Specifications
8-1
8
Dimensions:Overall length:2005 mm (78.9 in)
Overall width:
735 mm (28.9 in)
Overall height: 1050 mm (41.3 in)
Seat height: 795 mm (31.3 in)
Wheelbase:
1320 mm (52.0 in)
Ground clearance: 150 mm (5.91 in)
Minimum turning radius: 2.2 m (7.22 ft)Wei ght:Curb weight:
129 kg (284 lb)Engine:Combustion cycle:
4-stroke
Cooling system: Air cooled
Valve train: SOHC
Number of cylinders:
Single cylinder
Displacement: 125 cm³
Bore × stroke:
52.4 × 57.9 mm (2.06 × 2.28 in)
Compression ratio:
10.0 : 1 Starting system:
Electric starter
Lubrication system: Wet sump
Engine oil:Recommended brand:
YAMALUBE
SAE viscosity grades: 10W-40, 20W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity:
Oil change:1.00 L (1.06 US qt, 0.88 Imp.qt)
With oil filter removal:
1.10 L (1.16 US qt, 0.97 Imp.qt)Air filter:Air filter element:Dry element
Fuel:Recommended fuel:Regular unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity: 14 L (3.7 US gal, 3.1 Imp.gal)
Fuel reserve amount:
2.2 L (0.58 US gal, 0.48 Imp.gal)Fuel injection:Throttle body:ID mark:BT41 00Spark plu g(s):Manufacturer/model:
NGK/CPR8EA-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:
Wet, multiple-discDrivetrain:Primary reduction ratio:3.409 (75/22)
Final drive:
Chain
Secondary reduction ratio: 3.071 (43/14)
Transmission type: Constant mesh 5-speed
Gear ratio:
1st:2.714 (38/14)
2nd:
1.789 (34/19)
010305070 90110
130 ˚F
-20 -10 0 10 20 3040
50 ˚C
SAE 10W-40
SAE 20W-40
UBT4E0E0.book Page 1 Thursday, November 17, 2016 10:55 AM
Page 82 of 90
Specifications
8-2
8
3rd:1.318 (29/22)
4th: 1.045 (23/22)
5th:
0.875 (21/24)
Chassis:Frame type:Diamond
Caster angle:
25.0 °
Trail: 82 mm (3.2 in)Front tire:Type:
Tubeless
Size: 2.75-18M/C 42P
Manufacturer/model: CHENG SHIN/C910Rear tire:Type:Tubeless
Size: 100/80-18M/C 59P
Manufacturer/model:
CHENG SHIN/C905Loading:Maximum load:171 kg (377 lb)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):1 person:
Front: 175 kPa (1.75 kgf/cm², 25 psi)
Rear:
200 kPa (2.00 kgf/cm², 29 psi)
2 persons: Front:
175 kPa (1.75 kgf/cm², 25 psi)
Rear: 225 kPa (2.25 kgf/cm², 33 psi)
Maximum load: Front: 175 kPa (1.75 kgf/cm², 25 psi)
Rear: 250 kPa (2.50 kgf/cm², 36 psi)Front wheel:Wheel type:Cast wheel
Rim size: 18M/C x MT1.85Rear wheel:Wheel type:Cast wheel
Rim size: 18M/C x MT2.15Unified brake system:Operation:Activated by front brakeFront brake:Type:
Hydraulic single disc brake Specified brake fluid:
DOT 3 or 4
Rear brake:Type:
Mechanical leading trailing drum brakeFront suspension:Type:Telescopic fork
Spring:
Coil spring
Shock absorber: Hydraulic damper
Wheel travel: 120 mm (4.7 in)Rear suspension:Type:Swingarm
Spring: Coil spring
Shock absorber:
Hydraulic damper
Wheel travel: 112 mm (4.4 in)Electrical system:System voltage:
12 V
Ignition system: TCI
Charging system: AC magnetoBattery:Model:YTX5L-BS
UBT4E0E0.book Page 2 Wednesday, December 21, 2016 11:07 AM
Page 83 of 90
Specifications
8-3
8
Voltage, capacity:12 V, 4.0 Ah (10 HR)Headlight:Bulb type:
Halogen bulbBulb wattage:Headlight:HS1, 35.0 W/35.0 W
Front turn signal light:
10.0 W
Rear turn signal light: 10.0 W
Auxiliary light: 3.0 W
Meter lighting:
LED
Neutral indicator light: LED
High beam indicator light: LED
Turn signal indicator light:
LED
Engine trouble warning light: LED
ECO indicator light: LEDFuse(s):Main fuse:15.0 A
UBT4E0E0.book Page 3 Wednesday, December 21, 2016 11:07 AM
Page 84 of 90
Consumer information
9-1
9
EAU53562
Id entification num bersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442
En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU36981
Mo del la bel
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1
UBT4E0E0.book Page 1 Thursday, November 17, 2016 10:55 AM
Page 85 of 90
Consumer information
9-2
9
The model label is affixed to the frame
behind panel A. (See page 6-8.) Re-
cord the information on this label in the
space provided. This information will
be needed when ordering spare parts
from a Yamaha dealer.
EAU69910
Dia
gnostic connectorThe diagnostic connector is located as
shown.
EAU74701
Vehicle data recor din gThis model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research and de-
velopment purposes. This data will be
uploaded only when a special Yamaha
diagnostic tool is attached to the vehi-
cle, such as when maintenance checks
or service procedures are performed.
Although the sensors and recorded
data will vary by model, the main data
points are:
Vehicle status and engine perfor-
mance data
Fuel-injection and emission-relat-
ed data
Yamaha will not disclose this data to a
third party except: With the consent of the vehicle
owner
Where obligated by law
For use by Yamaha in litigation
For general Yamaha-conducted
research purposes when the data
is not related to an individual vehi-
cle nor owner
1. Diagnostic connector
1
UBT4E0E0.book Page 2 Thursday, November 17, 2016 10:55 AM
Page 86 of 90
10-1
10
IndexAAir filter element and check hose,
cleaning .............................................. 6-14
Auxiliary light bulb, replacing ................ 6-34BBattery .................................................. 6-30
Brake and clutch levers, checking and lubricating ........................................... 6-27
Brake and shift pedals, checking and
lubricating ........................................... 6-26
Brake fluid, changing ............................ 6-23
Brake fluid level, checking .................... 6-22
Brake lever .............................................. 3-7
Brake lever free play, checking............. 6-20
Brake light switches.............................. 6-21
Brake pads and shoes, checking ......... 6-22
Brake pedal............................................. 3-7
Brake pedal free play, adjusting ........... 6-21
Brake/tail light bulb, replacing .............. 6-35CCables, checking and lubricating ......... 6-26
Care ........................................................ 7-1
Catalytic converters .............................. 3-10
Centerstand and sidestand, checking and lubricating .................................... 6-28
Clutch lever ............................................. 3-6
Clutch lever free play, adjusting ........... 6-19
Cowling and panels, removing and installing................................................ 6-8DData recording, vehicle ........................... 9-2
Diagnostic connector.............................. 9-2
Dimmer switch ........................................ 3-5
Drive chain, cleaning and lubricating .... 6-25 Drive chain slack .................................. 6-24
EEco indicator light................................... 3-2
Engine break-in ...................................... 5-3
Engine idling speed .............................. 6-16
Engine oil and oil filter element ............ 6-11
Engine serial number .............................. 9-1
Engine trouble warning light ................... 3-2FFront fork, checking ............................. 6-29
Fuel ......................................................... 3-8
Fuel consumption, tips for reducing ...... 5-3
Fuel tank cap .......................................... 3-8
Fuse, replacing ..................................... 6-31HHandlebar switches ................................ 3-5
Headlight bulb, replacing ..................... 6-33
High beam indicator light ....................... 3-2
Horn switch ............................................ 3-5IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-13
Indicator lights and warning light ........... 3-2LLicense plate light bulb, replacing........ 6-36MMain switch/steering lock....................... 3-1
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control
system.................................................. 6-3
Matte color, caution ............................... 7-1
Model label ............................................. 9-1
Multi-function meter unit ........................ 3-3
NNeutral indicator light ..............................3-2PParking ....................................................5-4
Part locations ..........................................2-1
Pass switch .............................................3-5SSafety information ...................................1-1
Seat .......................................................3-11
Shifting ....................................................5-2
Shift pedal ...............................................3-6
Shock absorber assemblies, adjusting .............................................3-11
Sidestand ..............................................3-12
Spark plug, checking ............................6-10
Specifications .........................................8-1
Starting the engine ..................................5-1
Start switch .............................................3-6
Steering, checking ................................6-29
Storage ...................................................7-3
Swingarm pivots, lubricating ................6-28TThrottle grip and cable, checking and lubricating ...........................................6-26
Throttle grip free play, checking ...........6-16
Tires ......................................................6-17
Tool kit ....................................................6-2
Troubleshooting ....................................6-39
Troubleshooting chart ...........................6-41
Turn signal indicator light........................3-2
Turn signal light bulb, replacing ............6-35
Turn signal switch ...................................3-5VValve clearance .....................................6-17
UBT4E0E0.book Page 1 Thursday, November 17, 2016 10:55 AM
Page 87 of 90
Index
10-2
10
Vehicle identification number ................. 9-1WWheel bearings, checking .................... 6-30
Wheel (front) ......................................... 6-36
Wheel (rear)........................................... 6-37
Wheels .................................................. 6-19
UBT4E0E0.book Page 2 Thursday, November 17, 2016 10:55 AM
Page 88 of 90
A5-yoko_Blank.fm Page 1 Thursday, December 8, 2011 2:18 PM
Page 89 of 90
A5-yoko_Blank.fm Page 1 Thursday, December 8, 2011 2:18 PM
Page 90 of 90
DIC183
Original instructions
PRINTED IN CHINA2016.11
