3-5
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
2
3
1
1.Digital clock
2.Hour setting button ÒhÓ
3.Minute setting button ÒmÓ
EAU03800
ClockThe digital clock shows the time
regardless of the main switch posi-
tion.
To set the clock:
1.Turn the key to ÒONÓ.
2.Push or hold the hour setting
button ÒhÓ to change the hours.
3.Push or hold the minute setting
button ÒmÓ to change the min-
utes.
NOTE:
To set the clock after the power
source has been cut, first set the time
to 1:00 AM, and then set the clock to
the correct time.
1
2
3
4
EAU00118
Handlebar switches
EAU00119
Pass switch Ò&
Ó
Press this switch to flash the head-
light.
EAU00121
Dimmer switch
Set this switch to Ò&Ó for the high
beam and to Ò%Ó for the low beam.1.Pass switch Ò&Ó
2.Dimmer switch
3.Turn signal switch
4.Horn switch Ò*Ó
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 20
Page 22 of 106
3-6
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
2
3
EAU01871
Light switch
Set this switch to Ò
'
Ó to turn on
the auxiliary light, meter lighting, tail-
light and license plate light. Set the
switch to Ò:Ó to turn on the headlight
also.
1.Engine stop switch
2.Light switch
3.Start switch Ò,Ó
EAU00127
Turn signal switch
To signal a right-hand turn, push this
switch to Ò6Ó. To signal a left-hand
turn, push this switch to Ò4Ó. When
released, the switch returns to the
center position. To cancel the turn
signal lights, push the switch in after
it has returned to the center position.
EAU00129
Horn switch Ò*Ó
Press this switch to sound the horn.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 21
Page 23 of 106
3-7
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EAU00136
Headlight variationsNOTE:
Right and left are defined as seen when standing in front of the scooter.1
2
%
% &
&
LeftRightAuxBulb to be used
Destination2
1
1
31
3
2
1
Halogen
bulb
Halogen
bulbGermany, Belgium, Switzerland, Spain
France, Greece, Italy, Netherlands,
Norway, Portugal, Sweden
England 3 : High beam light on 2: Low beam light on
'
: Auxiliary light on 1: Light off
12V
55W
12V
60/55W
12V
60/55W
12V
55W '
'
'
'
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 22
Page 24 of 106
3-8
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EAU00138
Engine stop switch
Set this switch to Ò$Ó to stop the
engine in case of an emergency,
such as when the scooter overturns
or when the throttle cable is stuck.
EAU00143
Start switch Ò,Ó
Push this switch to crank the engine
with the starter.
EC000005
cCSee page 5-1 for starting instruc-
tions prior to starting the engine.
1
2
3
1.Engine stop switch
2.Light switch
3.Start switch Ò,Ó
1
1.Front brake lever
EAU03378
Front brake leverThe front brake lever is located at the
right handlebar grip. To apply the
front brake, pull this lever toward the
handlebar grip.
1
1.Rear brake lever
EAU00163
Rear brake leverThe rear brake lever is located on the
left handlebar grip. To apply the rear
brake, pull this lever toward the han-
dlebar grip.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 23
Page 25 of 106
3-9
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
2
EAU03090
Fuel tank capTo open the fuel tank cap
1.Open the lid by sliding the lever
forward, and then pull the lever
up.1.Lid
2.Lever
1
2.Insert the key into the lock and
turn it clockwise. The lock will be
released and the fuel tank cap
can be removed.1.Fuel tank cap
To install the fuel tank cap
1.Align the match marks, insert the
fuel tank cap into the tank open-
ing, and then push down on the
cap.
2.Turn the key counterclockwise to
the original position, and then
remove it.
3.Close the lid.
EWA00028
wBe sure the cap is properly
installed and locked in place
before riding the scooter.
1
1.Match marks
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 24
Page 26 of 106
3-10
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EAU00185
cCImmediately wipe off spilled fuel
with a clean, dry, soft cloth, since
fuel may deteriorate painted sur-
faces or plastic parts.
EAU03626
NOTE:
If knocking (or pinging) occurs, use
gasoline of a different brand or with a
higher octane grade.
Recommended fuel:
Regular unleaded gasoline with
a research octane number of 91
or higher
Fuel tank capacity (Total amount):
12 L
EAU03098
Catalytic converterThis scooter is equipped with a cat-
alytic converter in the muffler.
EW000128
wThe exhaust system is hot after
operation. Make sure that the
exhaust system has cooled down
before doing any maintenance
work.
1
2
EAU01183
FuelMake sure that there is sufficient fuel
in the tank. Fill the fuel tank to the
bottom of the filler tube as shown in
the illustration.
EW000130
w8Do not overfill the fuel tank,
otherwise it may overflow
when the fuel warms up and
expands.
8Avoid spilling fuel on the hot
engine.1.Filler tube
2.Fuel level
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 25
Page 27 of 106
3-11
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EC000114
cCThe following precautions must be
observed to prevent a fire hazard
or other damages.
8Use only unleaded gasoline.
The use of leaded gasoline will
cause unrepairable damage to
the catalytic converter.
8Never park the scooter near
possible fire hazards such as
grass or other materials that
easily burn.
8Do not allow the engine to idle
too long.
IGNITION
P
LOCK
ON
OFF
OPENPUSHPUSH
a
a.Open.
EAU03091
Rider seatTo open the rider seat
1.Place the scooter on the center-
stand.
2.Insert the key into the main
switch, and then turn it counter-
clockwise.NOTE:
Do not push inward when turning the
key.
1
3.Fold the rider seat up.
To close the rider seat
1.Fold the rider seat down, and
then push it down to lock it in
place.
2.Remove the key from the main
switch if the scooter will be left
unattended.NOTE:
Make sure that the seat is properly
secured before riding.1.Rider seat
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 26
Page 28 of 106
3-12
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
11
2
2
2.Remove the bolts and collars.
3.Slide the rider seat forward or
backward to the desired position.
4.Install the collars and securely
tighten the bolts.
5.Close the rider seat.1.Bolt (
´4)
2.Collar (´4)
1
2
a
1.Button
2.Lid
a.Lock.
EAU03331
Storage compartmentsFront storage compartment A
To open the storage compartment
when it is locked, insert the key in the
lock, turn it counterclockwise, and
then grasp the lock while pushing the
button in.
To open the storage compartment
when it is unlocked, simply grasp the
lock while pushing the button in.
To lock the storage compartment,
push the lid into the original position,
insert the key in the lock, turn it clock-
wise, and then remove it.Compartment A
1
EAU03096
Adjusting the rider seatThe rider seat can be adjusted as fol-
lows to change the riding position.
1.Open the rider seat. 1.Rider seat
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 27
Page 29 of 106
3-13
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
2
Front storage compartment B
To open the storage compartment,
slide the lever up, and then pull on
the lever.
To close the storage compartment,
push the lid into the original position.
EWA00034
wDo not store heavy items in this
compartment.1.Lever
2.LidCompartment B
1
1.Rider seatRear storage compartment
Two helmets can be stored in the
storage compartment under the
seats. (See page 3-11 for rider seat
opening and closing procedures.)
ECA00051
cCDo not leave the rider seat open
for an extended period of time as
the storage compartment light may
cause the battery to discharge.
EWA00035
wDo not exceed the loading limits:
Front storage compartment A: 2 kg
Rear storage compartment: 5 kg
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 28
Page 30 of 106
3-14
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
NOTE:
8Align the appropriate notch in the
adjusting ring with the position
indicator on the shock absorber.
8Use the spring preload adjusting
tool included in the ownerÕs tool
kit to make this adjustment.
Adjust the spring preload as follows.
To increase the spring preload and
thereby harden the suspension, turn
the adjusting ring on each shock
absorber assembly in direction a. To
decrease the spring preload and
thereby soften the suspension, turn
the adjusting ring on each shock
absorber assembly in direction b.
Setting
Minimum (soft)1
Standard4
Maximum (hard)7
a
b1
23
1.Spring preload adjusting ring
2.Position indicator
3.Spring preload adjusting tool
EAU03625
Adjusting the shock
absorber assembliesEach shock absorber assembly is
equipped with a spring preload
adjusting ring.
EC000015
cCNever attempt to turn an adjusting
mechanism beyond the maximum
or minimum settings.
EW000040
wAlways adjust both shock
absorber assemblies equally, oth-
erwise poor handling and loss of
stability may result.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 29
