YAMAHA DT125R 2002 Owners Manual
Manufacturer: YAMAHA, Model Year: 2002, Model line: DT125R, Model: YAMAHA DT125R 2002Pages: 96, PDF Size: 2.14 MB
Page 91 of 96
8-3
SPECIFICATIONS
8
90 kg load–maximum
load*
Front150 kPa (1.50 kgf/cm
2, 1.50 bar)
Rear 175 kPa (1.75 kgf/cm2, 1.75 bar)
Off-road riding
Front125 kPa (1.25 kgf/cm2, 1.25 bar)
Rear 150 kPa (1.50 kgf/cm2, 1.50 bar)
*Total weight of rider, passenger, cargo and accessories
Wheels
Front
Type Spoke wheel
Size 1.60 ×21
Rear
Type Spoke wheel
Size 1.85 ×18
Brakes
Front
Type Single disc brake
Operation Right hand operation
Fluid DOT 4Rear
Type Single disc brake
Operation Right foot operation
Fluid DOT 4
Suspension
Front Telescopic fork
Rear Swingarm (link suspension)
Shock absorber
Front Coil spring/oil damper
Rear Coil-gas spring/oil damper
Wheel travel
Front 270 mm
Rear 260 mm
Electrical
Ignition system C.D.I.
Charging system
Type A.C. magneto
Standard output 14V, 100W @ 5,000 r/min
3MB-9-E8 6/13/01 10:55 AM Page 90
Page 92 of 96
8-4
SPECIFICATIONS
8
Battery
Type GM3-3B
Voltage, capacity 12 V, 3 AH
Headlight typeConventional incandescent bulb
Bulb voltage, wattage ×quantity
Headlight 12 V, 45/40 W ×1
Tail/brake light 12 V, 5/21 W ×1
Front turn signal light 12 V, 21 W ×2
Rear turn signal light 12 V, 21 W ×2
Auxiliary light 12 V, 4 W ×1
12 V, 3.4 W ×1 (GB only)
Meter lighting 12 V, 3.4 W ×2
Neutral indicator light 12 V, 3.4 W ×1
High beam indicator light 12 V, 3.4 W ×1
Oil level indicator light 12 V, 3.4 W ×1
Turn indicator light 12 V, 3.4 W ×1
Fuse10 A
3MB-9-E8 6/13/01 10:55 AM Page 91
Page 93 of 96
8-5
SPECIFICATIONS
8
EAU03941
Conversion tableConversion tableAll specification data in this manual are listed in SI and
METRIC UNITS.
Use this table to convert METRIC unit data to
IMPERIAL unit data.
Ex.
METRIC MULTIPLIER IMPERIAL
** mm×0.03937 = ** in
2 mm×0.03937 = 0.08 in
METRIC TO IMPERIAL
Metric unit Multiplier Imperial unit
m•kgf 7.233 ft•lb
Torquem•kgf 86.794 in•lb
cm•kgf 0.0723 ft•lb
cm•kgf 0.8679 in•lb
Weightkg 2.205 lbg 0.03527 oz
Speed km/hr 0.6214 mph
km 0.6214 mi
m 3.281 ft
Distance m 1.094 yd
cm 0.3937 in
mm 0.03937 in
cc (cm
3) 0.03527 oz (IMP liq.)
Volume, cc (cm3) 0.06102 cu•in
capacity L (liter) 0.8799 qt (IMP liq.)
L (liter) 0.2199 gal (IMP liq.)
kgf/mm 55.997 lb/in
Misc. kgf/cm
2
14.2234 psi (lb/in
2)
Centigrade (°C)
9/5 + 32
Fahrenheit (°F)
CONVERSION TABLE
3MB-9-E8 6/13/01 10:55 AM Page 92
Page 94 of 96
9-1
EAU01039
CONSUMER INFORMATION
9
EAU02944
Identification numbersRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the
vehicle is stolen.
1. KEY IDENTIFICATION
NUMBER:
2. VEHICLE IDENTIFICATION
NUMBER:
3. MODEL LABEL INFORMATION:
EAU01042
Key identification numberThe key identification number is
stamped into the key.
Record this number in the space pro-
vided and use it for reference when
ordering a new key.
1
1. Key identification number
EAU01043
Vehicle identification numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your area.
1
1. Vehicle identification number
1
6
3MB-9-E8 6/13/01 10:55 AM Page 93
Page 95 of 96
9-2
CONSUMER INFORMATION
9
EAU03757
Model labelThe model label is affixed to the loca-
tion shown. Record the information
on this label in the space provided.
This information will be needed when
ordering spare parts from a Yamaha
dealer.
1
1. Model label
3MB-9-E8 6/13/01 10:55 AM Page 94
Page 96 of 96
PRINTED ON RECYCLED PAPERPRINTED IN JAPAN
2001·6–0.3×1(E)
!
OWNER’S MANUAL
3MB-28199-E8
DT125R
YAMAHA MOTOR CO., LTD.
