TOYOTA xD 2012 Owners Manual (in English)

271
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
■
Parking lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.
STEP 1
STEP 2

272 4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)
■Front side marker lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.
STEP 1
STEP 2

273
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
■
Stop/tail and rear side marker lights, rear turn signal lights
and back-up lights
Open the back door and remove
the cover.
To prevent damaging the vehicle,
wrap the flathead screwdriver
with a rag.
Turn the bulb bases counter-
clockwise.
Remove the light bulb.
Stop/tail and rear side marker
light
Rear turn signal light
Back-up light
STEP 1
STEP 2
STEP 3

274 4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)
■License plate lights
Open the back door and remove
the cover.
To prevent damaging the vehicle,
wrap the flathead screwdriver
with a rag.
Turn the bulb bases counter-
clockwise.
Remove the light bulb.
STEP 1
STEP 2
STEP 3

275
4-3. Do-it-yourself maintenance
4
Maintenance and care
Scion_xD_U_(OM52C20U)
■
LED light bulbs
The side turn signal lights and high mounted stoplight consist of a number of
LEDs. If any of the LEDs burn out, take your vehicle to your Scion dealer to
have the light replaced.
■ Condensation build-up on th e inside of the lens
Contact your Scion dealer for more information in the following situations.
Temporary condensation build-up on the inside of the headlight lens does
not indicate a malfunction.
● Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.
CAUTION
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immediately after
turning off the lights. 
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. Hold the
bulb by the plastic or metal portion. 
If the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Failing to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
● Do not attempt to repair or disassemble light bulbs, connectors, electric
circuits or component parts. 
Doing so may result in death or serious injury due to electric shock.
■ To prevent damage or fire
Make sure bulbs are fully seated and locked.

276 4-3. Do-it-yourself maintenance
Scion_xD_U_(OM52C20U)

When trouble arises5
277
Scion_xD_U_(OM52C20U)
5-1. Essential informationEmergency flashers ......... 278
If your vehicle needs to be towed .................... 279
If you think something 
is wrong ......................... 286
Fuel pump shut off 
system ........................... 287
Event data recorder ......... 288 5-2.
Steps to take in 
an emergency
If a warning light turns on  or a warning buzzer 
sounds... ........................ 290
If you have a flat tire......... 303
If the engine 
will not start .................... 317
If the shift lever cannot be 
shifted from P (automatic 
transmission) ................. 318
If you lose your keys ........ 319
If you cannot operate 
the back door opener ..... 320
If the vehicle battery 
is discharged .................. 321
If your vehicle 
overheats ....................... 326
If the vehicle becomes 
stuck .............................. 329
If your vehicle 
has to be stopped 
in an emergency ............ 331

278
Scion_xD_U_(OM52C20U)
5-1. Essential information
Emergency flashers
NOTICE
■To prevent battery discharge
Do not leave the emergency flashers on longer than necessary when the
engine is not running.
Use the emergency flashers if th e vehicle malfunctions or is
involved in an accident.
Press the switch to flash all
the turn signal lights. To turn
them off, press the switch
once again.

5
When trouble arises
279
5-1. Essential information
Scion_xD_U_(OM52C20U)
If your vehicle needs to be towed
Before towingThe following may indicate a problem with your transmission. Contact
your Scion dealer before towing.
● The engine is running but the vehicle will not move.
● The vehicle makes an abnormal sound.
If towing is necessary, we recommend having your vehicle towed by
your Scion dealer or a commercial towing service, using a lift-type
truck or flatbed truck. 
Use a safety chain system for all to wing, and abide by all state/pro-
vincial and local laws.

280 5-1. Essential information
Scion_xD_U_(OM52C20U)
Emergency towingIf a tow truck is not available in
an emergency, your vehicle may
be temporarily towed using a
cable or chain secured to the
emergency towing eyelet. This
should only be attempted on
hard surfaced roads for short
distances at low speeds.
A driver must be in the vehicle to
steer and operate the brakes.
The vehicle’s wheels, drive train,
axles, steering and brakes must
be in good condition.
