TOYOTA YARIS HATCHBACK 2020 Owners Manual (in English)

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3414-3. Bluetooth®
4
Interior Features
■Favorites Contacts
A maximum of 50 contacts can be registered. It will take less time to
make a call after registering the telephone number. In addition , you
do not have to look for the person you want to call in the phon e-
book.
● Registering to your favorites
Select the icon on the home screen and display the
Communication screen.
Select to display the favorites list.
Select .
Select or .
Select from the d isplayed list.
When “Add New Contact” is selected, information such as the
selected person’s name is also registered. In addition, when “A dd
New Contact Details” is selected, only the telephone number of the
selected person is registered.
● Making a call from your favorites
Select the icon on the home screen and display the
Communication screen.
Select to display the favorites list.
Only one phone number is registered to contact:
Select the contact information you would like to call. Go to
Step .
Multiple phone numbers are registered to contact:
Select the contact you would like to call to display the screen
indicating the details for the contact. Go to Step .
Select the phone number you would like to call.
Select .
1
2
3
4
5
1
2
3
5
4
4
5

342
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-3. Bluetooth®
●Deleting from your favorites
Select the icon on the home screen and display the
Communication screen.
Select to display the favorites list.
Select .
Select .
Select the contact information which you would like to delete.
Select .
● Changing the display orde r of your favorites list
Select the icon on the home screen and display the
Communication screen.
Select to display the favorites list.
Select .
Select .
The contact can be move d after it is selected.
Slide the contact or move it using the commander switch, then
select .
● Changing contact name of your favorites
Select the icon on the home screen and display the
Communication screen.
Select to display the favorites list.
Select .
Select .
Select the contact to disp lay the keyboard screen.
If a new name is input and is selected, the contact name is
stored.
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3434-3. Bluetooth®
4
Interior Features
■Telephone Number InputSelect the icon on the home screen and display the Com-
munication screen.
When is pressed, the dial pad is displayed.
Input the telephone number using the dial pad.
Select to make the call.
● Numeral or symbol entry
Use the dial pad.
Long-press the to input +.
Select to delete the currently input value.
Long-press to delete all input values.
■Redial Function
Makes a call to the last person called (latest person on outgoi ng call
record) from the mobile phone/vehicle.
Press the talk button.
Wait for the beep sound.
Say: “Redial”
■Call back Function
Makes a call to the last person who called your (latest person on
incoming call record) mobile phone/vehicle.
Press the talk button.
Wait for the beep sound.
Say: “Call back”
● Automatic 911 dialing
If the vehicle is involved in a moderate to severe collision, a call
is made automatically to 911 from the connected device. The
“Emergency Assistance Cal l” setting must be on.
Refer to Communication Settings on P. 351.
If the vehicle is involved in a moderate to severe collision, n oti-
fication of the call to 911 is made via audio and screen displa y.
To cancel the call, press or hang-up
button withi n 10 seconds.
If or hang-up button is not pressed
within 10 seconds, the call i s made to 911 automatically.
1
2
3
4
1
2
3
1
2
3
1
2

344
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-3. Bluetooth®
■Phonebook Usage
●A maximum of 1000 contacts can be registered to the phonebook.
● Phonebook, incoming/outgoing call record, and favorite memories are
exclusive to each mobile phone to protect privacy.
● Contacts with no telephone number are not registered.
■ Favorites Contacts
If the contact is long-pressed when the favorites list is displ ayed, the contact
information can be edited (deleted, moved).
■ Telephone Number Input
Practice this while parked until you are confident you can do i t while driving in
a non-taxing road situation. If you are not completely comforta ble, make all
calls from a safe parking position, and only start driving when you can devote
your full attention to driving.
■ Mobile 911 (U.S.A./Canada only)
●Automatic 911 dialing is a secondary function of the audio ente rtainment
system. Therefore, the Automatic 911 dialing function does not assure that
the call is always made to 911 after an accident occurs.
● A Hands-free device must be paired and connected. The 911 operator can
verify the vehicle’s position information using the Hands-free device GPS if
equipped. The 911 operator can verify the vehicle’s position in formation.
NOTICE
■Mobile 911 (U.S.A./Canada only)
Though the system can be set to not call 911, doing so will def eat the pur-
pose of the system. Toyota recommends that the Automatic 911 di aling sys-
tem remain activated.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3454-3. Bluetooth®
4
Interior Features
When an incoming call is received, the incoming call notification
screen is displayed. The “Incomi ng Call Notifications” setting must be
on.
Refer to Communication Settings on P. 351.
To accept the call, press the p ick-up button on the audio contr ol switch
or select on the screen.
To reject the call, press the hang-up button on the audio contr ol switch
or select on the screen.
The following icons are displayed on the screen during a call. Icons
which can be used differ d epending on use conditions.
Receiving an Incoming Call
IconFunction
Displays the Communication menu.
Ends the call.
Transferring a call from h ands-free to a mobile phone
Communication between the Bluetooth® unit and a device
(mobile phone) is canceled, and an incoming call will be
received by the device (mobile phone) like a standard call.
Transferring a call from a device (mobile phone) to
hands-free
Communication between devices (mobile phone) can be
switched to Bluetooth
® Hands-Free.
Mute
The microphone can be muted during a call.
When selected again, the mute is canceled.
A call is made to other person during a call and a 3-way
call can be made. Select the contact from the following to
make a call. : Call History is displayed.
: The phonebook is displayed.
: The dial pad is displayed. Input the phone number.
The device may be unusable depending on the contrac-
tual content.
The call on hold is made to make a 3-way call.
The device may be unusable depending on the contrac-
tual content.

346
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-3. Bluetooth®
●If the ignition is switched off during a hands-free call, the l ine is transferred
to the device (Mobile phone) automatically.
● If the DTMF code has two or more digits or symbols, each one must be
transmitted individually.
Switches the call on hold.
DTMF (Dual Tone Multi-Frequency Signal) Transmis-
sion
This function is used when transmitting DTMF via the dial
pad. The receiver of a DTMF transmission is generally a
home telephone answering machine or a company’s auto-
mated guidance call center.
Input the number using a dial pad.
IconFunction

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3474-3. Bluetooth®
4
Interior Features
A call can be interrupted to receive an incoming call from a third party.
When is selected or the pick-up button on the steering
wheel is pressed, the current call is held and the system switc hes to
the new incoming call.
When is selected, the current call is ended and the system
switches to the new incoming call (GSM network only).
When is selected or the hang-up button on the steering wheel
is pressed, an incomi ng call is refused.
●The function may not be available depending on the contractual content of
the mobile device.
● The function may not be operable depending on the type of the telephone
network and the mobile device.
SMS (Short Message Service) messages, and E-mail received by
connected devices can be downloa ded, displayed, and played (read
by the system).
Additionally, replies can also be made to calls and messages in the
received messages.
■Downloading messages
Up to 20 new messages can be downloaded and displayed from a
connected device.
For e-mail, 20 messages for each account can be downloaded.
Automatic downloading
The “Auto Download Email” (E-mail) or “Auto Download Text Mes-
sage” (SMS) setting must be on. A message is downloaded auto-
matically when the Bluetooth
® unit is connected to the device.
Refer to Communication Settings on P. 351.
Manually downloading
When the “Auto Download Email” (E-mail) or “Auto Download Text
Message” (SMS) setting is off, the message is downloaded using
the following procedure. Select the icon on the home screen and display the Com-
munication screen.
Call Interrupt
Receiving and Replying to Messages (available only with E-mail/
SMS compatible phones)
1

348
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-3. Bluetooth®
Select or to display the Inbox.
Select .
Download will be started from the mobile phone.
■Receiving messages
Method 1
When a device receives a message, a message received notifica-
tion is displayed. The “Email Not ifications” (E-mail) or “Text Notifica-
tions” (SMS) sett ing must be on.
Refer to Communication Settings on P. 351.
Select and displ ay the message.
Method 2
Select the icon on the home screen and display the Com-
munication screen.
Select and display the new message list for e-mail and
SMS.
Select the message you would like to display.
The following icons are displayed in the lower part of the deta ils on
the message. Icons which can be used differ depending on use
conditions.
2
3
4
1
2
3
IconFunction
Displays the Communication menu.
Displays the inbox.
Plays back a message.
When selected again, playback is temporarily stopped.
Displays the previous message.
Displays the next message.
Only replies to the sender of the currently displayed mes-
sage.
Select the sentence on the displayed reply screen and
select the sentence for sending from the preset message.
Select .

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3494-3. Bluetooth®
4
Interior Features
Up to three preset messages can be selected.
●Example of use (verify unread E-mail)
Select the icon on the home screen and display the
Communication screen.
Select to display the inbox.
Select the unread mes-
sage displayed in bold.
The details of the message are displayed and replying to the
message, making a call, o r playback can be performed.
Only E-mail:
Replies to all members including CC.
Select the sentence on the displayed reply screen and
select the sentence for sending from the preset message.
Select .
Makes a call to a person who sent a message.
For E-mail, this function may not work depending on the
device.
Deletes a message.
The messages stored in a device is also deleted.
IconFunction
1
2
3
4

350
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-3. Bluetooth®
●Changing account for displaying (E-mail only)
Select .
Select the account which you would like to display. Only the
messages for the sele cted account are displayed in the inbox.
● Editing preset messages
Select the icon on the home screen and display the
Communication screen.
Select .
Select .
Select the preset message which you would like to edit. The
keyboard screen is displayed.
When the message is input and is selected, the mes-
sage is stored as a preset message.
■ Downloading messages
●Attached data is not downloaded.
● Messages up to 1 kilobyte (e-mail)/140-bytes (SMS) can be downl oaded.
● A message list is created for each device.
● If the connected device does not correspond to MAP 1.0, the AT command
is used to download. The downloaded message indicates that it i s already
read.
● Downloading using the AT command may not function depending on the
connected device.
■ Editing preset messages
●Select the icon to change the language.
● Select the icon to switch between capitalized and lower-case charac-
ters.
● Select the icon to return to the previous screen without stori ng the
edit.
1
2
1
2
3
4
5
