411-2. Seat Belt Systems
1
Essential Safety Equipment
WARNING
■Wear seat belts only as recommended in this owner’s manual
Incorrect positioning of the driver and front passenger seat be lts is danger-
ous. Without proper positioning, the pretensioner and load limi ting systems
cannot provide adequate protection in an accident and this coul d result in
serious injury. For more details about wearing seat belts, refe r to “Fastening
the seat belts” ( P. 37).
■ Have your seat belts changed immed iately if the pretensioner or load
limiter has been expended
Always have your Toyota dealer immediately inspect the seat bel t preten-
sioners and air bags after any collision. Like the air bags, the seat belt pre-
tensioners and load limiters will only function once and must b e replaced
after any collision that caused them to deploy. A seat belt with an expended
pretensioner or load limiter is still better than wearing no se at belt at all;
however, if the seat belt pretensioners and load limiters are n ot replaced,
the risk of injury in a collision will increase.
■ Do not modify the components or wiring, or use electronic testi ng
devices on the pretensioner system
Modifying the components or wiring of the pretensioner system, including
the use of electronic testing devices is dangerous. You could accidentally
activate it or make it inoperable which would prevent it from a ctivating in an
accident. The occupants or repairers could be seriously injured .
■ Properly dispose of the pretensioner system
Improper disposal of the pretensioner system or a vehicle with non-deacti-
vated pretensioners is dangerous. Unless all safety procedures are fol-
lowed, injury could result. Have your Toyota dealer safely dispose of the
pretensioner system or scrap a pretensioner system equipped veh icle.
Page 42 of 572

42
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-2. Seat Belt Systems
Seat Belt Extender
This extender will be only for you and for the particular vehicle and
seat. Even if it plugs into other seat belts, it may not hold in the critical
moment of a crash.
When ordering an extender, only order one that provides the nec es-
sary additional length to fast en the seat belt properly.
Please contact your Toyota d ealer for more information.
When not in use, remove the seat belt extender and store it in the vehicle. If
the seat belt extender is left connected, the seat belt extender might get dam-
aged as it will not retract with the rest of the seat belt and can easily fall out of
the door when not in use and be damaged. In addition, the seat belt warning
light will not illuminate and function properly.
If your seat belt is not long enough, even when fully extended, a
seat belt extender may be available to you at no charge from
your Toyota dealer.
WARNING
■ Do not use a seat belt extender unless it is necessary
Using a seat belt extender when not necessary is dangerous. The seat belt
will be too long and not fit properly. In an accident, the seat belt will not pro-
vide adequate protection and you could be seriously injured. On ly use the
extender when it is required to fasten the seat belt properly.
■ Do not use an improper extender
Using a seat belt extender that is for another person or a diff erent vehicle or
seat is dangerous. The seat belt will not provide adequate protection and
the user could be seriously injured in an accident. Only use the extender
provided for you and for the particular vehicle and seat. NEVER use the
extender in a different vehicle or seat. If you sell your Toyot a, do not leave
your seat belt extender in the vehicle. It could be used accide ntally by the
new owner of the vehicle. After removing the seat belt extender, discard it.
Never use the seat belt extender in any other vehicle you may o wn in the
future.
Page 43 of 572

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
431-2. Seat Belt Systems
1
Essential Safety Equipment
WARNING
■Do not use an extende r that is too long
Using an extender that is too long is dangerous. The seat belt will not fit
properly. In an accident, the seat belt will not provide adequa te protection
and you could be seriously injured. Do not use the extender or choose one
shorter in length if the distance between the extender’s buckle and the cen-
ter of the user’s body is less than 6 in. (150 mm).
■ Do not leave a seat belt extende r connected to the buckle
Leaving a seat belt extender connected to the buckle without using the seat
belt is dangerous. When the seat belt extender is connected to the driver’s
seat belt buckle (or front passenger’s seat belt buckle), the S RS driver’s (or
front passenger’s) air bag system will determine that the drive r (or front pas-
senger) is wearing the seat belt even if the driver (or front p assenger) is not
wearing it. This condition could cause the driver’s (or front passenger’s) air
bag to not activate correctly and result in death or serious injury in the event
of collision. Always wear the seat belt with the seat belt exte nder.
■ Do not use the seat belt extender when installing a child-restr aint sys-
tem on the front or rear passenger seat
Using a seat belt extender to fasten a child-restraint system on any seat is
dangerous. Always follow the child-restraint system manufacture r’s installa-
tion instructions and never use a seat belt extender.
Page 44 of 572

44
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-3. Child Restraint
Child-Restraint Precautions
Whatever child-restraint system you consider, please pick the appro-
priate one for the age and size of the child, obey the law and follow
the instructions that come wit h the individual child-restraint system.
A child who has outgrown child-re straint systems should sit in the rear
and use seat belts, both lap and shoulder. If the shoulder belt crosses
the neck or face, move the child closer to the center of the ve hicle in
the outboard seats, and towards the buckle on the right if the child is
seated on the center seat.
Statistics confirm that the rear seat is the best place for all children up
to 12 years of age, and more so w ith a supplemental restraint system
(air bags).
A rear-facing child-restraint system should NEVER be used on th e
front seat with the air bag syst em activated. The front passeng er’s
seat is also the leas t preferred seat for other child-restraint systems.
To reduce the chance of injuries caused by deployment of the front
passenger air bag, the front passenger occupant classification sensor
works as a part of the supplemen tal restraint system. This system
deactivates the front passenger front and side air bags and als o the
front passenger seat belt pretens ioner system when the front passen-
ger air bag deactivation ind icator light illuminates.
When an infant or small child sits on the front passenger seat, the sys-
tem shuts off the front passeng er front and side air bags and seat belt
pretensioner system, so make sur e the front passenger air bag deac-
tivation indicator light illuminates.
Toyota strongly urges the use of child-restraint systems for chil-
dren small enough to use them.
You are required by law to use a child-restraint system for chil-
dren in the U. S. and Canada.
Check your local and state or provincial laws for specific
requirements regarding the safety of children riding in your
vehicle.
Page 45 of 572

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
451-3. Child Restraint
1
Essential Safety Equipment
Even if the front passenger air bag is shut off, Toyota strongly recom-
mends that children be properly restrained and child-restraint systems
of all kinds are properly secured on the rear seats which are t he best
place for children.
For more details, refer to “Fron t passenger occupant classification
sensor” ( P. 82).
Your Toyota is equipped with LATCH lower anchors for attachment of spe-
cially designed LATCH child-restraint systems on the rear seats. When using
these anchors to secure a child-restraint system, refer to “Usi ng LATCH
Lower Anchor” ( P. 61).
WARNING
■Use the correct size child-restraint system
For effective protection in vehicle accidents and sudden stops, a child must
be properly restrained using a seat belt or child-restraint sys tem depending
on age and size. If not, the child could be seriously injured o r even killed in
an accident.
■ Follow the manufacturer’s instructions and always keep the chil d-
restraint system buckled down
An unsecured child-restraint system is dangerous. In a sudden s top or a
collision it could move causing serious injury or death to the child or other
occupants. Make sure any child-restraint system is properly sec ured in
place according to the child-restraint system manufacturer’s in structions.
When not in use, remove it from the vehicle or fasten it with a seat belt, or
attach it to BOTH LATCH lower anchors for LATCH child-restraint systems
and the corresponding tether anchor.
■ Always secure a child in a proper child-restraint system
Holding a child in your arms while the vehicle is moving is ext remely dan-
gerous. No matter how strong the person may be, he or she canno t hold
onto a child in a sudden stop or collision and it could result in serious injury
or death to the child or other occupants. Even in a moderate accident, the
child may be exposed to air bag forces that could result in ser ious injury or
death to the child, or the child may be slammed into an adult, causing injury
to both child and adult.
Page 46 of 572

46
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-3. Child Restraint
WARNING
■Never use a rear-facing child-restraint system in the front sea t with an
air bag that could deploy
■ Do not install a front-facing c hild-restraint system on the fro nt passen-
ger seat unless it is unavoidable
Rear-facing child-restraint systems on
the front seat are particularly dangerous
even though you may feel assured that a
front passenger air bag will not deploy
based on the fact that the front passen-
ger air bag deactivation indicator light
illuminates. The child-restraint system
can be hit by a deploying air bag and
moved violently backward resulting in
serious injury or death to the child.
Vehicles with a front passenger air bag
have a warning label attached as shown
below.
The warning label reminds you not to put
a rear-facing child-restraint system on
the front passenger seat at any time.
In a collision, the force of a deploying air
bag could cause serious injury or death
to the child. If installing a front-facing
child-restraint system on the front pas-
senger seat is unavoidable, move the
front passenger seat as far back as pos-
sible.
Page 47 of 572

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
471-3. Child Restraint
1
Essential Safety Equipment
WARNING
■Seating a child in a child-restraint system on the front passen ger seat
is dangerous under certain conditions
Your vehicle is equipped with front passenger occupant classifi cation sen-
sor. Even with the front passenger occupant classification sensor, if you
must use the front passenger seat to seat a child, using a chil d-restraint
system on the front passenger seat under the following conditio ns
increases the danger of the front passenger air bag deploying a nd could
result in serious injury or death to the child.
● The front passenger air bag deactivation indicator light does not illuminate
when seating a child in the child-restraint system.
● Luggage or other items are placed on the seat with the child in the child-
restraint system.
● A rear passenger or luggage pushing or pulling down on the front passen-
ger seatback.
● Luggage or other items are placed on the seatback or hung on the head
restraint.
● The seat is washed.
● Liquids are spilled on the seat.
● The front passenger seat is moved backward, pushing into luggag e or
other items placed behind it.
● The front passenger seatback contacts the rear seat.
● Luggage or other items are placed between the front passenger s eat and
driver seat.
● An electric device is put on the front passenger’s seat.
● An additional electrical device, such as a seat warmer is installed to the
surface of the front passenger seat.
The designated positions with seat belts on the rear seats are the safest
places for children. Always use seat belts and child restraints .
Page 48 of 572

48
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-3. Child Restraint
WARNING
■Do not allow a child or anyone to lean over or against the side window
of a vehicle with side and curtain air bags
It is dangerous to allow anyone to lean over or against the sid e window, the
area of the front passenger seat, the front and rear window pil lars and the
roof edge along both sides from which the side and curtain air bags deploy,
even if a child-restraint system is used. The impact of inflati on from a side or
curtain air bag could cause serious injury or death to an out of position child.
Furthermore, leaning over or agai nst the front door could block the side and
curtain air bags and eliminate the advantages of supplemental p rotection.
With the front air bag and the additional side air bag that comes out of the
front seat, the rear seat is always a better location for child ren. Take special
care not to allow a child to lean over or against the side wind ow, even if the
child is seated in a child-restraint system.
■ Never use one seat belt on more than one person at a time
Using one seat belt for more than one person at a time is dangerous. A seat
belt used in this way cannot spread the impact forces properly and the two
passengers could be crushed together and seriously injured or even killed.
Never use one belt for more than one person at a time and alway s operate
the vehicle with each occupant properly restrained.
■ To prevent burns
A seat belt or child-restraint system can become very hot in a closed vehicle
during warm weather. To avoid burning yourself or a child, check them
before you or your child touches them.
Page 49 of 572

49
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-3. Child Restraint
1
Essential Safety Equipment
Child-Restraint System Installation
In this owner’s manual, explanat ion of child-restraint systems is pro-
vided for the following three types of popular child-restraint systems:
infant seat, child seat, booster seat.
Child-Restraint System Types
Infant seatChild seat
An infant seat provides restraint
by bracing the infant’s head, neck
and back against the seating sur-
face. A child seat restrains a child’s
body using the harness.
Booster seat
A booster seat is a child restraint
accessory designed to improve
the fit of the seat belt system
around the child’s body.
Page 50 of 572

50
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-3. Child Restraint
●Installation position is determined by the type of child-restra int system.
Always read the manufacturer’s instructions and this owner’s ma nual care-
fully.
● Due to variations in the design of child-restraint systems, veh icle seats and
seat belts, all child-restraint systems may not fit all seating positions. Before
purchasing a child-restraint system, it should be tested in the specific vehi-
cle seating position (or positions) where it is intended to be used. If a previ-
ously purchased child-restraint system does not fit, you may ne ed to
purchase a different one that will.
