DODGE DURANGO 2020 Owner's Guide

GETTING TO KNOW YOUR VEHICLE29
This device complies with Part 15 of the FCC
Rules and with Innovation, Science and
Economic Development Canada license-exempt
RSS standard(s). Operation is subject to the
following two conditions:

1. This device may not cause harmful
interference, and

2. This device must accept any interference received, including interference that may
cause undesired operation.
Le présent appareil est conforme aux CNR
d`Innovation, Science and Economic
Development applicables aux appareils radio
exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes:

1. l'appareil ne doit pas produire de brouillage, et

2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compro -
mettre le fonctionnement. La operación de este equipo está sujeta a las
siguientes dos condiciones:

1. es posible que este equipo o dispositivo no
cause interferencia perjudicial y

2. este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que
pueda causar su operación no deseada.
NOTE:
Changes or modifications not expressly
approved by the party responsible for compli -
ance could void the user’s authority to operate
the equipment.
AUTOMATIC UNLOCK ON EXIT FEATURE
— I
F EQUIPPED
If Auto Unlock is enabled, this feature will
unlock all the doors when any door is opened if
the vehicle is in PARK.
Refer to “Uconnect Settings” in “Multimedia”
for further information.
AUTOMATIC DOOR LOCKS — IF
E
QUIPPED
When enabled, the door locks will lock
automatically when the vehicle’s speed
exceeds 15 mph (24 km/h). Auto door lock
feature is enabled/disabled in the Uconnect
Settings sections in the radio. Refer to
“Uconnect Settings” in “Multimedia” for further
information.
CHILD-PROTECTION DOOR LOCK
S
YSTEM — REAR DOORS
To provide a safer environment for small
children riding in the rear seats, the rear doors
are equipped with Child-Protection Door Lock
system.
To Engage Or Disengage The Child Protection
Door Lock System

1. Open the rear door.

2. Insert the tip of the emergency key into the
lock and rotate to the lock or unlock
position.
2

20_WD_OM_EN_USC_t.book Page 29

30GETTING TO KNOW YOUR VEHICLE
3. Repeat steps 1 and 2 for the opposite rear
door.

Child-Protection Door Lock Function

NOTE:
For emergency exit with the system engaged,
move the lock knob up (unlocked position), roll
down the window, and open the door with the
outside door handle.DRIVER MEMORY SETTINGS — IF EQUIPPED
This feature allows the driver to save up to two
different memory profiles for easy recall
through a memory switch. Each memory profile
saves desired position settings for the following
features:
Driver seat
Easy Entry/Exit seat operation (on/off)
(if equipped)
Side mirrors
Power tilt and telescopic steering column (if
equipped)
A set of desired radio station presets
NOTE:
Your vehicle is equipped with two key fobs,
each can be linked to either memory position
1 or 2.
Be sure to program the radio presets prior to
programming the memory settings. The memory setting switch is located on the
driver’s door trim panel. The switch consists of
three buttons:
The set (S) button, which is used to activate
the memory save function.
The (1) and (2) buttons which are used to
recall either of two saved memory profiles.

Memory Setting Buttons

WARNING!
Avoid trapping anyone in a vehicle in a
collision. Remember that the rear doors can
only be opened from the outside with the
Child-Protection locks are engaged (locked).

20_WD_OM_EN_USC_t.book Page 30

GETTING TO KNOW YOUR VEHICLE31
PROGRAMMING THE MEMORY FEATURE
To create a new memory profile, perform the
following:

1. Place the vehicle’s ignition in the ON/RUN
position (do not start the engine).

2. Adjust all memory profile settings to desired preferences (i.e., seat, side mirror, power tilt
and telescopic steering column [if
equipped], and radio station presets).
3. Push the set (S) button on the memory switch, and then push the desired memory
button (1 or 2) within five seconds. The
instrument cluster display will display which
memory position has been set.
NOTE:
Memory profiles can be set without the vehicle
in PARK, but the vehicle must be in PARK to
recall a memory profile.
LINKING AND UNLINKING THE REMOTE
K
EYLESS ENTRY KEY FOB TO MEMORY
Your key fobs can be programmed to recall one
of two saved memory profiles by pushing the
unlock button on the key fob.
NOTE:
Before programming your key fobs you must
select the “Memory Linked To Fob” feature
through the Uconnect system settings. Refer to
“Uconnect Settings” in “Multimedia” for further
information.
To program your key fobs, perform the following:

1. Place the vehicle’s ignition in the OFF
position.

2. Select a desired memory profile, 1 or 2.
3. Once the profile has been recalled, push and release the set (S) button on the
memory switch. Then, within five seconds,
push and release button (1) or (2)
accordingly. “Memory Profile Set” (1 or 2)
will display in the instrument cluster display.
4. Push and release the lock button on the key fob within 10 seconds. NOTE:
Your key fobs can be unlinked from your
memory settings by pushing the set (S) button,
and within 10 seconds, followed by pushing the
unlock button on the key fob.
MEMORY POSITION RECALL
NOTE:
If a recall is attempted when the vehicle is not in
PARK, a message will be displayed in the instru
-
ment cluster display.
To recall the memory settings for driver one or
two, push the desired memory button (1 or 2) or
the unlock button on the key fob linked to the
desired memory position.
A recall can be canceled by pushing any of the
memory buttons during a recall (S, 1, or 2), or by
pushing any of the seat adjustment switches.
When a recall is canceled, the driver's seat and
telescopic steering column (if equipped) will
stop moving. A delay of one second will occur
before another recall can be selected.
2

20_WD_OM_EN_USC_t.book Page 31

32GETTING TO KNOW YOUR VEHICLE
(Continued)
SEATS
Seats are a part of the Occupant Restraint
System of the vehicle.
MANUAL ADJUSTMENT (FRONT SEATS)
— I
F EQUIPPED
Manual Front Passenger Seat Forward/
Rearward Adjustment
Some models may be equipped with a manual
front passenger seat. The passenger seat can
be adjusted forward or rearward by using a bar
located by the front of the seat cushion, near
the floor.
Adjustment Bar

While sitting in the seat, lift up on the bar
located under the seat cushion and move the
seat forward or rearward. Release the bar once
you have reached the desired position. Then,
using body pressure, move forward and
rearward on the seat to be sure that the seat
adjusters have latched.
WARNING!
It is dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely
to be seriously injured or killed.
Do not allow people to ride in any area of
your vehicle that is not equipped with seats
and seat belts. In a collision, people riding
in these areas are more likely to be seri -
ously injured or killed.
Be sure everyone in your vehicle is in a seat
and using a seat belt properly.
WARNING!
Adjusting a seat while the vehicle is moving
is dangerous. The sudden movement of the
seat could cause you to lose control. The
seat belt might not be adjusted properly
and you could be injured. Adjust the seat
only while the vehicle is parked.
Do not ride with the seatback reclined so
that the shoulder belt is no longer resting
against your chest. In a collision you could
slide under the seat belt and be seriously or
even fatally injured. Use the recliner only
when the vehicle is parked.
WARNING!
Adjusting a seat while driving may be
dangerous. Moving a seat while driving
could result in loss of control which could
cause a collision and serious injury or
death.

20_WD_OM_EN_USC_t.book Page 32

GETTING TO KNOW YOUR VEHICLE33
Manual Front Passenger Seatback
Adjustment — Recline
To adjust the seatback, lift the lever located on
the outboard side of the seat, lean back to the
desired position and release the lever. To return
the seatback, lift the lever, lean forward and
release the lever.

Recline Lever

Front Passenger Seat Fold-Flat Feature —
If Equipped
To fold the seatback to the flat load-floor
position, lift the recline lever and push the
seatback forward. To return to the seating
position, raise the seatback and lock it into
place.
Fold-Flat Passenger Seat

Seats should be adjusted before fastening
the seat belts and while the vehicle is
parked. Serious injury or death could result
from a poorly adjusted seat belt.
WARNING! (Continued)WARNING!
Do not ride with the seatback reclined so that
the shoulder belt is no longer resting against
your chest. In a collision you could slide under
the seat belt, which could result in serious
injury or death.
WARNING!
Adjusting a seat while the vehicle is moving
is dangerous. The sudden movement of the
seat could cause you to lose control. The
seat belt might not be properly adjusted,
and you could be severely injured or killed.
Only adjust a seat while the vehicle is
parked.
Do not ride with the seatback reclined so
that the seat belt is no longer resting
against your chest. In a collision, you could
slide under the seat belt and be severely
injured or killed. Use the recliner only when
the vehicle is parked.
CAUTION!
Do not place any article under a power seat
or impede its ability to move as it may cause
damage to the seat controls. Seat travel may
become limited if movement is stopped by an
obstruction in the seat's path.
2

20_WD_OM_EN_USC_t.book Page 33

34GETTING TO KNOW YOUR VEHICLE
MANUAL ADJUSTMENT (REAR SEATS)
60/40 Split Rear Seat
Second Row Fold Flat Seat
The second row seats can be folded flat to carry
cargo.
Pull upward on the release lever located on the
outboard side of the seat.

Release Lever Fold-Flat Second Row Seat

NOTE:
You may experience deformation in the seat
cushion from the seat belt buckles if the seats
are left folded for an extended period of time.
This is normal and by simply opening the seats
to the open position, over time the seat cushion
will return to its normal shape.
Easy Access For Third Row
Either side of the rear seat can be tumbled
forward to allow passengers to easily access the
third row seats.

1. Pull upward on the release lever to release the seat.
Release Lever

2. Tumble the seat forward using the pull strap located behind the seatback.

Tumble Pull Strap

WARNING!
Do not pile luggage or cargo higher than the
top of the seatback. This could impair
visibility or become a dangerous projectile in
a sudden stop or collision.

20_WD_OM_EN_USC_t.book Page 34

GETTING TO KNOW YOUR VEHICLE35

Tumbled Second Row

To Raise Rear Seat
Fold the seat rearward to its original position,
and lock it into place.Rear Captain’s Chairs — If Equipped
Second Row Captain’s Chairs Fold Flat Seats
The second row seats can be folded flat to carry
cargo.
Pull upward on the release lever located on the
outboard side of the seat.
Release Lever Fold-Flat Second Row Seats

NOTE:
You may experience deformation in the seat
cushion from the seat belt buckles if the seats
are left folded for an extended period of time.
This is normal and by simply opening the seats
to the open position, over time the seat cushion
will return to its normal shape.WARNING!
Do not drive the vehicle with the second row
seats in the tumbled position. The second
row seats are only intended to be tumbled for
entry and exit to the third row seat. Failure to
follow these instructions could result in
personal injury.
WARNING!
Be certain that the seatback is securely
locked into position. If the seatback is not
securely locked into position the seat will not
provide the proper stability for child seats
and/or passengers. An improperly latched
seat could cause serious injury.
2

20_WD_OM_EN_USC_t.book Page 35

36GETTING TO KNOW YOUR VEHICLE
Easy Access For Third Row
Either side of the rear seat can be tumbled
forward to allow passengers to easily access the
third row seats.

1. Pull upward on the release lever to release
the seat.

Release Lever

2. Tumble the seat forward using the pull strap located behind the seatback.
Tumble Strap

3. If your vehicle is equipped with a mini console, there is a stepping pad to allow
passengers to easily access the third row
seats.
Mini Console Stepping Pad

To Raise Rear Seat
Fold the seat rearward to its original position,
and lock it into place.
WARNING!
Do not drive the vehicle with the second row
seats in the tumbled position. The second
row seats are only intended to be tumbled for
entry and exit to the third row seat. Failure to
follow these instructions could result in
personal injury.
WARNING!
Be certain that the seatback is securely
locked into position. If the seatback is not
securely locked into position the seat will not
provide the proper stability for child seats
and/or passengers. An improperly latched
seat could cause serious injury.

20_WD_OM_EN_USC_t.book Page 36

GETTING TO KNOW YOUR VEHICLE37
Folding Third Row
Both third row seats can be folded forward to
increase the cargo area. To lower either seat,
pull on the release handle located on the back
of the seat and lower the seat using the pull
strap located next to the release handle.

Release Handles
Third Row Folded
NOTE:
The second row seats must be in their full
upright position, folded flat or tumbled when
folding the third row seats.
To raise the seat, pull the seat toward you using
the strap located on the back of the seat.
NOTE:
You may experience deformation in the seat
cushion from the seat belt buckles if the seats
are left folded for an extended period of time.
This is normal and by simply opening the seats
to the open position, over time the seat cushion
will return to its normal shape.
POWER ADJUSTMENT (FRONT SEATS) —
I
F EQUIPPED
Some models may be equipped with eight-way
power driver and front passenger seats. The
power seat switches are located on the
outboard side of the seat. There are two
switches that control the movement of the seat
cushion and the seatback.

Power Seat Switches

WARNING!
Be certain that the seatback is securely
locked into position. If the seatback is not
securely locked into position the seat will not
provide the proper stability for child seats
and/or passengers. An improperly latched
seat could cause serious injury.
1 — Seatback Switch
2 — Seat Switch
2

20_WD_OM_EN_USC_t.book Page 37

38GETTING TO KNOW YOUR VEHICLE
Adjusting The Seat Forward Or Rearward
The seat can be adjusted both forward and
rearward. Push the seat switch forward or
rearward. The seat will move in the direction of
the switch. Release the switch when the desired
position has been reached.
Adjusting The Seat Up Or Down
The height of the seats can be adjusted up or
down. Pull upward or push downward on the
rear of seat switch, the seat will move in the
direction of the switch. Release the switch when
the desired position has been reached.
Tilting The Seat Up Or Down
The angle of the seat cushion can be adjusted
in two directions. Pull upward or push
downward on the front of the seat switch, the
front of the seat cushion will move in the
direction of the switch. Release the switch when
the desired position has been reached.
Reclining The Seatback
The angle of the seatback can be adjusted
forward or rearward. Push the seatback switch
forward or rearward, the seat will move in the
direction of the switch. Release the switch when
the desired position is reached.
Power Lumbar — If Equipped
Vehicles equipped with power driver or
passenger seats may also be equipped with
power lumbar. The power lumbar switch is
located on the outboard side of the power seat.
Push the switch forward to increase the lumbar
support. Push the switch rearward to decrease
the lumbar support. Pushing upward or
downward on the switch will raise and lower the
position of the support.

Power Lumbar Switch
WARNING!
Adjusting a seat while driving may be
dangerous. Moving a seat while driving
could result in loss of control which could
cause a collision and serious injury or
death.
Seats should be adjusted before fastening
the seat belts and while the vehicle is
parked. Serious injury or death could result
from a poorly adjusted seat belt.
Do not ride with the seatback reclined so
that the shoulder belt is no longer resting
against your chest. In a collision you could
slide under the seat belt, which could result
in serious injury or death.
CAUTION!
Do not place any article under a power seat
or impede its ability to move as it may cause
damage to the seat controls. Seat travel may
become limited if movement is stopped by an
obstruction in the seat's path.

20_WD_OM_EN_USC_t.book Page 38
