YAMAHA WR 450F 2016 Owners Manual
Manufacturer: YAMAHA, Model Year: 2016, Model line: WR 450F, Model: YAMAHA WR 450F 2016Pages: 426, PDF Size: 10.86 MB
Page 101 of 426
PERIODIC MAINTENANCE
3-3
TIP
• The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
• Hydraulic brake service• After disassembling the brake master cylinders and calipers, always change the fluid. Regularly check the brake fluid levels and f ill the reservoirs as required.
• Every two years replace the internal components of the brake master cylinders and calipers, and
change the brake fluid.
• Replace the brake hoses every four years and if cracked or damaged.
13
Brake and
clutch lever
pivot shafts • Apply lithium-soap-based grease (all-
purpose grease) lightly.
14Brake pedal
pivot shafts• Apply lithium-soap-based grease (all-
purpose grease) lightly.
15Sidestand
pivot• Check operation.
• Apply lithium-soap-based grease (all-
purpose grease) lightly.
16*
Front fork • Check operation and for oil leakage.
• Replace if necessary.
17*Shock ab-
sorber as-
sembly • Check operation and for oil leakage.
• Replace if necessary.
18*Rear sus-
pension link
pivots • Apply molybdenum disulfide grease
lightly.
19*Control ca-
bles • Apply Yamaha chain and cable lube or
engine oil 10W-30 thoroughly.
20*Throttle grip
housing and
cable • Check operation and free play.
• Adjust the throttle cable free play if
necessary.
• Lubricate the throttle grip housing and cable.
21*
Chassis fas-
teners • Check all chassis fitting and fasteners.
• Correct if necessary.
22Battery• Check terminal for looseness and cor-
rosion.
NO. ITEM CHECKS AND MAINTENANCE JOBS
INITIAL
ODOMETER READ-
INGS
600 mi (1000
km) or 1 month 1800 mi
(3000
km) or 3 months 3000 mi
(5000
km) or 6 months
Page 102 of 426
PERIODIC MAINTENANCE
3-4
EAS2GC1078MAINTENANCE INTERVALS FOR COMPETITION USE
TIP
• The following schedule is intended as a general guide to maintenance and lubrication. Bear in mind that such factors as weather, terrain, geographical location, and individual usage will alter the re-
quired maintenance and lubrication intervals. If you ar e a doubt as to what intervals to follow in
maintaining and lubricating your ma chine, consult your Yamaha dealer.
• Periodic inspection is essential in making full use of the machine performance. The service life of
the parts varies substantially according to the en vironment in which the machine runs (e.g., rain,
dirt, etc.). Therefore, earlier inspection is required by reference to the list below.
ITEM After
break- in Every
race Every
third (or
500
km) Every
fifth (or
1,000 km) As re-
quired Remarks
ENGINE OIL Replace
VALVES Check the valve
clearances The engine must be cold.
Inspect Check the valve seats and
valve stems for wear.
Replace
VALVE SPRINGS Inspect Check the free length and the
tilt.
Replace
VALVE LIFTERS Inspect Check for scratches and wear.
Replace
CAMSHAFTS Inspect the camshaft surface.
Inspect Inspect the decompression
system.
Replace
CAMSHAFT
SPROCKETS Inspect Check for wear on the teeth
and for damage.
Replace
PISTON Inspect crack.
Inspect Inspect carbon deposits and
eliminate them.
Clean
Replace It is recommended that the pis-
ton pin and ring are also re-
placed at the same time.
PISTON RING
Inspect Check ring end gap.
Replace
Page 103 of 426
PERIODIC MAINTENANCE
3-5
PISTON PINInspect
Replace
CYLINDER HEAD Inspect carbon deposits and
eliminate them.
Inspect and clean
Change gasket.
CYLINDER
Inspect and clean Inspect score marks.
Inspect wear.
Replace
CLUTCH Inspect and adjust Inspect housing, friction plate,
clutch plate and spring.
Replace
TRANSMISSION Inspect
Replace bearing
SHIFT FORK, SHIFT
CAM, GUIDE BAR Inspect Inspect wear.
ROTOR NUT
Retighten
MUFFLER Inspect and re-
tighten
Clean
Replace
CRANK
Inspect and clean
THROTTLE BODY Inspect
SPARK PLUG Inspect and clean
Replace
DRIVE CHAIN Use chain lube.
Lubricate, slack,
alignment Chain slack: 50.0–60.0 mm
(1.97–2.36 in)
Replace ITEM
After
break- in Every
race Every
third (or
500
km) Every
fifth (or
1,000 km) As re-
quired Remarks
Page 104 of 426
PERIODIC MAINTENANCE
3-6
COOLING SYSTEMCheck coolant lev-
el and leakage
Check radiator cap
operation
Replace coolant Every two years
Inspect hoses
OUTSIDE NUTS
AND BOLTS
Retighten Refer to “STARTING AND
BREAK-IN” on page 1-28.
AIR FILTER
Clean and lubri-
cate Use Yamaha foam air filter oil
or other quality foam air filter
oil.
Replace
OIL FILTER
Replace
ENGINE GUARD Replace Breakage
FRAME Clean and inspect
FUEL TANK, FUEL
PUMP
Clean and inspect
FUEL HOSE Inspect
Replace Every four years
ITEM
After
break- in Every
race Every
third (or
500
km) Every
fifth (or
1,000 km) As re-
quired Remarks
Page 105 of 426
PERIODIC MAINTENANCE
3-7
BRAKESAdjust lever posi-
tion and pedal
height
Lubricate pivot
point
Check brake disc
surface
Check fluid level
and leakage
Retighten brake
disc bolts, caliper
bolts, master cylin-
der bolts and union
bolts
Replace pads
Replace brake flu-
id Every one year
FRONT FORKS Inspect and adjust
Replace oil Yamaha Suspension Oil S1
Replace oil seal
FRONT FORK OIL
SEAL AND DUST
SEAL Clean and lube Lithium-soap-based grease
PROTECTOR
GUIDE
Replace
REAR SHOCK AB-
SORBER (After
rain
ride)
Inspect and adjust
Lube Molybdenum disulfide grease
Retighten
DRIVE CHAIN
GUARD AND ROLL-
ERS
Inspect
DRIVE CHAIN
STOPPER Inspect ITEM
After
break- in Every
race Every
third (or
500
km) Every
fifth (or
1,000 km) As re-
quired Remarks
Page 106 of 426
PERIODIC MAINTENANCE
3-8
SWINGARMInspect, lube and
retighten Molybdenum disulfide grease
RELAY ARM, CON-
NECTING ROD Inspect, lube and
retighten Molybdenum disulfide grease
SIDESTAND Lubricate Lithium-soap-based grease
STEERING HEAD Inspect free play
and retighten
Clean and lube Lithium-soap-based grease
Replace bearing
TIRE, WHEELS
Inspect air pres-
sure, wheel run-
out, tire wear and
spoke looseness
Retighten sprocket
bolt
Inspect bearings
Replace bearings
Lubricate Lithium-soap-based grease
THROTTLE, CON-
TROL CABLE
Check routing and
connection
Lubricate Yamaha cable lube or SAE
10W-30 motor oil
ITEM
After
break- in Every
race Every
third (or
500
km) Every
fifth (or
1,000 km) As re-
quired Remarks
Page 107 of 426
PRE-OPERATION INSPECTION AND MAINTENANCE
3-9
EAS2GC1079
PRE-OPERATION INSPECTION AND MAINTENANCE
Before riding for break-in operation, practice or a race, make sure the machine is in good operating
condition.
Before using this machine, check the following points.
EAS2GC1080GENERAL INSPECTION AND MAINTENANCE
TIP
Perform usual maintenance enough so that, in the race course, a confirmation of that and simple set-
ting adjustments may only be left, in order to get enough time to use effectively.ITEM inspect Page
Coolant Check that coolant is filled up to the radiator cap.
Check the cooling system for leakage. 3-10 – 12
Fuel Check that a fresh gasoline is filled in the fuel tank.
Check the fuel line for leakage. 1-28
Engine oil Check that the oil level is correct. Check the crank-
case and oil line for leakage. 3-16 – 18
Gear shifter and clutch Check that gears can be shifted correctly in order and
that the clutch operates smoothly. 3-12 – 13
Throttle grip/Housing Check that the throttle grip operation and free play
are correctly adjusted. Lubricate the throttle grip and
housing, if necessary. 3-13 – 14
Brakes Check the play of front brake and effect of front and
rear brake. 3-25 – 31
Drive chain Check drive chain slack and alignment. Check that
the drive chain is lubricated properly. 3-31
5-69 – 70
Wheels Check for excessive wear and tire pressure. Check
for loose spokes and have no excessive play. 3-36 – 37
Steering Check that the handlebar can be turned smoothly and
have no excessive play. 3-37 – 38
Front forks and rear
shock absorber Check that they operate smoothly and there is no oil
leakage.
3-31 – 36
Cables (wires) Check that the clutch and throttle cables move
smoothly. Check that they are not caught when the
handlebars are turned or when the front forks travel
up and down.
—
Exhaust pipe Check that the exhaust pipe is tightly mounted and
has no cracks. 3-15 – 16
Rear wheel sprocket Check that the rear wheel sprocket tightening bolt is
not loose. 5-10 – 11
Lubrication Check for smooth operation. Lubricate if necessary. 3-14
3-38 – 39
Bolts and nuts Check the chassis and engine for loose bolts and
nuts. 1-32 – 33
Lead connectors Check that the AC magneto, ECU and ignition coil are
connected tightly. 1-9 – 12
Settings Is the machine set suitably for the condition of the rac-
ing course and weather or by taking into account the
results of test runs before racing? Are inspection and
maintenance completely done?
4-1 – 8
Page 108 of 426
ENGINE
3-10
EAS2GC1081
ENGINE
EAS2GC1082CHECKING THE COOLANT LEVELEWA
WARNING
If coolant seems hot, do not remove the ra-
diator cap.
1. Stand the vehicle upright on a level surface.
2. Remove:• Radiator cap “1”
3. Check: • Coolant levelMaximum level “a” or below Add coolant
up to the maximum level.
ECA
NOTICE
• Adding water instead of coolant lowers the
antifreeze content. If, therefore, water is
used instead of coolant, check, and if nec-
essary, adjust the antifreeze concentra-
tion.
• Use only distilled water. However, if dis- tilled water is not available, soft water may
be used.
4. Start the engine, warm this up for 3 minutes, and then stop it.
TIP
This model is equipped with an engine auto-
stop system. The engine stops automatically if
left idling for 7 minutes. If the engine stops,
push the start switch or push down the kick-
starter lever to restart the engine. 5. Check:
• Coolant level
TIP
Before checking the coolant level, wait a few
minutes until the coolant has settled.
EAS2GC1083CHECKING THE COOLING SYSTEM
1. Remove:• Seat
• Side cover (left/right)
• Air scoop (left/right)Refer to “GENERAL CHASSIS” on page 5-
1.
• Air filter case cover Refer to “THROTTLE BODY” on page 8-7.
2. Check:
• Radiator
• Radiator hosesCrack/damage Replace.
Refer to “RADIATOR” on page 7-1.
3. Install: • Air filter case cover
Refer to “THROTTLE BODY” on page 8-7.
• Air scoop (left/right)
• Seat
• Side cover (left/right) Refer to “GENERAL CHASSIS” on page 5-
1.
EAS2GC1084CHANGING THE COOLANTEWA
WARNING
If coolant seems hot, do not remove the ra-
diator cap.
1. Place a container under the engine.
2. Remove:• Coolant drain bolt “1”
1. Radiator
1
Page 109 of 426
ENGINE
3-11
3. Remove:• Radiator capSlowly loosen the radiator cap to drain cool-
ant.
TIP
When the radiator cap is loosened, coolant will
gush out transversely; therefore, bring the con-
tainer near to the outlet.
4. Thoroughly flush the cooling system with
clean tap water.
5. Install:
• Copper washer
• Coolant drain bolt
6. Pour coolant.
EWA
WARNING
• If coolant splashes in your eyes, thorough- ly wash them with water and consult a
doctor.
• If coolant splashes on your clothes, quick-
ly wash it away with water and then with
soap and water.
• If coolant is swallowed, induce vomiting
and get immediate medical attention.
ECA
NOTICE
• Adding water instead of coolant lowers the
antifreeze content of the coolant. If water
is used instead of coolant check, and if
necessary, correct the antifreeze concen-
tration of the coolant.
• Use only distilled water. However, if dis-
tilled water is not available, soft water may
be used.
• If coolant comes into contact with painted
surfaces, immediately wash them with wa-
ter.
• Do not mix different types of antifreeze.
7. Install:• Radiator cap 8. Start the engine, warm this up for 3 minutes,
stop it, and then wait for it to cool down.
TIP
This model is equipped with an engine auto-
stop system. The engine stops automatically if
left idling for 7 minutes. If the engine stops,
push the start switch or push down the kick-
starter lever to restart the engine.
9. Check:• Coolant levelRefer to “CHECKING THE COOLANT LEV-
EL” on page 3-10.
EAS2GC1085CHECKING THE RADIATOR CAP
1. Check:• Seal (radiator cap) “1”
• Valve and valve seat “2”
Crack/damage Replace.
Exist fur deposits Clean or replace.
EAS2GC1086CHECKING THE RADIATOR CAP VALVE
OPENING PRESSURE
1. Check:
• Radiator cap valve opening pressure
▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼
a. Install the radiator cap tester adapter “2” and the radiator cap tester “3” to the radiator cap
“1,” and activate the tester to check whether
it can stay for 5 to 10 seconds within stan-
dard pressure values.
TIP
Before attaching the cap to the tester, apply
water to its sealing surface.
No stay Replace.
Coolant drain bolt
10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Recommended coolant High quality ethylene glycol
anti-freeze containing anti-cor-
rosion for aluminum engine
Radiator (including all routes) 1.03 L (1.09 US qt, 0.91 Imp.qt)
Coolant mixing ratio 1:1 (Coolant:Water)
New
T R..
Radiator cap valve opening pres-
sure 107.9–137.3 kPa (1.08–1.37 kg/
cm
2,15.6–19.9 psi)
Page 110 of 426
ENGINE
3-12
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
EAS2GC1087CHECKING THE COOLANT CIRCULATORY
SYSTEM FOR LEAKS
1. Check:• Coolant level
2. Install: • Radiator cap tester “1”
• Adapter “2”
3. Activate the tester to apply the test pressure.
ECA
NOTICE
• Do not apply such a high pressure as ex- ceeds the test pressure.
• Make sure that a checkup after the cylin-
der head gasket is replaced is made after 3
minutes of warm-up.
• Make sure that coolant is filled up to the
upper level beforehand.
TIP
This model is equipped with an engine auto-
stop system. The engine stops automatically if
left idling for 7 minutes. If the engine stops,
push the start switch or push down the kick-
starter lever to restart the engine.
4. Check:
• Pressure valueNo stay for 5 to 10 seconds at the test pres-
sure value Correct.
• Radiator
• Radiator hose connections Coolant leaks Correct or replace.
• Radiator hoses Bulges Replace
EWA
WARNING
When the radiator cap tester is removed,
coolant will spout; therefore, cover it with a
cloth beforehand.
EAS2GC1088ADJUSTING THE CLUTCH LEVER FREE
PLAY
1. Check:
• Clutch lever free play “a”Out of specification Regulate.
Radiator cap tester
90890-01325
Mityvac cooling system tester kit YU-24460-A
Radiator cap tester adapter 90890-01352
Pressure tester adapter YU-33984
Radiator cap tester 90890-01325
Mityvac cooling system tester kit YU-24460-A
Radiator cap tester adapter 90890-01352
Pressure tester adapter YU-33984
Test pressure value 196 kPa (1.96 kg/cm
2, 27.9 psi)
Clutch lever free play 7.0–12.0 mm (0.28–0.47 in)
