ACURA CSX 2006 Service Repair Manual
Manufacturer: ACURA, Model Year: 2006, Model line: CSX, Model: ACURA CSX 2006Pages: 2893, PDF Size: 67.66 MB
Page 1081 of 2893
Î
Î
(#'
)
µ
µ
µ
µ
µ
µ µ
µ
µ
µ
DTC P0973:
YES
NO
YES
NO
YES
NO YES
NO
YES
NO
14-165
PCM CONNECTORS
B (44P) C (44P)
SHA (BLU/BLK)
LG1 (BRN/YEL)
PCM CONNECTORS B (44P) C (44P)
SHA (BLU/BLK)
LG1 (BRN/YEL)
Short in Shift Solenoid Valve A
Circuit
NOTE:
Before you troubleshoot, record all freeze data and any on-board snapshot with the HDS, and review
General Troubleshooting Information (see page 14-3).
This code is caused by an electrical circuit problem and cannot be caused by a mechanical problem in the
transmission.
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Test-drive the vehicle in 1st gear with the shift lever in D for at least 1 second.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 8.
Go to step 5.
5. Select Shift Solenoid Valve A in the Miscellaneous Test Menu, and test shift solenoid valve A with the
HDS.
Go to step 6.
Go to step 8.
6. Test-drive the vehicle in 1st gear with the shift lever in D for at least 1 second.
7. Monitor the OBD STATUS for P0973 in the DTCs MENU with the HDS.
Go to step 8.
If the HDS indicates PASSED, intermittent
failure, the system is OK at this time. Check for
intermittent short to body ground in the wire
between shift solenoid valve A and the PCM. If the
HDS indicates NOT COMPLETED, go to step 5.
8. Turn the ignition switch to LOCK (0). 9. Jump the SCS line with the HDS.
10. Disconnect PCM connectors B (44P) and C (44P).
11. Measure the resistance between PCM connector terminals B10 and C40.
Go to step 12.
Go to step 22.
12. Disconnect the shift solenoid wire harness connector.
13. Check for continuity between PCM connector terminals B10 and C40.
Repair short to body ground in the wire
between PCM connector terminal B10 and the shift
solenoid wire harness connector, then go to step
16.
Go to step 14.
(cont’d)
Terminal side of female terminals
Terminal side of female terminals
I s DT C P097 3 i nd i cat ed ?
Is a clicking sound heard?
Does the HDS ind icate F AILED? Is t her e l ess t han 12 ?
Is there continuity?
08/08/21 14:43:59 61SNR030_140_0167
ProCarManuals.com
DYNOMITE -2009-
Page 1082 of 2893
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO YES
NO
YES
NO
14-166Automatic Transmission
DTC Troubleshooting (cont’d)
14. Inspect shift solenoid valve A and the shift solenoid
wire harness (see page 14-215).
15. Replace either shift solenoid valve A or the shift solenoid wire harness (see page 14-217),
whichever failed the test, then go to step 16.
16. Reconnect all connectors.
17. Turn the ignition switch to ON (II).
18. Clear the DTC with the HDS.
19. Start the engine with the shift lever in P, and wait for at least 1 second. Then test-drive the vehicle in
1st gear in D for at least 1 second.
20. Check for Temporary DTCs or DTCs with the HDS.
Check for intermittent short to body ground
in the wire between shift solenoid valve A and the
PCM, then go to step 1.
Go to step 21.
21. Monitor the OBD STATUS for P0973 in the DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 20,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for
intermittent short to body ground in the wire
between shift solenoid valve A and the PCM, then
go to step 1. If the HDS indicates NOT COMPLETED,
go to step 19. 22. Reconnect all connectors.
23. Update the PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good PCM (see page 11-7).
24. Start the engine with the shift lever in P, and wait for at least 1 second. Then test-drive the vehicle in
1st gear in D for at least 1 second.
25. Check for Temporary DTCs or DTCs with the HDS.
Check for intermittent short to body ground
in the wire between shift solenoid valve A and the
PCM. If the PCM was updated, substitute a known-
good PCM (see page 11-7), then go to step 24. If the
PCM was substituted, go to step 1.
Go to step 26.
26. Monitor the OBD STATUS for P0973 in the DTCs MENU with the HDS.
If the PCM was updated, troubleshooting is
complete. If the PCM was substituted, replace the
original PCM (see page 11-228). If any other
Temporary DTCs or DTCs were indicated in step 25,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for
intermittent short to body ground in the wire
between shift solenoid valve A and the PCM. If the
PCM was updated, substitute a known-good PCM
(see page 11-7), then go to step 24. If the PCM was
substituted, go to step 1. If the HDS indicates NOT
COMPLETED, go to step 24.
I s DT C P097 3 i nd i cat ed ?
Does the HDS ind icate PASSED? I s DT C P097 3 i nd i cat ed ?
Does the HDS ind icate PASSED?
08/08/21 14:43:59 61SNR030_140_0168
ProCarManuals.com
DYNOMITE -2009-
Page 1083 of 2893
µ
Î
(#'
)
µ
µ
µ
µ
µ
µ µ
µ
DTC P0974:
YES
NO
YES
NO
YES
NO YES
NO
14-167
PCM CONNECTORS
B (44P) C (44P)
SHA (BLU/BLK)
LG1 (BRN/YEL)
Open in Shift Solenoid Valve A
Circuit
NOTE:
Before you troubleshoot, record all freeze data and any on-board snapshot with the HDS, and review
General Troubleshooting Information (see page 14-3).
This code is caused by an electrical circuit problem and cannot be caused by a mechanical problem in the
transmission.
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine with the shift lever in P, and wait for at least 1 second.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 8.
Go to step 5.
5. Select Shift Solenoid Valve A in the Miscellaneous Test Menu, and test shift solenoid valve A with the
HDS.
Go to step 6.
Go to step 8.
6. Start the engine with the shift lever in P, and wait for at least 1 second.
7. Monitor the OBD STATUS for P0974 in the DTCs MENU with the HDS.
Go to step 8.
If the HDS indicates PASSED, intermittent
failure, the system is OK at this time. Check for
poor connections or loose terminals between shift
solenoid valve A and the PCM. If the HDS indicates
NOT COMPLETED, go to step 5.
8. Turn the ignition switch to LOCK (0). 9. Jump the SCS line with the HDS.
10. Disconnect PCM connectors B (44P) and C (44P).
11. Measure the resistance between PCM connector terminals B10 and C40.
Go to step 22.
Go to step 12.
(cont’d)
Terminal side of female terminals
I s DT C P097 4 i nd i cat ed ?Is a clicking sound heard?
Does the HDS ind icate F AILED? Is there 12 25 ?
08/08/21 14:43:59 61SNR030_140_0169
ProCarManuals.com
DYNOMITE -2009-
Page 1084 of 2893
Î Î
µ
µ µ
µ
YES
NO
YES
NO
14-168Automatic Transmission
DTC Troubleshooting (cont’d)
PCM CONNECTOR B (44P)
SHIFT SOLENOID
WIRE HARNESS
CONNECTOR
SHA (BLU/BLK) SHA (BLU/BLK)
SHIFT SOLENOID WIRE
HARNESS CONNECTOR
SHIFT SOLENOID
VALVE A
CONNECTOR
SHA (BLU)
12. Disconnect the shift solenoid wire harnessconnector.
13. Check for continuity between PCM connector terminal B10 and shift solenoid wire harness
connector terminal No. 5.
Go to step 14.
Repair open in the wire between PCM
connector terminal B10 and the shift solenoid wire
harness connector, then go to step 16. 14. Remove the shift solenoid wire harness (see page
14-217).
15. Check for continuity between shift solenoid wire harness connector terminal No. 5 and the shift
solenoid valve A connector terminal.
Replace shift solenoid valve A (see page
14-217), then go to step 19.
Replace the shift solenoid wire harness
(see page 14-217), then go to step 19.
Wire side of
female terminals Terminal side of
female terminals
Terminal side of
male terminals
Wire side of
female terminals
I s t her e cont i nui t y ?
I s t her e cont i nui t y ?
08/08/21 14:44:00 61SNR030_140_0170
ProCarManuals.com
DYNOMITE -2009-
Page 1085 of 2893
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
14-169
16. Reconnect all connectors.
17. Turn the ignition switch to ON (II).
18. Clear the DTC with the HDS.
19. Start the engine with the shift lever in P, and wait
for at least 1 second. Then test-drive the vehicle in
1st gear in D for at least 1 second.
20. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals between shift solenoid valve A and the
PCM, then go to step 1.
Go to step 21.
21. Monitor the OBD STATUS for P0974 in the DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 20,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for poor
connections or loose terminals between shift
solenoidvalveAandthePCM,thengotostep1.If
the HDS indicates NOT COMPLETED, go to step 19. 22. Reconnect all connectors.
23. Update the PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good PCM (see page 11-7).
24. Start the engine with the shift lever in P, and wait for at least 1 second. Then test-drive the vehicle in
1st gear in D for at least 1 second.
25. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals between shift solenoid valve A and the
PCM. If the PCM was updated, substitute a known-
good PCM (see page 11-7), then go to step 24. If the
PCM was substituted, go to step 1.
Go to step 26.
26. Monitor the OBD STATUS for P0974 in the DTCs MENU with the HDS.
If the PCM was updated, troubleshooting is
complete. If the PCM was substituted, replace the
original PCM (see page 11-228). If any other
Temporary DTCs or DTCs were indicated in step 25,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for poor
connections or loose terminals between shift
solenoid valve A and the PCM. If the PCM was
updated, substitute a known-good PCM (see page
11-7), then go to step 24. If the PCM was substituted,
go to step 1. If the HDS indicates NOT COMPLETED,
go to step 24.
I s DT C P097 4 i nd i cat ed ?
Does the HDS ind icate PASSED? I s DT C P097 4 i nd i cat ed ?
Does the HDS ind icate PASSED?
08/08/21 14:44:00 61SNR030_140_0171
ProCarManuals.com
DYNOMITE -2009-
Page 1086 of 2893
Î
Î
(#'
)
µ
µ
µ
µ
µ
µ µ
µ
µ
µ
DTC P0976:
YES
NO
YES
NO
YES
NO YES
NO
YES
NO
14-170Automatic Transmission
DTC Troubleshooting (cont’d)
PCM CONNECTORS
B (44P) C (44P)
SHB (GRN/WHT)
LG1 (BRN/YEL)
PCM CONNECTORS B (44P) C (44P)
SHB (GRN/WHT)
LG1 (BRN/YEL)
Short in Shift Solenoid Valve B
Circuit
NOTE:
Before you troubleshoot, record all freeze data and any on-board snapshot with the HDS, and review
General Troubleshooting Information (see page 14-3).
This code is caused by an electrical circuit problem and cannot be caused by a mechanical problem in the
transmission.
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine with the shift lever in P, and wait for at least 1 second.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 8.
Go to step 5.
5. Select Shift Solenoid Valve B in the Miscellaneous Test Menu, and test shift solenoid valve B with the
HDS.
Go to step 6.
Go to step 8.
6. Start the engine with the shift lever in P, and wait for at least 1 second.
7. Monitor the OBD STATUS for P0976 in the DTCs MENU with the HDS.
Go to step 8.
If the HDS indicates PASSED, intermittent
failure, the system is OK at this time. Check for
intermittent short to body ground in the wire
between shift solenoid valve B and the PCM. If the
HDS indicates NOT COMPLETED, go to step 5.
8. Turn the ignition switch to LOCK (0). 9. Jump the SCS line with the HDS.
10. Disconnect PCM connectors B (44P) and C (44P).
11. Measure the resistance between PCM connector terminals B11 and C40.
Go to step 12.
Go to step 22.
12. Disconnect the shift solenoid wire harness connector.
13. Check for continuity between PCM connector terminals B11 and C40.
Repair short to body ground in the wire
between PCM connector terminal B11 and the shift
solenoid wire harness connector, then go to step
16.
Go to step 14.
Terminal side of female terminals
Terminal side of female terminals
I s DT C P097 6 i nd i cat ed ?
Is a clicking sound heard?
Does the HDS ind icate F AILED? Is t her e l ess t han 12 ?
Is there continuity?
08/08/21 14:44:00 61SNR030_140_0172
ProCarManuals.com
DYNOMITE -2009-
Page 1087 of 2893
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO YES
NO
YES
NO
14-171
14. Inspect shift solenoid valve B and the shift solenoid
wire harness (see page 14-215).
15. Replace either shift solenoid valve B or the shift solenoid wire harness (see page 14-217),
whichever failed the test, then go to step 16.
16. Reconnect all connectors.
17. Turn the ignition switch to ON (II).
18. Clear the DTC with the HDS.
19. Start the engine with the shift lever in P, and wait for at least 1 second. Test-drive the vehicle in D,
and let the transmission shift through 1st to 3rd
gears, then drive the vehicle in 3rd gear for at least
1 second.
20. Check for Temporary DTCs or DTCs with the HDS.
Check for intermittent short to body ground
in the wire between shift solenoid valve B and the
PCM, then go to step 1.
Go to step 21.
21. Monitor the OBD STATUS for P0976 in the DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 20,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for
intermittent short to body ground in the wire
between shift solenoid valve B and the PCM, then
go to step 1. If the HDS indicates NOT COMPLETED,
go to step 19. 22. Reconnect all connectors.
23. Update the PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good PCM (see page 11-7).
24. Start the engine with the shift lever in P, and wait for at least 1 second. Test-drive the vehicle in D,
and let the transmission shift through 1st to 3rd
gears, then drive the vehicle in 3rd gear for at least
1 second.
25. Check for Temporary DTCs or DTCs with the HDS.
Check for intermittent short to body ground
in the wire between shift solenoid valve B and the
PCM. If the PCM was updated, substitute a known-
good PCM (see page 11-7), then go to step 24. If the
PCM was substituted, go to step 1.
Go to step 26.
26. Monitor the OBD STATUS for P0976 in the DTCs MENU with the HDS.
If the PCM was updated, troubleshooting is
complete. If the PCM was substituted, replace the
original PCM (see page 11-228). If any other
Temporary DTCs or DTCs were indicated in step 25,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for
intermittent short to body ground in the wire
between shift solenoid valve B and the PCM. If the
PCM was updated, substitute a known-good PCM
(see page 11-7), then go to step 24. If the PCM was
substituted, go to step 1. If the HDS indicates NOT
COMPLETED, go to step 24.
I s DT C P097 6 i nd i cat ed ?
Does the HDS ind icate PASSED? I s DT C P097 6 i nd i cat ed ?
Does the HDS ind icate PASSED?
08/08/21 14:44:00 61SNR030_140_0173
ProCarManuals.com
DYNOMITE -2009-
Page 1088 of 2893
µ
Î
(#'
)
µ
µ
µ
µ µ
µ
µ
µ
DTC P0977:
YES
NO
YES
NO YES
NO
YES
NO
14-172Automatic Transmission
DTC Troubleshooting (cont’d)
PCM CONNECTORS
B (44P) C (44P)
SHB (GRN/WHT)
LG1 (BRN/YEL)
Open in Shift Solenoid Valve B
Circuit
NOTE:
Before you troubleshoot, record all freeze data and any on-board snapshot with the HDS, and review
General Troubleshooting Information (see page 14-3).
This code is caused by an electrical circuit problem and cannot be caused by a mechanical problem in the
transmission.
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Test-drive the vehicle with the shift lever in D, and let the transmission shift through 1st to 3rd gears,
then drive the vehicle in 3rd gear for at least
1 second.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 8.
Go to step 5.
5. Select Shift Solenoid Valve B in the Miscellaneous Test Menu, and test shift solenoid valve B with the
HDS.
Go to step 6.
Go to step 8.
6. Test-drive the vehicle with the shift lever in D, and let the transmission shift through 1st to 3rd gears,
then drive the vehicle in 3rd gear for at least
1 second. 7. Monitor the OBD STATUS for P0977 in the DTCs
MENU with the HDS.
Go to step 8.
If the HDS indicates PASSED, intermittent
failure, the system is OK at this time. Check for
poor connections or loose terminals between shift
solenoid valve B and the PCM. If the HDS indicates
NOT COMPLETED, go to step 5.
8. Turn the ignition switch to LOCK (0).
9. Jump the SCS line with the HDS.
10. Disconnect PCM connectors B (44P) and C (44P).
11. Measure the resistance between PCM connector terminals B11 and C40.
Go to step 22.
Go to step 12.
Terminal side of female terminals
I s DT C P097 7 i nd i cat ed ?
Is a clicking sound heard? Does the HDS ind icate F AILED?
Is there 12 25 ?
08/08/21 14:44:01 61SNR030_140_0174
ProCarManuals.com
DYNOMITE -2009-
Page 1089 of 2893
Î Î
µ
µ µ
µ
YES
NO
YES
NO
14-173
PCM CONNECTOR B (44P)
SHIFT SOLENOID WIRE
HARNESS CONNECTOR
SHB (GRN/WHT) SHB (GRN/WHT) SHIFT SOLENOID WIRE
HARNESS CONNECTOR
SHIFT SOLENOID
VALVE B
CONNECTOR
SHB (ORN)
12. Disconnect the shift solenoid wire harnessconnector.
13. Check for continuity between PCM connector terminal B11 and shift solenoid wire harness
connector terminal No. 2.
Go to step 14.
Repair open in the wire between PCM
connector terminal B11 and the shift solenoid wire
harness connector, then go to step 16. 14. Remove the shift solenoid wire harness (see page
14-217).
15. Check for continuity between shift solenoid wire harness connector terminal No. 2 and the shift
solenoid valve B connector terminal.
Replace shift solenoid valve B (see page
14-217), then go to step 19.
Replace the shift solenoid wire harness
(see page 14-217), then go to step 19.
(cont’d)
Terminal side of
female terminals
Wire side of
female terminals Terminal side of
male terminals
Wire side of
female terminals
I s t her e cont i nui t y ?
I s t her e cont i nui t y ?
08/08/21 14:44:01 61SNR030_140_0175
ProCarManuals.com
DYNOMITE -2009-
Page 1090 of 2893
µ
µ
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
14-174Automatic Transmission
DTC Troubleshooting (cont’d)
16. Reconnect all connectors.
17. Turn the ignition switch to ON (II).
18. Clear the DTC with the HDS.
19. Start the engine with the shift lever in P, and wait
for at least 1 second. Test-drive the vehicle in D,
and let the transmission shift through 1st to 3rd
gears, then drive the vehicle in 3rd gear for at least
1 second.
20. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals between shift solenoid valve B and the
PCM, then go to step 1.
Go to step 21.
21. Monitor the OBD STATUS for P0977 in the DTCs MENU with the HDS.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs were indicated in step 20,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for poor
connections or loose terminals between shift
solenoidvalveBandthePCM,thengotostep1.If
the HDS indicates NOT COMPLETED, go to step 19. 22. Reconnect all connectors.
23. Update the PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good PCM (see page 11-7).
24. Start the engine with the shift lever in P, and wait for at least 1 second. Test-drive the vehicle in D,
and let the transmission shift through 1st to 3rd
gears, then drive the vehicle in 3rd gear for at least
1 second.
25. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals between shift solenoid valve B and the
PCM. If the PCM was updated, substitute a known-
good PCM (see page 11-7), then go to step 24. If the
PCM was substituted, go to step 1.
Go to step 26.
26. Monitor the OBD STATUS for P0977 in the DTCs MENU with the HDS.
If the PCM was updated, troubleshooting is
complete. If the PCM was substituted, replace the
original PCM (see page 11-228). If any other
Temporary DTCs or DTCs were indicated in step 25,
go to the indicated DTC’s troubleshooting.
If the HDS indicates FAILED, check for poor
connections or loose terminals between shift
solenoid valve B and the PCM. If the PCM was
updated, substitute a known-good PCM (see page
11-7), then go to step 24. If the PCM was substituted,
go to step 1. If the HDS indicates NOT COMPLETED,
go to step 24.
I s DT C P097 7 i nd i cat ed ?
Does the HDS ind icate PASSED? I s DT C P097 7 i nd i cat ed ?
Does the HDS ind icate PASSED?
08/08/21 14:44:01 61SNR030_140_0176
ProCarManuals.com
DYNOMITE -2009-
