TOYOTA YARIS 2019 Owners Manual (in English)

141
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
2
Before Driving
Overloading
WARNING
■Be careful not to overload your vehicle
The gross axle weight rating (GAWR) and the gross vehicle weight rat-
ing (GVWR) of the vehicle are on the Motor Vehicle Safety Stand ard
Label on the driver’s door fram e. Exceeding these ratings can cause an
accident or vehicle damage. You can estimate the weight of the load by
weighing the items (or people) b efore putting them in the vehicle.

142
YARIS SEDAN_OM_OM99S50z_(U)
2-9. Driving Tips
Driving on Uneven Road
Use care not to damage the vehicle’s underbody, bumpers or muf-
fler(s) when driving under the following conditions:
• Ascending or descending a slope with a sharp transition angle
• Ascending or descending a drivew ay or trailer ramp with a sharp
transition angle
Your vehicle’s suspension and underbody can be damaged if
driven on rough/uneven roads or over speed bumps at exces-
sive speeds. Use care and reduce speed when traveling on
rough/uneven roads or over speed bumps.
NOTICE
This vehicle is equipped with low profile tires allowing class- leading perfor-
mance and handling. As a result, the sidewall of the tires are very thin and
the tires and wheels can be damaged if driven through potholes or on
rough/uneven roads at excessive speeds. Use care and reduce spe ed
when traveling on rough/uneven roads or through potholes.

143
YARIS SEDAN_OM_OM99S50z_(U)
2-10. Towing
2
Before Driving
Trailer Towing
Your Toyota is not designed for towing. Never tow a trailer with
your Toyota.

144
YARIS SEDAN_OM_OM99S50z_(U)
2-10. Towing
Recreational Towing
When doing recreational towing refer to “Towing Description” (P. 519)
and “Tiedown Hooks” ( P. 520) and carefully fo llow the instructions.
An example of “recreational towing” is towing your vehicle
behind a motorhome.
The transaxle is not designed for towing this vehicle on all 4
wheels.

145
YARIS SEDAN_OM_OM99S50z_(U)
3When Driving
3-1. Start/Stop EngineIgnition Switch ................... 146
Starting the Engine ........... 148
Turning the Engine Off ...... 153
3-2. Combination Meter and Display
Meters and Gauges .......... 154
Warning/Indicator Lights .............................. 162
3-3. Transaxle Manual Transaxle Operation ........................ 166
Automatic Transaxle Controls........................... 170
3-4. Switches and Controls Lighting Control ................. 181
Fog Lights ......................... 188
Turn and Lane-Change Signals ............................ 189
Windshield Wipers and Washer..................... 191
Rear Window Defogger ......................... 196
Hazard Warning Flasher ............................ 197
3-5. Brake Brake System .................... 198
Hill Launch Assist (HLA) ... 202 3-6. ABS/TCS/DSC
Antilock Brake System (ABS) .............................. 204
Traction Control System (TCS) .............................. 205
Dynamic Stability Control (DSC) .............................. 207
3-7. Fuel Economy Monitor Fuel Economy Monitor ...... 210
3-8. Drive Selection Drive Selection (Automatic Transaxle) ..... 213
3-9. Power Steering Power Steering ................. 215
3-10. Active Safety System Active Safety System ........ 216
Smart City Brake Support (SCBS)............................ 217
Laser Sensor..................... 223
3-11. Cruise Control Cruise Control ................... 225
3-12. Tire Pressure Monitoring System
Tire Pressure Monitoring System ............................ 230
3-13. Rear View Monitor Rear View Monitor ............ 234

146
YARIS SEDAN_OM_OM99S50z_(U)
3-1. Start/Stop Engine
Ignition Switch
The system operates only when the driver is in the vehicle or within
operational range while the key is being carried.
Each time the push button start is
pressed, the ignition switches in
the order of off, ACC, and ON.
Pressing the push button start
again from ON switches the igni-
tion off.
■Off
The power supply to electrical devices turns off and the push b utton
start indicator light (amber) also turns off.
In this position the st eering wheel is locked.
■ACC (Accessory)
Some electrical access ories will operate and the indicator light
(amber) illuminates.
■ON
This is the normal running posit ion after the engine is started. The
indicator light (amber) turns off. (The indicator light (amber) illumi-
nates when the ignition is switched ON and the engine is not ru n-
ning.)
Some indicator lights/warning lights should be inspected before the
engine is started ( P. 1 6 2 ) .
Push Button Start Positions
Push button start Indicator light

YARIS SEDAN_OM_OM99S50z_(U)
1473-1. Start/Stop Engine
3
When Driving
■Push Button Start Positions
●The engine starts by pressing the push button start while depre ssing the
clutch pedal (manual transaxle) or the brake pedal (automatic t ransaxle). To
switch the ignition position, press the push button start without depressing
the pedal.
● Do not leave the ignition switched ON while the engine is not r unning. Doing
so could result in the battery going dead. If the ignition is l eft in ACC (For
automatic transaxle, the selector lever is in the P position, a nd the ignition is
in ACC), the ignition switches off automatically after about 25 minutes.
■ ACC (Accessory)
The keyless entry system does not function while the push butto n start has
been pressed to ACC, and the doors will not lock/unlock even if they have
been locked manually.
■ ON
When the push button start is pressed to ON, the sound of the f uel pump
motor operating near the fuel tank can be heard. This does not indicate an
abnormality.
WARNING
■ Before leaving the driver’s seat, set the parking brake, make s ure the
selector lever is in 1st gear or R (manual transaxle) or in P ( automatic
transaxle), and always switch the ignition off
Leaving the driver’s seat without setting the parking brake, sh ifting the
selector lever to 1st gear or R (manual transaxle) or to P (automatic tran-
saxle), and switching the ignition off is dangerous. Unexpected vehicle
movement could occur which could result in an accident.
In addition, if your intention is to leave the vehicle for even a short period, it
is important to switch the ignition off, as leaving it in anoth er position will dis-
able some of the vehicle’s security systems and run the battery down.

148
YARIS SEDAN_OM_OM99S50z_(U)
3-1. Start/Stop Engine
Starting the Engine
Make sure you are carrying the key.
Occupants should fasten their seat belts.
Make sure the parking brake is on.
Continue to press the brake pedal firmly until the engine has c om-
pletely started.
Manual transaxle:
Continue to press the clutch pedal firmly until the engine has com-
pletely started.
The starter will not operate if the clutch pedal is not depress ed sufficiently.
Automatic transaxle:
Put the vehicle in park (P). If you must restart the engine while the
vehicle is moving, shift into neutral (N).
The starter will not operate if the selector lever is not in P or N and the
brake pedal is not depressed sufficiently.
Press the push button start after both the KEY indicator light
(green) in the combination meter and the push button start indi cator
light (green) illuminate.
After starting the engine, the push button start indicator ligh t (amber) turns
off and the ignition switches to the ON position.
1
2
3
4
5
Verify that the KEY indicator
light (green) in the combination
meter and the push button start
indicator light (green) illumi-
nate.
If the push button start indicator
light (green) flashes, make sure
that the key is being carried.
If the push button start indicator
light (green) flashes with the key
being carried, touch the key to the
push button start and start the
engine. Refer to Engine Start Func-
tion When Key Battery is Dead on
P. 151.
6
Push button start Indicator light
T

YARIS SEDAN_OM_OM99S50z_(U)
1493-1. Start/Stop Engine
3
When Driving
After starting the engine, let it idle for about ten seconds.
●The key must be carried because the key carries an immobilizer chip that
must communicate with the engine controls at short range.
● The engine can be started when the push button start is pressed from off,
ACC, or ON.
● The push button start system functions (function which can star t the engine
by only carrying the key) can be deactivated to prevent any pos sible
adverse effect on a user wearing a pacemaker or other medical d evice. If
the system is deactivated, you will be unable to start the engi ne by carrying
the key. Consult your Toyota dealer for details. If the push bu tton start sys-
tem functions have been deactivated, you can start the engine b y following
the procedure indicated when the key battery goes dead.
Refer to Engine Start Function When Key Battery is Dead on P. 151.
● After starting a cold engine, the engine speed increases and a whining
sound from the engine compartment can be heard.
This is for improved exhaust gas purification and does not indicate defect of
the parts.
● Engine-starting is controlled by the spark ignition system.
This system meets all Canadian Interference-Causing Equipment Standard
requirements regulating the impul se electrical field strength of radio noise.
● Under the following conditions, the KEY warning light (red) fla shes after the
push button start is pressed to inform the driver that the push button start
will not switch to ACC even if it is pressed from off.
• The key battery is dead.
• The key is out of operational range.
• The key is placed in areas where it is difficult for the syste m to detect the
signal ( P. 94).
• A key from another manufacturer similar to the key is in the o perational
range.
8

150
YARIS SEDAN_OM_OM99S50z_(U)
3-1. Start/Stop Engine
●Forced engine starting method:
If the KEY warning light (red) illuminates, or the push button start indicator
light (amber) flashes, this could indicate that the engine may not start using
the usual starting method. Have your vehicle inspected at your To y o t a
dealer as soon as possible. If this occurs, the engine can be f orce-started.
Press and hold the push button start until the engine starts. O ther proce-
dures necessary for starting the engine such as having the key in the cabin,
and depressing the clutch pedal (manual transaxle) or the brake pedal
(automatic transaxle) are required.
● When the engine is force-started, the KEY warning light (red) r emains illumi-
nated and the push button start indicator light (amber) remains flashing.
● Automatic transaxle:
When the selector lever is in the neutral (N) position, the KEY indicator light
(green) and the push button start indicator light (green) do no t illuminate.
● After pressing the push button start and before the engine star ts, the opera-
tion sound of the fuel pump motor from near the fuel tank can be heard,
however, this does not indicate a malfunction.
● Whether the engine is cold or warm, it should be started without the use of
the accelerator.
● If the engine does not start the first time, refer to Starting a Flooded Engine
under Emergency Starting. If the engine still does not start, have your vehi-
cle inspected by your Toyota dealer ( P. 515).
WARNING
■Radio waves from the key may affect medical devices such as pac e-
makers
Before using the key near people who use medical devices, ask t he medical
device manufacturer or your physician if radio waves from the key will affect
the device.
NOTICE
If the KEY warning light (red) illuminates, or the push button start indicator
light (amber) flashes, this could indicate a problem with the e ngine starting
system and the inability to start the engine or switch the igni tion to ACC or
ON. Have your vehicle inspected at your Toyota dealer as soon a s possible.
