CHRYSLER VOYAGER 1996 Service Manual

Component/
GroundColor Location Fig.
Transmission
Control
SolenoidsBK Front of
Transmission7, 9
Turbine Speed
SensorGY Front of
Transmission7, 9
Turn Signal/
Hazard SwitchBK Part of
Multifunction
Switch11
Upstream
Heated Oxygen
SensorGY Rear of Engine 5, 6, 7,
8, 9Component/
GroundColor Location Fig.
Vehicle Speed
Control ServoBK LT Rear of
Engine
Compartment5, 6, 7,
8, 9
Vehicle Speed
SensorBK Rear of
Transmission5, 6, 8
Windshield
Wiper SwitchBK Part of
Multifunction
Switch11
Wiper Module BK LT Side of
Engine2
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 7
DESCRIPTION AND OPERATION (Continued)

Fig. 1 Ground LocationsÐLHD
8W - 90 - 8 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)

Fig. 2 Engine Compartment ConnetionsÐLHD
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 9
DESCRIPTION AND OPERATION (Continued)

Fig. 3 Engine Compartment ConnectionsÐLHD
8W - 90 - 10 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)

Fig. 4 Engine Compartment ConnectionsÐLHD
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 11
DESCRIPTION AND OPERATION (Continued)

Fig. 5 Engine ConnectionsÐ2.0L, LHD
8W - 90 - 12 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)

Fig. 6 Engine ConnectionsÐ2.4L (M/T), LHD
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 13
DESCRIPTION AND OPERATION (Continued)

Fig. 7 Engine ConnectionsÐ2.4L (A/T), LHD
8W - 90 - 14 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)

Fig. 8 Engine ConnectionsÐ2.5L, LHD
NS/GS8W - 90 CONNECTOR/GROUND LOCATIONS 8W - 90 - 15
DESCRIPTION AND OPERATION (Continued)

Fig. 9 Engine ConnectionsÐ3.3L, 3.8L, LHD
8W - 90 - 16 8W - 90 CONNECTOR/GROUND LOCATIONSNS/GS
DESCRIPTION AND OPERATION (Continued)
