Harness
Connector Usage
HEADLINER 3 Headliner Harness Connector 3
HEADLINER 2 Headliner Harness Connector 2
HEADLINER 1 Headliner Harness Connector 1
SEO/UPFITTER Special Equipment Option Upfitter
Harness Connector
Circuit Breaker Usage
CB1 Passenger Side Power Window
Circuit Breaker
CB2 Passenger Seat Circuit Breaker
CB3 Driver Seat Circuit Breaker
CB4 Rear Sliding Window Underhood Fuse Block
The underhood fuse block is located in the engine
compartment, on the driver side of the vehicle. Lift the
cover for access to the fuse/relay block.
If the vehicle is a Two-mode Hybrid, see the Two-mode
Hybrid manual for more information.
Notice: Spilling liquid on any electrical component
on the vehicle may damage it. Always keep the
covers on any electrical component.
To remove fuses, hold the end of the fuse between your
thumb and index finger and pull straight out.
7-113

Black plate (114,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Fuses Usage
1 Right Trailer Stop/Turn Lamp
2 Electronic Stability Suspension
Control, Automatic Level Control
Exhaust
3 Left Trailer Stop/Turn Lamp
4 Engine Controls Fuses Usage
5 Engine Control Module, Throttle
Control
6 Trailer Brake Controller
7 Front Washer
8 Oxygen Sensors
9 Antilock Brakes System 2
10 Trailer Back-up Lamps
11 Driver Side Low-Beam Headlamp
12 Engine Control Module (Battery)
13 Fuel Injectors, Ignition Coils
(Right Side)
14 Transmission Control Module
(Battery)
15 Vehicle Back-up Lamps
16 Passenger Side Low-Beam Headlamp
17 Air Conditioning Compressor
18 Oxygen Sensors
19 Transmission Controls (Ignition)
20 Fuel Pump
21 Fuel System Control Module
22 Headlamp Washer
23 Rear Windshield Washer
7-114

Black plate (115,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Fuses Usage
24 Fuel Injectors, Ignition Coils
(Left Side)
25 Trailer Park Lamps
26 Driver Side Park Lamps
27 Passenger Side Park Lamps
28 Fog Lamps
29 Horn
30 Passenger Side High-Beam
Headlamp
31 Daytime Running Lamps (DRL)
32 Driver Side High-Beam Headlamp
33 Daytime Running Lamps 2
34 Sunroof
35 Key Ignition System, Theft Deterrent
System
36 Windshield Wiper
37 SEO B2 Upfitter Usage (Battery)
38 Electric Adjustable Pedals
39 Climate Controls (Battery)
40 Airbag System (Ignition)
41 Amplifier
42 Audio System Fuses Usage
43 Miscellaneous (Ignition), Cruise
Control
44 Liftgate Release
45 Airbag System (Battery)
46 Instrument Panel Cluster
47 Not Used
48 Auxiliary Climate Control (Ignition)
49 Center High-Mounted Stoplamp
(CHMSL)
50 Rear Defogger
51 Heated Mirrors
52 SEO B1 Upfitter Usage (Battery)
53 Cigarette Lighter, Auxiliary Power
Outlet
54 Automatic Level Control Compressor
Relay
55 Climate Controls (Ignition)
56 Engine Control Module, Secondary
Fuel Pump (Ignition)
J-Case Fuses Usage
57 Cooling Fan 1
58 Automatic Level Control Compressor
7-115

Black plate (117,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Capacities and Specifications The following approximate capacities are given in English and metric conversions. See Recommended Fluids and
Lubricants on page 8 ‑ 10 for more information.
Application Capacities
English Metric
Air Conditioning Refrigerant For the air conditioning system refrigerant charge
amount, see the refrigerant caution label located
under the hood. See your dealer for more information.
Cooling System 17.6 qt 16.7 L
Engine Oil with Filter 6.0 qt † 5.7 L †
Fuel Tank
Regular 26.0 gal 98.4 L
Extended 31.5 gal 119.2 L
7-117

Black plate (118,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Application Capacities
English Metric
Transmission Fluid (Pan Removal and Replacement) 6.0 qt 5.7 L
Transfer Case Fluid 1.5 qt 1.4 L
Wheel Nut Torque 140 lb ft 190 Y
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.
Recheck fluid after filling.
† Oil filter should be changed at every oil change.
Engine SpecificationsEngine VIN Code Transmission Spark Plug Gap
6.2L V8 F Automatic 0.040 in (1.02 mm)
7-118

Black plate (1,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Section 8 Maintenance ScheduleMaintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Scheduled Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Owner Checks and Services . . . . . . . . . . . . . . . . . . . . 8-8 Recommended Fluids and Lubricants . . . . . . . . . . 8-10
Maintenance Replacement Parts . . . . . . . . . . . . . . 8-12
Engine Drive Belt Routing . . . . . . . . . . . . . . . . . . . . . 8-13
Maintenance Record . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
8-1

Black plate (3,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
At your dealer, you can be certain that you will receive
the highest level of service available. Your dealer has
specially trained service technicians, uses genuine
replacement parts, as well as, up to date tools and
equipment to ensure fast and accurate diagnostics.
The proper replacement parts, fluids, and lubricants to
use are listed in Recommended Fluids and Lubricants
on page 8 ‑ 10 and Maintenance Replacement Parts on
page 8 ‑ 12
. We recommend the use of genuine parts
from your dealer.
Rotation of New Tires To maintain ride, handling, and performance of the
vehicle, it is important that the first rotation service for
new tires be performed when they have 8 000 to
13 000 km (5,000 to 8,000 miles). See Tire Inspection
and Rotation on page 7 ‑ 71 . Scheduled Maintenance When the Change Engine Oil Soon
Message Displays Change engine oil and filter. See Engine Oil on
page 7 ‑ 17 . An Emission Control Service.
When the Change Engine Oil Soon message displays,
service is required for the vehicle as soon as possible,
within the next 1 000 km/600 miles. If driving under the
best conditions, the engine oil life system might not
indicate the need for vehicle service for more than a
year. The engine oil and filter must be changed at least
once a year and the oil life system must be reset. Your
dealer has trained service technicians who will perform
this work and reset the system. If the engine oil life
system is reset accidentally, service the vehicle within
5 000 km/3,000 miles since the last service. Reset the
oil life system whenever the oil is changed. See Engine
Oil Life System on page 7 ‑ 20 .
When the Change Engine Oil Soon message displays,
certain services, checks, and inspections are required.
8-3

Black plate (4,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Every Engine Oil Change .
Change engine oil and filter. See Engine Oil on
page 7 ‑ 17 . An Emission Control Service..
Engine coolant level check. See Engine Coolant
on page 7 ‑ 29 ..
Windshield washer fluid level check. See
Windshield Washer Fluid on page 7 ‑ 39 ..
Tire inflation check. See Inflation - Tire Pressure
on page 7 ‑ 65 ..
Tire wear inspection. See Tire Inspection and
Rotation on page 7 ‑ 71 ..
Rotate tires. See Tire Inspection and Rotation on
page 7 ‑ 71 ..
Fluids visual leak check (or every 12 months,
whichever occurs first). A leak in any system must
be repaired and the fluid level checked. .
Engine air cleaner filter inspection. See Engine Air
Cleaner/Filter on page 7 ‑ 22 ..
Brake system inspection (or every 12 months,
whichever occurs first). .
Lubricate the front suspension, steering linkage,
and parking brake cable guides. Control arm ball
joints are maintenance ‐ free..
Steering and suspension inspection. Visual
inspection for damaged, loose, or missing parts or
signs of wear. .
Engine cooling system inspection. Visual
inspection of hoses, pipes, fittings, and clamps and
replacement, if needed. .
Windshield wiper blade inspection for wear,
cracking, or contamination and windshield and
wiper blade cleaning, if contaminated. See
Windshield, Backglass, and Wiper Blades
on
page 7 ‑ 105 . Worn or damaged wiper blade
replacement. See Windshield Wiper Blade
Replacement on page 7 ‑ 57 . .
Body hinges and latches, key lock cylinders, rear
compartment hinges, outer tailgate handle pivot
points, and folding seat hardware lubrication.
See Recommended Fluids and Lubricants on
page 8 ‑ 10
. More frequent lubrication may be
required when vehicle is exposed to a corrosive
environment. Applying silicone grease on
weatherstrips with a clean cloth makes them last
longer, seal better, and not stick or squeak. .
Restraint system component check. See Checking
the Restraint Systems on page 2 ‑ 91 . .
Automatic transmission fluid level check and
adding fluid, if needed. See Automatic
Transmission Fluid on page 7 ‑ 24 .
8-4

Black plate (5,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Additional Required Services At Each Fuel Stop .
Engine oil level check. See Engine Oil on
page 7 ‑ 17
..
Engine coolant level check. See Engine Coolant
on page 7 ‑ 29 ..
Windshield washer fluid level check. See
Windshield Washer Fluid on page 7 ‑ 39 .
Once a Month .
Tire inflation check. See Inflation - Tire Pressure
on page 7 ‑ 65 ..
Tire wear inspection. See Tire Inspection and
Rotation on page 7 ‑ 71 .
Once a Year .
Starter switch check. See Owner Checks and
Services on page 8 ‑ 8 ..
Parking brake and automatic transmission P (Park)
mechanism check. See Owner Checks and
Services on page 8 ‑ 8 . .
Automatic transmission shiftlock control system
check. See Owner Checks and Services on
page 8 ‑ 8 . .
Ignition transmission lock check. See Owner
Checks and Services on page 8 ‑ 8 . .
Engine cooling system and pressure cap pressure
check. Radiator and air conditioning condenser
outside cleaning. See Cooling System
on
page 7 ‑ 27 . .
Exhaust system and nearby heat shields
inspection for loose or damaged components. .
Accelerator pedal check for damage, high effort,
or binding. Replace if needed. .
Hood and liftgate support gas strut inspection for
signs of wear, corrosion, cracks, loss of lubricant,
or other damage. Check the hold open ability of
the gas strut. If necessary, replace with genuine
parts from your dealer.
8-5

Black plate (6,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
First Engine Oil Change After Every
40 000 km/25,000 Miles .
Fuel system inspection for damage or leaks.
First Engine Oil Change After Every
80 000 km/50,000 Miles .
Engine air cleaner filter replacement. See Engine
Air Cleaner/Filter on page 7 ‑ 22 ..
Automatic transmission fluid and filter change
(severe service) for vehicles mainly driven in heavy
city traffic in hot weather, in hilly or mountainous
terrain, when frequently towing a trailer, or used for
taxi, police, or delivery service. See Automatic
Transmission Fluid on page 7 ‑ 24 ..
Four ‐ wheel drive only: Transfer case fluid change
(severe service) for vehicles mainly driven when
frequently towing a trailer, or used for taxi, police,
or delivery service. Check vent hose at transfer
case for kinks and proper installation. Check to be
sure vent hose is unobstructed, clear, and free of debris. During any maintenance, if a power washer
is used to clean mud and dirt from the underbody,
care should be taken to not directly spray the
transfer case output seals. High pressure water
can overcome the seals and contaminate the
transfer case fluid. Contaminated fluid will
decrease the life of the transfer case and should
be replaced. .
Evaporative control system inspection. Check all
fuel and vapor lines and hoses for proper hook ‐ up,
routing, and condition. Check that the purge valve,
if the vehicle has one, works properly. Replace as
needed. An Emission Control Service. The U.S.
Environmental Protection Agency or the California
Air Resources Board has determined that the
failure to perform this maintenance item will not
nullify the emission warranty or limit recall liability
prior to the completion of the vehicle's useful life.
We, however, urge that all recommended
maintenance services be performed at the
indicated intervals and the maintenance be
recorded.
8-6
