YAMAHA MAJESTY 250 2000 Workshop Manual

6-7
1
2
2 11
1.Mat A
2.Mat B1.Screw (´4)
2.Cowling A
EAU03615
Cowling A
To remove the cowling1.Pull up the left floorboard mats
as shown.2.Remove the screws.
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
1.Panel A
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 50

6-8
1
1
2
3.Pull the cowling down slightly,
and then pull it outward as
shown.To install the cowling
1.Insert the tabs on the cowling
into the slots as shown, and then
install the screws.
2.Place the floorboard mats in the
original position.
ECA00067
cCTake care not to damage the tabs
on the cowling when removing and
or installing it.
EAU03632
Cowling B
To remove the cowling1.Pull up the right floorboard mats
as shown.
1.Tab (´10)1.Mat A
2.Mat B
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 51

6-9
2 1
1
1
2.Remove the screws.1.Screw (´4)
2.Cowling B1.Tab (´10)
3.Pull the cowling down slightly,
and then pull it outward as
shown.To install the cowling
1.Insert the tabs on the cowling
into the slots as shown, and then
install the screws.
2.Place the floorboard mats in the
original position.
ECA00067
cCTake care not to damage the tabs
on the cowling when removing and
or installing it.
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
95GM-9-E1(No ABS) 9/27/00 2:18 PM Page 52

6-10
1
aa
EAU03617
Cowling C
To remove the cowling1.Remove the screws.2.Push the cowling in lightly, and
then pull it back as shown.
ECA00067
cCTake care not to damage the tabs
on the cowling when removing and
or installing it.
1.Screw (´2)a.Push.
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 53

6-11
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
2
To install the cowling1.Insert the tabs on the cowling
into the slots as shown, and then
push the cowling in until it snaps
into place.
2.Install the screws.1.Tab (´4)
2.Slot (´4)
EAU03628
Panel A
To remove the panelRemove the bolts, and then pull the
panel out as shown.
1
2
1.Bolt (´2)
2.Panel A
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 54

6-12
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
1
1.Tab (´4)To install the panelPlace the panel in the original posi-
tion, and then install the bolts.
1
To remove the spark plug
1.Remove cowling B. (See page
6-8 for cowling removal and
installation procedures.)
2.Remove the spark plug cap.1.Spark plug cap
EAU03620
Checking the spark plugThe spark plug is an important
engine component, which is easy to
check. Since heat and deposits will
cause any spark plug to slowly erode,
the spark plug should be removed
and checked in accordance with the
periodic maintenance and lubrication
chart. In addition, the condition of the
spark plug can reveal the condition of
the engine.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 55

1
3.Remove the spark plug as
shown, with the spark plug
wrench included in the ownerÕs
tool kit.1.Spark plug wrench
6-13PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9To check the spark plug
1.Check that the porcelain insula-
tor around the center electrode
of the spark plug is a medium-to-
light tan (the ideal color when the
scooter is ridden normally).
NOTE:
If the spark plug shows a distinctly
different color, the engine could be
defective. Do not attempt to diagnose
such problems yourself. Instead,
have a Yamaha dealer check the
scooter.2.Check the spark plug for elec-
trode erosion and excessive car-
bon or other deposits, and
replace it if necessary.
a
a.Spark plug gap
Spark plug gap:
0.6Ð0.7 mm
To install the spark plug
1.Measure the spark plug gap with
a wire thickness gauge and, if
necessary, adjust the gap to
specification.
2.Clean the surface of the spark
plug gasket and its mating sur-
face, and then wipe off any grime
from the spark plug threads.
3.Install the spark plug with the
spark plug wrench, and then
tighten it to the specified torque. Specified spark plug:
DR8EA (NGK)
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 56

6-14
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
NOTE:
If a torque wrench is not available
when installing a spark plug, a good
estimate of the correct torque is
1/4Ð1/2 turn past finger tight.
However, the spark plug should be
tightened to the specified torque as
soon as possible.4.Install the spark plug cap.
5.Install the cowling. Tightening torque:
Spark plug:
17.5 Nm (1.75 m0kg)
EAU03119
Engine oilThe engine oil level should be
checked before each ride. In addition,
the oil must be changed at the inter-
vals specified in the periodic mainte-
nance and lubrication chart and when
the oil change indicator light comes
on.To check the engine oil level
1.Place the scooter on the center-
stand.
NOTE:
Make sure that the scooter is posi-
tioned straight up when checking the
oil level. A slight tilt to the side can
result in a false reading.2.Start the engine, warm it up for
several minutes, and then turn it
off.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 57

6-15
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
93.Wait a few minutes until the oil
settles, remove the oil filler cap,
wipe the dipstick clean, insert it
back into the oil filler hole (with-
out screwing it in), and then
remove it again to check the oil
level.
NOTE:
The engine oil should be between the
minimum and maximum level marks.
3121
1.Engine oil filler cap
2.Maximum level mark
3.Minimum level mark
4.If the engine oil is below the min-
imum level mark, add sufficient
oil of the recommended type to
raise it to the correct level.
5.Insert the dipstick into the oil filler
hole, and then tighten the oil filler
cap.

1
1.Engine oil drain boltTo change the engine oil
1.Start the engine, warm it up for
several minutes, and then turn it
off.
2.Place an oil pan under the
engine to collect the used oil.
3.Remove the engine oil filler cap
and the engine oil drain bolt to
drain the oil from the crankcase.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 58

6-16
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
12
4.Check the washer for damage
and replace it if necessary.
5.Install the washer and the engine
oil drain bolt, and then tighten
the drain bolt to the specified
torque.NOTE:
Make sure that the washer is properly
seated.1.Engine oil drain bolt
2.Washer
Tightening torque:
Engine oil drain bolt:
20 Nm (2.0 m0kg)
6.Add the specified amount of the
recommended engine oil, and
then install and tighten the oil
filler cap.
EC000030
cC8Do not put in any chemical
additives or use oils with a
grade of CD or higher. Also, be
sure not to use oils labeled
ÒENERGY CONSERVING
IIÓ or
higher.
8Be sure no foreign material
enters the crankcase.
Recommended oil:
See page 8-1.
Oil quantity:
Periodic oil change:
1.2 L
Total amount (dry engine):
1.4 L
7.Start the engine, and then let it
idle for several minutes while
checking it for oil leakage. If oil is
leaking, immediately turn the
engine off and check for the
cause.
8.Reset the oil change indicator
light according to the following
procedure.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 59
