Citroen C4 RHD 2012 2.G Owner's Manual

249
7
8
06

Enter the same code on the telephone then accept
the connection.
The " Hands-free mode
" should be used in preference if
"Streaming" is not desired.
Then accept automatic connection on the telephone to allow
the telephone to reconnect automatically every time the vehicle
is started.


USING THE TELEPHONE


The ability of the system to connect in only one mode depends on
the telephone. The two modes may both connect by default.
The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone
manual and with your network provider for details of the services available to you.

Select a code for the connection then
confi rm " OK
".
On return to the vehicle, the last telephone connected
automatically reconnects, within around 30 seconds after
switching on the ignition (Bluetooth activated and visible).
To modify the automatic connection mode, remove the pairing and
pair the telephone again with the desired mode.

250
1
2a
2b
2c
2d
2e
06USING THE TELEPHONE

DIRECTORY/SYNCHRONIZING CONTACTS


Press PHONE
then select " Contacts
management
" and confi rm.

Select " New contact
" to enter a new
contact.

Select " Delete all contacts
" to delete
the contacts saved in the system.

Select " Import all the entries
" to import
all the contacts in the telephone and
save them in the system.
Once imported, a contact remains visible
whatever telephone is connected.
Selection " Synchronization options
":


- No synchronization: only the
contacts saved in the system
(always present).

- Display telephone contacts: only the
contacts saved in the telephone.

- Display SIM card contacts: only the
contacts saved on the SIM card.

- Display all phone contacts:
contacts on the SIM card and in the
telephone.


Select " Contact mem. status
" to see the
number of contacts saved in the system
or imported, and the free memory.

251
1
2
3
4
5
6
7
06

MANAGING CONTACTS


Press PHONE
then select " Directory of
contacts
" and confi rm.

Select the desired contact and confi rm.
Select " Import
" to copy one contact to
the system.

Select " Call
" to start the call.

Select " Open
" to view an external contact
or modify a contact saved in the system.
Select OK
or ESC
to exit this menu.

Select " Delete
" to delete a contact saved
in the system.
It is necessary to import an external contact to modify the record.
It will be saved in the system. It is not possible to modify or delete
contacts in the telephone or the SIM card via the Bluetooth
connection.
USING THE TELEPHONE

252
1
2
2
3
1
3
4
06USING THE TELEPHONE

Press PHONE
twice.

Select " Dial
" then confi rm.
Select " Directory of contacts
" then
confi rm.

Dial the telephone number using the
virtual keypad selecting each number
in turn.
Confi rm " OK
" to make the call.

Press TEL
or twice on PHONE
.
CALLING A NEW NUMBER

CALLING A CONTACT

Select the desired contact and confi rm.
If access was via the PHONE
button,
select " Call
" and confi rm.

Select the number and confi rm to start
the call.








MAKING A CALL

Use of the telephone is not recommended while driving. We
recommended that you park safely or make use of the steering
mounted controls.

253
1
2
06
1
USING THE TELEPHONE


CALLING A RECENTLY ENTERED NUMBER

Press TEL
, select " Call list
" and
confi rm,

Select the desired number and confi rm.

To erase the calls log, press PHONE
twice, select " Phone
functions
" and confi rm then select " Delete calls log
" and
confi rm.



ENDING A CALL


Press PHONE
then select " OK
" to end
the call.

Or make a long press on TEL
at the
steering mounted controls.

Or make two short presses on TEL
at
the steering mounted controls.

Or press the MODE
button, as many
times as necessary, until the telephone
screen is displayed. press PHONE
to display the calls log. or
Press " OK
" to display the contextual
menu then select " Hang up
" and
confi rm.

254
1
2
06USING THE TELEPHONE

RECEIVING A CALL


An incoming call is announced by a ring and a superimposed display
on the screen.


"Ye s
" to accept the call is selected by
default.
Press " OK
" to accept the call.
Select " No
" and confi rm to reject the
call.

A short press on TEL
accepts an
incoming call.
A long press on TEL
rejects an
incoming call.

255
1
2a
2b
2c
2d
06USING THE TELEPHONE

OPTIONS DURING A CALL *


During a call, press the MODE
button
several times to select display of the
telephone screen, then press " OK
" to
open the contextual menu.

Select " Private mode
" and confi rm to
take the call on the handset.
Or select " Hands-free mode
" and
confi rm to take the call via the vehicle's
speakers.

Select " Put call on hold
" and confi rm to
put the current call on hold.
Or select " Resume the call
" and
confi rm to resume the call on hold.
Select " DTMF ring tones
" to use the
numerical keypad, so as to navigate
through the menu of an interactive vocal
server.

Select " Hang up
" to end the call.

* Depending on the compatibility of the phone and your service plan.
it is possible to hold a 3-way conference call by making 2 calls
in succession. Select " Conference



mode call
" in the contextual
menu accessible using the TEL
button at the steering mounted
controls.

256
1
2
3
1
2
3
4
5
06

Press PHONE
twice.

Select " List of the paired peripherals
"
and confi rm.

It is possible to:


- " Connect
" or " Disconnect
" the
selected telephone,

- delete the pairing of the selected
telephone.
It is also possible to select all pairings.

USING THE TELEPHONE


MANAGING PAIRED TELEPHONES
CHANGING THE RING TONE


Press PHONE
twice.

Select " Phone functions
" and confi rm.

Select " Ring options
" and confi rm.

You can adjust the volume and the type
of ring tone.
Select " Bluetooth functions
".

Select " OK
" and confi rm to save
the changes.

257
07 RADIO







Access to the "RADIO" menu


" FM/AM band
"

" Following waveband
" (" AM/FM
")
" Guidance options
" (" TA, RDS
”)
" Audio settings
" (see this section)
" Update radio list
"
Aphabetical list of stations
received.

Press
or
or use the rotary control to select the
previous or next station in the list.

This list can also be displayed by pressing LIST
on the
steering mounted controls.
Go from the list to the menu (left/right).
or

A long press on LIST
refreshes
the list of stations received.
Press RADIO
.

258
07
1a
1b
1c
1
2
RADIO

By alphabetical list
Press RADIO
or LIST
, select the station
of your choice and confi rm.

By automatic frequency search
Press
or
for the automatic search
for a lower or higher radio frequency.
Or turn the thumb wheel at the steering
mounted controls.

By manual frequency search
Press
or
to adjust the radio
frequency step by step.

Press the button on the numerical
keypad to recall a preset station.
Or press then turn the thumb wheel at
the steering mounted controls.








SELECTING A STATION


The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode. This
phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.


PRESETTING A STATION


Press one of the buttons on the
numerical keypad for 2 seconds to
preset the current station.
An audible signal confi rms that the
station has been preset.
The quality of reception is represented
by the number of active waves in this
symbol.
