Citroen C4 RHD 2012 2.G Owner's Manual

259
1
2
3
07

Press RADIO
.







ACTIVATE/DEACTIVATE RDS


RDS, if activated, allows you to continue listening to the same
station by automatic retuning to alternative frequencies. However,
in certain conditions, coverage of an RDS station may not be
assured throughout the entire country as radio stations do not
cover 100 % of the territory. This explains the loss of reception of
the station during a journey.

Select " Guidance options
" and confi rm.

Select " Activate/Deactivate RDS
" and
confi rm.
RADIO

Select " Activate/Deactivate RDS
".
Radio displayed, press " OK
" to display the contextual menu.

260
08 MUSIC MEDIA PLAYERS







Access to the "MUSIC MEDIA PLAYER" menu


" MEDIA
"

" Following media source
"
" Eject USB device
" (if USB
connected)
" Play mode
" (" Normal
",
" Random
", " Random on all
media
", " Repetition
")
" Audio settings
" (see this section)
" Activate/Deactivate AUX input
" List of the current media
tracks.

This list can also be displayed by pressing LIST

at the steering mounted controls.
Go from the list to the menu (left/right).
or

Press MUSIC
.

261
08MUSIC MEDIA PLAYERS

CD, MP3 CD, USB PLAYER


The audio equipment will only play audio fi les with ".m4a, .wma,
.m4b, .aac, .fl ac, .ogg and .mp3" fi le extensions and with a bit rate of
between 32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of fi le (.mp4, .m3u...) can be played.
WMA fi les must be of the standard wma 9 type.
The sampling rates supported are 11, 22, 44 and 48 KHz.

It is advisable to restrict fi le names to 20 characters, without using of
special characters (e.g.: " " ? ; ù) to avoid any playing and displaying
problems.

In order to be able to play a recorded CDR or CDRW, when recording
it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it may not be played correctly.
It is recommended that the same recording standard is always used
for an individual disc, with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the Joliet standard is
recommended.
INFORMATION AND ADVICE

The system supports USB mass storage or iPod
devices via the USB port (suitable cable not supplied).
Control of the peripheral device is with the audio
system controls.
Other peripherals, not recognised on connection, must
be connected to the auxiliary socket using a Jack cable
(not supplied).

In order to be read, a USB memory stick must be formatted FAT 16 or 32.

262
08
1
2
3
MUSIC MEDIA PLAYERS

CD, MP3 CD, USB PLAYER


Insert the CD in the player, insert the USB memory stick
in the USB player or connect the USB peripheral to the
USB port using a suitable cable (not supplied).
The system builds playlists (in temporary memory), an
operation which can take from a few seconds to several
minutes at the fi rst connection.
Reduce the number of non-music fi les and the number
of folders to reduce the waiting time.
The playlists are updated every time the ignition is
switched off or connection of a USB memory stick.
However, the system memorises these lists and if they
are not modifi ed, the loading time will be shorter.
Play starts automatically after a period which depends
on the capacity of the USB memory stick.




SELECTION OF SOURCE
The SOURCE
button on the steering mounted controls allows a
direct change to the next media source.
" CD/CD MP3
"
" USB, IPod
"
" AUX
"
" STREAMING
" " RADIO
"
Press MUSIC
to display the " MEDIA
"
menu.

Select " Following media source
" and
confi rm.

Repeat the operation as many times as necessary to obtain the
desired media source (except for radio which is accessible either
with SOURCE
or RADIO
).

263
08
/
/
//
//
// +/


SELECTING A TRACK
MUSIC MEDIA PLAYERS


Previous track.

Next track.

Previous folder.

Next folder.

Fast forward.

Fast backward.

Pause: long press on SRC
.


LIST: List of USB or CD tracks
or folders

Up or down in the list.

Confi rm, next menu level.

Up one menu level.
Long press
Long press

264
1
2
1
2
08






AUDIO STREAMING


Streaming allows audio fi les on your telephone to be played via the
vehicle's speakers.

Connect the telephone: see "USING THE TELEPHONE".
Select " Audio
" or " All
" profi le.

If play does not start automatically, it may be necessary to start the
audio playback from the telephone.
Control is from the peripheral device or by using the audio system
buttons.

Once connected in streaming mode, the telephone is considered to be
a media source.
It is recommended that you activate " Repeat
" on the Bluetooth
peripheral.

MUSIC MEDIA PLAYERS


IPOD/IPHONE


Connect the iPod or iPhone to the USB port using a suitable cable
(not supplied).
Play starts automatically.

Control is via the audio system.

The classifi cations available are those of the portable device
connected (artists/albums/genres/playlists/audiobooks/podcasts).
The default classifi cation used is by artist. To modify the classifi cation
used, return to the fi rst level of the menu then select the desired
classifi cation (playlists for example) and confi rm to go down through
the menu to the desired track.

The version of software in the audio system may not be compatible
with the generation of your iPod
® or iPhone.
The list of devices compatible with software versions is available from
CITROËN dealers.

265
08
12
3
MUSIC MEDIA PLAYERS












USING THE AUXILIARY INPUT (AUX)
Cable not supplied

Connect the portable device (MP3 player…) to the auxiliary JACK
socket using an audio cable.
Press MUSIC
to display the " MEDIA
"
menu.

Select " Activate/Deactivate AUX input
"
and confi rm.
First adjust the volume of your portable
device (to a high level). Then adjust the
volume of your audio system.

Display and management of the controls are via the portable device.

266
09
1
2
AUDIO SETTINGS



They are accessible by a long press on
RADIO
or MUSIC
or from the " FM/AM
band
" or " MEDIA
" menus.



- " Equalizer
" (choice of 6 musical ambiences)

- " Bass
"

- " Treble
"

- " Loudness
" (Activate/Deactivate)

- " Distribution
" (" Driver
", " All passengers
")

- " Le-Ri balance
" (Left/Right)

- " Fr-Re balance
" (Front/Rear)

- " Auto. Volume
" depending on road speed (Activate/Deactivate)


The audio settings ( Equalizer
, Bass
, Treble
and Loudness
) are
different and independent for each sound source.
The settings for distribution and balance are common to all sources.

The distribution (or spatialisation) of sound is an audio process that
allows the audio quality to be adapted to the number of listeners in
the vehicle.

267
10
1
2
3a
3b
1
2
3
4
CONFIGURATION


Press SETUP
to display the
" Confi guration
" menu.

Select " Adjust luminosity
" and confi rm
to adjust the screen brightness.
Press " OK
" to save the changes.
The settings for day and night are
independent.

Select " Choose colour
" and confi rm to
select the screen colour harmony and
the map presentation mode:


- day mode,

- night mode,

- automatic day/night mode,
according to whether the
headlamps are on.
























SETTING THE DATE AND TIME


Select " Set date and time
" and
confi rm.

Select the setting to adjust.
Confi rm by pressing OK
, then adjust
the setting and confi rm again to save
the modifi cation.
Select " Display confi guration
" and
confi rm.
Press SETUP
to display the
" Confi guration
" menu.

Select " Display confi guration
" and
confi rm.

Adjust the settings one by one.
Then select " OK
" on the screen and
confi rm to save the settings.



DISPLAY CONFIGURATION


Select " Synchronize the minutes with GPS
" so that setting the
minutes is done automatically by satellite reception.

268
11

"Navigation - guidance"
MENU

Enter an address

Select destination


Directory

GPS coordinates (Archive)



Journey leg and route


Add a stage

Enter an address


Directory


Previous destinations



Order/delete journey legs

Divert route

Chosen destination



Guidance options


Defi ne calculation criteria

Set speech synthesis

Delete last destinations


Map management


Map orientation

Select TMC station


Automatic TMC

Manual TMC

List of TMC stations



Display/Do not display
messages

SCREEN MENU MAP










MAIN FUNCTION


option A1


option A2


OPTION A

OPTION B...


Map details

Move the map/"Vehicle monitoring"

Mapping and updating

Description of risk areas database



Stop/Restore guidance
"TRAFFIC" MENU
Geographic filter


Retain all the messages:

Retain the messages:

Around the vehicle


On the route





Set parameters for risk areas

1
3
3
2
3
1
1
1
2
2
2
1
2
3
2
2
2
2
1
2
2
2
2
2
2
2
2
2
2
2
1
1
2
2
3
3
1
2
