fuse box CITROEN BERLINGO VAN 2021 Handbook (in English)

5
Overview
Instruments and controls
1.Bonnet release
2. Dashboard fuses
3. Horn
4. Instrument panel 5.
Alarm
Courtesy lamp
Warning lamp display for seat belts and front
passenger airbag
Panoramic roof blind control
Interior rear view mirror
Monitoring mirror
Emergency and assistance call buttons
6. Monochrome screen with audio system
Touch screen with CITROËN Connect Radio
or CITROËN Connect Nav
7. USB port
8. Heating
Manual air conditioning
Dual-zone automatic air conditioning
Front demisting - defrosting
Rear screen demisting – defrosting
9. Electric parking brake
"START/STOP" button
10. Gearbox
11 . 12 V socket
12. 230 V accessory socket
13. Glove box
USB port (inside the glove box)
14. Glove box
15. Front passenger airbag deactivation (on the
side of the glove box, with the door open)
Steering mounted controls
1.External lighting / direction indicators control
stalk
Voice recognition activation button
2. Wiper / screenwash / trip computer control
stalk
3. Controls to select the multimedia source
(SRC), manage music (LIST) and manage
phone calls (" telephone" symbol)
4. Speed Limiter / Programmable Cruise Control
/ Adaptive cruise control controls
5. Instrument panel display mode selection
wheel
6. Voice control
Volume adjustment
7. Audio system setting controls

120
Driving
Displays in the instrument
panel


7.Vehicle detected by the system (full symbol)
8. Cruise control active (colour not in grey)
9. Value of the speed setting
10. Speed suggested by the Speed Limit
Recognition and Recommendation
11 . Vehicle held stationary (versions with
automatic gearbox)


12.Inter-vehicle distance setting
13. Position of the vehicle detected by the
system
Messages and alerts
The display of these messages or alerts
is not sequential.
"Cruise control paused" or "Cruise control
suspended" following a brief acceleration
by the driver.
"Cruise control active", no vehicle
detected.
"Cruise control paused", vehicle detected.
"Cruise control active", vehicle detected.
"Take back control" (orange).
►

Brake or accelerate, depending on the
context.
"Take back control" (red).
►

T

ake back control of the vehicle
immediately: the system cannot manage the
current driving situation.
"Activation not possible, conditions
unsuitable". The system refuses to
activate cruise control, as the necessary
conditions are not fulfilled.
Stop function
"Cruise control paused" (for a few
seconds).
The system has brought the vehicle to a
complete stop and is holding it immobilised:
cruise control is paused.
The driver must accelerate to move off again,
then reactivate cruise control.
Operating limits
Cruise control operates by day and night, in fog
or moderate rainfall.
Certain situations cannot be managed by the
system and require driver intervention.
Elements not detected by the system:
–

Pedestrians, some cyclists, animals.
–


Stationary vehicles (traffic jam, breakdown,
etc.).


– Vehicles crossing your lane.
– V ehicles driving in the opposite direction.
Situations in which the driver must pause the
cruise control system:


– Vehicles in a tight bend.
– When approaching a roundabout.

147
Practical information
7► Lower the bonnet and release it near the end
of its travel.
►

Pull on the bonnet to check that it is locked
correctly

.
Because of the presence of electrical
equipment under the bonnet, it is
recommended that exposure to water (rain,
washing, etc.) be limited.
Engine compartment
The engine represented is an example given for
illustration purposes only.
The locations of the following elements may
vary:
–

Air filter
.
–

Engine oil dipstick.
–


Engine oil filler cap.
Petrol engine

Diesel engine

1. Screenwash fluid reservoir
2. Engine coolant reservoir
3. Brake fluid reservoir
4. Battery / Fuses
5. Remote earth point (-)
6. Fusebox
7. Air filter
8. Engine oil filler cap
9. Engine oil dipstick
The Diesel fuel system operates under
very high pressure.
All work on this circuit must be carried out
only by a CITROËN dealer or a qualified
workshop.
Checking levels
Check all of the following levels regularly in
accordance with the manufacturer's service
schedule. Top them up if required, unless
otherwise indicated.
If a level drops significantly, have the
corresponding system checked by a CITROËN
dealer or a qualified workshop.
The fluids must comply with the manufacturer's requirements and with
the vehicle's engine.
Take care when working under the bonnet, as certain areas of the engine
may be extremely hot (risk of burns) and the
cooling fan could start at any time (even with
the ignition off).
Used products
Avoid prolonged contact of used oil or fluids with the skin.
Most of these fluids are harmful to health and
very corrosive.
Do not discard used oil or fluids into
sewers or onto the ground.
Empty used oil into the containers reserved
for this purpose at a CITROËN dealer or a
qualified workshop.
Engine oil
The level is checked, with the engine having been switched off for at least 30
minutes and on level ground, either using the oil
level indicator in the instrument panel when the

167
In the event of a breakdown
8► Unclip the interior trim.
► Disconnect the connector by moving aside
its tab.
►

T
urn the bulb holder a quarter turn
anti-clockwise.
►

Change the bulb.
►


Put the bulb holder back in place and
reconnect the connector

.
►

Put the trim back in place.
With tailgate


► Remove the plastic lens using a screwdriver .
► Change the bulb.
►

Refit the plastic lens and press on it.
Third brake lamp
Type A, W16W - 16W

– Unscrew the two nuts. –
Push the rods.
–

If necessary
, disconnect the connector to
remove the lamp.
–
Replace the bulb.
Changing a fuse
Accessing the tools







The extraction tweezers are located behind the
fusebox cover.
►
Unclip the cover by pulling at the top left, then
right.
►


Remove the cover completely
.
►

T
ake the tweezers from their housing.
Changing a fuse
Before changing a fuse:
► Identify the cause of the fault and fix it.
►

Stop all power consumption.
►


Immobilise the vehicle and switch the ignition
off.
►


Identify the defective fuse using the current
allocation tables and diagrams.
T

o replace a fuse, it is essential to:
►

Use the special tweezers to extract the fuse
from its housing and check the condition of its
filament.
►


Always replace the failed fuse with a fuse of
the same rating (same colour); use of a different
rating may cause malfunctions - risk of fire!
If the fault recurs after replacing a fuse, have the
electrical system checked by a CITROËN dealer
or a qualified workshop.
The fuse allocation tables and the corresponding diagrams are available
from a CITROËN dealer or from a qualified
workshop.
The replacement of a fuse not shown in the allocation tables may cause a serious

168
In the event of a breakdown
Fuse No. Rating (A) Functions
F34 5Mirror control.
F36 5 USB port.
Engine compartment fuses
The fusebox is placed in the engine
compartment near the battery.
Access to the fuses

► Release the two latches A.
► Remove the cover.
► Change the fuse.
► When you have finished, close the cover
carefully then engage the two latches A, to
ensure correct sealing of the fusebox.

malfunction of your vehicle. Contact a
CITROËN dealer or a qualified workshop.


Good
Failed

Tweezers
Installing electrical accessories
Your vehicle's electrical system is
designed to operate with standard or optional
equipment.
Before installing other electrical equipment
or accessories on your vehicle, contact a
CITROËN dealer or a qualified workshop.
CITROËN will not accept responsibility
for the cost incurred in repairing your
vehicle or for rectifying malfunctions resulting
from the installation of accessories not
supplied and not recommended by CITROËN
and not installed in accordance with its
instructions, in particular when the combined
consumption of all of the additional equipment
connected exceeds 10 milliamperes.
For more information on installing a
towbar or TAXI type equipment, contact a
CITROËN dealer.
Dashboard fuses
The fusebox is placed in the lower dashboard
(left-hand side).
Access to the fuses
► Unclip the cover by pulling at the top left, then
right.
The fuses described below vary according to the equipment in your vehicle.


Fuse No. Rating (A) Functions
F1 10Wireless
smartphone
charger, interior
electrochrome
rear view mirror.
Fuse No. Rating (A) Functions
F415Horn.
F6 20Screenwash
pump.
F7 1012 V socket
(rear).
F10 30 Electric locks
module.
F13 10 Telematics and
radio controls.
F14 5 Alarm,
advanced
telematic unit.
F19 3 Trailer interface
unit.
F23 5 Generic trailer
interface unit.
F27 5 Additional
heating.
F29 20 Audio system,
touch screen.
F31 15 Audio system
(as an
accessory).
F32 15 12 V socket
(front).

169
In the event of a breakdown
8Fuse No. Rating (A) Functions
F34 5Mirror control.
F36 5 USB port.
Engine compartment fuses
The fusebox is placed in the engine
compartment near the battery.
Access to the fuses

► Release the two latches A .
► Remove the cover .
►

Change the fuse.
►


When you have finished, close the cover
carefully then engage the two latches A

, to
ensure correct sealing of the fusebox.


Fuse No. Rating (A) Functions
F16 15 Front foglamp.
F18 10 Right-hand
main beam
headlamp.
F19 10 Left-hand
main beam
headlamp.
F29 40 Windscreen
wipers.
12 V battery
Procedure for starting the engine using another
battery or charging a discharged battery.
Lead-acid starter batteries
Batteries contain harmful substances
such as sulphuric acid and lead.
They must be disposed of in accordance
with regulations and must not, in any
circumstances, be discarded with household
waste.
Take used remote control batteries and
vehicle batteries to a special collection point.
Protect your eyes and face before
handling the battery.
All operations on the battery must be carried
out in a well ventilated area and away from
naked flames and sources of sparks, so as to
avoid the risk of explosion or fire.
Wash your hands afterwards.
Versions equipped with Stop & Start are
fitted with a 12 V lead-acid battery with
special technology and specifications.
It should only be replaced by a CITROËN
dealer or a qualified workshop.
Access to the battery
The battery is located under the bonnet.
► Open the bonnet using the interior release
lever
, then the exterior safety catch.
►

Secure the bonnet stay
.

235
Alphabetical index
Filter, air 150
Filter, oil
150
Filter, particle

149–150
Filter, passenger compartment

52, 149
Finisher

161
Fitting a wheel

159, 161
Fitting roof bars

145
Fittings, interior

45, 49
Flap, fuel filler

140–141
Flashing indicators

62–63, 166
Fluid, brake

148
Fluid, engine coolant

148
Foglamp, rear

166
Foglamps

165
Foglamps, front

61, 163
Foglamps, rear

61
Folding the rear seats

41–43
Frequency (radio)

223
Fuel

7, 140
Fuel consumption

7
Fuel tank

140–141
Fusebox, dashboard

167
Fusebox, engine compartment

167, 169
Fuses

167–169
G
Gauge, fuel 140–141
Gearbox, automatic
96, 100–105, 150
Gearbox, manual

100–101, 105, 150
Gear lever, automatic gearbox

101–103
Gear lever, manual gearbox 100–101
Gear shift indicator ~ Gear efficiency
indicator

104
Glove box

45
G.P.S.

216
H
Hazard warning lamps 52, 72
headlamp adjustment
65
Headlamp adjustment

65
Headlamps, automatic dipping

63–64, 128
Headlamps, automatic illumination

62–63
Headlamps, dipped beam

61, 163–164
Headlamps, halogen

162
Headlamps, main beam

61, 163–164
Head restraints, front

45
Head restraints, rear

41–42
Head-up display

107–108
Heating

52–53, 55, 57–58
Heating, additional

33, 57–58
Heating, programmable

33, 57–58
Hill Assist Descent Control (HADC)

77
Hill Descent Control

77
Hill start assist

99–100
Horn

73
I
Ignition 96, 227
Ignition on 96
Immobiliser, electronic
93
Indicator, coolant temperature

16
Indicator lamps, operation

61
Indicators, direction

62
Inflating tyres

150, 181
Inflating tyres and accessories
(using the kit)

156, 158
Infrared camera

109
Instrument panel

9, 110
Internet browser

217, 221
ISOFIX

89
J
Jack 158, 224
Jump starting
170
K
Key 23–24, 26–28
Key, electronic
23, 96
Keyless Entry and Starting

23, 25–26, 94, 96
Key with remote control

26
Kit, hands-free

189–190, 202, 225–226
Kit, puncture repair

155
Kit, temporary puncture repair

155–156, 158

237
Alphabetical index
Priming the fuel system 155
Profiles
204, 228
Programmable cruise control

11 5
Protecting children

80, 82–85
Puncture

156, 158
R
Radar (warnings) 109
Radio
184–185, 197, 200, 222
Radio, digital (Digital Audio Broadcasting -
DAB)

185, 199–200, 223
Range, AdBlue

149
RDS

198, 223
Rear screen, demisting

56
Recharging the battery

170–171
Recirculation, air

53–54
Recovery

172
Reduction of electrical load

145
Regeneration of the particle filter

150
Reinitialisation of the under-inflation
detection system

107
Reinitialising the remote control

29
Reminder, key in ignition

96
Reminder, lighting on

61–62
Remote control

23–27, 93
Removing a wheel

159, 161
Removing the mat

45
Replacing bulbs

161–162
Replacing fuses

167–169
Replacing the air filter

150
Replacing the oil filter 150
Replacing the passenger compartment
filter

149
Reservoir, screenwash

149
Reversing camera

109, 132–133
Reversing lamps

166
Roof

46
Roof bars

145
Running out of fuel (Diesel)

155
S
Safety, children 80, 82–85
Saturation of the particle filter (Diesel)
150
Screen menu map

201
Screen, multifunction (with audio system)

183
Screenwash, front

66
Screenwash, rear

66
SCR (Selective Catalytic Reduction)

151
Seat belts

77–78, 85
Seat, rear bench

41, 43
Seats, front

37–39
Seats, heated

39
Seats, rear

37, 41–44, 83
Sensors (warnings)

109
Serial number, vehicle

181
Service indicator

16
Servicing

16, 149
Settings, system

204, 228
Sidelamps

61, 63, 163–164
Side parking sensors

131
Side repeater 163
Sliding side door, electric
26, 32
Snow chains

106, 142
Snow chains, link

142
Socket, 12 V accessory

45, 47
Socket, 220 V

47
Socket, auxiliary

187, 200, 224
Socket, Jack

187, 224
Speed limiter

112–115, 121
Speed limit recognition

11 0 – 111
Speedometer

11 0
Stability control (ESC)

73–76
Starting a Diesel engine

140
Starting the engine

93
Starting the vehicle

94, 96, 101–103
Starting using another battery

170
Station, radio

184, 197, 222–223
Stay, bonnet

146
Steering mounted controls,
audio

183–184, 195, 209
Steering wheel, adjustment

40
Stickers, customising ~ Stickers,
expressive

154
Stopping the vehicle

96, 101–103
Stop & Start

22, 53, 56, 104–106,
140, 146, 149, 169, 172
Storage

46
Storage boxes

49
Stowing rings

51
Sunshine sensor

52
Switching off the engine

93, 95
Synchronising the remote control

29
