Yaris_Yaris hatchback_Navi_OM99V62z_(U)
Tilting up and
down
, Changes the vertical view angle of the map in 3D
mode.
Select the button once to modify the view in large
steps, or select and hold the button to modify it
continuously and smoothly.
Rotating left
and right , Changes the horizontal v
iew angle of the map.
Select the button once to modify the view in large
steps, or select and hold the button to modify it
continuously and smoothly.
Compass The direction of the compass shows North. Select
the button to switch to N orth-up view, and then
select again to rotate the map in the previous
direction.
Open/close , The UMP (menu bar) is displayed on the lower
part of the screen.
Hides the displayed UMP if the UMP has been
displayed.
Select
destination Select this button to sel
ect the Cursor as a new
destination. The route is automatically calculated.
Return to
normal
navigation Select this button to move the map back to follow
the current GPS position. Automatic map rotation
is also re-enabled.
The map manipulation buttons disappear and
navigation continues.
ActionButton(s)Description

22
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
2D or 3D view
, , When this button is select
ed, the map view mode
can be changed.
• : The map is displayed so that north is up
regardless of the direction of travel.
• : The map is rotated so that the direction of travel is displayed in the upward direction.
• : Displays things such as actual construction sites three dimensionally on the map.
Zoom-in/
zoom-out mode You can zoom-in/zoom-out of maps.
Rotate mode Rotates maps.
Perspective
angle mode You can change the angle
of perspective on a map.
ActionButton(s)Description

23
1
2
3
4
5
6
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
2.4.5 Checking the details of t
he current position (Where Am I?)
This screen contains information about the current position (or about the last known
position if GPS receptio n is not available).
You can access this scr een from the map in one of the following ways:
1. Select after selectin g on the MAP screen.
2. Select the Where Am I? screen.

24
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
2.5 Voice Recognition
Some items can be operated by vo ice using the vehicle’s microphone.
1. Press the talk button on the steering switch.
2. After “Say a command” is outpu t from the speaker and the beep sound is
heard, say your commands.
Set a new destination, “Gas station ” (on navigation
screen). 1) Press the talk button on the steering switch.
2) After “Say a command” is outpu t from the speaker and the beep sound is
heard, say, “New Destination”.
3) After “Which type of destination would you like?” is output f rom the speaker
and the beep sound is hear d, say, “Gas station”.
4) After “Gas station, say the des ired line number. You can also say: Try again”
is output from the speaker and the beep sound is heard, say, “N umber one”
(Destination is gas sta tion on the first row).
5) After “To begin navigation, say start” is output from the spe aker and the beep
sound is heard, say, “Start” to start route guidance.
2.5.1 Voice command list
If you have seven or more candida tes, say the command, “Page down” to move the
list.
Function operationVoice command
Switches to the screen where
new destinations can be selected. New Destination
Displays the route to your home. Take me home
Specifies the destination using
the address. Navigate to an address
Displays the history of the
recently specified destinations. Navigate to a r
ecent destination
Displays the current location. Where am I?
Reads out the previous guidance
again. Repeat instruction
Adds a route using keywords. Add way Point ~
Zooms in/out of the map screen. Zoom in/Zoom out
Adds the route using the address. Add way point address/Travel v ia address

25
1
2
3
4
5
6
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
Memo

26
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
3 On-road navigation
You can set up your route in different ways:
If you need a route for immediate navigation, you can select the destination and start
navigating to it right away (normal navigation).
You can plan routes with multiple destinations. Select the first destination. Then
select a second destination and add it to your route to create a multi-point route. You
can add as many destinations to your route as you like.
3.1 Selecting the destination of a route
The navigation system offers yo u several ways of choosing your destination:
• Enter a full address or a p art of an address (page 27).
• Select a POI (point of interest ) from a database as your destination (page 40).
• Searches the destination from the map (page 56).
• Use a previously saved Favorite destination (page 58).
• Select a location from the History of previously used destinat ions (page 60).
• Enter the coordinate of the destination (page 62).
There are other convenient functions.

27
1
2
3
4
5
6
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
3.1.1 Entering an address
or a part of the address
If you know at least a part of the address, it is the quickest way to select the
destination of the route.
Using the same screen, you can f ind an address by entering:
• Destination address
• The center of a city
• An intersection
• The midpoint of a street
3.1.1.1 Entering an address
To enter an address as the d estination, do as follows:
1. Select after selectin g on the MAP screen.
2. Select .
3. By default, the navigation syst em proposes the country and city where you
are. If needed, select , enter t he first few letters of the country name
on the keyboard, and select one c ountry from the list of results.
If an address or part of a facility name is input, a search can didate list including the
input characters is displayed. The greater the number of charac ters input the more
the list is refined.

28
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
4. If needed, select a new city:
a. Select .
b. Start entering the name of the city on the keyboard.
c. Find the city you need: • The most likely city name is always shown in the input field. To accept
it, select .
• If the desired name does not s how up, the names that match the string
appear in a list after entering a couple of characters (to open the list of
results before it appears automa tically, select ). Select the city from
the list.

29
1
2
3
4
5
6
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
5. Enter the street name:
a. Select .
b. Start entering the str eet name on the keyboard.
c. Find the street you need: • The most likely street name is always shown in the input field . To accept
it, select .
• If the desired name does not s how up, the names that match the string
appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, select ). Select the s treet from
the list.

30
Yaris_Yaris hatchback_Navi_OM99V62z_(U)
6. Enter the house number:
a. Select .
b. Enter the house number on the keyboard and select . (To enter letters,
select .)
c. Select the house number from the list.
7. The selected location is shown on the map. The system transitions to the next screen by selecting , or it
returns to the previous screen by selecting the button. By tou ching the
location displayed on the scree n, you can change the destinatio n to anywhere
on the map.
• : You can search for POI (point of interest)
around the selected location.
• : The selected location can be registered to Favorites.
