YAMAHA MAJESTY 250 2000 Manual PDF

6-27
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
Observe these precautions:
8When checking the fluid level,
make sure that the top of the
master cylinder or brake fluid
reservoir is level.
8Use only the recommended qual-
ity brake fluid, otherwise the rub-
ber seals may deteriorate, caus-
ing leakage and poor braking
performance.1.Minimum level markREARRecommended brake fluid:
DOT 4
8Refill with the same type of brake
fluid. Mixing fluids may result in a
harmful chemical reaction and
lead to poor braking perfor-
mance.
8Be careful that water does not
enter the master cylinder or
brake fluid reservoir when refill-
ing. Water will significantly lower
the boiling point of the fluid and
may result in vapor lock.
8Brake fluid may deteriorate paint-
ed surfaces or plastic parts.
Always clean up spilled fluid
immediately.
8As the brake pads wear, it is nor-
mal for the brake fluid level to
gradually go down. However, if
the brake fluid level goes down
suddenly, have a Yamaha dealer
check the cause.
1
EAU03607
Checking the brake fluid
levelInsufficient brake fluid may allow air
to enter the brake system, possibly
causing it to become ineffective.
Before riding, check that the brake
fluid is above the minimum level mark
and replenish if necessary. A low
brake fluid level may indicate worn
brake pads and/or brake system
leakage. If the brake level is low, be
sure to check the brake pads for
wear and the brake system for leak-
age.1.Minimum level mark FRONT
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 70

6-28
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU03073
Changing the brake fluidHave a Yamaha dealer change the
brake fluid at the intervals specified in
the periodic maintenance and lubrica-
tion chart. In addition, have the oil
seals of the master cylinder and
caliper as well as the brake hoses
replaced at the intervals listed below
or whenever they are damaged or
leaking.
8Oil seals: Replace every two
years.
8Brake hoses: Replace every four
years.
EAU02962
Checking and lubricating the
cablesThe operation of all control cables
and the condition of the cables
should be checked before each ride,
and the cables and cable ends
should be lubricated if necessary. If
a cable is damaged or does not move
smoothly, have a Yamaha dealer
check or replace it.
EW000112
wDamage to the outer sheath may
interfere with proper cable opera-
tion and will cause the inner cable
to rust. Replace a damaged cable
as soon as possible to prevent
unsafe conditions.
Recommended lubricant:
Engine oil
EAU03118
Lubricating the front and
rear brake leversThe pivoting points of the front and
rear brake levers must be lubricated
at the intervals specified in the peri-
odic maintenance and lubrication
chart.
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 71

6-29
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU02939
Checking the front forkThe condition and operation of the
front fork must be checked as follows
at the intervals specified in the peri-
odic maintenance and lubrication
chart.
To check the condition
EW000115
wSecurely support the scooter so
that there is no danger of it falling
over.Check the inner tubes for scratches,
damage and excessive oil leakage. Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
Centerstand
EAU03371
Checking and lubricating the
centerstand and sidestandThe operation of the centerstand and
sidestand should be checked before
each ride, and the pivots and metal-
to-metal contact surfaces should be
lubricated if necessary.
EW000114
wIf the centerstand or sidestand
does not move up and down
smoothly, have a Yamaha dealer
check or repair it.Sidestand
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 72

6-30
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9 To check the operation
1.Place the scooter on a level sur-
face and hold it in an upright
position.
2.While applying the front brake,
push down hard on the handle-
bars several times to check if the
front fork compresses and
rebounds smoothly.
EC000098
cCIf any damage is found or the front
fork does not operate smoothly,
have a Yamaha dealer check or
repair it.
EAU00794
Checking the steeringWorn or loose steering bearings may
cause danger. Therefore, the opera-
tion of the steering must be checked
as follows at the intervals specified in
the periodic maintenance and lubrica-
tion chart.
1.Place a stand under the engine
to raise the front wheel off the
ground.
EW000115
wSecurely support the scooter so
that there is no danger of it falling
over.
2.Hold the lower ends of the front
fork legs and try to move them
forward and backward. If any
free play can be felt, have a
Yamaha dealer check or repair
the steering.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 73

6-31
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU00796
Removing the battery coverThe battery cover needs to be
removed to access the battery, the
fuse box and the coolant reservoir
tank cap.
To remove the battery cover, pull up
the right footboard mat as shown,
and then remove the screws and the
battery cover.
2
3
1
1.Right footboard mat
2.Screw (´2)
3.Battery cover
1
1.Battery
EAU01271
BatteryThis scooter is equipped with a
sealed-type (MF) battery, which does
not require any maintenance. There
is no need to check the electrolyte or
to add distilled water.
To charge the battery
Have a Yamaha dealer charge the
battery as soon as possible if it
seems to have discharged. Keep in
mind that the battery tends to dis-
charge more quickly if the scooter is
equipped with optional electrical
accessories.
EAU01144
Checking the wheel bearingsThe front and rear wheel bearings
must be checked at the intervals
specified in the periodic maintenance
and lubrication chart. If there is play
in the wheel hub or if the wheel does
not turn smoothly, have a Yamaha
dealer check the wheel bearings.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 74

6-32
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EW000116
w8Electrolyte is poisonous and
dangerous since it contains
sulfuric acid, which causes
severe burns. Avoid any con-
tact with skin, eyes or clothing
and always shield your eyes
when working near batteries.
In case of contact, administer
the following FIRST AID.
8EXTERNAL: Flush with
plenty of water.
8INTERNAL: Drink large
quantities of water or milk
and immediately call a
physician.
8EYES: Flush with water for
15 minutes and seek
prompt medical attention.
8Batteries produce explosive
hydrogen gas. Therefore, keep
sparks, flames, cigarettes,
etc., away from the battery and
provide sufficient ventilation
when charging it in an en-
closed space.To store the battery
1.If the scooter will not be used for
more than one month, remove
the battery, fully charge it, and
then place it in a cool, dry place.
2.If the battery will be stored for
more than two months, check it
at least once a month and fully
charge it if necessary.
3.Fully charge the battery before
installation.
EC000102
cC8Always keep the battery
charged. Storing a discharged
battery can cause permanent
battery damage.
8To charge a sealed-type (MF)
battery, a special (constant-
voltage) battery charger is
required. Using a conventional
battery charger will damage
the battery. If you do not have
access to a sealed-type (MF)
battery charger, have a
Yamaha dealer charge your
battery.
8KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OF
CHILDREN.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 75

2.Remove the blown fuse, and
then install a new fuse of the
specified amperage.
EC000103
cCDo not use a fuse of a higher
amperage rating than recommend-
ed to avoid causing extensive
damage to the electrical system
and possibly a fire.3.Turn the key to ÒONÓ and turn on
the electrical circuit in question to
check if the device operates.
6-33
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
94.If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
Specified fuses:
Main fuse:30 A
Clock fuse:10 A
Radiator fan fuse:4 A
Ignition fuse:7.5 A
Headlight fuse:15 A
Signaling system fuse:15 A
4
5
67
1
32
78
EAU03622
Replacing the fusesThe fuse boxes are located under the
battery cover. (See page 6-31 for bat-
tery cover removal and installation
procedures.)
If a fuse is blown, replace it as fol-
lows.
1.Turn the key to ÒOFFÓ and turn
off all electrical circuits.1.Main fuse
2.Clock fuse
3.Radiator fan fuse
4.Ignition fuse
5.Headlight fuse
6.Signaling system fuse
7.Spare fuse (´4)
8.Spare main fuse
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 76

6-34
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU03630
Replacing a headlight bulbThis scooter is equipped with quartz
bulb headlights.
If a headlight bulb burns out, replace
it as follows.
1.Place the scooter on the center-
stand.
2.Remove panel A. (See page
6-11 for panel removal and
installation procedures.)
1
2
3.Disconnect the headlight cou-
pler, and then remove the head-
light bulb cover.1.Headlight coupler
2.Headlight bulb cover
1
4.Unhook the headlight bulb hold-
er, and then remove the defec-
tive bulb.
EW000119
wHeadlight bulbs get very hot.
Therefore, keep flammable prod-
ucts away from a lit headlight bulb,
and do not touch the bulb until it
has cooled down.1.Headlight bulb holder
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 77

6-35
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
5.Place a new bulb into position,
and then secure it with the bulb
holder.
EC000105
cCDo not touch the glass part of the
headlight bulb to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the
bulb, and the bulb life will be
adversely affected. Thoroughly
clean off any dirt and fingerprints
on the headlight bulb using a cloth
moistened with alcohol or thinner.6.Install the bulb cover, and then
connect the headlight coupler.
7.Install the panel.
8.Have a Yamaha dealer adjust
the headlight beam if necessary.
a
a.Do not touch this area.
EAU03111
Replacing a front turn signal
light bulb1.Place the scooter on the center-
stand.
2.Remove panel A. (See page
6-11 for panel removal and
installation procedures.)
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 78

6-36
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
3.Remove the socket (together
with the turn signal light bulb) by
turning it counterclockwise.
4.Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
5.Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
6.Install the socket (together with
the bulb) by turning it clockwise.
7.Install the panel.1.Socket
EAU03618
Replacing a rear turn signal
light bulb1.Place the scooter on the center-
stand.
2.Remove cowling C. (See page
6-10 for cowling removal and
installation procedures.)
1
1.Socket3.Remove the socket (together
with the bulb) by turning it coun-
terclockwise.
4.Remove the defective bulb by
pulling it out.
5.Insert a new bulb into the socket.
6.Install the socket (together with
the bulb) by turning it clockwise.
7.Install the cowling.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 79
