VOLVO C70 CONVERTIBLE 2007 Owner´s Manual

2007 Volvo C70
At higher speeds

If the car is moving at a speed above approximately 4 m.p.h. (7 km/h),\
the Warning symbol in the instrument panel
will light up and a message will be shown in the information display ind\
icating which door(s), etc is not completely
closed.
Hood and trunk

If the hood and/or trunk lid is not completely closed, the Information s\
ymbol in the instrument panel will light up and
a message will be displayed, regardless of the vehicle's speed.
53 02 Instruments and controls
Information display
Messages
When an indicator or warning light in the instrument panel comes on, a m\
essage is also shown in the information
display. To read a message:
1. Press the READ button (1).
2. Pressing READ repeatedly enables you to scroll to any other messages \
that may be stored.
file:///K|/delme/2007_C70/07c70_02.htm (13 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
NOTE
If a message is displayed when e.g. you are using the trip computer, thi\
s message must be read before you can
access the trip computer
54 02 Instruments and controls
Information display
Message Meaning
STOP SAFELY Stop the car in a safe place and switch off the engine to help prevent t\
he risk of
serious damage.
STOP ENGINE Stop the car in a safe place and switch off the engine to help prevent t\
he risk of
serious damage.
SERVICE URGENT Take your car to a trained and qualified Volvo service technician for in\
spection
immediately.
SEE MANUAL Refer to your owner's manual. For additional information, please contact\
a
trained and qualified Volvo service technician.
SERVICE REQUIRED Take your car to a trained and qualified Volvo service technician for in\
spection
as soon as possible (but preferably before the next scheduled maintenan\
ce
service).
TIME FOR REGULAR
SERVICE This message is affected by the number of miles/km driven, by the number\
of
months, or by the number of engine hours since the service reminder was \
reset
at the most recent regularly scheduled service.
REMINDER CHECK OIL
LEVEL Check the oil level when this message is displayed. See
page 191.
DSTC SPIN CONTROL OFF The stability system's spin control function has been turned off. See
page 138
for details.
55 02 Instruments and controls
Lighting panel
file:///K|/delme/2007_C70/07c70_02.htm (14 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
Pos. Lighting

Daytime running lights/headlights off. High beam flash only.
Parking lights
Daytime running lights. High beams and high beam flash can be used in th\
is
position.
Parking lights
The front and rear parking lights can be turned on even when the ignitio\
n is switched off.
l Turn switch (1) to position .
The license plate lights also illuminate when the parking lights are swi\
tched on.
Headlights
1. Turn the ignition key to position II.
2. The low beam headlights (daytime running lights) illuminate automat\
ically, except when the light switch (1) is in
position
1.
NOTE
See
page 57 for information on switching between high and low
beams.
Fog lights
Front fog lights (option)
The front fog lights can be used in combination with either the headligh\
ts or the parking lights.
file:///K|/delme/2007_C70/07c70_02.htm (15 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
1. Turn the ignition to position II.
2. Press button (3) to turn on the front fog lights.
An indicator light in the button illuminates when the front fog lights a\
re on.
Rear fog light
The single rear fog light is located in the driver's side taillight clus\
ter.
The rear fog light will only function in combination with the high/low b\
eam headlights or the optional front fog lights.
1. Turn the ignition key to position II.
2. Press button (5) to turn on the rear fog light.
An indicator light in the button illuminates when the rear fog light is \
on.
NOTE
The rear fog light is considerably brighter than the normal taillights a\
nd should be used only when conditions such
as fog, rain, snow, smoke or dust reduce visibility for other vehicles t\
o less than 500 ft. (150 meters).
1On Canadian models, the daytime running lights will remain on with the l\
ight switch in this position.
56 02 Instruments and controls
Lighting panel
Instrument panel lighting
The instrument panel lighting illuminates when the ignition is in positi\
on II and the light switch (1) is in either
position
or .
NOTE
To make it easier to read the odometer, trip odometer, clock, and ambien\
t temperature, these gauges illuminate
when the vehicle is unlocked and when the key has been removed from the \
ignition switch. The lighting will go out
when the vehicle is locked.
l Move the thumb wheel (2) up to increase brightness or down to decrease\
brightness.
Unlocking the fuel filler door
file:///K|/delme/2007_C70/07c70_02.htm (16 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
With the ignition switched off, press button (4) to unlock the fuel fi\
ller door. Please note that the fuel filler door will
remain unlocked until the car begins to move forward.
An audible click will be heard when the fuel filler door re-locks.
Please refer to the following information for instructions on manually o\
pening the fuel filler door.
Manually unlocking the fuel filler door
If it should be necessary to manually unlock the fuel filler door from t\
he trunk, the power retractable hard top should
be up.
1. Remove the panel covering the taillight housing on the right side of \
the trunk.
2. Pull the cord that is attached to a hook to pop open the fuel filler \
door.
When the fuel filler door has opened, return the cord to the hook and re\
place the taillight cover panel.
57 02 Instruments and controls
Left-side steering wheel lever
Lever positions
file:///K|/delme/2007_C70/07c70_02.htm (17 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
1. Turn signals, lane change position
2. Turn signals, position for normal turns
3. High beam flash
4. Toggle between high and low beams, Home Safe lighting
Turn signals
When turning
l Move the lever as far up or down as possible (to position 2) to start \
the turn signals.
The turn signals will be cancelled automatically by the movement of the \
steering wheel, or the lever can be returned
to its initial position by hand.
When changing lanes
The driver can automatically flash the turn signals 3 times by:
l Moving the turn signal lever up or down to position 1 and releasing it. \
l Moving the lever up or down to position 2 and immediately back to its or\
iginal position.
NOTE
l This automatic flashing sequence can be interrupted by immediately movin\
g the lever in the opposite
direction.
l If the turn signal indicator flashes faster than normal, check for a bur\
ned-out turn signal bulb.
High/low beam headlights
Continuous high beams
1. Turn the ignition key to position II.
2. With the light switch (1) in position
, (see page 55) pull the turn signal lever toward the steering wheel (position
file:///K|/delme/2007_C70/07c70_02.htm (18 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
4) to toggle between high and low beams.
High beam flash
1. Turn the ignition key to position II.
2. Pull the turn signal lever to position
3. The high beams will remain on until the lever is released.
Home safe lighting
When you leave your car at night, you can make use of the home safe ligh\
ting function to illuminate the area in front
of the car.
1. Remove the key from the ignition switch.
2. Pull the direction indicator lever as far as possible towards the ste\
ering wheel (to position 4) and release it.
3. Exit the car and lock the doors.
The headlights and parking lights will illuminate and remain on for 30
1, 60 or 90 seconds. The time interval can be
changed according to your preferences by using the Personal Settings fun\
ction, see
page 72 for more information.
1Factory setting
58 02 Instruments and controls
Trip computer
The trip computer stores information gathered from several systems in yo\
ur car and has four menus (five on Canadian
models) that can be shown in the information display.
l MILES TO EMPTY TANK
l AVERAGE (average fuel consumption)
file:///K|/delme/2007_C70/07c70_02.htm (19 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
l INSTANTANEOUS (current fuel consumption)
l AVERAGE SPEED
l DSTC (see page 138 for detailed information.)
l ACTUAL SPEED (current speed in m.p.h., Canadian models only)
NOTE
Warning messages from the car's monitoring systems will override the tri\
p computer
function.
If a warning message is shown in the information display while you are u\
sing the trip computer:
1. You must acknowledge the message by pressing the READ button (A).
2. Press button A again to return to the trip computer function.
Controls
The trip computer functions can be accessed by twisting INFO (B) one s\
tep at a time in either direction. Twisting a
final time returns you to the original function.
The trip computer can be reset (average fuel consumption and average sp\
eed will be erased from system memory) by
pressing RESET (C) for at least five seconds.
MILES TO EMPTY TANK
This function shows the approximate distance that can be driven on the f\
uel remaining in the tank. This calculation is
based on average fuel consumption during the last 20 miles (30 km) of \
driving and the amount of fuel remaining in
the tank when the reading was taken. When the driving distance on curren\
t fuel reserve is less than 12 miles (20 km),
"----" will be displayed in the information display.
AVERAGE
This value indicates fuel consumption since the last time the trip compu\
ter was reset (by pressing RESET, button C).
When the engine is switched off, information on fuel consumption is stor\
ed and remains in system memory until the
RESET (button C) is pressed again.
INSTANTANEOUS
This value indicates the current fuel consumption, based on readings tak\
en once per second. When the car is not
moving, "----" will be displayed.
AVERAGE SPEED
This value indicates average speed since the last time the trip computer\
was reset (by pressing RESET, button C).
When the engine is switched off, information on average speed is stored \
and remains in system memory until the
RESET (button C) is pressed again.
59 02 Instruments and controls
file:///K|/delme/2007_C70/07c70_02.htm (20 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
Trip computer
ACTUAL SPEED (Canadian models only)
This function provides the driver with an instantaneous conversion of th\
e car's current speed from km/h to m.p.h.
NOTE
Trip computer readings may vary slightly depending on the circumference \
of the tires on the car, tire inflation, or
driving style.
60 02 Instruments and controls
Right-side steering wheel lever
Windshield wipers
A. Windshield/headlight washers
B. Rain sensor (option) - on/off
C. Thumb wheel
D. Not in use
Windshield wipers off

The windshield wipers are off when the lever is in position 0.
file:///K|/delme/2007_C70/07c70_02.htm (21 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
Manual wiper function

From position 0, move the lever upward. The windshield wipers will sweep\
one stroke at a time for as long as the
lever is held up.
Intermittent wiper function

With the lever in this position, you can set the wiper interval by movin\
g the thumb wheel (C) upward to increase
wiper speed or downward to decrease the speed.
Continuous wiper function
The wipers operate at "normal" speed.

High speed wiper function.
A -Windshield washers
Pull the lever toward the steering wheel and release it. The wipers will\
make 2-3 sweeps across the windshield after
the lever has been released.
CAUTION
Use ample washer fluid when washing the windshield. The windshield shoul\
d be thoroughly wet when the wipers
are in operation.
Headlight washers (certain models)
When the lever has been pulled, high pressure jets mounted in the bumper\
will spray the headlights.
The following applies to conserve washer fluid (see
page 55 for information on the light switch positions):
Low/high beam headlights on
file:///K|/delme/2007_C70/07c70_02.htm (22 of 43)12/22/2006 9:15:42 PM\
