AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-1


Engine, disassembling and
assembling Lock carrier, moving into service position

Special tools and equipment
3369 support tool
1 -
Bolts
45 Nm (33 ft lb)
2 -
Bolts 45 Nm (33 ft lb)

Page 2 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-2


 Repair Manual, Body Exterior, Repair Group 63
    -  Remove front bumper.
-  Remove 3 quick-release screws on front of noise
insulation panel.
-  Unbolt air guide between lock carrier and

Page 3 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-3


 Repair Manual, Body Exterior, Repair Group 63
    -  After installing lock carrier, check wiring for
proper routing near coolant fan.
-  Install front bumper.
Pa
ge 3 of 38 En
gine, disas

Page 4 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-4


Ribbed belt for power steering pump,
generator and viscous fan, and V-belt for
coolant pump

CAUTION!
Before removing ribbed belt, note direction of
rotation with chalk or felt-tip mark

Page 5 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-5


5 -
Ribbed belt
Removing and installing   Page 13
-15
Check for wear
6 -
Special bolt Tighten to 40 Nm (30 ft lb)Only use VW bolts, bolt strength grade
10.9   parts catalog
7 -
Vibrati

Page 6 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-6


11 -
Circlip
For viscous fan bearingRemoving and installing   Page 13
-20
12 -
Bolt for belt pulley
10 Nm (7 ft lb)
13 -
Bearing For viscous fanRemoving and installing   Page 13
-20
14

Page 7 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-7


Note:
For easier installation of generator into the bracket,
push back lower bolt bushing slightly.  17 -
Generator
  Removing:
  - Disconnect battery Ground (GND) strap.
 - Loosen ribb

Page 8 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 21 -
Bolt
25 Nm (18 ft lb)
Pa
ge 8 of 38 En
gine, disassemblin
g and assemblin
g
11/18/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.GE02.13.1

Page 9 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 13-8


22 -
Brace
For intake manifold
23 -
Bolt 20 Nm (15 ft lb)
24 -
Bolt 40 Nm (30 ft lb)
25 -
Bolt 25 Nm (18 ft lb)
26 -
Bolt 25 Nm (18 ft lb)
27 -
Bracket For generator, power steering p

Page 10 of 38

AUDI A3 1995 8L / 1.G AEB ATW Engines Engine Assembly Workshop Manual 25 Nm (18 ft lb)
Pa
ge 10 of 38 En
gine, disassemblin
g and assemblin
g
11/18/2002 htt
p://127.0.0.1:8080/audi/servlet/Dis
play?action=Goto&t
yp
e=re
pair&id=AUDI.B5.GE02.13.1
