Citroen DS5 2016 1.G Owner's Manual

219
DS5_en_Chap08_info-pratiques_ed02-2015
Changing a fuse
The fuse extraction tweezer is fitted to the back
of the dashboard fusebox cover.
For access to it:
F
re
move the cover completely and turn it
ove r,
F
re

move the tweezer.
Access to tooling
Before changing a fuse, it is necessary to:
F identify the cause of the failure and
correct it,
F
sw

itch off all electrical consumers,
F
im

mobilise the vehicle and switch off the
ignition,
F
id

entify the failed fuse using the allocation
tables and diagrams presented on the
following pages.
changing a fuse
Good Failed
To remove or fit a fuse, it is essential to:
F
us

e the special tweezer to extract the fuse
from its housing and check the condition of
its filament.
F
al

ways replace the failed fuse with a fuse
of the same rating (same colour); a fuse of
different rating could cause a fault (risk of
f i r e).
The replacement of a fuse not
mentioned in the tables below could
cause a serious malfunction of your
vehicle. Contact a CITROËN dealer or a
qualified workshop.
If the fault recurs after replacing a fuse, have
the electrical system checked by a CITROËN
dealer or a qualified workshop. Tw e e z e r
Practical information

DS5_en_Chap08_info-pratiques_ed02-2015
Installing electrical
accessories
Your vehicle's electrical system is
designed to operate with standard or
optional equipment.
Before installing other electrical
equipment or accessories on your
vehicle, contact a CITROËN dealer or a
qualified workshop.CITROËN will not accept responsibility
for the cost incurred in repairing your
vehicle or for rectifying malfunctions
resulting from the installation of
accessories not supplied and not
recommended by CITROËN and
not installed in accordance with its
instructions, in particular when the
combined consumption of all of the
additional equipment connected
exceeds 10 milliamperes.

221
DS5_en_Chap08_info-pratiques_ed02-2015
dashboard fuses
The fusebox is placed in the lower dashboard
(left-hand side).
Access to the fuses
F See the "Access to tooling" section.
Table of fuses
Fuse N° Rating
(A) Functions
F6 A or B 15Audio system.
F8 3Alarm.
F13 10Front cigarette lighter, front 12 V socket.
F14 10Rear 12 V socket.
F16 3Rear map reading lamps.
F17 3Courtesy mirror.
F28 A or B 15Audio system.
F30 20Rear wiper.
F32 10Audio amplifier.
Practical information

DS5_en_Chap08_info-pratiques_ed02-2015
Engine compartment fuses
The fusebox is placed in the engine
compartment near the battery.
Access to the fuses
F Unclip the cover.
F Ch ange the fuse.
For information on the special requirements
and precautions to take before changing a fuse,
refer to the start of this section.
F
Wh

en you have finished, close the cover
carefully to ensure correct sealing of the
fusebox. Fuse
N° Rating
(A) Functions
F20 15Front / rear screenwash pump.
F21 20Headlamp wash pump.
F22 15Horn.
F23 15Right-hand main beam headlamp.
F24 15Left-hand main beam headlamp.
F27 5Left hand lamp mask.
F28 5Right hand lamp mask.
Table of fuses

223
DS5_en_Chap08_info-pratiques_ed02-2015
12 V battery
The battery is located under the bonnet.
To gain access to it:
F
op
en the bonnet using the interior release
lever, then the exterior safety catch,
F
ra

ise the plastic cover on the (+) terminal.
Access to the battery
Protect your eyes and face before
handling the battery.
All operations on the battery must be
carried out in a well ventilated area and
away from naked flames and sources
of sparks, so as to avoid the risk of
explosion or fire.
Wash your hands after wards.
Procedure for starting the engine using another battery or charging a discharged battery.
General points
Lead-acid starter batteries
Batteries contain harmful substances
such as sulphuric acid and lead.
They must be disposed of in
accordance with regulations and must
not, in any circumstances, be discarded
with household waste.
Take used remote control batteries and
vehicle batteries to a special collection
point.
If your vehicle has an automatic
gearbox, do not try to start the engine
by pushing the vehicle.
Versions equipped with Stop & Start are
fitted with a 12 V lead-acid battery of
specific technology and specification.
Its replacement should be carried out
only by a CITROËN dealer or a qualified
workshop.
The battery (-) terminal is not accessible.
A remote earth point is provided at the front of
the vehicle.
For access to it:
F
un

clip the plastic cover, located alongside
the left-hand headlamp.
Practical information

DS5_en_Chap08_info-pratiques_ed02-2015
Starting using another
battery
Never try to start the engine by
connecting a battery charger.
Never use a 24 V or higher battery
b o o s t e r.
First check that the slave battery has a
nominal voltage of 12 V and a capacity
at least equal to that of the discharged
battery.
The two vehicles must not be in contact
with each other.
Switch off the electrical consumers on
both vehicles (audio system, wipers,
lighting, ...).
Ensure that the jump lead cables do
not pass close to moving parts of the
engine (cooling fan, belts, ...).
Do not disconnect the (+) terminal when
the engine is running.F
St

art the engine of the vehicle with the
good battery and leave it running for a
few
mi
nutes.
F Op erate the starter on the broken down
vehicle and let the engine run.
If t

he engine does not start straight away,
switch off the ignition and wait a few
moments before trying again.
When your vehicle's battery is discharged, the
engine can be started using a slave battery
(external or on another vehicle) and jump lead
cables or a battery booster.
F
Wa
it until the engine returns to idle then
disconnect the jump lead cables in the
reverse order.
F
Re

fit the plastic cover to the (+) terminal, if
your vehicle has one.
F
Al

low the engine to run for at least
30
m

inutes, by driving or with the vehicle
stationary, so that the battery reaches an
adequate state of charge.
F
Ra

ise the plastic cover on the (+) terminal,
if your vehicle has one.
F
Co

nnect the red cable to the positive
terminal (+) of the flat battery A (at the metal
elbow) then to the positive terminal
(

+) of the
slave battery B or the booster.
F
Co

nnect one end of the green or black
cable to the negative terminal (-) of the
slave battery B or the booster (or earth
point on the other vehicle). Some functions, including Stop & Start,
are not available if the battery is not
sufficiently charged.
F
Co

nnect the other end of the green or black
cable to the earth point
c o
n the broken
down vehicle.

225
DS5_en_Chap08_info-pratiques_ed02-2015
For optimum service life of the battery, it is
essential to maintain an adequate state of
charge.
In some circumstances it may be necessary to
charge the battery:
-
if y
ou use your vehicle essentially for short
journeys,
-
if t

he vehicle is to be taken off the road for
several weeks.
Contact a CITROËN dealer or a qualified
workshop.
charging the battery using
a b attery charger
Never try to charge a frozen battery.
If the battery has been frozen, have
it checked by a CITROËN dealer or a
qualified workshop, who will check that
the internal components have not been
damaged and the casing is not cracked,
which could cause a leak of toxic and
corrosive acid.
If you envisage charging your vehicle's
battery yourself, use only a charger
compatible with lead-acid batteries of a
nominal voltage of 12 V. Follow the instructions for use provided
by the manufacturer of the charger.
Never reverse polarities.
It is not necessary to disconnect the
battery.
F
Sw

itch off the ignition.
F
Sw

itch off all electrical consumers (audio
system, lighting, wipers, ...).
F
Sw

itch off the charger B before connecting
the cables to the battery, so as to avoid any
dangerous sparks.
F
En

sure that the charger cables are in good
condition.
F Co
nnect the charger B cables as follows:
- th
e positive (+) red cable to the (+)
terminal of the battery A ,
-
th

e negative (-) black cable to the earth
point
c o

n the vehicle.
F
At t

he end of the charging operation, switch
off the charger B before disconnecting the
cables from the battery A .
If this label is present, it is essential
to use only a 12 V charger, to avoid
causing irreversible damage to the
electrical components related to the
Stop & Start system.
Practical information

DS5_en_Chap08_info-pratiques_ed02-2015
disconnecting the battery
In order to maintain an adequate state
of charge for starting the engine, it is
recommended that the battery be disconnected
if the vehicle is taken out of service for a long
period.
Wait 2 minutes after switching off the ignition
before disconnecting the battery.
F
cl
ose the windows and the doors before
disconnecting the battery,
F
sw

itch off all electrical consumers (audio
system, wipers, lighting, ...),
F
sw

itch off the ignition and wait for
four
mi

nutes.
Having exposed the battery, it is only
necessary to disconnect the (+) terminal.
Quick release terminal
dis

connecting the (+) terminal
F Raise the lever A fully to release the
c lamp B.
Following reconnection of the battery
Reconnecting the (+) terminal
F Position the open clamp B of the cable on
t
he positive post (+) of the battery.
F
Pr

ess down on the clamp to position it
correctly on the battery post.
F
Lo

ck the clamp by lowering the lever A .
Do not force the lever as locking will
not be possible if the clamp is not
positioned correctly; start the procedure
again. The Stop & Start system may not be
operational during the trip following the
first engine start.
In this case, the system will only be
available again after a continuous
period of immobilisation of the vehicle,
a period which depends on the ambient
temperature and the state of charge of
the battery (up to about 8 hours).
After reconnecting the battery, switch on the
ignition and wait 1 minute before starting to
allow initialisation of the electronic systems.
However, if minor problems persist following
this operation, contact a CITROËN dealer or a
qualified workshop.
Referring to the corresponding section, you
must yourself reinitialise or reset certain
systems, such as:
-
th

e remote control or electronic key
(depending on version),
-
th
e electric blind(s),
-
th
e electric windows
-
th
e date and time,
-
th
e radio preset stations.

227
DS5_en_Chap08_info-pratiques_ed02-2015
Load reduction mode
System which manages the use of certain
functions according to the level of charge
remaining in the battery.
When the vehicle is being driven, the load
reduction function temporarily deactivates
certain functions, such as the air conditioning,
the heated rear screen...
The deactivated functions are reactivated
automatically as soon as conditions permit.System which manages the duration of use of
certain functions to conserve a sufficient level
of charge in the battery.
After the engine has stopped, you can
still use functions such as the audio and
telematics system,
w

indscreen wipers, dipped
beam headlamps,
c

ourtesy lamps, etc. for
a maximum combined duration of about
forty
mi

nutes.
Energy economy mode
Switching to economy mode
A message then appears in the instrument
panel screen indicating that the vehicle has
switched to economy mode and the active
functions are put on standby.
If a telephone call is being made at this time,
it
w
ill be maintained for around 10 minutes
with the Bluetooth hands-free system of your
audio
s

ystem.
Exiting economy mode
These functions are reactivated automatically
next time the vehicle is driven.
In order to restore the use of these functions
immediately, start the engine and let it run:
-
fo
r less than ten minutes, to use the
equipment for approximately five minutes,
-
fo

r more than ten minutes, to use the
equipment for up to approximately
thirty
mi

nutes.
Let the engine run for the duration specified to
ensure that the battery charge is sufficient.
Do not repeatedly and continuously restart the
engine in order to charge the battery.
A flat battery prevents the engine from
starting.
For more information on the battery,
refer to the corresponding section.
Practical information

DS5_en_Chap08_info-pratiques_ed02-2015
Changing a wiper blade
Before removing a front
wiper blade
F Within one minute after switching off
the ignition, operate the wiper stalk to
position the wiper blades vertically on the
windscreen.
Removing
F Raise the corresponding wiper arm.
F Un clip the wiper blade and remove it.
Fitting
F Put the corresponding new wiper blade in
place and clip it.
F
Fo

ld down the wiper arm carefully.
After fitting a front wiper
blade
F Switch on the ignition.
F Op erate the wiper stalk again to park the
wiper blades.
