138
Checks T o c h e c k t h e m a i n l e v e l s
and certain components,
in accordance with the
manufacturer's servicing schedule,
refer to the pages of the servicing
b o o k l e t w h i c h c o r r e s p o n d t o y o u r
vehicle's engine.
Bleeding the water contained in
the Diesel filter
Manual gearbox
H a v e t h e l e v e l c h e c k e d i n a c c o r d a n c e w i t h
the manufacturer's servicing schedule.
Only use products recommended
by CITROËN or products of
e q u i v a l e n t q u a l i t y a n d s p e c i fi c a t i o n .
In order to optimise the operation
o f u n i t s a s i m p o r t a n t a s t h e b r a k i n g
system, CITROËN selects and offers
s p e c i fi c p r o d u c t s .
In order to avoid damaging the
electrical units, high pressure washing
to clean the engine compartment is
strictly prohibited.
If this warning lamp comes
o n , b l e e d t h e fi l t e r . O t h e r w i s e
bleed regularly each time the
engine oil is changed.
To drain the water, unscrew
t h e b l e e d s c r e w l o c a t e d o n t h e fi l t e r .
Operate until all of the water no longer
fl o w s i n t h e t r a n s p a r e n t p i p e , t h e n
tighten the bleed screw.
HDi engines use advanced technology.
A l l w o r k r e q u i r e s s p e c i a l t r a i n i n g , w h i c h
is assured by a CITROËN dealer.
According to country.
Page 142 of 223
139
6
Fuel
FILLING WITH FUEL
Low fuel level Filling
T h e f u e l t a n k m u s t b e fi l l e d
with the
engine off .
- O p e n t h e f u e l fi l l e r fl a p .
- I n s e r t t h e k e y , t h e n t u r n i t a q u a r t e r turn.
- R e m o v e t h e c a p a n d h o o k i t o n t o t h e c l i p l o c a t e d o n t h e i n s i d e o f t h e fl a p .
W h e n fi l l i n g w i t h f u e l , a
mechanical system prevents
o p e n i n g o f t h e l e f t - h a n d s i d e d o o r .
W h e n t h e f u e l fi l l e r fl a p i s o p e n , e n s u r e
that no one tries to slide this door.
O n c e t h e fl a p h a s b e e n c l o s e d , t h e
s l i d i n g s i d e d o o r m a y j a m , p u s h t h e
door to close it then open it.
W h e n t h e m i n i m u m f u e l t a n k
level is reached, this warning
light comes on.
You then have
approximately 8 litres of
fuel remaining. Fill up without delay to
avoid running out of fuel.
N e v e r r i s k d r i v i n g u n t i l y o u r u n o u t
of fuel as this may damage the
a n t i p o l l u t i o n a n d i n j e c t i o n s y s t e m s . A l a b e l a f fi x e d t o t h e i n s i d e o f t h e fl a p
reminds you of the type of fuel to be
used.
Y o u m u s t fi l l w i t h a t l e a s t 5 l i t r e s o f f u e l
for it to be registered by the fuel gauge.
W h e n t h e f u e l fi l l e r c a p i s o p e n e d ,
there may be a slight air suction noise.
This vacuum is entirely normal and is
due to the sealing of the fuel circuit.
W h e n fi l l i n g t h e f u e l t a n k , d o n o t
c o n t i n u e a f t e r t h e 3 r d c u t - o f f o f t h e
nozzle. This could cause malfunctions.
T h e c a p a c i t y o f t h e f u e l t a n k i s
approximately 60 litres.
- A f t e r fi l l i n g t h e f u e l t a n k , l o c k t h e
c a p a n d c l o s e t h e fl a p . Quality of the fuel used for
petrol engines
The petrol engines are perfectly
compatible with E10 type petrol
b i o f u e l s ( c o n t a i n i n g 1 0 % e t h a n o l ) ,
conforming to European standards
EN 228 and EN 15376.
E 8 5 t y p e f u e l s ( c o n t a i n i n g u p t o 8 5 %
e t h a n o l ) a r e r e s e r v e d e x c l u s i v e l y f o r
v e h i c l e s m a r k e t e d f o r t h e u s e o f t h i s
t y p e o f f u e l ( B i o F l e x v e h i c l e s ) . T h e
quality of the ethanol must comply with
European standard EN 15293.
For Brazil only, special vehicles are
m a r k e t e d t o r u n o n f u e l s c o n t a i n i n g u p
t o 1 0 0 % e t h a n o l ( E 1 0 0 t y p e ) .
Page 143 of 223
DIESEL
140
Fuel
FUEL CIRCUIT DISARMED
In a serious collision, a mechanism
automatically prevents fuel from
reaching the engine. T h e fl a s h i n g o f t h i s w a r n i n g
light is accompanied by a
message on the display.
C h e c k t h a t t h e r e i s n o o d o u r o r
l e a k a g e o f f u e l o u t s i d e t h e v e h i c l e a n d
r e - e s t a b l i s h t h e f u e l s u p p l y :
- s w i t c h o f f t h e i g n i t i o n ( S T O P p o s i t i o n ) ,
- r e m o v e t h e k e y ,
- p u t t h e k e y b a c k i n t h e i g n i t i o n ,
- s w i t c h o n t h e i g n i t i o n a n d s t a r t .
DIESEL REPRIMING PUMP
If you should run out of fuel, it is
n e c e s s a r y t o r e - p r i m e t h e c i r c u i t :
- fi l l t h e f u e l t a n k w i t h a t l e a s t fi v e litres of diesel,
- s q u e e z e a n d r e l e a s e t h e m a n u a l r e - p r i m i n g p u m p , u n d e r t h e b o n n e t
under the protective cover,
- o p e r a t e t h e s t a r t e r u n t i l t h e e n g i n e starts.
Refer to the "Under the bonnet"
section of chapter 6.
Quality of the fuel used for
Diesel engines
The Diesel engines are perfectly
compatible with biofuels which conform
to current and future European
s t a n d a r d s ( D i e s e l f u e l w h i c h c o m p l i e s
with standard EN 590 mixed with a
biofuel which complies with standard
E N 1 4 2 1 4 ) a v a i l a b l e a t t h e p u m p s
( c o n t a i n i n g u p t o 7 % F a t t y A c i d M e t h y l
E s t e r ) .
The B30 biofuel can be used in certain
Diesel engines; however, this use
i s s u b j e c t t o s t r i c t a p p l i c a t i o n o f t h e
special servicing conditions. Consult a
CITROËN dealer.
T h e u s e o f a n y o t h e r t y p e o f ( b i o ) f u e l
( v e g e t a b l e o r a n i m a l o i l s , p u r e o r
d i l u t e d , d o m e s t i c f u e l . . . ) i s s t r i c t l y
p r o h i b i t e d ( r i s k o f d a m a g e t o t h e
e n g i n e a n d f u e l s y s t e m ) .
Page 144 of 223
DIESEL
140
Fuel
FUEL CIRCUIT DISARMED
In a serious collision, a mechanism
automatically prevents fuel from
reaching the engine. T h e fl a s h i n g o f t h i s w a r n i n g
light is accompanied by a
message on the display.
C h e c k t h a t t h e r e i s n o o d o u r o r
l e a k a g e o f f u e l o u t s i d e t h e v e h i c l e a n d
r e - e s t a b l i s h t h e f u e l s u p p l y :
- s w i t c h o f f t h e i g n i t i o n ( S T O P p o s i t i o n ) ,
- r e m o v e t h e k e y ,
- p u t t h e k e y b a c k i n t h e i g n i t i o n ,
- s w i t c h o n t h e i g n i t i o n a n d s t a r t .
DIESEL REPRIMING PUMP
If you should run out of fuel, it is
n e c e s s a r y t o r e - p r i m e t h e c i r c u i t :
- fi l l t h e f u e l t a n k w i t h a t l e a s t fi v e litres of diesel,
- s q u e e z e a n d r e l e a s e t h e m a n u a l r e - p r i m i n g p u m p , u n d e r t h e b o n n e t
under the protective cover,
- o p e r a t e t h e s t a r t e r u n t i l t h e e n g i n e starts.
Refer to the "Under the bonnet"
section of chapter 6.
Quality of the fuel used for
Diesel engines
The Diesel engines are perfectly
compatible with biofuels which conform
to current and future European
s t a n d a r d s ( D i e s e l f u e l w h i c h c o m p l i e s
with standard EN 590 mixed with a
biofuel which complies with standard
E N 1 4 2 1 4 ) a v a i l a b l e a t t h e p u m p s
( c o n t a i n i n g u p t o 7 % F a t t y A c i d M e t h y l
E s t e r ) .
The B30 biofuel can be used in certain
Diesel engines; however, this use
i s s u b j e c t t o s t r i c t a p p l i c a t i o n o f t h e
special servicing conditions. Consult a
CITROËN dealer.
T h e u s e o f a n y o t h e r t y p e o f ( b i o ) f u e l
( v e g e t a b l e o r a n i m a l o i l s , p u r e o r
d i l u t e d , d o m e s t i c f u e l . . . ) i s s t r i c t l y
p r o h i b i t e d ( r i s k o f d a m a g e t o t h e
e n g i n e a n d f u e l s y s t e m ) .
Page 145 of 223
141
Battery
QUICK HELP
7
BATTERY
Before disconnecting the battery, you
must wait for 2 minutes after switching
off the ignition.
Never disconnect a terminal when the
engine is running.
N e v e r c h a r g e a b a t t e r y w i t h o u t fi r s t
disconnecting the terminals.
After every reconnection of the battery,
switch on the ignition and wait 1 minute
before starting to allow the electronic
systems to be initialised. If slight
d i f fi c u l t i e s a r e e x p e r i e n c e d a f t e r t h i s ,
p l e a s e c o n t a c t a C I T R O Ë N d e a l e r .
After changing bulbs, wait
a p p r o x i m a t e l y 3 m i n u t e s b e f o r e
reconnecting the battery. It is advisable to disconnect the
battery if the vehicle is not to be used
f o r a p e r i o d o f m o r e t h a n o n e m o n t h .
To charge the battery using a
battery charger
- Disconnect the battery,
- Follow the instructions for use
given by the battery charger
manufacturer,
- R e c o n n e c t s t a r t i n g w i t h t h e negative (-) terminal,
- C h e c k t h a t t h e t e r m i n a l s a n d connectors are clean. If they are
c o v e r e d w i t h s u l p h a t e ( w h i t e o r
g r e e n i s h d e p o s i t ) , d i s c o n n e c t t h e m
and clean them.
To start the vehicle from
another battery
- C o n n e c t t h e r e d c a b l e t o t h e p o s i t i v e ( + ) t e r m i n a l s o f t h e t w o
batteries,
- C o n n e c t o n e e n d o f t h e g r e e n o r b l a c k c a b l e t o t h e n e g a t i v e ( - )
terminal of the slave battery,
- C o n n e c t t h e o t h e r e n d o f t h e g r e e n o r b l a c k c a b l e t o a n e a r t h p o i n t o n
t h e b r o k e n d o w n v e h i c l e a s f a r a s
p o s s i b l e f r o m t h e b a t t e r y ,
- O p e r a t e t h e s t a r t e r , l e t t h e e n g i n e r u n ,
- Wait for the engine to return to idle, then disconnect the cables. A f t e r t h e e n g i n e h a s s t o p p e d , w i t h
t h e k e y i n t h e i g n i t i o n p o s i t i o n , c e r t a i n
f u n c t i o n s ( w i n d s c r e e n w i p e r , e l e c t r i c
windows, courtesy lights, audio
e q u i p m e n t , e t c . ) c a n o n l y b e u s e d f o r
a cumulative duration of thirty minutes,
t o p r e v e n t d i s c h a r g i n g o f t h e b a t t e r y .
O n c e t h e t h i r t y m i n u t e s a r e o v e r , t h e
a c t i v e f u n c t i o n s a r e p u t o n s t a n d b y
a n d t h e b a t t e r y w a r n i n g l i g h t fl a s h e s
a c c o m p a n i e d b y a m e s s a g e o n
t h e d i s p l a y .
T o r e s u m e t h e u s e o f t h e s e f u n c t i o n s
immediately, start the engine and let it
run for a few minutes.
T h e t i m e a v a i l a b l e w i l l t h e n b e d o u b l e
the time for which the engine was left
running. However, this time will always
b e b e t w e e n fi v e a n d t h i r t y m i n u t e s .
A fl a t b a t t e r y w i l l p r e v e n t t h e e n g i n e
from starting.
Page 146 of 223
142
Changing a wheel
T h e t e m p o r a r y t y r e r e p a i r k i t c o n s i s t s
o f a c o m p r e s s o r a n d a b o t t l e
(containing a sealant). Using the kit
1. T i c k t h e d e fl a t e d w h e e l o n t h e
s p e e d l i m i t a t i o n s t i c k e r t h e n a f fi x
t h e s t i c k e r t o t h e v e h i c l e ' s s t e e r i n g
wheel to remind you that a wheel is
i n t e m p o r a r y u s e .
2. C l i p t h e b o t t l e 1 o n t h e c o m p r e s s o r 2 .
3. C o n n e c t t h e b o t t l e 1 to the valve of
t h e t y r e t o b e r e p a i r e d .
4. T a k e c a r e t o u n w i n d t h e
c o m p r e s s o r p i p e b e f o r e c o n n e c t i n g
it to the bottle.
5. C o n n e c t t h e p o w e r l e a d t o o n e o f
t h e v e h i c l e ' s 1 2 V s o c k e t s .
6. S w i t c h o n t h e c o m p r e s s o r b y
p r e s s i n g b u t t o n A until the tyre
p r e s s u r e r e a c h e s 2 . 0 b a r s . I f t h i s
p r e s s u r e c a n n o t b e r e a c h e d , t h e
t y r e c a n n o t b e r e p a i r e d .
7. R e m o v e a n d s t o r e t h e c o m p r e s s o r .
8. Drive immediately, for a few miles
( k i l o m e t r e s ) , a t r e d u c e d s p e e d , t o
fi l l t h e p u n c t u r e .
9. A d j u s t t h e p r e s s u r e u s i n g t h e
c o m p r e s s o r i n a c c o r d a n c e w i t h t h e
recommendation for the vehicle and
c h e c k t h a t t h e l e a k i s fi l l e d c o r r e c t l y
( n o f u r t h e r l o s s o f p r e s s u r e ) .
10. D r i v e a t r e d u c e d s p e e d ( 5 0 m p h
[ 8 0 k m / h ] ) . T h e t y r e m u s t b e
e x a m i n e d a n d r e p a i r e d b y a
p r o f e s s i o n a l a s s o o n a s p o s s i b l e . After use, the bottle can be stored in
a p l a s t i c b a g , s u p p l i e d i n t h e k i t , t o
avoid staining your vehicle with traces
o f fl u i d .
Warning: the bottle of gel contains
e t h y l e n e - g l y c o l , a p r o d u c t w h i c h
is harmful if swallowed and which
causes irritation to the eyes.
K e e p i t o u t o f r e a c h o f c h i l d r e n .
After use, do not discard the bottle into
t h e e n v i r o n m e n t , t a k e i t t o a C I T R O Ë N
d e a l e r o r t o a n s p e c i a l i s e d w a s t e
d i s p o s a l s i t e .
R e p l a c e m e n t b o t t l e s o f s e a l a n t a r e
a v a i l a b l e f r o m C I T R O Ë N d e a l e r s .
T h e k i t i s l o c a t e d i n o n e o f t h e t w o
s t o r a g e c o m p a r t m e n t s l o c a t e d u n d e r
the front seats.
V e h i c l e s s u p p l i e d w i t h a t e m p o r a r y
p u n c t u r e r e p a i r k i t d o n o t h a v e a s p a r e
w h e e l o r t o o l i n g ( j a c k , w h e e l b r a c e , . . . ) .
Page 147 of 223
1 4 3
QUICK HELP
7
Changing a wheel
1. PARKING THE VEHICLE
- T h e o c c u p a n t s m u s t g e t o u t o f t h e vehicle and wait in a safe location.
- I f p o s s i b l e , p a r k t h e v e h i c l e o n l e v e l , s t a b l e a n d n o n - s l i p p e r y g r o u n d .
- A p p l y t h e p a r k i n g b r a k e , s w i t c h o f f t h e i g n i t i o n a n d e n g a g e fi r s t o r
reverse gear. - I f a v a i l a b l e , p l a c e a c h o c k u n d e r
t h e w h e e l d i a g o n a l l y o p p o s i t e t h e
one to be changed.
I f t h e v e h i c l e i s fi t t e d w i t h a t o w b a r ,
it is sometimes necessary to raise
t h e v e h i c l e s l i g h t l y t o m a k e i t e a s i e r
t o r e m o v e t h e s p a r e w h e e l f r o m i t s
carrier.
O n c e r t a i n t y p e s o f g r o u n d a n d / o r
if considerable loads are being
t r a n s p o r t e d , c a l l a C I T R O Ë N d e a l e r .
CHANGING A WHEEL
2. TOOLS
- T h e t o o l s a r e s t o w e d i n a s t o r a g e c o m p a r t m e n t l o c a t e d u n d e r t h e
front seat. If necessary, move the
seat forward to access the storage
c o m p a r t m e n t f r o m t h e r e a r .
- U n s c r e w t h e n u t t h e n t a k e o u t t h e j a c k a n d t h e w h e e l b r a c e .
1. Wheelbrace.
2. J a c k .
3. Alloy wheel embellisher remover.
4. C h o c k .
T h e j a c k a n d t h e t o o l k i t a r e s p e c i fi c t o
your vehicle. Do not use them for other
p u r p o s e s .
Page 148 of 223
144
Changing a wheel
3. SPARE WHEEL - Unscrew the bolt using the wheelbrace until the carrier is
lowered fully.
- O p e n t h e r e a r d o o r s t o g a i n a c c e s s
t o t h e s p a r e w h e e l . - D e t a c h t h e c a r r i e r f r o m t h e h o o k
a n d p l a c e t h e s p a r e w h e e l n e a r t h e
wheel to be changed.
Page 149 of 223
1 4 5
QUICK HELP
7
Changing a wheel
4. OPERATING PROCEDURE - P l a c e t h e j a c k i n c o n t a c t w i t h t h e l o c a t i n g p o i n t p r o v i d e d , t h e o n e
which is closest to the wheel to
b e c h a n g e d . E n s u r e t h a t t h e j a c k
is straight and that the base of
t h e j a c k i s f u l l y i n c o n t a c t w i t h t h e
ground.
- E x t e n d t h e j a c k t o l i f t t h e w h e e l clear of the ground.
- R e s u m e a n d c o m p l e t e t h e unscrewing of the wheel bolts.
- R e m o v e t h e b o l t s a n d r e m o v e the wheel.
- R e m o v e t h e t r i m p u l l i n g i t u s i n g t h e
embellisher remover.
- Loosen the wheel bolts and start unscrewing them. D o n o t e x t e n d t h e j a c k u n t i l y o u h a v e
started unscrewing the bolts on the
w h e e l t o b e c h a n g e d a n d h a v e p l a c e d
t h e c h o c k u n d e r t h e w h e e l d i a g o n a l l y
o p p o s i t e .
Page 150 of 223
146
Changing a wheel - L o w e r t h e v e h i c l e c o m p l e t e l y b y f o l d i n g t h e j a c k , t h e n r e m o v e t h e
j a c k .
- T i g h t e n t h e b o l t s a g a i n u s i n g t h e wheelbrace, tighten them fully
without forcing them.
- P l a c e t h e w h e e l t o b e r e p a i r e d i n the carrier. - S e c u r e t h e c a r r i e r o n t h e h o o k t h e n
raise the carrier using the bolt and
the wheelbrace.
Never go underneath a vehicle that
i s s u p p o r t e d o n l y b y a j a c k ( u s e a
r a m p ) . N e v e r u s e a s c r e w d r i v e r i n
p l a c e o f t h e w h e e l b r a c e .
5. FITTING THE SPARE WHEEL
- Position the wheel on the hub and
start tightening the bolts by hand.
- C a r r y o u t a n i n i t i a l t i g h t e n i n g o f t h e bolts using the wheelbrace.
