10-4
10
Tire air pressure (measured on cold tires):Recommended:Vehicle load:0 - 195 kg (0 - 430 lb)
Front: 114.0 kPa (1.140 kgf/cm², 16.5 psi)
Rear:
128.0 kPa (1.280 kgf/cm², 18.5 psi)
Vehicle load: 195 kg - maximum (430 lb - maximum)
Front: 114.0 kPa (1.140 kgf/cm², 16.5 psi)
Rear:
169.0 kPa (1.690 kgf/cm², 24.5 psi)
Minimum: Vehicle load:
0 - 195 kg (0 - 430 lb)
Front: 110.0 kPa (1.100 kgf/cm², 16.0 psi)
Rear: 124.0 kPa (1.240 kgf/cm², 18.0 psi)
Vehicle load:
195 kg - maximum (430 lb - maximum)
Front: 110.0 kPa (1.100 kgf/cm², 16.0 psi)
Rear: 165.0 kPa (1.650 kgf/cm², 24.0 psi)Front wheel:Wheel type:Cast wheel
Rim size: 14 x 6.5AT
Rear wheel:Wheel type:Cast wheel
Rim size:
14 x 8.0ATFront brake:Type:Disc brake
Operation:
Unified brake
Specified brake fluid: DOT 4Rear brake:Type:
Disc brake
Operation: Unified brake
Specified brake fluid: DOT 4Front suspension:Type:Double wishbone
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel:
410 mm (16.2 in)Rear suspension:Type:Double wishbone
Spring/shock absorber type:
Coil spring/gas-oil damper
U2HC7LE0.book Page 4 Wednesday, October 7, 2015 12:09 PM
Page 192 of 200
10-5
10
Wheel travel:432 mm (17.0 in)Electrical system:Ignition system:
TCI
Charging system: AC magnetoBattery:Model:
U1-H11L
Voltage, capacity: 12 V, 28.0 AhBulb voltage, wattage × quantity:Headlight:
LED
Tail/brake light: LED
Neutral indicator light: LED
Reverse indicator light:
LED
Coolant temperature warning light: LED
Engine trouble warning light: LED
Parking brake indicator light:
LED
Differential gear lock indicator light: LED
EPS warning light: LED Helmet/Seat belt indicator light:
14 V, 0.85 W × 2
Shift timing indicator light: LED
Fuses:Main fuse:40.0 A
Fuel injection system fuse: 15.0 A
EPS fuse:
40.0 A
Headlight fuse: 15.0 A
Signaling system fuse: 10.0 A
Ignition fuse:
15.0 A
Auxiliary DC jack fuse: 10.0 A
Backup fuse: 10.0 A
Four-wheel-drive motor fuse:
10.0 A
Radiator fan motor fuse: 30.0 A
U2HC7LE0.book Page 5 Wednesday, October 7, 2015 12:09 PM
Page 193 of 200
10-6
10
EBU33220For Europe only
The figures quoted are emission levels and
are not necessarily safe working levels. Whilst
there is a correlation between the emission
and exposure levels, this cannot be used reli-
ably to determine whether or not further pre-
cautions are required. Factors that influence
the actual level of exposure of work-force in-
clude the characteristics of the work room,
the other sources of noise, etc. i.e. the num-
ber of machines and other adjacent process-
es, and the length of time for which an
operator is exposed to the noise. Also the
permissible exposure level can vary from
country. This information, however, will en-
able the user of the machine to make a better
evaluation of the hazard and risk.U2HC7LE0.book Page 6 Wednesday, October 7, 2015 12:09 PM
Page 194 of 200
11-1
11
EBU32770
CONSUMER INFORMATION
EBU33320Identification number recordsRecord the vehicle identification number and
model label information in the spaces provid-
ed for assistance when ordering spare parts
from a Yamaha dealer or for reference, in
case the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:EBU32800Vehicle identification number
The vehicle identification number is stamped
into the frame.The vehicle identification number is used to
identify your vehicle.
EBU33331Model label
The model label can be found under the driver
seat. Record the information on this label in
the space provided. This information will be
needed to order spare parts from your
Yamaha dealer.1. Vehicle identification number
1
U2HC7LE0.book Page 1 Wednesday, October 7, 2015 12:09 PM
Page 195 of 200
11-2
11
1. Model label
1
U2HC7LE0.book Page 2 Wednesday, October 7, 2015 12:09 PM
Page 196 of 200
12-1
12
INDEX
