YAMAHA DT125R 2000 User Guide
Manufacturer: YAMAHA, Model Year: 2000, Model line: DT125R, Model: YAMAHA DT125R 2000Pages: 91, PDF Size: 4.67 MB
Page 11 of 91
EAU00026
DESCRIPTION
12
3
4
5
6
7
8
9
2-1
1
23 4 5 6
7 8
9 10
Left view1.Headlight (page 6-33)
2.Radiator cap (page 6-13)
3.Fuel cock (page 3-9)
4.Air filter (page 6-15)
5.Coolant reservoir tank (page 6-13)
6.Helmet holder (page 3-12)7.Starter (choke) (page 3-10)
8.Shift pedal (page 3-5, 5-4)
9.Y.E.I.S. (page 3-14)
10.Y.P.V.S. (page 3-15)
3MB-9-E7 12/27/00 2:52 PM Page 10
Page 12 of 91
DESCRIPTION
12
3
4
5
6
7
8
9
2-2
111213
14 15
Right view11.Tool kit (page 6-1)
12.Fuse (page 6-33)
13.Engine oil tank (page 3-9)
14.Rear brake pedal (page 3-6, 6-22)
15.Rear shock absorber spring
preload adjusting nut (page 3-13)
3MB-9-E7 12/27/00 2:52 PM Page 11
Page 13 of 91
12
3
4
5
6
7
8
9
DESCRIPTION
2-3
16.Clutch lever (page 3-5, 6-21)
17.Left handlebar switches (page 3-4)
18.Speedometer (page 3-3)
19.Coolant temperature gauge (page 3-4)
20.Tachometer (page 3-3)21.Right handlebar switches (page 3-5)
22.Front brake lever (page 3-6, 6-27)
23.Throttle grip (page 6-17, 6-27)
24.Fuel tank cap (page 3-6)
25.Main switch (page 3-1)
16171819202122
23 24 25
Controls/Instruments
3MB-9-E7 12/27/00 2:52 PM Page 12
Page 14 of 91
3-1
ON
OFF
EAU00028
Main switchThe main switch controls the ignition
and lighting systems. Its operation is
described below.
EAU00036
ON
Electrical circuits are switched on.
The engine can be started. The key
cannot be removed in this position.
EAU00038
OFF
All electrical circuits are switched off.
The key can be removed in this posi-
tion.EAU00027
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EAU00063
High beam indicator light Ò
&Ó
This indicator comes on when the
headlight high beam is used.
EAU01313
Oil level indicator light Ò
7
Ó
This indicator comes on when the oil
level is low. This light circuit can be
checked by the procedure on page 3-
2.EC000000
cCDo not run the motorcycle until
you know it has sufficient engine
oil.NOTE
Even if the oil is filled to the specified
level, the indicator light may flicker
when riding on a slope or during sud-
den acceleration or deceleration, but
this is normal.
1
2
3
4
EAU00056
Indicator lights
EAU00057
Turn indicator light Ò5Ó
This indicator flashes when the turn
switch is moved to the left or right.
EAU00061
Neutral indicator light ÒNÓ
This indicator comes on when the
transmission is in neutral.1.Turn indicator light Ò5Ó
2.High beam indicator light Ò&Ó
3.Neutral indicator light ÒNÓ
4.Oil level indicator light Ò
7
Ó
3MB-9-E7 12/27/00 2:52 PM Page 13
Page 15 of 91
EAU00075
Oil level indicator circuit check
3-2
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9Turn the main switch to ÒONÓ.
Put the transmission in neutral.
Oil level indicator light
does not come on.Ask a Yamaha dealer to
inspect electrical circuit.
Oil level indicator light
comes on.
Oil level indicator light
does not come on.
Supply engine oil.
Shift into gear.
Engine oil level and
electrical circuit are OK.
Go ahead with riding.
Oil level indicator light
comes on.
3MB-9-E7 12/27/00 2:52 PM Page 14
Page 16 of 91
3-3
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
2
1.Tachometer
2.Red zone
EAU00102
TachometerThis model is equipped with a
tachometer so the rider can monitor
the engine speed and keep it within
the ideal power range.
EC000003
cCDo not operate in the red zone.
Red zone: 10,500 r/min and above
4
2
3
1
EAU01087
SpeedometerThe speedometer shows riding
speed. This speedometer is equipped
with an odometer and trip odometer.
The trip odometer can be reset to Ò0Ó
with the reset knob. Use the trip
odometer to estimate how far you
can ride on a tank of fuel. This infor-
mation will enable you to plan fuel
stops in the future.1.Speedometer
2.Odometer
3.Trip odometer
4.Reset knob
NOTE:
(for German model equipped with
speed limiter only)
This motorcycle is equipped with a
speed limiter which prevents it from
exceeding a top speed of
80 km/h.
3MB-9-E7 12/27/00 2:52 PM Page 15
Page 17 of 91
3-4
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EAU00127
Turn signal switch
To signal a right-hand turn, push the
switch to Ò6Ó. To signal a left-hand
turn, push the switch to Ò4Ó. Once
the switch is released it will return to
the center position. To cancel the sig-
nal, push the switch in after it has
returned to the center position.
EAU00129
Horn switch Ò*Ó
Press the switch to sound the horn.
1
2
1.Coolant temperature gauge
2.Red zone
EAU01652
Coolant temperature gaugeThis gauge indicates the coolant tem-
perature when the main switch is on.
The engine operating temperature
will vary with changes in weather and
engine load. If the needle points to
the red zone or higher, stop your
motorcycle and let the engine cool.
(See page 6-13 for details.)
EC000002
cCWhen the engine is overheated, do
not continue riding.
2
1
3
4
1.Lights switch
2.Dimmer switch
3.Turn signal switch
4.Horn switch Ò*Ó
EAU00118
Handlebar switches
EAU00134
Lights switch
Turning the light switch to Ò
'
Ó,
turns on the auxiliary light, meter
lights and taillight. Turning the light
switch to Ò:Ó, turns the headlight on
also.
EAU00121
Dimmer switch
Turn the switch to Ò&Ó for the high
beam and to Ò%Ó for the low beam.
3MB-9-E7 12/27/00 2:52 PM Page 16
Page 18 of 91
3-5
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
1.Engine stop switch
EAU00138
Engine stop switch
The engine stop switch is a safety
device for use in an emergency such
as when the motorcycle overturns or
if trouble occurs in the throttle sys-
tem. Turn the switch to Ò#Ó to start
the engine. In case of emergency,
turn the switch to Ò$Ó to stop the
engine.
EAU00155
Clutch leverThe clutch lever is located on the left
handlebar. Pull the clutch lever to the
handlebar to disengage the clutch,
and release the lever to engage the
clutch. The lever should be pulled
rapidly and released slowly for
smooth clutch operation.
6
5
4
3
2
1 N
1
EAU00157
Shift pedalThis motorcycle is equipped with a
constant-mesh 6-speed transmission.
The shift pedal is located on the left
side of the engine and is used in
combination with the clutch when
shifting.1.Shift pedal
N.Neutral
1
1.Clutch lever
3MB-9-E7 12/27/00 2:52 PM Page 17
Page 19 of 91
3-6
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
1.Front brake lever
EAU00158
Front brake leverThe front brake lever is located on
the right handlebar. Pull it toward the
handlebar to apply the front brake.
1
1.Rear brake pedal
EAU00162
Rear brake pedalThe rear brake pedal is on the right
side of the motorcycle. Press down
on the brake pedal to apply the rear
brake.
31
2
EAU00177
Fuel tank capTo open
Insert the key and turn it 1/4 turn
counterclockwise. Turn the cap 1/3
turn counterclockwise and remove it
from the tank.
To close
Put the cap in the filler neck and turn
it 1/3 turn clockwise. Lock the cap by
turning the key 1/4 turn clockwise,
and remove the key.1.Fuel tank cap
2.Unlock
3.Open
3MB-9-E7 12/27/00 2:52 PM Page 18
Page 20 of 91
3-7
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
NOTE:
The tank cap cannot be reinstalled
unless it is unlocked. The key must
remain in the cap until the cap is
properly installed and locked onto the
fuel tank.
EW000023
wBe sure the cap is properly
installed and locked in place
before riding the motorcycle.
21
1.Filler tube
2.Fuel level
EAU01183
Fuel(except for Switzerland and
Austria)
Make sure there is sufficient fuel in
the tank. Fill the fuel tank to the bot-
tom of the filler tube as shown in the
illustration.
EW000130
wDo not overfill the fuel tank. Avoid
spilling fuel on the hot engine. Do
not fill the fuel tank above the bot-
tom of the filler tube or it may
overflow when the fuel heats up
later and expands.
2
1 3 4
1.Filler tube
2.Filling nozzle
3.Leaf valve
4.Fuel level
EAU01184
Fuel(for Switzerland and Austria)
Make sure there is sufficient fuel in
the tank. When refueling, be sure to
insert the filling nozzle into the filler
hole and fill the tank to the bottom of
the filler tube as shown in the illustra-
tion.
3MB-9-E7 12/27/00 2:52 PM Page 19
