Page 261 of 400
05 Infotainment system
Voice recognition* mobile phone
05
* Option/accessory, for more information, see Introduction.259 Introduction
The infotainment system's voice recognition1
allows the driver to voice-activate certain func-
tions in a Bluetooth Ÿ-connected mobile phone
or in Volvo's navigation system - RTI (Road and
Traffic Information System).
NOTE
•The information in this section
describes the use of voice commands
to control a mobile phone connected
using Bluetooth
Ÿ. For detailed infor-
mation on using a mobile phone con-
nected using Bluetooth
Ÿ with the car's
Infotainment system see page 251.
•The Volvo navigation system RTI (Road
and Traffic Information System) has a
separate user manual which contains
more information on voice control and
voice commands to control that sys-
tem.
Voice commands offer convenience and help
the driver to avoid being distracted, and
instead concentrate on driving and focus
attention on the road and traffic conditions.
WARNING
The driver always holds overall responsibil-
ity for driving the vehicle in a safe manner
and complying with all applicable rules of
the road.
The voice recognition system allows the driver
to voice-activate certain functions of a
Bluetooth
Ÿ-connected mobile phone and in
Volvo's navigation system - RTI (Road and
Traffic Information System), while the driver
can keep his/her hands on the wheel at the
same time. The input data are in dialogue form
with spoken commands from the user and ver-
bal replies from the system. The voice recog-
nition system uses the same microphone as
the Bluetooth
Ÿ handsfree system (see illustra-
tion on page 251) and the voice recognition
system's replies come via the car's speakers.
Language
Language list.
Voice recognition is not possible for all lan-
guages. Languages available for voice recog-
nition are marked with an icon in the language
list -
. Changing the language is performed
in the menu system MY CAR, see page 146.
1Only applies to vehicles equipped with Volvo's navigation system - RTI (Road and Traffic Information System).
ProCarManuals.com
Page 262 of 400
05 Infotainment system
Voice recognition* mobile phone
05
260* Option/accessory, for more information, see Introduction.
Remember
Steering wheel keypad.
Button for voice recognition
To activate the systemBefore voice commands to a mobile phone can
be used the mobile phone must be paired and
connected via Bluetooth
Ÿ handsfree. If a tele-
phone command is given and no mobile phone
is paired, then the system will provide informa-
tion about this. For information on pairing and
connecting a mobile phone, see page 252.
•Press the button for voice recognition (1) in
order to activate the system and initiate a
dialogue with voice commands. The sys-
tem will then display commonly used com-
mands in the TV screen in the centre con-
sole.Keep the following things in mind when you use
the voice recognition system:
•For a command - speak after the tone, with
normal voice at normal speed.
•Do not speak while the system is replying
(the system cannot understand commands
during this time).
•The car's doors, windows and sunroof*
must be closed.
•Avoid background noise in the passenger
compartment.
NOTE
If the driver is unsure of which command to
use, he (she) can say "Help" - the system
then responds with a few different com-
mands which can be used in the current sit-
uation.
Voice commands can be disabled by:
•saying "Cancel"
•not speaking
•a long press on the steering wheel but-
ton for Voice recognition
•Press EXIT or another source button
(e.g. MEDIA).
Help functions for voice recognition
•Instructions: A function that helps you get
familiar with the system and the procedure
for giving commands.
•Voice training: A function that enables the
voice recognition system to learn to know
your voice and your accent. The function
provides an opportunity to voice train two
user profiles.
The help functions can be accessed by press-
ing the MY CAR button on the control panel in
the centre console and then turning TUNE to
the desired menu option.
InstructionsThe instructions can be started in two ways:
NOTE
This instruction and voice training can only
be started when the car is parked.
•Press the button for Voice recognition and
say "Voice instructions".
•Activate the instructions in the menu sys-
tem MY CAR under Settings
Voice
settings
Voice tutorial. For a descrip-
tion of the menu system, see page 144.
The instructions are divided into 3 lessons,
which take around 5 minutes in total to com-
plete. The system starts with the first lesson.
ProCarManuals.com
Page 263 of 400
05 Infotainment system
Voice recognition* mobile phone
05
* Option/accessory, for more information, see Introduction.261
To skip a lesson and go to the next one, press
the button for voice recognition and say
"Next". Go back to the previous lesson by say-
ing "Previous".
Exit the instructions by means of a long press
on the button for voice recognition.
Voice trainingThe system displays up to fifteen phrases for
you to say. Voice training can be started in the
menu system MY CAR under Settings
Voice settingsVoice training. Choose
between
User 1 or User 2. For a description
of the menu system, see page 144.
After voice training has been completed,
remember to set your user profile under
Voice
user setting.
Additional settings in MY CAR
•User setting - Two user profiles can be
set, the function is activated in the menu
system MY CAR under Settings
Voice
settings
Voice user setting. Choose
between
User 1 or User 2. For a descrip-
tion of the menu system, see page 144.
•Voice volume - Can be changed in the
menu system MY CAR under Settings
Voice settingsVoice output
volume. For a description of the menu sys-
tem, see page 144.
Using voice commands
The driver initiates a dialogue with the voice
commands by pressing the button for voice
recognition (see illustration on page 260).
Once a dialogue has been started, commonly
used commands will be shown in the TV
screen. Greyed-out text or text within brackets
is not included in the spoken command.
When the driver becomes accustomed to the
system, he/she can speed up the command
dialogue and skip the prompts from the sys-
tem, by briefly pressing the button for voice
recognition.
Commands can be given in several ways
The command "Phone call contact" can be
pronounced as e.g.:
•"Phone > Call contact" - Say "Phone", wait
for the system's reply, and then continue
by saying "Call contact."
or
•"Phone call contact" - Say the whole com-
mand in one sequence.
Quick commandsQuick commands for the phone can be found
in the menu system MY CAR under Settings
Voice settingsVoice command list
Phone commands and Generalcommands
. For a description of the menu
system, see page 144.
Dial a numberThe system understands the numbers 0 (zero)
to 9 (nine). These numbers can be pronounced
individually, in groups of several numbers at a
time, or the whole number all at once. Numbers
greater than 9 (nine) cannot be handled by the
system, e.g. 10 (ten) or 11 (eleven) are not pos-
sible.
The following is an example of a dialogue with
voice commands. The system's reply will vary
depending on the situation.
The user starts the dialogue by saying:Phone > call number
or
Phone call number
System replyNumber?
User actionStart saying the numbers (as individual units,
i.e. six-eight-seven, etc.) in the phone number.
If you say several numbers and pause, the sys-
tem will repeat them, and then say "Continue".
Continue to say the numbers. When finished,
finish the command by saying "Call".
•You can also change the number by saying
the commands "Correct" (which deletes
ProCarManuals.com
Page 264 of 400
05 Infotainment system
Voice recognition* mobile phone
05
262* Option/accessory, for more information, see Introduction.
the last spoken group of numbers) or
"Delete" (which deletes the whole spoken
phone number).
Dialling from the call registerThe following dialogue allows you to make a
phone call from one of your mobile phone's call
registers.
The user starts the dialogue by saying:Phone > call from the call register
or
Phone call from the call register
Continue by responding to the system's
prompts.
Call a contactThe following dialogue allows you to call your
pre-defined contacts in the mobile phone.
The user starts the dialogue by saying:Phone > call contact
or
Phone call contact
Continue by responding to the system's
prompts.
Consider the following when you call a contact:
•If there are several contacts with similar
names, they will be presented in the dis-play in the numbered rows and the system
prompts you to select a row number.
•If there are more rows in the list than can
be displayed simultaneously, saying
"Down" allows you to scroll down in the list
(and saying "Up" allows you to scroll up in
the list).
Calling voice mailboxThe following dialogue allows you to call your
voice mailbox to check if you have received
any messages. The phone number for your
voice mailbox must be registered in the
Bluetooth
Ÿ function, see page 254.
The user starts the dialogue by saying:Phone > call voice mailbox
or
Phone call voice mailbox
Continue by responding to the system's
prompts.
ProCarManuals.com
Page 265 of 400
05 Infotainment system
Menu navigation, Infotainment
05
* Option/accessory, for more information, see Introduction.263 To navigate in the menus
The infotainment system's functions are con-
trolled via the system's menus. Each source in
the infotainment system (e.g. RADIO, MEDIA)
has its own separate menus. In order to access
the menus and activate a function a source
must first have been selected (e.g.
RADIO/FM1). Then press OK/MENU for access into
the menu for the selected source.
The menu options are selected by means of the
buttons in the centre console or via the steering
wheel keypad*. The functions are described
under their respective sections.
Controls in the centre console
RADIO
MEDIA
TEL
TUNE
OK/MENU
Search pathsThe search paths to the menu functions are
specified in the owner's manual with the form:Audio settings
Equalizer, which requires
that the following is carried out beforehand:
1. Select a source by pressing one of the but-
tons (e.g. RADIO, MEDIA etc.). Continue
to press in order to scroll down among the
options on the TV screen (e.g.
FM1),
release and wait a second and the selec-
tion is accepted automatically. Alterna-
tively, turn TUNE and confirm with OK/
MENU.
2.
Press OK/MENU and turn TUNE, or use
the thumbwheel* on the steering wheel
keypad to reach the desired menu option
e.g.
Audio settings and press OK/
MENU.
3.
Turn TUNE again to reach the desired sub-
menu, e.g.
Equalizer, and press OK/
MENU.
Menus RADIO
Main menu AMAM menu
Show presets1
Scan
1Only applies to High Performance Multimedia and Premium Sound Multimedia.
ProCarManuals.com
Page 266 of 400
05 Infotainment system
Menu navigation, Infotainment
05
264* Option/accessory, for more information, see Introduction.
Audio settings2
Sound stage3
Equalizer4
Volume compensation
Reset all audio settings
Main menu FM1/FM2FM menu
TP
Show radio text
Show presets1
Scan
News settings
Advanced settings
REG
Alternative frequency
EON
Set TP favourite
PTY settingsReset all FM settings
Audio settings5
Main menu DAB1*/DAB2*DAB menu
Ensemble learn
PTY filtering
Turn off PTY filtering
Show radio text
Show presets1
Scan
Advanced settings
DAB linking
DAB band
Sub channels
Show PTY text
Reset all DAB settings
Audio settings5
Menus MEDIA
Main menu CD AudioDisc menu
Random
Scan
Audio settings5
Main menu CD/DVD1 DataDisc menu
Play/Pause
Stop
Random
Repeat folder
Change subtitle
Change audio track
Scan
Audio settings5
2The menu options for audio settings are the same for all audio sources.3Only applies to Premium Sound Multimedia.4Does not apply to Performance.1Only applies to High Performance Multimedia and Premium Sound Multimedia.5For submenus, see "Main menu AM".
ProCarManuals.com
Page 267 of 400
05 Infotainment system
Menu navigation, Infotainment
05
* Option/accessory, for more information, see Introduction.265
Main menu DVD1 VideoDisc menu
DVD disc menu
Play/Pause/Continue
Stop
Subtitles
Audio tracks
Advanced settings
Angle
DivX® VOD code
Audio settings5
Main menu iPod4
iPod menu
Random
Scan
Audio settings5
Main menu USB4
USB menu
Play/Pause
Stop
Random
Repeat folder
Select USB device
Change subtitle
Change audio track
Scan
Audio settings5
Main menu Media Bluetooth4
Bluetooth menu
Random
Change device
Remove Bluetooth device
Scan
Bluetooth software version in car
Audio settings5
Main menu AUXAUX menu
AUX input volume
Audio settings5
Main menu TV*TV menu
Select country
Reorganize presets
Autostore
Scan
Audio settings5
Pop-up menu6 video and TV*
Press OK/MENU when a video file is being
played back or TV* is being shown in order to
access the pop-up menu.
Image settings
1Only applies to High Performance Multimedia and Premium Sound Multimedia.5For submenus, see "Main menu AM".4Does not apply to Performance.6Only applies when playing back videos or displaying TV*.
ProCarManuals.com
Page 268 of 400
05 Infotainment system
Menu navigation, Infotainment
05
266
Source menu7
DVD video menu8
DVD disc TOP menu8
Menus TEL
Main menu Bluetooth Ÿ Ÿ handsfree4
Phone menu
All calls
All calls
Missed calls
Answered calls
Dialled calls
Call duration
Phone book
Search
New contact
Speed dials
Receive vCard
Memory status
Clear phone bookChange phone
Remove Bluetooth device
Phone settings
Discoverable
Sounds and volume
Phonebook download
Bluetooth software version in
car
Call options
Auto answer
Voicemail number
Disconnect phone
7What is shown in the pop-up menu for the source menu depends on what is being played back or displayed, it can be e.g. Disc menu or USB menu.8Only applies to DVD video discs.4Does not apply to Performance.
ProCarManuals.com
Page 269 of 400
05 Infotainment system
05
267ProCarManuals.com
Page 270 of 400
268
Recommendations during driving......................................................... 270
Refuelling.............................................................................................. 273
Fuel....................................................................................................... 274
Loading................................................................................................. 278
Cargo area............................................................................................ 280
Driving with a trailer.............................................................................. 283
Towing and recovery............................................................................. 289
ProCarManuals.com
