Yaris iA_Navi_OM99N92z_(U)
• - The navigation system includes ferries in a planned
route by default. However, a map does not necessarily contain information
about the accessibility of temporary ferr ies. You might also need to pay a
fare on ferries.
• - Setting in which routes with carpool lanes can be created or not created.
• - A border crossing may be a shorter route depending on the route. For this function, you can select whether or not to
cross a border when planning the route.
• - The navigation system excludes unpaved roads by default: unpaved roads can be in a bad condition and usually you
cannot reach the speed limit on them.
4. The route has already been recalculate d. Select to return to the Map
screen.
Some functions are not available depending on some countries and regions.

72Yaris iA_Navi_OM99N92z_(U)
3.4 Saving a location as a Favorite destination
You can add any location to Favorites, the list of frequently used destinations.
Planning a route to one of the Favorite destinations is described on page 58.1. Select a destination as described before. It can be an address, a Place, any location on the map, a previously used destination from History, etc.
2. A searched destination can be re gistered to Favorites by selecting
on the verification screen of the destination search
results.
3.4.1 Editing the details of a Favorite destination
You can select a location that you have already saved as a Favorite and edit its
details. Adding a location to the list of Favorite destinations is described on page 72. 1. Press the Favorites button on the commander switch.
2. Select the Navigation tab.
3. The list of Favorite destinations is displayed.

73
1
2
3
4
5
6
Yaris iA_Navi_OM99N92z_(U)
The following functions can be used by selecting Add/Edit Navigation
Favorite.
Add Current Location
: Set the current location to Favorites.
Add Current Destination : Register the current destination to Favorites.
Add from Contact : Register an address registered to the contacts list.
Move : Switch the Favorites order.
Delete : Delete the registered Favorites.
Your home address can be registered/changed by selecting Home.
The following functions can be used by selecting the registered Favorites.
Replace with Current Location : Set the current location to Favorites.
Replace with Current Destination : Register the current destination to
Favorites.
Replace with Address from Contacts : Register an address registered to the
contacts list.
Move : Switch the Favorites order.
Rename : Edit the registered Favorites name.
Delete : Delete the selected Favorites.

74Yaris iA_Navi_OM99N92z_(U)
4 Reference Guide
4.1 Concepts
4.1.1 Smart Zoom
Smart Zoom provides much more than just a usual automatic zoom feature:
• While following a route: when approaching a turn, it will zoom in and raise the
view angle to let you easily recognize your maneuver at the next junction. If the
next turn is at a distance, it will zoom out and lower the view angle to be flat so
you can see the road in front of you.
• While driving without an active route: Smart Zoom will zoom in if you drive
slowly and zoom out when you drive at high speed.
• Off: Turns the Smart Zoom setting off.
4.1.2 Route calculat ion and recalculation
The navigation system calculates the route based on your preferences:
• Route planning methods: • : Gives a quick route if you can tr avel at or near the speed limit
on all roads.
• : Gives a route that has the smallest total distance of all possible routes.
• : This method combines the merits of the Fast and
Short routes: The navigation system makes a calculation for the Fast
route, but it also includes other road s in the calculation in consideration
of fuel economy.
• : Results in a route with fewer turns and no difficult maneuvers. With this option, you can make the navigation system take, for example,
the highway/freeway instead of a series of smaller roads or streets.

75
1
2
3
4
5
6
Yaris iA_Navi_OM99N92z_(U)
• Road type used for route plan:
•
•
•
•
•
•
•
Whenever data exist, route calculation take s into account historical traffic data for
the given day of week and time of day (page 78).
If the setting for Traffic Settings is valid, Real-time Traffic events are taken into
account and the route is largely modified.
The navigation system automa tically recalculates the route if you deviate from the
proposed itinerary or if a newly received Traffic event concerns a part of the
recommended route.
For further information about Route Settings see page 82.
Some functions are not available depending on some countries and regions.

76Yaris iA_Navi_OM99N92z_(U)
4.1.3 Road safety cameras and other proximity alert points (Only some
countries and regions)
There is a special proximity warning for road safety camer as (like speed or red light
cameras) and other proximity alert points (like schools or railroad crossings).
The application can warn you when you a pproach road safety cameras like speed
cameras or dangerous areas li ke school zones or railroad crossings. You can set up
the different alert type s individually in Warning Settings (page 80).
The following alert types are available:
• Audio warning: When appr oaching one of these points, a beep sound (regular
sound) can be used or the type of warning can be announced (TTS), and an extra
alert can warn you if you exceed the given speed limit while approaching the point.
• Always: The type of the alert point, its distance, and the related speed limit appear
on the Map screen while you are approaching one of these points.
For some of the alert points, the enforced or expected speed limit is available. For
these points, the audio alert can be diff erent if you are below or above the given
speed limit.
Setting can be selected using Warning Settings:
• Only when speeding: The audio alert is only played when you exceed the given
speed limit.
• When approaching: The audio alert is always played when approaching one of these alert points. To draw you attentio n, the alert may differ if you exceed the
speed limit.
The warning for road safety cameras is di sabled when you are in a country where
road safety camera warning is prohibited. However, you must ensure on your own
liability that using this feature is legal in the country where you intend to use it.

77
1
2
3
4
5
6
Yaris iA_Navi_OM99N92z_(U)
4.1.4 Speed limit warning (Onl
y some countries and regions)
Maps may contain information about the speed limits of the roads. The navigation
system is able to warn you if you exceed the current limit. This information may not
be available for your region (ask your local dealer), or may not be fully correct for all
roads on the map.
Except vehicles with Active Dr iving Display (Windshield type)
The speed warning can be set from the Warning Settings (page 80).
Setting can be selected using Warning Settings:
• Audio warning: You will hear a warning beep if you exceed the speed limit by a certain percentage.
• Visual warning (other than vehicles with Traffic Sign Recognition System (TSR)):
If you exceed the speed limi t on a road, the speed limit for the current road is
shown on the map.
• Visual warning (vehicles with Traffic Sign Recognition System (TSR)): If you exceed the speed limit on a road, the speed limit for the current road is shown in
the active driving display.
You can also choose to see the speed limit sign on the map all the time.
Vehicles with Active Drivin g Display (Windshield type)
1. Select the icon on the home scr een to display the Settings screen.
2. Select the tab.
3. Press the icon on the screen to select the item you
would like to change.
Safety
Speed Limit Warning

78Yaris iA_Navi_OM99N92z_(U)
4.1.5 Traffic information in
route planning (Only some countries and regions)
The recommended route is not always the same between two points. Offline
historical traffic info rmation (historical speed informat ion or traffic patterns) can be
taken into account in the route calculation based on the time of day and the day of
week whenever suitable data exists. In addition, real-time traffic information can
help you avoid current traffic events like temporary road closures or a traffic jam
caused by an accident. Both functions are subject to data availability.
Select after selecting on the MA P screen to display the historical
traffic information on the map. A 2D map is displayed with road segments colored
by the density of the traffic in the given period. The current information is shown
when you open the screen. Modify the day of week and the time of day to see the
desired period.
4.1.5.1 Historical traffic
If historical traffic informat ion is available with the map data, the navigation system
can use it when planning a route. In norma l cases, these statistics help you avoid
usual traffic jams on the given day of week in the given hour but in some cases like
on public holidays that fall on normal weekdays, they can be misleading. You can
disable this feature in Traffic Settings (page 81).
Select after selecting on the MAP screen to display the historical
traffic information on the map.

79
1
2
3
4
5
6
Yaris iA_Navi_OM99N92z_(U)
4.2 Settings menu
You can configure the program settings, and modify the behaviour of the navigation
system. Select after sel ecting on the MAP screen.
ButtonDescription
You can fine-tune the appearan ce of the Map screen. Adjust
the map view to your needs, show or hide 3D buildings, and
manage POI (point of interest) display settings (which POI to
show on map).
A guidance-related setting is available during route guidance.
A setting related to warnings is available.
Refer to Changing the road types used in route planning
(page 70).
A setting for traffic information is available.
A setting for on-line service is available.
Some functions are not available depending on some countries and regions.

80Yaris iA_Navi_OM99N92z_(U)
4.2.1 Guidance Settings
4.2.2 Warning Settings
Warning and alert settings are available.
ButtonDescription
The guidance audio volume can be changed during
route guidance.
ButtonDescription
The following alert types are available:
: No display and sound
: Only display : Both sound and display
* If the guidance volume is set to 0, the speed limit notification is also 0 because it is part of the guidance.
* Except vehicles with Active
Driving Display
(Windshield
type) The speed limit warning
display can be changed.
: Constantly displayed
: Displays only when vehicle speed
exceeds speed limit
A setting is available which sou nds a beep at alert points, and
it can be set to on or off. In addition, detailed settings
concerning the warning can be made.
: No display and sound
: Only display : Both sound and display
The speed camera warning setting can be changed.
: No display and sound
: Only display : Both sound and display
