TOYOTA YARIS 2019 Owners Manual (in English)

YARIS SEDAN_OM_OM99S50z_(U)
1312-8. Security System
2
Before Driving
An armed system can be turned off using any one of the following
methods: • Pressing the unlock button on the smart key.
• Starting the engine with the push button start.
• With the advanced ke yless function:
Pressing a request switch on the doors.
The hazard warning li ghts will flash twice.
When the doors are unlocked by pressing the unlock button on the smart key
while the theft deterrent system is turned off, the hazard warn ing lights will
flash twice to indicate that the system is turned off.
A triggered alarm can be turned off using any one of the follow ing
methods: • Pressing the unlock button or t he trunk button on the smart key.
• Starting the engine with the push button start.
• With the advanced ke yless function:
Pressing a request switch on the doors.
The hazard warning li ghts will flash twice.
To Turn Off an Armed System
To Stop the Alarm

132
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
Break-In Period
No special break-in is necessary, but a few precautions in the first 600
miles (1,000 km) may add to the performance, economy, and life of
the vehicle. • Do not race the engine.
• Do not maintain one constant speed, either slow or fast, for a long
period of time.
• Do not drive constant ly at full-throttle or high engine rpm fo r
extended periods of time.
• Avoid unnecessa ry hard stops.
• Avoid full-throttle starts.

133
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
2
Before Driving
Saving Fuel and Protection of the Environment
How you operate your Toyota determines how far it will travel o n a
tank of fuel. Use these suggesti ons to help save fuel and reduce CO2.
• Avoid long warm-ups. Once the engine runs smoothly, begin driv -
ing.
• Avoid fast starts.
• Drive at lower speeds.
• Anticipate when to apply the br akes (avoid sudden braking).
• Follow the maintenance schedule and have your Toyota dealer pe r-
form inspections and servicing.
• Use the air conditioner only when necessary.
• Slow down on rough roads.
• Keep the tires properly inflated.
• Do not carry unnecessary weight.
• Do not rest your foot on the brake pedal while driving.
• Keep the wheels in correct alignment.
• Keep windows clos ed at high speeds.
• Slow down when driving in crosswinds and headwinds.
WARNING
■ Never stop the engine when going down a hill
Stopping the engine when going down a hill is dangerous. This c auses the
loss of power steering and power brake control, and may cause d amage to
the drivetrain. Any loss of steering or braking control could c ause an acci-
dent.

134
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
Hazardous Driving
When driving on ice or in water, snow, mud, sand, or similar hazards:
• Be cautious and allow ex tra distance for braking.
• Avoid sudden braking and sudden maneuvering.
• Do not pump the brakes. Continue to press down on the brake pedal. Refer to Antilock Brake System (ABS) on P. 204.
• If you get stuck, select a lower gear and accelerate slowly. D o not
spin the front wheels.
• For more traction in starting on slippery surfaces such as ice or
packed snow, use sand, rock sal t, chains, carpeting, or other non-
slip material under the front wheels.
Use snow chains only on the front wheels.
WARNING
■ Be extremely careful if it is necessary to downshift on slipper y sur-
faces
Downshifting into lower gear while driving on slippery surfaces is danger-
ous. The sudden change in tire speed could cause the tires to s kid. This
could lead to loss of vehicle control and an accident.

135
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
2
Before Driving
Floor Mat
When setting a floor mat, position
the floor mat so that its grommets
are inserted over the pointed end
of the retention posts.
Use only floor mats designed specifically for vehicles of the
same model and model year as your vehicle.
WARNING
■Make sure the floor mats are hooked on the retention pins to pr event
them from bunching up under the foot pedals
Using a floor mat that is not secured is dangerous as it will i nterfere with the
accelerator and brake pedal operation, which could result in an accident.
■ Do not install two floor mats, one on top of the other, on the driver’s
side
Installing two floor mats, one on top of the other, on the driv er’s side is dan-
gerous as the retention pins can only keep one floor mat from s liding for-
ward.
If using an all weather mat for winter use always remove the or iginal floor
mat.
Loose floor mat(s) will interfere with the foot pedal and could result in an
accident.

136
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
Rocking the Vehicle
If you must rock the vehicle to free it from snow, sand or mud, depress
the accelerator slightly and slow ly move the shift lever from 1 (D) to R
position.
WARNING
■ Do not spin the wheels at more th an 35 mph (56 km/h), and do not
allow anyone to stand behind a wheel when pushing the vehicle
When the vehicle is stuck, spinning the wheels at high speed is dangerous.
The spinning tire could overheat and explode. This could cause serious
injuries.
NOTICE
Too much rocking may cause engine overheating, transaxle failure, and tire
damage.

137
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
2
Before Driving
Winter Driving
Carry emergency gear, including tire chains, window scraper, flares, a
small shovel, jumper cables, and a small bag of sand or salt.
Ask your Toyota dealer to check the following:
• Have the proper ratio of ant ifreeze in the radiator.
Refer to Engine Coolant on P. 445.
• Inspect the battery and its cabl es. Cold reduces battery capacity.
• Use an engine oil appropriate for the lowest ambient temperatures that the vehicle w ill be driven in (P. 442).
• Inspect the ignition system for damage and loose connections.
• Use washer fluid made with antifreeze but do not use engine cool-
ant antifreeze for washer fluid ( P. 449).
●Do not use the parking brake in freezing weather as it may freeze. Instead,
shift to 1 or R with a manual transaxle and to P with an automa tic transaxle.
Block the rear wheels.
● Remove snow before driving. Snow left on the windshield is dang erous as it
could obstruct vision.
● Do not apply excessive force to a window scraper when removing ice or fro-
zen snow on the mirror glass and windshield.
● Never use warm or hot water for removing snow or ice from windo ws and
mirrors as it could result in the glass cracking.
● Drive slowly. Braking performance can be adversely affected if snow or ice
adheres to the brake components. If this situation occurs, drive the vehicle
slowly, releasing the accelerator pedal and lightly applying the brakes sev-
eral times until the brake performance returns to normal.

138
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
■Use snow tires on all four wheels
Do not go faster than 75 mph (120 km/h) while driving with snow
tires. Inflate snow tires 30 kPa (0.3 kgf/cm
2, 4.3 psi) more than rec-
ommended on the tire pressure label (driver’s door frame), but
never more than the maximum cold-tire pressure shown on the
tires.
The vehicle is originally equipped with all season radials desi gned
to be used all year around. In some extreme climates you may fi nd
it necessary to replace them wit h snow tires during the winter
months to further improve tracti on on snow and ice covered road s.
Check local regulations before using tire chains.
Install the chains on the front tires only.
Do not use chains o n the rear tires.
Please consult your Toyota dealer.
■Installing the chains
If your vehicle is equipped with wheel covers remove them, oth-
erwise the chain bands will scratch them.
Secure the chains on the front tires as tightly as possible.
Always follow the chain manuf acturer’s instructions.
Retighten the chains after dri ving 1/4—1/2 mile (1/2—1 km).
If your vehicle is equipped with the tire pressure monitoring s ystem, the
system may not function correctly when using tire chains.
Snow Tires
WARNING
■Use only the same size and type tires (snow, radial, or non-rad ial)
on all four wheels
Using tires different in size or type is dangerous. Your vehicl e’s handling
could be greatly affected and result in an accident.
NOTICE
Check local regulations before using studded tires.
Tire Chains
1
2
3

YARIS SEDAN_OM_OM99S50z_(U)
1392-9. Driving Tips
2
Before Driving
WARNING
■Driving with tire chains
● Chains may affect handling.
● Do not go faster than 30 mph (50 km/h) or the chain manufacture r’s rec-
ommended limit, whichever is lower.
● Drive carefully and avoid bumps, holes, and sharp turns.
● Avoid locked-wheel braking.
NOTICE
●Do not use chains on a temporary spare tire; it may result in d amage to the
vehicle and to the tire.
● Do not use chains on roads that are free of snow or ice. The ti res and
chains could be damaged.
● Chains may scratch or chip aluminum wheels.

140
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
Driving In Flooded Area
WARNING
■Dry off brakes that have become wet by driving slowly, releasin g the
accelerator pedal and lightly applying the brakes several times until
the brake performance returns to normal
Driving with wet brakes is dangerous. Increased stopping distan ce or the
vehicle pulling to one side when braking could result in a seri ous accident.
Light braking will indicate whether the brakes have been affect ed.
NOTICE
Do not drive the vehicle on flooded roads as it could cause sho rt circuiting
of electrical/electronic parts, or engine damage or stalling fr om water
absorption. If the vehicle has been immersed in water, consult your Toyota
dealer.
