VOLVO XC70 2004 Owners Manual

2004 VOLVO XC70
NOTE: Please be aware that if the tailgate is unlocked using the tailgate unlo\
ck button, opened, and
closed again, it will remain unlocked and the alarm will not be rearmed. Press the lock button on the
remote control to relock the tailgate and rearm the alarm.

Central locking buttons
Central locking buttons
These buttons (located on the both front door armrests) can be used to\
lock/unlock all doors and the
tailgate and set the alarm.
The rear passenger doors can also be locked and unlocked with the indivi\
dual lock buttons on each door.

pg. 80 Alarm
Alarm
The alarm is automatically armed whenever you lock your car. When armed,\
the alarm continuously
monitors a number of points on the car. The following conditions will se\
t off the alarm:
l The hood is forced open.
l The tailgate is forced open.
l A door is forced open.
l The ignition switch is tampered with.
l If there is movement in the passenger compartment (if the car is equipp\
ed with the optional movement
sensor).
l The car is lifted or towed (if the car is equipped with the optional in\
clination sensor).
l The battery is disconnected (while the alarm is armed).
Arming the alarm
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (7 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
Press the LOCK button on the remote control, lock the car using the key \
in the driver's door or press the
central lock button on one of the front doors with the door open. One lo\
ng flash of the turn signals will
confirm that the alarm is armed.
Disarming the alarm
Press the UNLOCK button on the remote control or unlock the doors with t\
he key.
Turning off (stopping) the alarm
If the alarm is sounding, it can be stopped by pressing the UNLOCK butto\
n on the remote control or by
unlocking the driver's door with the key.
Visual alarm signal
The visual alarm signal is given by flashing all turn signals and turnin\
g on the interior lighting for
approximately 5 minutes.
Audible alarm signal
An audible alarm signal is given by a battery powered siren. One alarm c\
ycle lasts for 25 seconds.
"Panic" button
In an emergency situation, this feature can be used to attract attention\
. Activate the "panic" function by
pressing the red button on the remote control (see illustration on
page 77) for at least 3 seconds or by
pressing this button twice within 3 seconds. The turn signals will flash\
, the interior lights will go on and
the car's horn will sound.
The function can be turned off by pressing any of the buttons on the rem\
ote control or will stop
automatically after 25 seconds. When a button is pressed, there is a 5 s\
econd delay before the
panic alarm is deactivated.
NOTE: This function will NOT unlock the car.

pg. 81 Alarm

file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (8 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
Temporarily turning off the inclination and movement alarm
sensor(s) - accessory
This button will only be found in cars equipped with the accessory incli\
nation and/or movement sensors.
FCC ID: MAYDA5823
This device complies with part 15 of the FCC rules. Operation is subject\
to the following conditions: (1)
This device may not cause harmful interference, and (2) this device mu\
st accept any interference
received, including interference that may cause undesired operation.
Canadian IC: 4405A-DA5823
Movement sensor DA5823 by Dynex
Operation is subject to the following conditions: (1) this device may \
not cause interference, and (2) this
device must accept any interference, including interference that may cau\
se undesired operation of the
device.
In certain situations it may be desirable to turn off the optional incli\
nation and movement alarm sensors
if, for example, you drive your car onto a ferry where the rocking of th\
e boat could trigger the alarm or if
a pet is left in the car with the doors locked.
To temporarily turn off the inclination and movement alarm sensors from \
the alarm system:
From the time the ignition key is turned from the Drive position (posit\
ion II) until you lock the car, you
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (9 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
can press the button in the center console. The LED in the switch will l\
ight up and a message will be
displayed in the text window to indicate that the sensors are disconnect\
ed.
The car can then be locked in the usual way to set the alarm.
NOTE:
l This function will not turn off the vehicle's standard alarm.
l The optional sensors are automatically reconnected to the alarm system t\
he next time the car is
unlocked and then locked again.
LED alarm status signals
The status of the alarm system is indicated by the red LED at the top of\
the dash:
l LED off - the alarm is not armed
l LED flashes once per second - the alarm is armed
l LED flashes rapidly before the ignition is switched on - the alarm has b\
een triggered
l Fault in the alarm system: If a fault has been detected in the alarm system, a message will be
displayed in the text window. Contact a Volvo retailer.
Automatic re-lock/re-arm system
If the car is unlocked with the remote, the car will re-lock and the ala\
rm will re-arm after 2 minutes
unless a door or the tailgate has been opened.

pg. 82 Child safety locks - rear doors

Child safety lock control in left rear

file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (10 of 11)12/30/200\
6 4:33:01 PM

2004 VOLVO XC70
door Child safety lock control in right rear door
Child safety locks - rear doors
The controls are located on the rear door jambs. Use the ignition key or\
a screwdriver to adjust these
controls.
A The door cannot be opened from the inside. Normal operation from the out\
side.
B The door lock functions normally. WARNING!
Remember, in the event of an accident, the rear seat passengers cannot o\
pen the doors from the inside
with the buttons in position A.




Contents | Top of Page
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (11 of 11)12/30/200\
6 4:33:01 PM

2004 VOLVO XC70
2 0 0 4
VOLVO XC70
Chapter 6 - Starting and driving


pg. 83 Starting and driving

<
Fuel requirements 84
Fuel Formulations 85
Refueling 86
Starting the engine 87
Manual transmission 89
Automatic transmission (AW5) 90
Automatic transmission
(Geartronic) 92
All Wheel Drive 94
Four-C active chassis system 95
Driving economy, Handling 95
Points to remember 96
file:///K|/ownersdocs/2004/2004_XC70/04xc70_06a.htm12/30/2006 4:33:02 PM\

2004 VOLVO XC70

pg. 100 Emergency towing


Front towing eyelet
Emergency towing
The towing eyelet is located in the tool bag, under the floor of the car\
go area, with the spare tire. This
eyelet must be screwed into the positions provided on the right sides of\
either the front or rear bumper
(see illustration). To attach the towing eyelet:
l Use a coin to pry open the lower edge of the cover (A).
l Screw the towing eyelet in place, first by hand and then using the tire \
iron (B) until it is securely in
place.
After the car has been towed, the eyelet should be removed and returned \
to the tool bag. Press the cover
back into position.

file:///K|/ownersdocs/2004/2004_XC70/04xc70_06b.htm (1 of 10)12/30/200\
6 4:33:02 PM

2004 VOLVO XC70
Rear towing eyelet
Precautions when the car is in tow
l The steering wheel must be unlocked. Turn the ignition key to position I\
or II.
l The gear selector must be in position N.
l Maximum speed: 50 mph (80 km/h)
l Maximum distance with front wheels on ground: 50 miles (80 km).
l While the car is being towed, try to keep the tow rope taut at all times\
.
l Cars with an automatic transmission should only be towed in forward dire\
ction.
CAUTION:
l Please check with state and local authorities before attempting this typ\
e of towing, as vehicles being
towed are subject to regulations regarding maximum towing speed, length \
and type of towing device,
lighting, etc.
l If the car's battery is dead, do not attempt to start the vehicle by pus\
hing or pulling it as this will
damage the three-way catalytic converter(s). The engine must be jump s\
tarted using an auxiliary battery
(see
page 104).
l If the car is being towed on a flat bed truck, the towing eyelets must n\
ot be used to secure the car on
the flat bed. Consult the tow truck operator.
WARNING!
l Remember that the power brakes and power steering will not function when\
engine is not running.
The braking and steering systems will function but the brake pedal press\
ure required is 3 - 4 times
above normal and greater steering effort must be exerted.
l The towing eyelets must not be used for pulling another vehicle out of a\
ditch or for any similar
purpose involving severe strain.
l Do not use the towing eyelets to pull the car up onto a flat bed tow tru\
ck.


pg. 101 Vehicle towing information

file:///K|/ownersdocs/2004/2004_XC70/04xc70_06b.htm (2 of 10)12/30/200\
6 4:33:02 PM

2004 VOLVO XC70
Towing cars with all wheel drive/front wheel drive
Volvo recommends the use of flat bed equipment. If wheel lift equipment \
must be used, please use
extreme caution to help avoid damage to the car. In this case, the car should be towed with the rear
wheels on the ground if at all possible.
If it is absolutely necessary to tow the vehicle with the front wheels o\
n the ground, please refer to the
towing information on the previous page.
CAUTION:
l The car must not be driven with wheels of different dimensions/specifica\
tions or with a spare tire
other than the one that came with the car. The use of different size whe\
els can seriously damage your
car's transmission.
l Sling-type equipment applied at the front will damage radiator and air c\
onditioning lines.
l It is equally important not to use sling-type equipment at the rear or a\
pply lifting equipment inside the
rear wheels; serious damage to the rear axle may result.
l If the car is being towed on a flat bed truck, the towing eyelets must n\
ot be used to secure the car on
the flat bed. Consult the tow truck operator.
WARNING!
l Do not use the towing eyelets to pull the car up onto a flat bed tow tru\
ck.
s


file:///K|/ownersdocs/2004/2004_XC70/04xc70_06b.htm (3 of 10)12/30/200\
6 4:33:02 PM

2004 VOLVO XC70
pg. 102 Towing a trailer
When preparing for trailer towing, observe the following:
Volvo recommends the use of Volvo trailer hitches which are specially de\
signed for the car.
l Maximum trailer weight recommended by Volvo is:
Trailers without brakes: 1100 lbs (500 kg)
Trailers with brakes: 3300 lbs* (1,500 kg),
Observe the legal requirements of the state/province in which the vehicl\
es are registered.
l All Volvo models are equipped with energy-absorbing shock-mounted bumper\
s. Trailer hitch
installation should not interfere with the proper operation of this bump\
er system.
Trailer towing does not normally present any particular problems, but ta\
ke into consideration:
l Increase tire pressure to recommended full. See section "Wheels and tire\
s".
l When your car is new, avoid towing heavy trailers during the first 620 m\
iles (1000 km).
l Recommended hitch tongue load is:
Trailer weights below 2,650 lbs (1,200 kg) - 110 lbs (50 kg)
Trailer weights above 2,650 lbs (1,200 kg) - 165 lbs (75 kg)
l Maximum speed when towing a trailer: 50 mph (80 km/h).
l Engine and transmission are subject to increased loads. Therefore, engin\
e coolant temperature should
be closely watched when driving in hot climates or hilly terrain. Use a \
lower gear and turn off the air
conditioner if the temperature gauge needle enters the red range.
l If the automatic transmission begins to overheat, a message will be disp\
layed in the text window.
l Avoid overload and other abusive operation.
l Hauling a trailer affects handling, durability, and economy.
l It is necessary to balance trailer brakes with the towing vehicle brakes\
to provide a safe stop (check
and observe state/local regulations).
l Do not connect the trailer's brake system directly to the vehicle's brak\
e system.
l More frequent vehicle maintenance is required.
l Remove the ball and drawbar assembly when the hitch is not being used.
l Volvo recommends the use of synthetic engine oil when towing a trailer o\
ver long distances or in
mountainous areas.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_06b.htm (4 of 10)12/30/200\
6 4:33:02 PM
