4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
Air conditioning filter (for Puerto Rico)
The air conditioning filter must be changed regularly to maintain air
conditioning efficiency.
■ Removal method
Turn the engine switch off.
Open the glove box. Slide off
the damper.
Push in each side of the glove
box to disconnect the claws.
Remove the filter cover.
STEP 1
STEP 2
STEP 3
STEP 4
Page 252 of 392
252 4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)
Pull out the filter.
Rotate the filter to remove it.
■ Replacement method
Set a new filter.
The “UP” marks shown on
the filter should be pointing up.
Rotate the filter.
Push in the filter.
STEP 5
Page 253 of 392
253
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
■
Checking interval
Inspect and replace the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, early replacement
may be required. (For scheduled maintenance information, please refer to
the “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.)
■ If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
NOTICE
■When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the
system.
Page 254 of 392
254
4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)
Wireless remote control batter y
Replace the battery with a new one if it is depleted.
■You will need the following items:
●Flathead screwdriver
● Lithium battery (CR2016)
■ Replacing the battery
Remove the cover.
To prevent damage to the key,
cover the tip of the screwdriver
with a rag.
Remove the module.
Remove the battery cover and
the depleted battery.
Insert a new battery with the
“+” terminal facing up.
STEP 1
STEP 2
STEP 3
Page 255 of 392

255
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
■
Use a CR2016 lithium battery
● Batteries can be purchased at your Scion dealer, local electrical appli-
ance shops or camera stores.
● Replace only with the same or equivalent type recommended by the
manufacturer.
● Dispose of used batteries according to local laws.
■ If the key battery is depleted
The following symptoms may occur:
● The wireless remote control will not function properly.
● The operational range will be reduced.
CAUTION
■Removed battery and other parts
Keep away from children. These parts are small and if swallowed by a child,
they can cause choking. Failure to do so could result in death or serious
injury.
NOTICE
■For normal operation after replacing the battery
Observe the following precautions to prevent accidents:
● Always work with dry hands.
Moisture may cause the battery to rust.
● Do not touch or move any other component inside the remote control.
● Do not bend either of the battery terminals.
Page 256 of 392
256
4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have
blown. If this happens, check and replace the fuses as necessary.
Turn the engine switch off.
Open the fuse box cover.
Engine compartment Push the tab in and lift the lid
off.
Under the driver’s side instrument panel Remove the lid.STEP 1
STEP 2
Page 257 of 392
257
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
Driver’s side instrument panel
Remove the auxiliary box.
After a system failure, see “Fuse layout and amperage rat-
ings” ( P. 260) for details about which fuse to check.
Remove the fuse.
Only type A fuse can be
removed using the pullout
tool.
STEP 3
STEP 4
Page 258 of 392
258 4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)
Check if the fuse is blown.
Ty p e A Normal fuse
Blown fuse
Replace the blown fuse with a
new fuse of an appropriate
amperage rating. The amper-
age rating can be found on the
fuse box lid.
Ty p e B
Normal fuse
Blown fuse
Replace the blown fuse with a
new fuse of an appropriate
amperage rating. The amper-
age rating can be found on the
fuse box lid.
Ty p e CNormal fuse
Blown fuse
Contact your Scion dealer.
STEP 5
12
ITY42C012
12
ITY42C013
12
ITY42C014
Page 259 of 392
259
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
Ty p e D
Normal fuse
Blown fuse
Contact your Scion dealer.12
ITY42C015
Page 260 of 392
260 4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)
Fuse layout and amperage ratings■ Engine compartment
FuseAmpereCircuit
1AM215 A Starting system, multi-port fuel
injection system/sequential multi-
port fuel injection system
2HORN10 A Horn
3EFI20 AMulti-port fuel injection system/
sequential multi-port fuel injection
system
4 SPARE 30 A Spare fuse
5 SPARE 15 A Spare fuse
6 SPARE 10 A Spare fuse
7 HTR SUB2 40 A Air conditioning system
8 EPS 50 A Electric power steering
