Citroen JUMPY MULTISPACE 2011 2.G Repair Manual

59

Ventilation

EASE OF USE and COMFOR
T
3

Press the air conditioning.


Manual mode

Direct the control to this
temperature setting.
Increase the air flow setting.
DE-ICING AND DEMISTING

Returning to exterior air intake
open permits renewal of the air
in the passenger compartment
(diode off). Direct the control to this air
distribution setting.

60
Ventilation
Pressing this button, with the engine
running, activates the rapid demisting -
de-icing of the rear screen and/or electric
mirrors.
This function switches off:


- when the button is pressed,

- when the engine is switched off,

- automatically to prevent excessive
energy consumption.



De-icing the rear screen and/or mirrors



Automatic air conditioning: visibility
programme
The comfort programme (AUTO) may not
be sufficient to quickly demist or de-ice the
windows (humidity, several passengers, ice).
In this case, select the visibility programme.
The visibility programme indicator light
comes on.
It activates the air conditioning, the air flow,
the de-icing of the rear screen and provides
optimum distribution of the ventilation to the
windscreen and side windows.
It deactivates the air recirculation.

61

Ventilation

EASE OF USE and COMFOR
T
3

REAR VENTILATION

If your vehicle is fitted with an additional air
conditioning unit, located in the rear of the
vehicle. The distribution rail located in the
roof and the 6 individualised diffusion vents
provide a perfect diffusion of the ambient air
selected.
The warm air diffused at the floor, from the
front air conditioning unit, is distributed at
the feet of the rear passengers of the
2nd row.
A warm air diffusion vent, located on the
specific unit, completes the assembly for the
feet of the rear passengers of the 3rd row.

Temperature adjustment

Control positioned:


- on the blue, triggers cool air,

- on the red, triggers heating of the
ambient air.


Activation/Deactivation
Air flow

The force of the blown air, via the
vents, varies from 1 to the strongest 4.
To obtain a comfortable level of
ambient air, remember to adjust this
control.
To deactivate the blower, place the control
in position 0. This button, located on the
overhead storage unit, enables
you to activate/deactivate the
operation of the rear controls
from the driver's seat or the front passenger
seat.
The first press activates (green diode lit).
A second press deactivates (diode off).

62
Ventilation
ADDITIONAL HEATING
Vehicles fitted with an HDi engine may be
fitted with a heater. When the engine is at
idle or the vehicle is stationary, it is normal
to notice a high-pitched whistling noise and
a slight emission of smoke and odour.



Rear ventilation


Coolant circuit heater
This is an additional and separate system
which heats the Diesel engine hot coolant
loop to make starting easier.
It improves the demisting and defrosting
performance.

63

Ventilation

EASE OF USE and COMFOR
T
3

Have the heater checked at least
once a year at the beginning of winter.
Maintenance and repairs should only be
carried out by a CITROËN dealer or a
qualified workshop. Use recommended
replacement parts only.

Good practice

To avoid any risk of poisoning or
asphyxiation, the heater must not be used,
even for short periods, in an enclosed space
such as a garage or workshop which is not
fitted with an exhaust gas extraction system.
Do not park the vehicle on an inflammable
surface (dry grass, dead leaves, paper…),
there is a risk of fire.
The temperature near the heater must not
exceed 120 °C. A temperature higher than
this (for example in the case of painting in
an oven) could damage the components of
the electronic circuits.
The heater is supplied by the vehicle's fuel
tank. Ensure that the low fuel warning lamp
is not on.

64

65


Seats

EASE OF USE and COMFOR
T
3
FRONT SEATS

Depending on the version and configuration
of your vehicle, different front seats are
fitted, either:


- a driver's seat and a passenger seat,

- an individual driver's seat and a
two-seat passenger bench.
3 - Driver's seat height adjustment
Depending on the version and configuration
of your vehicle, you have either:


- a passive adjustment: pull the handle
upwards then take your weight off the
seat to raise, or push on the seat to
lower,
2 - Seat back angle adjustment
Pull the lever upwards and set the required
angle.

1 - Forwards/backwards adjustment
Lift the bar and slide the seat forwards or
backwards. Depending on the models, the following
adjustments are available:

66
Seats

- an active adjustment: manoeuvre the
handle upwards or downwards until the
desired position is reached.


Head restraint height adjustment
To raise or lower the restraint, pull it
forwards, then slide it. The adjustment is correct when the upper
edge of the head restraint is level with the
top of the head.
Never drive with the head restraints
removed; they must be in place and
correctly adjusted.
Front heated seat controls


Adjustable armrest
To place the armrest in its rest position:


- raise it until it is in the centreline of the
seat back.

4 - Driver's seat lumbar adjustment
Move the lever up or down to obtain the
required position. To remove it, set it in the high position, press
the tabs and pull upwards and forwards at
the same time.
To re-install, engage the head restraint rods
in the holes, making sure they are aligned
with the seat back.
To place the armrest in a position for use:


- fold it down fully,

- raise it slowly to the required position,

- if you pass the required position, raise it
fully then repeat the operations above.


Press the corresponding control,
located on the overhead storage
unit.


The temperature is controlled
automatically.
Pressing a second time stops operation.

67


Seats

EASE OF USE and COMFOR
T
3

2-SEAT FRONT BENCH

If your vehicle is fitted with this bench seat,
it is fixed and has a 3rd seat belt.

Head restraint

Press the tab to adjust the height of the
head restraint.
To remove the head restraint, press the tabs
and raise the head restraint.
The adjustment is correct when the upper
edge of the head restraint is level with the
top of the head.
Never drive with the head restraints
removed; they must be in place and
adjusted correctly.


Seat back pockets

If your vehicle is fitted with these, they are
located on the backs of the front seats.

68
Seats
Writing table

If fitted in your vehicle, the back of the
centre seat of the bench (Row 1) folds to
form a writing table with two cup holder
recesses.
Pull the handle located at the top of the seat
back cushion.
