”
Time period before lights turn off (if a
door is opened and closed, and engine
switch is in ACC or LOCK)
Screen text: HEADLAMPS AUTO OFF
TIMER
“30 SECONDS”
∗
“90 SECONDS”
“60 SECONDS”“0 SECONDS”
Time period before lights turn off
Screen text: COURTESY OFF TIMER
“15 SECONDS”
∗“30 SECONDS”
“8 SECONDS”
Default settings of all items
Screen text: HOLD RESET TO
RESTORE DEFAULT SETTINGS
∗: Default setting After customizing is complete, press the
“SET UP” button to set the selected item.
If the customization fails, the previous set-
ting will be displayed. If no button is
pressed for 10 seconds, the display
switches to INFO mode.
As for any items except “UNITS”, the set-
tings cannot be changed at a vehicle
speed of 5 km/h (3 mph) or more. A mes-
sage, “PLEASE STOP VEHICLE TO
CHANGE SETTINGS”, will be indicated on
the screen and customizing operation can-
not be accomplished.
If the “SYSTEM ERROR” message is indi-
cated on the screen, the customizing op-
eration cannot be performed due to a
communication error. In such cases, turn
the engine switch off and then on again.
When the communication returns to nor-
mal, the customizing operation can then
be performed. If the “SYSTEM ERROR”
message is indicated again, contact your
Toyota dealer.

192
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
XS16013d
Normal display
XS16014c
Zoom display
This meter displays the odometer and
two trip meters.
Selecting the zoom display of the
odometer and trip meter allows the
odometer and one of the trip meters to
be displayed simultaneously.
1. Odometer—Shows the total distance the vehicle has been driven.
2. Two trip meters—Show two different distances independently driven since
the last time each trip meter was set
to zero.
You can use one trip meter to calculate
the fuel economy and the other to
measure the distance on each trip. All
trip meter data is cancelled if the elec-
trical power source is disconnected.
3. Trip meter reset knob—Resets the two trip meters to zero, and also changes
the meter display.
To change the meter display, quickly
push and release the knob. The meter
display changes in the order from the
odometer to trip meter A to trip meter
B, then back to the odometer each
time you push. To reset trip meter A to zero, display
the meter A reading, then push and
hold the knob until the meter is set to
zero. The same process can be applied
for resetting trip meter B.
—Odometer and two trip
meters

193
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
MessageStatusAction
(a)Parking brake is not released.Release parking brake.
(b)Engine coolant temperature is too high.Stop your vehicle and allow engine to cool.
(c)Any of doors are opened.Close doors completely.
—Warning messages

194
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
MessageStatusAction
(d)Fuel in tank becomes nearly empty.Fill up tank.
(e)Automatic transmission fluid temperature is
too high.Stop and check.
(f)Oil change is nearly due.Check engine oil.
(g)Oil change is due.Replace engine oil.
(h)Washer fluid level is low.Add washer fluid.

195
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
(a)
This message is to warn the driver that
the parking brake is not completely re-
leased at a vehicle speed of 5 km/h (3
mph) or more.
Stop the vehicle and release the park-
ing brake fully.
When the message appears, the master
warning light flashes, the brake system
warning light remains on, and an intermit-
tent warning tone also sounds.
(b)
This message is to warn the driver that
the engine coolant temperature is too
high.
Stop the vehicle and allow the engine
to cool.
The message appears, the master warning
light flashes, and a warning tone also
sounds.
NOTICE
Do not continue driving with an over-
heated engine. See “If your vehicle
overheats” on page 502 in Section 4.
(c)
This message is to remind the driver
that one or more of the doors are
opened.
Close the door securely.
The message appears, the master warning
light flashes, the open door warning light
remains on, and a warning tone also
sounds when the vehicle speed rises
above 5 km/h (3 mph).
(d)
This message is to remind the driver
that the fuel is nearly empty. When the message appears, the low fuel
level warning light comes on, and a warn-
ing tone also sounds. If it appears, fill the
fuel tank as soon as possible.
The message disappears by pressing the
“SELECT RESET” button when the engine
switch is in the “ON” position. However,
the low fuel level warning light remains
on.
(e)
This message is to warn the driver that
the automatic transmission fluid tem-
perature is too high.
If the automatic transmission fluid temper-
ature is too high, the message appears,
the automatic transmission fluid tempera-
ture warning light comes on, and a warn-
ing tone also sounds.
If this message appears while you are
driving, slow down and pull off the road.
Stop the vehicle at a safe place and put
the selector lever in “P”. With the engine
idling, wait until the message goes off. If
the message goes off, you may start the
vehicle again. If the message does not go
off, call a Toyota dealer or qualified repair
shop for assistance.

196
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
NOTICE
Continue driving with the warning
message on may result in damage of
the automatic transmission.
(f) (U.S.A. only)
This message is to remind the driver to
change the engine oil. The message is
a prior notice.
Toyota recommends that the engine oil
be changed as soon as possible.
If the driving distance after the previous
oil change reaches 7200 km (4500 miles),
the message appears for about 15 sec-
onds, the master warning light comes on,
and a warning tone also sounds.
The engine oil maintenance data must be
reset after the engine oil change. See
following “Resetting the engine oil
maintenance data”. (g)
(U.S.A. only)
This message is to remind the driver to
change the engine oil.
Change the engine oil as soon as pos-
sible.
If the driving distance after the previous
oil change reaches 8000 km (5000 miles),
the message appears, the master warning
light comes on, and a warning tone also
sounds. The message stays on when the
engine switch is turned to the “ON” posi-
tion.
The engine oil maintenance data must be
reset after the engine oil change. See
“Resetting the engine oil maintenance
data” below for the procedure to reset the
system.
Resetting the engine oil maintenance
data
The engine oil maintenance data must be
reset after replacement of the engine oil.
Reset the data by the following procedure: 1. Turn the engine switch to the “ACC” or “LOCK” position with the trip meter A
reading shown. (For details, see
“Odometer and two trip meters” on
page 186 in this Section.) 2. Turn the engine switch to the “ON”
position while holding down the trip
meter reset knob.
Hold down the knob for at least 5
seconds. The information display indicates
“MAINT REQD RESET MODE
COMPLETE”, the master warning light
comes on and the tone sounds.
If the system fails to reset, perform the
above procedure again.
(h)
This message appears when the washer
fluid level becomes very low.
Fill the tank as soon as possible.
The message appears the master warning
light comes on and a warning tone also
sounds.
If the message appears, fill the washer
tank as soon as possible. For instruc-
tions, see “Adding washer fluid” on
page 567 in Section 73.

197
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
If the indicator or buzzer comes on...Do this.
(a)
(indicator and buzzer)
orIf parking brake is off, stop immediately and contact Toyota dealer.
(b)
(indicator and buzzer)
Fasten driver ’s seat belt.
(c)
(indicator and buzzer)
Fasten front passenger ’s seat belt.
(d)Stop immediately and contact Toyota dealer.
(e)Stop and check.
(f)Take vehicle to Toyota dealer.
Service reminder indicators and warning buzzers

198
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
If the indicator or buzzer comes on...Do this.
(g)Replace engine oil.
(h)Fill up tank.
(i)orTake vehicle to Toyota dealer.
If brake system warning light is also on, stop immediately and contact Toyota dealer.
(j)andIf the “VSC OFF” indicator light flashes and the slip indicator light comes on, contact
Toyota dealer.
(k)
(indicator and buzzer)
Close all doors.

199
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
If the indicator or buzzer comes on...Do this.
(l)Take vehicle to Toyota dealer immediately.
(m)Adjust tire inflation pressure. If the warning light comes on after blinking for 1 minute,
contact Toyota dealer.
(n)Stop and check.
(o)Read a warning message on multi −information display.
(p)Add washer fluid.
(q)Key reminder buzzerRemove key.
(r)Parking brake reminder buzzerRelease parking brake.
(s)Four −wheel drive system warning
buzzerShift the transfer mode correctly.

200
2008 TUNDRA from Apr. ’08 Prod. (OM 34477U)
If the indicator or buzzer comes on...Do this.
(t)Open moon roof reminder buzzerClose moon roof.
