YAMAHA KODIAK 400 2002 Owners Manual

8-22
FBU00616
Cache B
DéposeRetirer les boulons.
Mise en placeRemettre le cache à sa place, puis monter les boulons.
SBU00616
Panel B
Para extraerloExtraiga los pernos.
Para instalarloColoque el panel en su posición original e instale los
pernos.
U5GH62.book Page 22 Monday, August 6, 2001 9:09 AM

8-23 1. Bolt (× 4)
1. Boulon (× 4)
1. Perno (× 4)
1. Bolt (× 2)
1. Boulon (× 2)
1. Perno (× 2)
EBU00617
Panel C
To remove1. Remove the front carrier bolts and the front
carrier.
2. Remove the quick fasteners and pull upward.
U5GH62.book Page 23 Monday, August 6, 2001 9:09 AM

8-24
FBU00617
Cache C
Dépose1. Retirer les boulons du porte-bagages avant, puis
déposer ce dernier.
2. Retirer les fixations rapides et tirer vers le haut.
SBU00617
Panel C
Para la extracción1. Extraiga los pernos del portaequipajes delante-
ro y el portaequipajes delantero.
2. Extraiga los fijadores rápidos y tire hacia arriba.
U5GH62.book Page 24 Monday, August 6, 2001 9:09 AM

8-25 1. Quick fastener (× 2)
1. Fixation rapide (× 2)
1. Fijador rápido (× 2)
To install1. Place the panel in the original position and in-
stall the quick fasteners.
2. Install the front carrier and the bolts, then
tighten to the specified torque.
Tightening torque:
Carrier bolts:
19 Nm (1.9 m·kgf)
U5GH62.book Page 25 Monday, August 6, 2001 9:09 AM

8-26
Mise en place1. Remettre le cache à sa place, puis monter les fixa-
tions rapides.
2. Remonter le porte-bagages avant et ses boulons,
puis serrer ces derniers au couple spécifié.
Couple de serrage:
Boulons de porte-bagages:
19 Nm (1,9 m·kgf)
Para la instalación1. Ponga el panel en la posición original e instale
los fijadores rápidos.
2. Instale el portaequipajes delantero y los per-
nos, y apriételos a la torsión especificada.
Torsión de apriete:
Pernos del portaequipajes:
19 Nm (1,9 m·kgf)
U5GH62.book Page 26 Monday, August 6, 2001 9:09 AM

8-27 1. Panel E 2. Bolt (× 3)
1. Cache E 2. Boulon (× 3)
1. Panel E 2. Perno (× 3)
EBU00616
Panel E
To removeRemove the bolts.
To installPlace the panel in the original position and install
the bolts.
U5GH62.book Page 27 Monday, August 6, 2001 9:09 AM

8-28
FBU00616
Cache E
DéposeRetirer les boulons.
Mise en placeRemettre le cache à sa place, puis monter les boulons.
SBU00616
Panel E
Para extraerloExtraiga los pernos.
Para instalarloColoque el panel en su posición original e instale los
pernos.
U5GH62.book Page 28 Monday, August 6, 2001 9:09 AM

8-29 1. Panel F
1. Cache F
1. Panel F
EBU00638
Panel F
To removePull outward on the areas shown.
To installPlace the panel in its original position.
U5GH62.book Page 29 Monday, August 6, 2001 9:09 AM

8-30
FBU00638
Cache F
DéposeTirer vers l’extérieur aux endroits indiqués.
Mise en placeRemettre le cache à sa position d’origine.
SBU00638
Panel F
Para extraerloTire hacia afuera por las partes indicadas.
Para instalarloColoque el panel en su posición original.
U5GH62.book Page 30 Monday, August 6, 2001 9:09 AM

8-31 1. Engine oil dipstick
1. Jauge d’huile
1. Varilla de medición del aceite de motor
1. Maximum level mark 2. Minimum level mark
1. Repère de niveau maximum 2. Repère de niveau minimum
1. Marca de nivel máximo 2. Marca de nivel mínimo
EBU00847
Engine oil
Oil level inspection
1. Remove panel E. (See page 8-27 for panel
removal and installation procedures.)
2. Place the ATV on a level place and warm up
the engine for several minutes.
3. Stop the engine.
4. Remove the dipstick and wipe it off with a
clean rag. Insert the dipstick in the filler hole
without screwing it in.NOTE:_ Wait a few minutes until the oil level settles before
checking. _5. The oil level should be between the maxi-
mum and minimum marks. If the level is low,
fill the engine with sufficient oil to reach the
specified level.
