Black plate (7,1)Cadillac STS Owner Manual - 2011
Programming Transmitters to the
Vehicle
Only keyless access transmitters programmed to this
vehicle will work. If a transmitter is lost or stolen, a
replacement can be purchased and programmed
through your dealer. The vehicle can be reprogrammed
so that lost or stolen transmitters no longer work. Each
vehicle can have up to four transmitters programmed
to it.
Programming with a Recognized
Transmitter
A new transmitter can be programmed to the vehicle
when there is one recognized transmitter. For vehicles
sold in Canada, two recognized transmitters are
required to program a new transmitter.1. The vehicle must be off.
2. Both the recognized and new transmitters must be with you.
3. Insert the vehicle key into the key cylinder located on the outside of the driver door. 4. Turn the key to the unlock position five times within
five seconds.
5. The Driver Information Center (DIC) displays READY FOR FOB 2, 3 or 4.
6. Place the new transmitter into the transmitterpocket, located inside the center console storage
area located between the driver and front
passenger seats, with the transmitter buttons
facing the front of the vehicle.
3-7

Black plate (8,1)Cadillac STS Owner Manual - 2011
7. A beep sounds once programming in complete.The DIC displays READY FOR 3 or 4, or MAX #
FOBS LEARNED.
8. Remove the transmitter from the transmitter pocket and press
Ktwice on each newly programmed
transmitter to complete the process.
9. To program additional transmitters, repeat Step 6. Press Acc. on the ignition switch if programming is
complete.
Programming without a Recognized
Transmitter
This procedure requires three ten minutes cycles to
complete the programming process. United States
owners are permitted to program a new transmitter to
their vehicle when a recognized transmitter is not
available. The Canadian immobilizer standard requires
that Canadian owners see their dealer for programming
new transmitters when two recognized transmitters are
not available.
1. The vehicle must be off.
2. Place the new transmitter into the transmitter pocket, located inside the center console storage
area located between the driver and front
passenger seats, with the transmitter buttons
facing the front of the vehicle.
3. Insert the vehicle key into the key lock cylinder located on the driver door.
4. Turn the key to the unlock position five times within five seconds.
5. The DIC message displays OFF/ACC TO LEARN.
6. Press Acc. on the ignition switch.
3-8

Black plate (9,1)Cadillac STS Owner Manual - 2011
7. The DIC reads WAIT 10 MINUTES and countsdown to zero.
8. The DIC displays OFF/ACC TO LEARN again.
9. Press Acc. on the ignition switch.
10. Steps 7, 8 and 9 will be repeated two more times. 11. A beep sounds and the DIC reads READY FOR FOB 1. All previously known transmitter
programming has been erased.
12. A beep sounds once programming in complete. The DIC displays READY FOR FOB #2.
13. To program additional transmitters, take transmitter 1 out of the transmitter pocket and place
transmitter 2 in the pocket. Up to four transmitters
can be programmed. The DIC will then display
MAX # FOBS LEARNED and will exit the
programming mode.
14. Remove the transmitter from the transmitter pocket and press
Ktwice on each newly programmed
transmitter to complete the process.
Starting the Vehicle with a Low
Transmitter Battery
If the transmitter battery is weak, the DIC may display
NO FOBS DETECTED when trying to start the vehicle.
To start the vehicle, place the transmitter in the center
console storage area transmitter pocket with the
buttons facing to the front of the vehicle. Then, with
the vehicle in P (Park) OR N (Neutral), press the brake
pedal and
/. Replace the transmitter battery as soon
as possible. Change the transmitter battery if the DIC
displays KEY FOB BATTERY LOW.
3-9

Black plate (12,1)Cadillac STS Owner Manual - 2011
The remote start feature will not operate if any of the
following occur:
.The check engine light is displayed. See“Check
Engine Light” underMalfunction Indicator Lampon
page 4‑62.
.The valet lockout switch is on.
.The keyless access transmitter is in the vehicle.
.The vehicle's hood is open.
.An unauthorized vehicle entry or a vehicle theft
was attempted.
If your vehicle has the remote start feature, the keyless
access transmitter functions will have an increased
range of operation. However, the range may be less
while the vehicle is running.
There are other conditions which can affect the
performance of the transmitter, see Keyless Access
System on page 3‑4.
Doors and Locks
Door Locks
{WARNING:
Unlocked doors can be dangerous.
.Passengers, especially children, can easily
open the doors and fall out of a moving
vehicle. When a door is locked, the handle will
not open it. The chance of being thrown out of
the vehicle in a crash is increased if the doors
are not locked. So, all passengers should
wear safety belts properly and the doors
should be locked whenever the vehicle is
driven.
.Young children who get into unlocked vehicles
may be unable to get out. A child can be
overcome by extreme heat and can suffer
permanent injuries or even death from heat
stroke. Always lock the vehicle whenever
leaving it.
(Continued)
3-12

Black plate (14,1)Cadillac STS Owner Manual - 2011
Programmable Automatic Door
Locks
The vehicle was programmed so when the doors are
closed, the ignition is on, and the shift lever is moved
out of P (Park), all the doors will lock.
The front doors can still be opened from the inside while
the doors are locked. If a rear passenger needs to exit
the vehicle, have that person use the manual knob or
use the power door lock switch on either front door.
When the door is closed again, it will not lock
automatically. Use the manual knob or the power
door lock switch to lock the door.
The doors were also pre-programmed to unlock every
time the shift lever is moved into P (Park).
The power door locks can be programmed through the
radio display. The radio display allows you to choose
various lock and unlock settings. For more information
on programming, seeVehicle Personalization
on
page 3‑59.
Rear Door Security Locks
The vehicle has rear door security locks to prevent
passengers from opening the rear doors from the
inside.
Open the rear doors to
access the security locks
on the inside edge of
each door.
To set the locks, insert a key into the slot and turn it to
the horizontal position. The door can only be opened
from the outside with the door unlocked. To return the
door to normal operation, turn the slot to the vertical
position.
3-14

Black plate (27,1)Cadillac STS Owner Manual - 2011
If the engine is off, press this button to turn on the
accessory mode. ACCESSORY ACTIVE will display on
the Driver Information Center (DIC). Accessory mode
allows use of the audio system and windshield wipers.
Accessory mode must be used if the vehicle must be
towed or in motion when the engine is not running.
After the vehicle has been in accessory mode for more
than 20 minutes, the vehicle will enter RAP or turn off,
depending on if the doors are opened or closed.
Retained Accessory Power (RAP)
These vehicle accessories can be used for up to
20 minutes after the engine is turned off:
.Audio System
.Audio Steering Wheel Controls
.Power Windows
Power to these accessories will work up to 20 minutes
or until one of the front doors is opened. For an
additional 20 minutes of operation, close all the doors
and press Acc. to place the vehicle in accessory mode.
Press the button again to return to RAP.
Starting the Engine
To place the transmission in the proper gear:
Move the shift lever to P (Park) or N (Neutral). To restart
the engine when the vehicle is already moving, use
N (Neutral).
Notice: Do not try to shift to P (Park) if the
vehicle is moving. If you do, you could damage
the transmission. Shift to P (Park) only when the
vehicle is stopped.
The keyless access transmitter must be inside the
vehicle for the ignition to work.
Cell phone chargers can interfere with the operation of
the Keyless Access System. Battery chargers should
not be plugged in when starting or turning off the
engine.
To start the vehicle, do the following:
Starting Procedure
1. With your foot on the brake pedal, press the START button located on the instrument panel.
If there is not a keyless access transmitter
in the vehicle or if there is something causing
interference with it, the DIC will display NO FOBS
DETECTED. See DIC Warnings and Messages
on
page 4‑76for more information.
3-27

Black plate (28,1)Cadillac STS Owner Manual - 2011
2. When the engine begins cranking, let go of thebutton and the engine cranks automatically until
it starts. If the battery in the keyless access
transmitter is weak, the DIC displays KEY FOB
BATTERY LOW. You can still drive the vehicle.
See “Battery Replacement” underKeyless Access
System Operation
on page 3‑5for more
information. If the fob battery is dead, you need to
insert the fob into the fob slot to enable engine
starting. See “No Fobs Detected” underDIC
Warnings and Messages on page 4‑76.
3. Do not race the engine immediately after starting it. Operate the engine and transmission gently until
the oil warms up and lubricates all moving parts.
4. If the engine does not start and no DIC message is displayed, wait 15 seconds before trying again to
let the cranking motor cool down.
If the engine does not start after 5-10 seconds,
especially in very cold weather (below
0°F or −18°C), it could be flooded with too
much gasoline. Try pushing the accelerator
pedal all the way to the floor while cranking
for up to 15 seconds maximum. Notice:
Cranking the engine for long periods of
time, by pressing the START button immediately
after cranking has ended, can overheat and damage
the cranking motor, and drain the battery. Wait at
least 15 seconds between each try, to allow the
cranking motor to cool down.
When the engine starts, let go of the accelerator. If the
vehicle starts briefly but then stops again, do the same
thing. This clears the extra gasoline from the engine.
The vehicle has a Computer-Controlled Cranking
System. This feature assists in starting the engine and
protects components. Once cranking has been initiated,
the engine continues cranking for a few seconds or until
the vehicle starts. If the engine does not start, cranking
automatically stops after 15 seconds to prevent
cranking motor damage. To prevent gear damage, this
system also prevents cranking if the engine is already
running.
Notice: The engine is designed to work with the
electronics in the vehicle. If you add electrical
parts or accessories, you could change the way
the engine operates. Before adding electrical
equipment, check with your dealer. If you do not,
the engine might not perform properly. Any
resulting damage would not be covered by the
vehicle warranty.
3-28

Black plate (29,1)Cadillac STS Owner Manual - 2011
Stopping the Engine
Move the shift lever to P (Park) and press the Acc.
button located on the instrument panel. If the shifter is
not in P (Park), the engine shuts off and the vehicle
goes into the Accessory Mode. The DIC displays SHIFT
TO PARK. Once the shifter is moved to P (Park), the
vehicle turns off.
The DIC displays NO FOB, OFF OR RUN?, if the
keyless access transmitter is not detected inside the
vehicle when it is turned off.
SeeDIC Warnings and Messages
on page 4‑76for
more information.
Engine Coolant Heater
The engine coolant heater can provide easier starting
and better fuel economy during engine warm‐up in
cold weather conditions at or below −18°C (0°F).
Vehicles with an engine coolant heater should be
plugged in at least four hours before starting. Some
models have an internal thermostat in the cord which
will prevent engine coolant heater operation at
temperatures above −18°C (0°F).
To Use the Engine Coolant Heater
1. Turn off the engine.
2. Open the hood and unwrap the electrical cord.
The cord is located in the front of the engine
compartment, on the passenger side of the vehicle.
3. You must remove the plastic cap to access the plug.
4. Plug it into a normal, grounded 110-volt AC outlet.
{WARNING:
Plugging the cord into an ungrounded outlet could
cause an electrical shock. Also, the wrong kind of
extension cord could overheat and cause a fire.
You could be seriously injured. Plug the cord into
a properly grounded three-prong 110-volt AC
outlet. If the cord will not reach, use a heavy-duty
three-prong extension cord rated for at least
15 amps.
5. Before starting the engine, be sure to unplug and store the cord as it was before to keep it away from
moving engine parts. If you do not, it could be
damaged.
3-29

Black plate (32,1)Cadillac STS Owner Manual - 2011
Driver Shift Control (DSC)
Notice:If you drive the vehicle at a high rpm
without upshifting while using Driver Shift Control
(DSC), you could damage the vehicle. Always
upshift when necessary while using DSC.
Driver Shift Control (DSC) allows you shift an automatic
transmission similar to a manual transmission. To use
the DSC feature:
1. Move the shift lever to the right from D (Drive) into the DSC area.
When in DSC mode, the
sport symbol will appear
in the Driver Information
Center (DIC).
The vehicle will remain in sport mode if the
shift lever is not moved. Sport mode will shift
automatically but remain in a gear longer then it
would in normal driving mode based on braking
and acceleration. 2. Press the shift lever forward to upshift or rearward
to downshift.
When using the DSC
mode, the number
displayed on the Driver
Information Center (DIC)
indicates the gear that the
transmission is in. See
Driver Information Center
(DIC)
on page 4‑69for
more information on
the DIC.
When starting the vehicle from a stopped condition, only
1 (First) and 2 (Second) gear may be used.
While using the DSC feature the vehicle will have firmer
shifting and increased performance. You can use this
for sport driving or when climbing/descending hills to
stay in gear longer or to down shift for more power or
engine braking.
The transmission will only allow you to shift into
gears appropriate for the vehicle speed and engine
Revolutions Per Minute (RPM). The transmission will
not automatically shift to the next higher gear if the
engine RPM is too high.
3-32

Black plate (37,1)Cadillac STS Owner Manual - 2011
WARNING: (Continued)
death. Never run the engine in an enclosed area
that has no fresh air ventilation. For more
information, seeEngine Exhaust on page 3‑36.
{WARNING:
It can be dangerous to get out of the vehicle if the
automatic transmission shift lever is not fully in
P (Park) with the parking brake firmly set. The
vehicle can roll. Do not leave the vehicle when the
engine is running unless you have to. If you have
left the engine running, the vehicle can move
suddenly. You or others could be injured. To be
sure the vehicle will not move, even when you are
on fairly level ground, always set the parking
brake after you move the shift lever to P (Park).
Follow the proper steps to be sure the vehicle will not
move. See Shifting Into Park on page 3‑34.
If parking on a hill and pulling a trailer, see Towing a
Trailer on page 5‑31.
Mirrors
Automatic Dimming Rearview Mirror
The vehicle may have an inside rearview mirror with
automatic dimming and OnStar®controls; or it may
have OnStar®and a compass display. See the OnStar®
owner guide and/or Compasson page 3‑38for more
information.
O(On/Off): Press to turn the dimming feature on or off.
Automatic Dimming Mirror Operation
Automatic dimming reduces the glare of lights from
behind the vehicle. The dimming feature comes on and
the indicator light illuminates each time the vehicle is
started.
Cleaning the Mirror
Do not spray glass cleaner directly on the mirror. Use a
soft towel dampened with water.
3-37
