Page 361 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 9-6
7. Afin de parfaire le travail, appliquer une cire pour
automobiles sur toutes les surfaces peintes et chro-
mées. Éviter l’emploi de cires détergentes. Bon
nombre d’entre-elles contiennent

Page 362 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 9-7
EBU00427
B. STORAGE
Long term storage (60 days or more) of your ma-
chine will require some preventive procedures to
guard against deterioration. After thoroughly
cleaning the machine, prepare for

Page 363 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 9-8
FBU00427
B. REMISAGE
Un remisage prolongé (60 jours ou plus) du véhicule exi-
ge l’application de certaines mesures afin de le maintenir
en bon état. Il convient de le nettoyer à fond avant

Page 364 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 9-9
5. Tie a plastic bag over the exhaust pipe outlet
to prevent moisture from entering.
6. If storing in a humid or salt-air atmosphere,
coat all exposed metal surfaces with a light
film of oil. Do n

Page 365 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 9-10
5. Fixer un sac en plastique sur la sortie du pot
d’échappement afin de le protéger contre l’humidi-
té.
6. Si le véhicule est remisé dans un endroit humide ou
exposé à l’air marin,

Page 366 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 10-1
EBU00428
1-SPECIFICATIONS
Model YFM400FP/YFM400FW
Dimensions:
Overall length 1,956 mm
Overall width 1,155 mm
Overall height 1,144 mm
Seat height 845 mm
Wheelbase 1,210 mm
Minimum ground clearance

Page 367 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 10-2
10
Noise and vibration level:
Noise level (77/311/EEC) 87.1 dB (A)
Vibration on seat (EN1032, ISO5008) Not exceed 0.5 m/s
2
Vibration on handlebar (EN1032, ISO5008) Not exceed 2.5 m/s
2
Engine oi

Page 368 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 10-3
Quantity:
Periodic oil change (engine oil): 2.4 L
Periodic oil change
(engine oil with oil filter replacement): 2.5 L
Periodic oil change
(engine oil and transfer gear oil with
oil filter repla

Page 369 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 10-4
Fuel:
Type For Europe: Regular unleaded gasoline only
For Australia: Unleaded gasoline only
Fuel tank capacity 13.5 L
Fuel reserve amount 1.3 L
Carburetor:
Type / manufacturer BTM32SH/MIKUNI
Spa

Page 370 of 388

YAMAHA BIG BEAR PRO 400 2003  Owners Manual 10-5
Gear Ratio:
Chassis:
Frame type Steel tube frame
Caster angle 2.5°
Trail 15 mm
Tire:
Ty p e T u b e l e s s
Size (front) AT25
× 8-12
(rear) AT25
× 10-12
Brake:
Front brake type Disc brake
op
