YAMAHA WR 450F 2013 Service Manual
Manufacturer: YAMAHA, Model Year: 2013, Model line: WR 450F, Model: YAMAHA WR 450F 2013Pages: 98, PDF Size: 2.59 MB
Page 41 of 98
OPERATION AND IMPORTANT RIDING POINTS
5-3
2
3
456
7
8
9
TIPIf the engine fails to start, push the main
switch to “OFF” and give the kickstarter
10 to 20 slow kicks at full throttle in or-
der to clear the engine of the rich air-fu-el mixture retained in it.
EAU52971
Starting a warm engine Follow the same procedure as for start-
ing a cold engine with the exception
that the starter is not required when the
engine is warm.TIP
If the engine does not start at high
altitude, start the engine with the
throttle grip opened by one degree
or two degrees.
The mark on the throttle housing
indicates five degrees. Use the
mark for your reference whenopening the throttle grip.
EAU16671
Shifting Shifting gears lets you control the
amount of engine power available for
starting off, accelerating, climbing hills,
etc.
The gear positions are shown in the il-
lustration.TIPTo shift the transmission into the neu-
tral position, press the shift pedal down
repeatedly until it reaches the end of itstravel, and then slightly raise it.NOTICE
ECA10260
Even with the transmission in
1. Mark
1
1. Shift pedal
2. Neutral position
2 3
4 5N11
2
1DX-9-E1.book 3 ページ 2012年7月31日 火曜日 午前9時31分
Page 42 of 98
OPERATION AND IMPORTANT RIDING POINTS
5-4
1
2
3
45
6
7
8
9the neutral position, do not
coast for long periods of time
with the engine off, and do not
tow the motorcycle for long dis-
tances. The transmission is
properly lubricated only when
the engine is running. Inade-
quate lubrication may damage
the transmission.
Always use the clutch while
changing gears to avoid damag-
ing the engine, transmission,
and drive train, which are not
designed to withstand theshock of forced shifting.
EAU16810
Tips for reducing fuel
consumption Fuel consumption depends largely on
your riding style. Consider the following
tips to reduce fuel consumption:
Shift up swiftly, and avoid high en-
gine speeds during acceleration.
Do not rev the engine while shifting
down, and avoid high engine
speeds with no load on the engine.
Turn the engine off instead of let-
ting it idle for an extended length of
time (e.g., in traffic jams, at traffic
lights or at railroad crossings).
EAU52940
Engine break-in
WARNING
EWA10321
Failure to properly maintain the ve-
hicle or performing maintenance ac-
tivities incorrectly may increase
your risk of injury or death during
service or while using the vehicle. If
you are not familiar with vehicle ser-
vice, have a Yamaha dealer performservice.
1. Before starting the engine, fill the fuel tank with the fuel.
2. Start and warm up the engine. Check the operation of the controls
and the engine stop switch. (See
page 3-7.) Then, restart the engine
and check its operation within no
more than 5 minutes after it is re-
started.
3. Operate the motorcycle in the low- er gears at moderate throttle open-
ings for five to eight minutes. Stop
the engine.
4. Check how the engine runs when the motorcycle is ridden with the
throttle 1/4 to 1/2 open (low to me-
dium speed) for about one hour.
1DX-9-E1.book 4 ページ 2012年7月31日 火曜日 午前9時31分
Page 43 of 98
OPERATION AND IMPORTANT RIDING POINTS
5-5
2
3
456
7
8
9
5. Start the engine and check the op-
eration of the motorcycle through-
out its entire operating range.
Restart the motorcycle and ride it
for about 10 to 15 more minutes.
The motorcycle will now be ready
to ride normally.
After the engine break-in period, thor-
oughly check the motorcycle for loose
parts, oil leakage and any other prob-
lems. Be sure to inspect and make ad-
justments thoroughly, especially cable
and drive chain slack and loose
spokes. In addition, check all fittings
and fasteners for looseness, and tight-
en if necessary.
NOTICE
ECA15560
When any of the following parts
have been replaced, they must
be broken in.
Cylinder or crankshaft:
About one hour of break-in op-
eration is necessary.
Piston, rings or transmission
gears:
These parts require about 30
minutes of break-in operation at
half-throttle or less. Observe the condition of the engine carefully
during operation.
If any engine trouble should oc-
cur during the engine break-in
period, immediately have a
Yamaha dealer check the vehi-cle.
EAU52410
Parking When parking, stop the engine by
pushing the main switch to “OFF”.
WARNING
EWA10311
Since the engine and exhaust
system can become very hot,
park in a place where pedestri-
ans or children are not likely to
touch them and be burned.
Do not park on a slope or on soft
ground, otherwise the vehicle
may overturn, increasing the
risk of a fuel leak and fire.
Do not park near grass or other
flammable materials whichmight catch fire.
1DX-9-E1.book 5 ページ 2012年7月31日 火曜日 午前9時31分
Page 44 of 98
6-1
1
2
3
4
56
7
8
9
PERIODIC MAINTENANCE AND ADJUSTMENT
EAU17244
Periodic inspection, adjustment, and lu-
brication will keep your vehicle in the
safest and most efficient condition pos-
sible. Safety is an obligation of the vehi-
cle owner/operator. The most important
points of vehicle inspection, adjust-
ment, and lubrication are explained on
the following pages.
The intervals given in the periodic
maintenance charts should be simply
considered as a general guide under
normal riding conditions. However, de-
pending on the weather, terrain, geo-
graphical location, and individual use,
the maintenance intervals may need to
be shortened.
WARNING
EWA10321
Failure to properly maintain the ve-
hicle or performing maintenance ac-
tivities incorrectly may increase
your risk of injury or death during
service or while using the vehicle. If
you are not familiar with vehicle ser-
vice, have a Yamaha dealer performservice.
WARNING
EWA15122
Turn off the engine when performing
maintenance unless otherwise
specified.
A running engine has moving
parts that can catch on body
parts or clothing and electrical
parts that can cause shocks or
fires.
Running the engine while ser-
vicing can lead to eye injury,
burns, fire, or carbon monoxide
poisoning – possibly leading to
death. See page 1-2 for more in-
formation about carbon monox-ide.WARNING
EWA15460
Brake discs, calipers, drums, and
linings can become very hot during
use. To avoid possible burns, let
brake components cool beforetouching them.
EAU17302
Emission controls not only function to
ensure cleaner air, but are also vital to
proper engine operation and maximum
performance. In the following periodic
maintenance charts, the services relat-
ed to emissions control are grouped
separately. These services require
specialized data, knowledge, and
equipment. Maintenance, replacement,
or repair of the emission control devic-
es and systems may be performed by
any repair establishment or individual
that is certified (if applicable). Yamaha
dealers are trained and equipped to
perform these particular services.
1DX-9-E1.book 1 ページ 2012年7月31日 火曜日 午前9時31分
Page 45 of 98
PERIODIC MAINTENANCE AND ADJUSTMENT
6-2
2
3
4
567
8
9
EAU17311
Owner’s tool kit The service information included in this
manual and the tools provided in the
owner’s tool kit are intended to assist
you in the performance of preventive
maintenance and minor repairs. How-
ever, additional tools such as a torque
wrench may be necessary to perform
certain maintenance work correctly.TIPIf you do not have the tools or experi-
ence required for a particular job, havea Yamaha dealer perform it for you.
1DX-9-E1.book 2 ページ 2012年7月31日 火曜日 午前9時31分
Page 46 of 98
PERIODIC MAINTENANCE AND ADJUSTMENT
6-3
1
2
3
4
56
7
8
9
EAU52500
TIP
The annual checks must be performed every year, except if a kilometer-based maintenance, or for the UK, a
mileage-based maintenance, is performed instead.
From 7000 km (4200 mi) or 9 months, repeat the maintenance intervals starting from 3000 km (1800 mi) or 3 months.
Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technicalskills.
EAU52510
Periodic maintenance chart for the emission control system NO. ITEM CHECKS AND MAINTENANCE JOBS INITIAL
ODOMETER
READINGS
ANNUAL CHECK
1000 km
(600 mi) or
1 month 3000 km
(1800 mi) or 3
months 5000 km
(3000 mi) or 6
months
1* Fuel line Check fuel hoses for cracks or damage.
2* Spark plug Check condition.
Clean and regap.
Replace if necessary.
3* Valves Check valve clearance.
Adjust.
4* Breather system Check ventilation hose for cracks or damage and drain any
deposits.
5* Fuel injection Adjust engine idling speed.
6 Muffler and
exhaust pipe Check the screw clamp(s) for looseness.
1DX-9-E1.book 3 ページ 2012年7月31日 火曜日 午前9時31分
Page 47 of 98
PERIODIC MAINTENANCE AND ADJUSTMENT
6-4
2
3
4
567
8
9
EAU52581
General maintenance and lubrication chart NO. ITEM CHECKS AND MAINTENANCE JOBS INITIAL
ODOMETER
READINGS
ANNUAL CHECK
1000 km
(600 mi) or 1 month 3000 km
(1800 mi) or 3
months 5000 km
(3000 mi) or 6
months
1* Air filter element Clean.
Replace if damaged.
2 Clutch Check operation.
Adjust or replace cable.
3* Front brake Check operation, fluid level
and vehicle for fluid leakage.
Replace brake pads. Whenever worn to the limit
4* Rear brake Check operation, fluid level
and vehicle for fluid leakage.
Replace brake pads. Whenever worn to the limit
5* Brake hoses Check for cracks or damage.
Check for correct routing and clamping.
Replace. Every 20000 km (12000 mi) or every two years
6* Brake fluid Replace. Every 2 years
7* Wheels Check runout, spoke tightness and for damage.
Tighten spokes if necessary.
8* Tires Check tread depth and for damage.
Replace if necessary.
Check air pressure.
Correct if necessary.
9* Wheel bearings Check bearing for looseness or damage.
10 * Swingarm Check operation and for excessive play.
Lubricate with lithium-soap-based grease.
11 Drive chain Check chain slack, alignment and condition.
Adjust and lubricate chain with a special O-ring chain
lubricant thoroughly. Every ride
1DX-9-E1.book 4 ページ 2012年7月31日 火曜日 午前9時31分
Page 48 of 98
PERIODIC MAINTENANCE AND ADJUSTMENT
6-5
1
2
3
4
56
7
8
9
12 *Steering bearings Check bearing play and steering for roughness.
Lubricate with lithium-soap-based grease.
13 * Chassis fasteners Make sure that all nuts, bolts and screws are properly
tightened.
14 Brake lever pivot
shaft Lubricate with silicone grease.
15 Brake pedal pivot
shaft Lubricate with lithium-soap-based grease.
16 Clutch lever pivot
shaft Lubricate with lithium-soap-based grease.
17 Sidestand Check operation.
Lubricate with lithium-soap-based grease.
18 * Sidestand switch Check operation.
19 * Front fork Check operation and for oil leakage.
20 * Shock absorber
assembly Check operation and shock absorber for oil leakage.
21 * Rear suspension
relay arm and
connecting arm
pivoting points Check operation.
22 Engine oil Change.
Check oil level and vehicle for oil leakage.
23 Engine oil filter
element Replace.
NO. ITEM CHECKS AND MAINTENANCE JOBS
INITIAL
ODOMETER
READINGS
ANNUAL CHECK
1000 km
(600 mi) or
1 month 3000 km
(1800 mi) or 3
months 5000 km
(3000 mi) or 6
months1DX-9-E1.book 5 ページ 2012年7月31日 火曜日 午前9時31分
Page 49 of 98
PERIODIC MAINTENANCE AND ADJUSTMENT
6-6
2
3
4
567
8
9
EAU53210
TIP
The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
Hydraulic brake service
Regularly check and, if necessary, correct the brake fluid level.
Every two years replace the internal components of the brake master cylinders and calipers, and change the brake
fluid. Replace the brake hoses every tw o years and if cracked or damaged.
24 *Cooling system Check hoses for cracks of damage.
Replace if necessary.
Check coolant level and vehicle for coolant leakage.
Change with ethylene glycol anti-freeze coolant. Every 1 year
25 * Front and rear
brake switches Check operation.
26 * Moving parts and
cables Lubricate.
27 * Throttle grip Check operation.
Check throttle grip free play, and adjust if necessary.
Lubricate cable and grip housing.
28 * Lights, signals and
switches Check operation.
Adjust headlight beam.
NO. ITEM CHECKS AND MAINTENANCE JOBS
INITIAL
ODOMETER
READINGS
ANNUAL CHECK
1000 km
(600 mi) or
1 month 3000 km
(1800 mi) or 3
months 5000 km
(3000 mi) or 6
months
1DX-9-E1.book 6 ページ 2012年7月31日 火曜日 午前9時31分
Page 50 of 98
PERIODIC MAINTENANCE AND ADJUSTMENT
6-7
1
2
3
4
56
7
8
9
EAU18751
Removing and installing the
panel The panel shown needs to be removed
to perform some of the maintenance
jobs described in this chapter. Refer to
this section each time the panel needs
to be removed and installed.
EAU52872
Panel A
To remove the panel1. Remove the seat. (Seepage 3-13.)
2. Remove the bolts. 3. Pull the front part of the panel out-
ward, and then remove the panel
by pulling it off.
To install the panel
1. Place the panel in the original posi- tion, and then install the bolts.
2. Install the seat.
EAU19622
Checking the spark plug The spark plug is an important engine
component, which should be checked
periodically, preferably by a Yamaha
dealer. Since heat and deposits will
cause any spark plug to slowly erode, it
should be removed and checked in ac-
cordance with the periodic mainte-
nance and lubrication chart. In addition,
the condition of the spark plug can re-
veal the condition of the engine.
The porcelain insulator around the cen-
ter electrode of the spark plug should
be a medium-to-light tan (the ideal color
when the vehicle is ridden normally). If
the spark plug shows a distinctly differ-
ent color, the engine could be operating
improperly. Do not attempt to diagnose
such problems yourself. Instead, have
a Yamaha dealer check the vehicle.
If the spark plug shows signs of elec-
trode erosion and excessive carbon or
other deposits, it should be replaced.
Before installing a spark plug, the spark
plug gap should be measured with a
1. Panel A
1
1. Bolt
1 1
Specified spark plug:NGK/CR8E
1DX-9-E1.book 7 ページ 2012年7月31日 火曜日 午前9時31分
