TOYOTA YARIS HATCHBACK 2020 Owners Manual (in English)

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4115-3. Owner Maintenance
5
Maintenance and Care
Insert the tape-wrapped flat-
head screwdriver into the
gap and slide it in the direc-
tion of the arrow.
Twist the flathead screw-
driver in the direction of the
arrow and remove the cover.
Remove the battery cap,
then remove the battery.
Insert a new battery with the
positive pole facing up, and
then cover the battery with
the battery cap.Cover
Gap
3
Cover
Q
R
S

4125-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
Close the cover.
Reinsert the auxiliary key.7
NOTICE
●Make sure the battery is installed correctly. Battery leakage c ould occur if it
is not installed correctly.
● When replacing the battery, be careful not to touch any of the internal cir-
cuitry and electrical terminals, bend the electrical terminals, or get dirt in
the smart key as the smart key could be damaged.
● There is the danger of explosion if the battery is not correctl y replaced.
● Dispose of used batteries according to the following instructio ns.
• Insulate the plus and minus terminals of the battery using cellophane or equivalent tape.
• Never disassemble.
• Never throw the battery into fire or water.
• Never deform or crush.
● Replace only with the same type battery (CR2025 or equivalent).
8
●Be careful not to allow the rubber ring
shown in the figure to be scratched or
damaged.
● If the rubber ring detaches, reattach it
before inserting a new battery.Rubber ring

413
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
5-3. Owner Maintenance
5
Maintenance and Care
Tires
Inspect all tire pressures monthly (including the spare) when the tires
are cold. Maintain recommended pressures for the best ride, han -
dling, and minimum tire wear.
Refer to the spec ification charts
(P. 5 5 3).
With tire pressure m onitoring system:
After adjusting the tire pressur e, initialization of the tire p ressure mon-
itoring system is necessary to m ake the system operate normally .
Refer to Tire Pressure Monitorin g System Initialization on P. 244.
For reasons of proper performan ce, safety, and better fuel econ-
omy, always maintain recommended tire inflation pressures and
stay within the recommended load limits and weight distribu-
tion.
WARNING
■Using Different Tire Types
Driving your vehicle with differ ent types of tires is dangerous . It could
cause poor handling and poor bra king; leading to loss of control.
Except for the limited use of the temporary spare tire, use onl y the same
type tires (radial, bi as-belted, bias-type) on all four wheels.
■Using Wrong-Sized Tires
Using any other tire size than wh at is specified for the vehicle (P. 5 5 3 )
is dangerous. It could seriously affect ride, handling, ground clearance,
tire clearance, and speedometer calibration. This could cause y ou to
have an accident. Use only tires that are the correct size spec ified for
the vehicle.
Tire Inflation Pressure

4145-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
●Always check tire pressure when tires are cold.
●Warm tires normally exceed recommended pressures. Do not releas e
air from warm tires to adjust the pressure.
●Underinflation can cause reduced fuel economy, uneven and accel er-
ated tire wear, and poo r sealing of the tire bead, which will d eform the
wheel and cause separat ion of tire from rim.
●Overinflation can produce a harsh ride, uneven and accelerated tire
wear, and a greater p ossibility of damage from road hazards.
Keep your tire pressure at the correct levels. If one frequentl y needs
inflating, have it inspected.
During rotation, inspect them for
correct balance.
WARNING
■Always inflate the tires to the correct pressure
Overinflation or underinflation o f tires is dangerous. Adverse handling or
unexpected tire failure could result in a serious accident.
Refer to Tires on (P. 553).
■Use only a Toyota-genuine tire valve cap
Use of a non-genuine part is dangerous as the correct tire air pressure
cannot be maintained if the tire valve becomes damaged. If the vehicle
is driven under this condition, the tire air pressure will decr ease which
could result in a serious accident. Do not use any part for the tire valve
cap that is not a Toyota-genuine part.
Tire Rotation
Forward
Do not include
(TEMPORARY USE ONLY)
spare tire in rotation.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4155-3. Owner Maintenance
5
Maintenance and Care
Also, inspect them for uneven wear and damage. Abnormal wear is
usually caused by one or a combination of the following:
• Incorrect tire pressure
• Improper wheel alignment
• Out-of-balance wheel
• Severe braking
After rotation, inflate all tire pressures to specification (
P. 553) and
inspect the lug nu ts for tightness.
With tire pressure monitoring system:
After adjusting the tire pressur e, initialization of the tire p ressure mon-
itoring system is necessary to m ake the system operate normally .
Refer to Tire Pressure Monitorin g System Initialization on P. 244.
WARNING
■Rotate tires periodically
Irregular tire wear is dangerous. To equalize tire wear and ext end tire
life, Toyota recommends that tire rotation is carried out at th e same
interval as tire inspection.
For scheduled maintenance information, please refer to the “Own er’s
Manual Supplement/Schedul ed Maintenance Guide”.
NOTICE
Rotate unidirectional tires and radial tires that have an asymm etrical
tread pattern or studs only from front to rear, not from side t o side. Tire
performance will be redu ced if rotated from side to side.

4165-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
If a tire wears evenly, a wear indicator will appear as a solid band
across the tread.
Replace the tire when this happens.New tread
Worn tread
Tread wear indicator
You should replace the tire bef ore the band crosses the entire tread.
With tire pressure monitoring system:
After adjusting the tire pressur e, initialization of the tire p ressure mon-
itoring system is necessary to m ake the system operate normally .
Refer to Tire Pressure Monitorin g System Initialization on P. 244.
Tires degrade over time, even wh en they are not being used on the road.
It is recommended that tires gen erally be replaced when they are 6 years
or older. Heat caused by hot climates or frequent high loading conditions
can accelerate the aging process. You should replace the spare tire when
you replace the other road tires due to the aging of the spare tire. The
period in which the tire was manufactured (both week and year) is indi-
cated by a 4-digit number.
Refer to Tire Labeling on P. 522.
Replacing a Tire
1
2
3
WARNING
■Always use tires that are in good condition
Driving with worn tires is dangero us. Reduced braking, steering, and
traction could result in an accident.
■Replace all four tires at the same time
Replacing just one tire is dangerous. It could cause poor handl ing and
poor braking resulting in loss of vehicle control. Toyota strongly recom-
mends that you replace all four tires at the same time. If you replace
only two tires, the new tires should be installed on the rear o f the vehi-
cle.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4175-3. Owner Maintenance
5
Maintenance and Care
Inspect the temporary spare tire at least monthly to make sure it is
properly inflated and stored.
The temporary spare tire is easier to handle because of its con struc-
tion which is lighter and smaller than a conventional tire. Thi s tire
should be used only for an emergency and only for a short dista nce.
Use the temporary spare tire o nly until the conventional tire is
repaired, which should be as soon as possible.
Refer to Tires on P. 553.
●The temporary spare tire condition gradually deteriorates even if it has
not been used.
●Tires degrade over time, even when they are not being used on t he
road. It is recommended that tires generally be replaced when t hey are
6 years or older. Heat caused by hot climates or frequent high loading
conditions can accelerate the aging process. You should replace the
spare tire when you replace the other road tires due to the agi ng of the
spare tire. The period in which the tire was manufactured (both week
and year) is indicated by a 4-digit number.
Refer to Tire Labeling on P. 522.
Proper tire balancing provides t he best riding comfort and help s
reduce tread wear. Out-of-balance tires can cause vibration and
uneven wear, such as c upping and flat spots.
When replacing a wheel, make sure the new one is the same as th e orig-
inal factory wheel in diameter, rim width, and offset (inset/outset).
For details, contact your Toyota dealer.
Temporary Spare Tire
NOTICE
●Do not use your temporary spare tire rim with a snow tire or a conven-
tional tire. Neither will properly fit and could damage both tire and rim.
●The temporary spare tire has a tread life of less than 3,000 mi les
(5,000 km). The tread life may be shorter depending on driving condi-
tions.
●The temporary spare tire is for limited use, however, if the tr ead wear
solid-band indicator appears, replace the tire with the same ty pe of
temporary spare ( P. 417).
Replacing a Wheel

4185-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
WARNING
■Always use wheels of the correct size on your vehicle
Using a wrong-sized wheel is dangerous. Braking and handling could
be affected, leading to loss of control and an accident.
NOTICE
A wrong-sized wheel may adversely affect:
●Tire fit
●Wheel and bearing life
●Ground clearance
●Snow-chain clearance
●Speedometer calibration
●Headlight aim
●Bumper height
●Tire Pressure Monitoring System (if equipped)

419
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
5-3. Owner Maintenance
5
Maintenance and Care
Light Bulbs
■Front
With Halogen Headlights
Headlights (Low/High beam)/
Daytime running lights
Front side-marker lights
Overhead lights/Map lights
Side turn signal lights (if
equipped)
Front turn signal lights/Park-
ing lights
Fog lights (if equipped)
With LED Headlights
Headlights (High beam)
Headlights (Low beam)
Front side-marker lights
Overhead lights/Map lights
Side turn signal lights (if
equipped)
Front turn signal lights/Park-
ing lights
Daytime running light/Park-
ing light
Fog lights
1
2
3
4
5
6
1
2
3
4
5
6
7
8

4205-3. Owner Maintenance
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
■Rear
4-DoorTrunk light
High-mount brake lights
License plate lights
Reverse lights
Rear turn signal lights
Brake lights/Taillights/Rear
side-marker lights
5-DoorHigh-mount brake light
License plate lights
Reverse lights
Rear turn signal lights
Brake lights/Tail lights
Rear side-marker lights
Luggage compartment light
●To replace the bulb, contact your Toyota dealer.
● If the halogen bulb is accidentally touched, it should be clean ed with rubbing
alcohol before being used.
● Use the protective cover and carton of the replacement bulb to dispose of
the old bulb promptly out of the reach of children.
1
2
3
4
5
6
1
2
3
4
5
6
7
